Perform noise analysis on surface-based pressure data. More...

Inheritance diagram for surfaceNoise:

Collaboration diagram for surfaceNoise:

[legend]

Public Member Functions
	TypeName ("surfaceNoise")

	surfaceNoise (const dictionary &dict, const bool readFields=true)

virtual	~surfaceNoise ()=default

virtual bool	read (const dictionary &dict)

virtual void	calculate ()

Public Member Functions inherited from noiseModel
	TypeName ("noiseModel")

	declareRunTimeSelectionTable (autoPtr, noiseModel, dictionary,(const dictionary &dict),(dict))

	noiseModel (const dictionary &dict, const bool readFields=true)

virtual	~noiseModel ()=default

tmp< Foam::scalarField >	PSD (const scalarField &PSDf) const

tmp< scalarField >	SPL (const scalarField &Prms2, const scalar f) const

tmp< scalarField >	SPL (const scalarField &Prms2, const scalarField &f) const

void	cleanFFTW ()

void	writeWeightings () const

Protected Member Functions
void	initialise (const fileName &fName)

void	readSurfaceData (const labelList &procFaceOffset, List< scalarField > &pData)

scalar	writeSurfaceData (const fileName &outDirBase, const word &fName, const word &title, const scalar freq, const scalarField &data, const labelList &procFaceOffset, const bool writeSurface) const

scalar	surfaceAverage (const scalarField &data, const labelList &procFaceOffset) const

Protected Member Functions inherited from noiseModel
void	readWriteOption (const dictionary &dict, const word &lookup, bool &option) const

scalar	checkUniformTimeStep (const scalarList &times) const

bool	validateBounds (const scalarList &p) const

label	findStartTimeIndex (const instantList &allTimes, const scalar startTime) const

fileName	baseFileDir (const label dataseti) const

tmp< scalarField >	uniformFrequencies (const scalar deltaT, const bool check) const

tmp< scalarField >	octaves (const scalarField &data, const scalarField &f, const labelUList &freqBandIDs) const

tmp< scalarField >	Pf (const scalarField &p) const

tmp< scalarField >	meanPf (const scalarField &p) const

tmp< scalarField >	RMSmeanPf (const scalarField &p) const

tmp< scalarField >	PSDf (const scalarField &p, const scalar deltaT) const

scalar	RAf (const scalar f) const

scalar	gainA (const scalar f) const

scalar	RBf (const scalar f) const

scalar	gainB (const scalar f) const

scalar	RCf (const scalar f) const

scalar	gainC (const scalar f) const

scalar	RDf (const scalar f) const

scalar	gainD (const scalar f) const

Protected Attributes
List< fileName >	inputFileNames_

word	pName_

label	pIndex_

scalarList	times_

scalar	deltaT_

label	startTimeIndex_

label	nFace_

label	fftWriteInterval_

bool	areaAverage_

word	readerType_

autoPtr< surfaceReader >	readerPtr_

autoPtr< surfaceWriter >	writerPtr_

Protected Attributes inherited from noiseModel
const dictionary	dict_

scalar	rhoRef_

label	nSamples_

scalar	fLower_

scalar	fUpper_

scalar	startTime_

autoPtr< windowModel >	windowModelPtr_

word	graphFormat_

weightingType	SPLweighting_

scalar	dBRef_

scalar	minPressure_

scalar	maxPressure_

fileName	outputPrefix_

bool	writePrmsf_

bool	writeSPL_

bool	writePSD_

bool	writePSDf_

bool	writeOctaves_

planInfo	planInfo_

Additional Inherited Members
Public Types inherited from noiseModel
enum	weightingType { none, dBA, dBB, dBC, dBD }

Static Public Member Functions inherited from noiseModel
static autoPtr< noiseModel >	New (const dictionary &dict)

Static Public Attributes inherited from noiseModel
static const Enum< weightingType >	weightingTypeNames_

Static Protected Member Functions inherited from noiseModel
static void	setOctaveBands (const scalarField &f, const scalar fLower, const scalar fUpper, const scalar octave, labelList &fBandIDs, scalarField &fCentre)

Detailed Description

Perform noise analysis on surface-based pressure data.

Input data is read from a dictionary, e.g.

// Pressure reference
pRef            0;

// Number of samples in sampling window, default = 2^16 (=65536)
N               4096;

// Lower frequency bounds
fl              25;

// Upper frequency bounds
fu              25;

// Start time
startTime       0;

windowModel     <modelType>
<modelType>Coeffs
{
    ...
}

// Input file
file            "postProcessing/faceSource1/surface/patch/patch.case";
//files           ("postProcessing/faceSource1/surface/patch/patch.case");

// Write interval for FFT data, default = 1
fftWriteInterval 100;

// Area-weighted averaging switch, default = no (ensemble) for backwards
// compatibility
areaAverage     yes;

// Surface reader
reader          ensight;

// Surface writer
writer          ensight;

// Collate times for ensight output - ensures geometry is only written once
writeOptions
{
    ensight
    {
        collateTimes true;
    }

    // Write Prmsf; default = yes
    writePrmsf  no;

    // Write SPL; default = yes
    writeSPL    yes;

    // Write PSD; default = yes
    writePSD    yes;

    // Write PSDf; default = yes
    writePSDf   no;

    // Write writeOctaves; default = yes
    writeOctaves yes;
}

Source files

See also: noiseModel.H

Definition at line 126 of file surfaceNoise.H.

Constructor & Destructor Documentation

◆ surfaceNoise()

surfaceNoise	(	const dictionary &	dict,
		const bool	readFields = `true`
	)

Definition at line 423 of file surfaceNoise.C.

References dict, surfaceNoise::read(), and Foam::readFields().

Here is the call graph for this function:

◆ ~surfaceNoise()

virtual ~surfaceNoise ( )

virtualdefault

Member Function Documentation

◆ initialise()

void initialise ( const fileName & fName )

protected

Definition at line 42 of file surfaceNoise.C.

References noiseModel::checkUniformTimeStep(), surfaceNoise::deltaT_, Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, fieldNames(), noiseModel::findStartTimeIndex(), forAll, Foam::Info, UPstream::master(), surfaceReader::New(), surfaceNoise::nFace_, surfaceNoise::pIndex_, surfaceNoise::pName_, surfaceNoise::readerPtr_, surfaceNoise::readerType_, Pstream::scatter(), List::setSize(), MeshedSurface::size(), noiseModel::startTime_, surfaceNoise::startTimeIndex_, surfaceNoise::times_, and noiseModel::windowModelPtr_.

Referenced by surfaceNoise::calculate().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ readSurfaceData()

void readSurfaceData	(	const labelList &	procFaceOffset,
		List< scalarField > &	pData
	)

protected

Definition at line 111 of file surfaceNoise.C.

References UPstream::allProcs(), Foam::average(), PstreamBuffers::clear(), Foam::endl(), PstreamBuffers::finishedSends(), forAll, Foam::Info, UPstream::master(), UPstream::myProcNo(), Foam::nl, UPstream::nonBlocking, p, UPstream::parRun(), Foam::returnReduce(), and List::setSize().

Referenced by surfaceNoise::calculate().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ writeSurfaceData()

scalar writeSurfaceData	(	const fileName &	outDirBase,
		const word &	fName,
		const word &	title,
		const scalar	freq,
		const scalarField &	data,
		const labelList &	procFaceOffset,
		const bool	writeSurface
	)		const
