Given a displacement moves the mesh by scaling the displacement back until there are no more mesh errors. More...

Inheritance diagram for motionSmoother:

Collaboration diagram for motionSmoother:

Public Member Functions
	ClassName ("motionSmoother")

	motionSmoother (polyMesh &mesh, pointMesh &pMesh, indirectPrimitivePatch &pp, const labelList &adaptPatchIDs, const dictionary &paramDict, const bool dryRun=false)

	motionSmoother (polyMesh &mesh, indirectPrimitivePatch &pp, const labelList &adaptPatchIDs, const pointVectorField &displacement, const dictionary &paramDict, const bool dryRun=false)

Public Member Functions inherited from motionSmootherData
	motionSmootherData (const pointMesh &pMesh)

	motionSmootherData (const pointVectorField &displacement)

pointVectorField &	displacement ()

const pointVectorField &	displacement () const

const pointScalarField &	scale () const

const pointField &	oldPoints () const

Public Member Functions inherited from motionSmootherAlgo
	ClassName ("motionSmootherAlgo")

	motionSmootherAlgo (polyMesh &, pointMesh &, indirectPrimitivePatch &pp, pointVectorField &displacement, pointScalarField &scale, pointField &oldPoints, const labelList &adaptPatchIDs, const dictionary &paramDict, const bool dryRun=false)

	~motionSmootherAlgo ()

const polyMesh &	mesh () const

const pointMesh &	pMesh () const

const indirectPrimitivePatch &	patch () const

const labelList &	adaptPatchIDs () const

const dictionary &	paramDict () const

pointVectorField &	pointDisplacement ()

const pointVectorField &	pointDisplacement () const

void	correct ()

void	setDisplacementPatchFields ()

void	setDisplacement (pointField &patchDisp)

void	correctBoundaryConditions (pointVectorField &) const

void	modifyMotionPoints (pointField &newPoints) const

tmp< pointField >	curPoints () const

scalar	setErrorReduction (const scalar)

bool	scaleMesh (labelList &checkFaces, const bool smoothMesh=true, const label nAllow=0)

bool	scaleMesh (labelList &checkFaces, const List< labelPair > &baffles, const bool smoothMesh=true, const label nAllow=0)

bool	scaleMesh (labelList &checkFaces, const List< labelPair > &baffles, const dictionary &paramDict, const dictionary &meshQualityDict, const bool smoothMesh=true, const label nAllow=0)

void	movePoints ()

void	updateMesh ()

template<class Type >
void	smooth (const GeometricField< Type, pointPatchField, pointMesh > &fld, const scalarField &edgeWeight, GeometricField< Type, pointPatchField, pointMesh > &newFld) const

template<class Type >
Foam::tmp< Foam::GeometricField< Type, Foam::pointPatchField, Foam::pointMesh > >	avg (const GeometricField< Type, pointPatchField, pointMesh > &fld, const scalarField &edgeWeight) const

Additional Inherited Members
Static Public Member Functions inherited from motionSmootherAlgo
static void	setDisplacementPatchFields (const labelList &patchIDs, pointVectorField &pointDisplacement)

static void	setDisplacement (const labelList &patchIDs, const indirectPrimitivePatch &pp, pointField &patchDisp, pointVectorField &displacement)

static bool	checkMesh (const bool report, const polyMesh &mesh, const dictionary &dict, labelHashSet &wrongFaces, const bool dryRun=false)

static bool	checkMesh (const bool report, const polyMesh &mesh, const dictionary &dict, const labelList &checkFaces, labelHashSet &wrongFaces, const bool dryRun=false)

static bool	checkMesh (const bool report, const polyMesh &mesh, const dictionary &dict, const labelList &checkFaces, const List< labelPair > &baffles, labelHashSet &wrongFaces, const bool dryRun=false)

static bool	checkMesh (const bool report, const dictionary &dict, const polyMeshGeometry &, const pointField &, const labelList &checkFaces, labelHashSet &wrongFaces, const bool dryRun=false)

static bool	checkMesh (const bool report, const dictionary &dict, const polyMeshGeometry &, const pointField &, const labelList &checkFaces, const List< labelPair > &baffles, labelHashSet &wrongFaces, const bool dryRun=false)

template<class Type >
static Type	get (const dictionary &dict, const word &keyword, const bool noExit, enum keyType::option matchOpt, const Type &defaultValue=Zero)

Protected Attributes inherited from motionSmootherData
pointVectorField	displacement_

pointScalarField	scale_

pointField	oldPoints_

Detailed Description

Given a displacement moves the mesh by scaling the displacement back until there are no more mesh errors.

Holds displacement field (read upon construction since need boundary conditions) and scaling factor and optional patch number on which to scale back displacement.

E.g.

    // Construct iterative mesh mover.
    motionSmoother meshMover(mesh, labelList(1, patchi));

    // Set desired displacement:
    meshMover.displacement() = ..

    for (label iter = 0; iter < maxIter; iter++)
    {
        if (meshMover.scaleMesh(true))
        {
            Info<< "Successfully moved mesh" << endl;
            return true;
        }
    }

Note

Shared points (parallel): a processor can have points which are part of pp on another processor but have no pp itself (i.e. it has points and/or edges but no faces of pp). Hence we have to be careful when e.g. synchronising displacements that the value from the processor which has faces of pp get priority. This is currently handled in setDisplacement by resetting the internal displacement to zero before doing anything else. The combine operator used will give preference to non-zero values.
Various routines take baffles. These are sets of boundary faces that are treated as a single internal face. This is a hack used to apply movement to internal faces.
Mesh constraints are looked up from the supplied dictionary. (uses recursive lookup)

Source files

Definition at line 87 of file motionSmoother.H.

Constructor & Destructor Documentation

◆ motionSmoother() [1/2]

motionSmoother	(	polyMesh &	mesh,
		pointMesh &	pMesh,
		indirectPrimitivePatch &	pp,
		const labelList &	adaptPatchIDs,
		const dictionary &	paramDict,
		const bool	dryRun = `false`
	)

Parameters

pp	'outside' points
adaptPatchIDs	patches forming 'outside'

Definition at line 34 of file motionSmoother.C.

◆ motionSmoother() [2/2]

motionSmoother	(	polyMesh &	mesh,
		indirectPrimitivePatch &	pp,
		const labelList &	adaptPatchIDs,
		const pointVectorField &	displacement,
		const dictionary &	paramDict,
		const bool	dryRun = `false`
	)

Parameters

pp	'outside' points
adaptPatchIDs	patches forming 'outside'

Definition at line 60 of file motionSmoother.C.

Member Function Documentation

◆ ClassName()

ClassName ( "motionSmoother" )

The documentation for this class was generated from the following files:

src/dynamicMesh/motionSmoother/motionSmoother.H
src/dynamicMesh/motionSmoother/motionSmoother.C
