Perform noise analysis on point-based pressure data. More...

Inheritance diagram for pointNoise:

Collaboration diagram for pointNoise:

Public Member Functions
	TypeName ("pointNoise")

	pointNoise (const dictionary &dict, const bool readFields=true)

virtual	~pointNoise ()=default

virtual bool	read (const dictionary &dict)

virtual void	calculate ()

Public Member Functions inherited from noiseModel
	TypeName ("noiseModel")

	declareRunTimeSelectionTable (autoPtr, noiseModel, dictionary,(const dictionary &dict),(dict))

	noiseModel (const dictionary &dict, const bool readFields=true)

virtual	~noiseModel ()=default

tmp< Foam::scalarField >	PSD (const scalarField &PSDf) const

tmp< scalarField >	SPL (const scalarField &Prms2, const scalar f) const

tmp< scalarField >	SPL (const scalarField &Prms2, const scalarField &f) const

void	cleanFFTW ()

void	writeWeightings () const

Protected Member Functions
void	filterTimeData (const scalarField &t0, const scalarField &p0, scalarField &t, scalarField &p) const

void	processData (const label dataseti, const Function1Types::CSV< scalar > &data)

Protected Member Functions inherited from noiseModel
void	readWriteOption (const dictionary &dict, const word &lookup, bool &option) const

scalar	checkUniformTimeStep (const scalarList &times) const

bool	validateBounds (const scalarList &p) const

label	findStartTimeIndex (const instantList &allTimes, const scalar startTime) const

fileName	baseFileDir (const label dataseti) const

tmp< scalarField >	uniformFrequencies (const scalar deltaT, const bool check) const

tmp< scalarField >	octaves (const scalarField &data, const scalarField &f, const labelUList &freqBandIDs) const

tmp< scalarField >	Pf (const scalarField &p) const

tmp< scalarField >	meanPf (const scalarField &p) const

tmp< scalarField >	RMSmeanPf (const scalarField &p) const

tmp< scalarField >	PSDf (const scalarField &p, const scalar deltaT) const

scalar	RAf (const scalar f) const

scalar	gainA (const scalar f) const

scalar	RBf (const scalar f) const

scalar	gainB (const scalar f) const

scalar	RCf (const scalar f) const

scalar	gainC (const scalar f) const

scalar	RDf (const scalar f) const

scalar	gainD (const scalar f) const

Protected Attributes
List< fileName >	inputFileNames_

Protected Attributes inherited from noiseModel
const dictionary	dict_

scalar	rhoRef_

label	nSamples_

scalar	fLower_

scalar	fUpper_

scalar	startTime_

autoPtr< windowModel >	windowModelPtr_

word	graphFormat_

weightingType	SPLweighting_

scalar	dBRef_

scalar	minPressure_

scalar	maxPressure_

fileName	outputPrefix_

bool	writePrmsf_

bool	writeSPL_

bool	writePSD_

bool	writePSDf_

bool	writeOctaves_

planInfo	planInfo_

Additional Inherited Members
Public Types inherited from noiseModel
enum	weightingType { none, dBA, dBB, dBC, dBD }

Static Public Member Functions inherited from noiseModel
static autoPtr< noiseModel >	New (const dictionary &dict)

Static Public Attributes inherited from noiseModel
static const Enum< weightingType >	weightingTypeNames_

Static Protected Member Functions inherited from noiseModel
static void	setOctaveBands (const scalarField &f, const scalar fLower, const scalar fUpper, const scalar octave, labelList &fBandIDs, scalarField &fCentre)

Detailed Description

Perform noise analysis on point-based pressure data.

Input data is read from a dictionary, e.g.

// Pressure reference
pRef            0;

// Number of samples in sampling window, default = 2^16 (=65536)
N               4096;

// Lower frequency bounds
fl              25;

// Upper frequency bounds
fu              25;

// Start time
startTime       0;

windowModel     <modelType>
<modelType>Coeffs
{
    ...
}

// Pressure data supplied in CSV file format
file            "pressureData";
//files           ("pressureData1" "pressureData2");
nHeaderLine     1;
refColumn       0;
componentColumns (1);
separator       " ";
mergeSeparators yes;

graphFormat     raw;
