mixedFvPatchField< Type > Class Template Reference
Boundary conditions » Generic

This boundary condition provides a base class for 'mixed' type boundary conditions, i.e. conditions that mix fixed value and patch-normal gradient conditions. More...

Inheritance diagram for mixedFvPatchField< Type >:
Inheritance graph
[legend]
Collaboration diagram for mixedFvPatchField< Type >:
Collaboration graph
[legend]

Public Member Functions

 TypeName ("mixed")

 mixedFvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &)

 mixedFvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const dictionary &)

 mixedFvPatchField (const mixedFvPatchField< Type > &, const fvPatch &, const DimensionedField< Type, volMesh > &, const fvPatchFieldMapper &)

 mixedFvPatchField (const mixedFvPatchField< Type > &)

virtual tmp< fvPatchField< Type > > clone () const

 mixedFvPatchField (const mixedFvPatchField< Type > &, const DimensionedField< Type, volMesh > &)

virtual tmp< fvPatchField< Type > > clone (const DimensionedField< Type, volMesh > &iF) const

virtual bool fixesValue () const

virtual bool assignable () const

virtual Field< Type > & refValue ()

virtual const Field< Type > & refValue () const

virtual Field< Type > & refGrad ()

virtual const Field< Type > & refGrad () const

virtual scalarField & valueFraction ()

virtual const scalarField & valueFraction () const

virtual Field< Type > & source ()

virtual const Field< Type > & source () const

virtual void autoMap (const fvPatchFieldMapper &)

virtual void rmap (const fvPatchField< Type > &, const labelList &)

virtual tmp< Field< Type > > snGrad () const

virtual void evaluate (const Pstream::commsTypes commsType=Pstream::commsTypes::blocking)

virtual tmp< Field< Type > > valueInternalCoeffs (const tmp< scalarField > &) const

virtual tmp< Field< Type > > valueBoundaryCoeffs (const tmp< scalarField > &) const

virtual tmp< Field< Type > > gradientInternalCoeffs () const

virtual tmp< Field< Type > > gradientBoundaryCoeffs () const

virtual void write (Ostream &) const

virtual void operator= (const UList< Type > &)

virtual void operator= (const fvPatchField< Type > &)

virtual void operator+= (const fvPatchField< Type > &)

virtual void operator-= (const fvPatchField< Type > &)

virtual void operator*= (const fvPatchField< scalar > &)

virtual void operator/= (const fvPatchField< scalar > &)

virtual void operator+= (const Field< Type > &)

virtual void operator-= (const Field< Type > &)

virtual void operator*= (const Field< scalar > &)

virtual void operator/= (const Field< scalar > &)

virtual void operator= (const Type &)

virtual void operator+= (const Type &)

virtual void operator-= (const Type &)

virtual void operator*= (const scalar)

virtual void operator/= (const scalar)

- Public Member Functions inherited from fvPatchField< Type >
 TypeName ("fvPatchField")

 declareRunTimeSelectionTable (tmp, fvPatchField, patch,(const fvPatch &p, const DimensionedField< Type, volMesh > &iF),(p, iF))

 declareRunTimeSelectionTable (tmp, fvPatchField, patchMapper,(const fvPatchField< Type > &ptf, const fvPatch &p, const DimensionedField< Type, volMesh > &iF, const fvPatchFieldMapper &m),(dynamic_cast< const fvPatchFieldType & >(ptf), p, iF, m))

 declareRunTimeSelectionTable (tmp, fvPatchField, dictionary,(const fvPatch &p, const DimensionedField< Type, volMesh > &iF, const dictionary &dict),(p, iF, dict))

 fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &)

 fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const Type &value)

 fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const word &patchType)

 fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const Field< Type > &)

 fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const dictionary &, const bool valueRequired=true)

 fvPatchField (const fvPatchField< Type > &, const fvPatch &, const DimensionedField< Type, volMesh > &, const fvPatchFieldMapper &)

 fvPatchField (const fvPatchField< Type > &)

 fvPatchField (const fvPatchField< Type > &, const DimensionedField< Type, volMesh > &)

virtual tmp< fvPatchField< Type > > clone () const

Foam::tmp< Foam::fvPatchField< Type > > NewCalculatedType (const fvPatch &p)

Foam::tmp< Foam::fvPatchField< Type > > NewCalculatedType (const fvPatchField< Type2 > &pf)

virtual ~fvPatchField ()=default

bool useImplicit () const noexcept

bool useImplicit (bool on) noexcept

virtual bool fixesValue () const

virtual bool assignable () const

virtual bool coupled () const

const objectRegistry & db () const

const fvPatch & patch () const

const DimensionedField< Type, volMesh > & internalField () const

const Field< Type > & primitiveField () const

const word & patchType () const

word & patchType ()

bool updated () const

bool manipulatedMatrix () const

virtual tmp< Field< Type > > snGrad () const

virtual tmp< Field< Type > > snGrad (const scalarField &deltaCoeffs) const

virtual void updateCoeffs ()

virtual void updateWeightedCoeffs (const scalarField &weights)

virtual tmp< Field< Type > > patchInternalField () const

virtual void patchInternalField (Field< Type > &) const

virtual tmp< Field< Type > > patchNeighbourField () const

virtual void initEvaluate (const Pstream::commsTypes commsType=Pstream::commsTypes::blocking)

virtual tmp< Field< Type > > valueInternalCoeffs (const tmp< Field< scalar >> &) const

virtual tmp< Field< Type > > valueBoundaryCoeffs (const tmp< Field< scalar >> &) const

virtual tmp< Field< Type > > gradientInternalCoeffs () const

virtual tmp< Field< Type > > gradientInternalCoeffs (const scalarField &deltaCoeffs) const

virtual tmp< Field< Type > > gradientBoundaryCoeffs () const

virtual tmp< Field< Type > > gradientBoundaryCoeffs (const scalarField &deltaCoeffs) const

virtual void manipulateMatrix (fvMatrix< Type > &matrix)

virtual void manipulateMatrix (fvMatrix< Type > &matrix, const scalarField &weights)

virtual void manipulateMatrix (fvMatrix< Type > &matrix, const label iMatrix, const direction cmp)

void check (const fvPatchField< Type > &) const

virtual void operator== (const fvPatchField< Type > &)

virtual void operator== (const Field< Type > &)

virtual void operator== (const Type &)


Additional Inherited Members

- Public Types inherited from fvPatchField< Type >
typedef fvPatch Patch

typedef calculatedFvPatchField< Type > Calculated

- Static Public Member Functions inherited from fvPatchField< Type >
static tmp< fvPatchField< Type > > New (const word &, const fvPatch &, const DimensionedField< Type, volMesh > &)

static tmp< fvPatchField< Type > > New (const word &, const word &actualPatchType, const fvPatch &, const DimensionedField< Type, volMesh > &)

static tmp< fvPatchField< Type > > New (const fvPatchField< Type > &, const fvPatch &, const DimensionedField< Type, volMesh > &, const fvPatchFieldMapper &)

static tmp< fvPatchField< Type > > New (const fvPatch &, const DimensionedField< Type, volMesh > &, const dictionary &)

static tmp< fvPatchField< Type > > NewCalculatedType (const fvPatch &)

static tmp< fvPatchField< Type > > NewCalculatedType (const fvPatchField< Type2 > &)

static const word & calculatedType ()

- Static Public Attributes inherited from fvPatchField< Type >
static int disallowGenericFvPatchField


Detailed Description

template<class Type>
class Foam::mixedFvPatchField< Type >

This boundary condition provides a base class for 'mixed' type boundary conditions, i.e. conditions that mix fixed value and patch-normal gradient conditions.

The respective contributions from each is determined by a weight field:

\[ x_p = w x_p + (1-w) \left(x_c + \frac{\nabla_\perp x}{\Delta}\right) \]

where

$ x_p $ = patch values
$ x_c $ = patch internal cell values
$ \Delta$ = inverse distance from face centre to internal cell centre
$ w $ = weighting values (0-1)
Usage
Property Description Required Default
refValue fixed value yes
refGradient patch normal gradient yes
valueFraction value weighting (0-1) yes
Note
This condition is not usually applied directly; instead, use a derived mixed condition such as inletOutlet
See also
Foam::inletOutletFvPatchField
Source files

Definition at line 119 of file mixedFvPatchField.H.

Constructor & Destructor Documentation

◆ mixedFvPatchField() [1/5]

mixedFvPatchField ( const fvPatch &  p,
const DimensionedField< Type, volMesh > &  iF
)

Definition at line 27 of file mixedFvPatchField.C.

◆ mixedFvPatchField() [2/5]

mixedFvPatchField ( const fvPatch &  p,
const DimensionedField< Type, volMesh > &  iF,
const dictionary &  dict
)

Definition at line 42 of file mixedFvPatchField.C.

◆ mixedFvPatchField() [3/5]

mixedFvPatchField ( const mixedFvPatchField< Type > &  ptf,
const fvPatch &  p,
const DimensionedField< Type, volMesh > &  iF,
const fvPatchFieldMapper &  mapper
)

Definition at line 61 of file mixedFvPatchField.C.

◆ mixedFvPatchField() [4/5]

mixedFvPatchField ( const mixedFvPatchField< Type > &  ptf)

Definition at line 88 of file mixedFvPatchField.C.

◆ mixedFvPatchField() [5/5]

mixedFvPatchField ( const mixedFvPatchField< Type > &  ptf,
const DimensionedField< Type, volMesh > &  iF
)

Definition at line 102 of file mixedFvPatchField.C.

Member Function Documentation

◆ TypeName()

TypeName ( "mixed"  )

◆ clone() [1/2]

virtual tmp<fvPatchField<Type> > clone ( ) const
inlinevirtual

Reimplemented in codedMixedFvPatchField< Type >, waveTransmissiveFvPatchField< Type >, advectiveFvPatchField< Type >, mappedMixedFieldFvPatchField< Type >, mappedMixedFvPatchField< Type >, freestreamFvPatchField< Type >, uniformInletOutletFvPatchField< Type >, exprMixedFvPatchField< Type >, inletOutletFvPatchField< Type >, outletInletFvPatchField< Type >, acousticWaveTransmissiveFvPatchField< Type >, fixedMeanOutletInletFvPatchField< Type >, externalCoupledMixedFvPatchField< Type >, and externalCoupledMixedFvPatchField< scalar >.

Definition at line 177 of file mixedFvPatchField.H.

◆ clone() [2/2]

virtual tmp<fvPatchField<Type> > clone ( const DimensionedField< Type, volMesh > &  iF) const
inlinevirtual

Reimplemented from fvPatchField< Type >.

Reimplemented in velocityFilmShellFvPatchVectorField, codedMixedFvPatchField< Type >, waveTransmissiveFvPatchField< Type >, mappedMixedFieldFvPatchField< Type >, advectiveFvPatchField< Type >, mappedMixedFvPatchField< Type >, freestreamFvPatchField< Type >, uniformInletOutletFvPatchField< Type >, exprMixedFvPatchField< Type >, inletOutletFvPatchField< Type >, outletInletFvPatchField< Type >, acousticWaveTransmissiveFvPatchField< Type >, fixedMeanOutletInletFvPatchField< Type >, externalCoupledMixedFvPatchField< Type >, externalCoupledTemperatureMixedFvPatchScalarField, prghPermeableAlphaTotalPressureFvPatchScalarField, vibrationShellFvPatchScalarField, externalCoupledMixedFvPatchField< scalar >, and totalFlowRateAdvectiveDiffusiveFvPatchScalarField.

Definition at line 194 of file mixedFvPatchField.H.

◆ fixesValue()

virtual bool fixesValue ( ) const
inlinevirtual

Definition at line 212 of file mixedFvPatchField.H.

◆ assignable()

virtual bool assignable ( ) const
inlinevirtual

Reimplemented in uniformInletOutletFvPatchField< Type >, and inletOutletFvPatchField< Type >.

Definition at line 218 of file mixedFvPatchField.H.

◆ refValue() [1/2]

virtual Field<Type>& refValue ( )
inlinevirtual

Definition at line 226 of file mixedFvPatchField.H.

Referenced by freestreamFvPatchField< Type >::freestreamValue(), and codedMixedFvPatchField< Type >::updateCoeffs().

Here is the caller graph for this function:

◆ refValue() [2/2]

virtual const Field<Type>& refValue ( ) const
inlinevirtual

Definition at line 231 of file mixedFvPatchField.H.

◆ refGrad() [1/2]

virtual Field<Type>& refGrad ( )
inlinevirtual

Definition at line 236 of file mixedFvPatchField.H.

Referenced by codedMixedFvPatchField< Type >::updateCoeffs().

Here is the caller graph for this function:

◆ refGrad() [2/2]

virtual const Field<Type>& refGrad ( ) const
inlinevirtual

Definition at line 241 of file mixedFvPatchField.H.

◆ valueFraction() [1/2]

virtual scalarField& valueFraction ( )
inlinevirtual

Definition at line 246 of file mixedFvPatchField.H.

Referenced by codedMixedFvPatchField< Type >::updateCoeffs().

Here is the caller graph for this function:

◆ valueFraction() [2/2]

virtual const scalarField& valueFraction ( ) const
inlinevirtual

Definition at line 251 of file mixedFvPatchField.H.

◆ source() [1/2]

virtual Field<Type>& source ( )
inlinevirtual

Definition at line 256 of file mixedFvPatchField.H.

Referenced by mixedEnergyFvPatchScalarField::manipulateMatrix().

Here is the caller graph for this function:

◆ source() [2/2]

virtual const Field<Type>& source ( ) const
inlinevirtual

Definition at line 261 of file mixedFvPatchField.H.

◆ autoMap()

void autoMap ( const fvPatchFieldMapper &  m)
virtual

Reimplemented from fvPatchField< Type >.

Reimplemented in freestreamFvPatchField< Type >, prghPermeableAlphaTotalPressureFvPatchScalarField, mappedMixedFieldFvPatchField< Type >, mappedMixedFvPatchField< Type >, uniformInletOutletFvPatchField< Type >, and totalFlowRateAdvectiveDiffusiveFvPatchScalarField.

Definition at line 119 of file mixedFvPatchField.C.

◆ rmap()

void rmap ( const fvPatchField< Type > &  ptf,
const labelList &  addr
)
virtual

Reimplemented from fvPatchField< Type >.

Reimplemented in prghPermeableAlphaTotalPressureFvPatchScalarField, totalFlowRateAdvectiveDiffusiveFvPatchScalarField, freestreamFvPatchField< Type >, mappedMixedFieldFvPatchField< Type >, mappedMixedFvPatchField< Type >, and uniformInletOutletFvPatchField< Type >.

Definition at line 133 of file mixedFvPatchField.C.

Referenced by mixedFvPatchField< vector >::rmap().

Here is the caller graph for this function:

◆ snGrad()

Foam::tmp< Foam::Field< Type > > snGrad
virtual

Definition at line 175 of file mixedFvPatchField.C.

◆ evaluate()

void evaluate ( const Pstream::commsTypes  commsType = Pstream::commsTypes::blocking)
virtual

Reimplemented from fvPatchField< Type >.

Reimplemented in codedMixedFvPatchField< Type >.

Definition at line 151 of file mixedFvPatchField.C.

◆ valueInternalCoeffs()

Foam::tmp< Foam::Field< Type > > valueInternalCoeffs ( const tmp< scalarField > &  ) const
virtual

Definition at line 188 of file mixedFvPatchField.C.

◆ valueBoundaryCoeffs()

Foam::tmp< Foam::Field< Type > > valueBoundaryCoeffs ( const tmp< scalarField > &  ) const
virtual

Definition at line 199 of file mixedFvPatchField.C.

◆ gradientInternalCoeffs()

Foam::tmp< Foam::Field< Type > > gradientInternalCoeffs
virtual

Definition at line 211 of file mixedFvPatchField.C.

◆ gradientBoundaryCoeffs()

Foam::tmp< Foam::Field< Type > > gradientBoundaryCoeffs
virtual

Definition at line 219 of file mixedFvPatchField.C.

◆ write()

void write ( Ostream &  os) const
virtual

Reimplemented from fvPatchField< Type >.

Reimplemented in externalCoupledTemperatureMixedFvPatchScalarField, exprMixedFvPatchField< Type >, velocityFilmShellFvPatchVectorField, codedMixedFvPatchField< Type >, prghPermeableAlphaTotalPressureFvPatchScalarField, advectiveFvPatchField< Type >, waveTransmissiveFvPatchField< Type >, mappedMixedFieldFvPatchField< Type >, mappedMixedFvPatchField< Type >, freestreamFvPatchField< Type >, uniformInletOutletFvPatchField< Type >, inletOutletFvPatchField< Type >, acousticWaveTransmissiveFvPatchField< Type >, outletInletFvPatchField< Type >, fixedMeanOutletInletFvPatchField< Type >, totalFlowRateAdvectiveDiffusiveFvPatchScalarField, and vibrationShellFvPatchScalarField.

Definition at line 228 of file mixedFvPatchField.C.

Referenced by vibrationShellFvPatchScalarField::write(), prghPermeableAlphaTotalPressureFvPatchScalarField::write(), and velocityFilmShellFvPatchVectorField::write().

Here is the caller graph for this function:

◆ operator=() [1/3]

virtual void operator= ( const UList< Type > &  )
inlinevirtual

Reimplemented from fvPatchField< Type >.

Definition at line 324 of file mixedFvPatchField.H.

◆ operator=() [2/3]

virtual void operator= ( const fvPatchField< Type > &  )
inlinevirtual

Reimplemented from fvPatchField< Type >.

Reimplemented in uniformInletOutletFvPatchField< Type >, and inletOutletFvPatchField< Type >.

Definition at line 326 of file mixedFvPatchField.H.

◆ operator+=() [1/3]

virtual void operator+= ( const fvPatchField< Type > &  )
inlinevirtual

Reimplemented from fvPatchField< Type >.

Definition at line 327 of file mixedFvPatchField.H.

◆ operator-=() [1/3]

virtual void operator-= ( const fvPatchField< Type > &  )
inlinevirtual

Reimplemented from fvPatchField< Type >.

Definition at line 328 of file mixedFvPatchField.H.

◆ operator*=() [1/3]

virtual void operator*= ( const fvPatchField< scalar > &  )
inlinevirtual

Reimplemented from fvPatchField< Type >.

Definition at line 329 of file mixedFvPatchField.H.

◆ operator/=() [1/3]

virtual void operator/= ( const fvPatchField< scalar > &  )
inlinevirtual

Reimplemented from fvPatchField< Type >.

Definition at line 330 of file mixedFvPatchField.H.

◆ operator+=() [2/3]

virtual void operator+= ( const Field< Type > &  )
inlinevirtual

Reimplemented from fvPatchField< Type >.

Definition at line 332 of file mixedFvPatchField.H.

◆ operator-=() [2/3]

virtual void operator-= ( const Field< Type > &  )
inlinevirtual

Reimplemented from fvPatchField< Type >.

Definition at line 333 of file mixedFvPatchField.H.

◆ operator*=() [2/3]

virtual void operator*= ( const Field< scalar > &  )
inlinevirtual

Reimplemented from fvPatchField< Type >.

Definition at line 335 of file mixedFvPatchField.H.

◆ operator/=() [2/3]

virtual void operator/= ( const Field< scalar > &  )
inlinevirtual

Reimplemented from fvPatchField< Type >.

Definition at line 336 of file mixedFvPatchField.H.

◆ operator=() [3/3]

virtual void operator= ( const Type &  )
inlinevirtual

Reimplemented from fvPatchField< Type >.

Definition at line 338 of file mixedFvPatchField.H.

◆ operator+=() [3/3]

virtual void operator+= ( const Type &  )
inlinevirtual

Reimplemented from fvPatchField< Type >.

Definition at line 339 of file mixedFvPatchField.H.

◆ operator-=() [3/3]

virtual void operator-= ( const Type &  )
inlinevirtual

Reimplemented from fvPatchField< Type >.

Definition at line 340 of file mixedFvPatchField.H.

◆ operator*=() [3/3]

virtual void operator*= ( const  scalar)
inlinevirtual

Reimplemented from fvPatchField< Type >.

Definition at line 341 of file mixedFvPatchField.H.

◆ operator/=() [3/3]

virtual void operator/= ( const  scalar)
inlinevirtual

Reimplemented from fvPatchField< Type >.

Definition at line 342 of file mixedFvPatchField.H.

The documentation for this class was generated from the following files:

Copyright © 2011-2018  OpenFOAM | OPENFOAM® is a registered trademark of OpenCFD Ltd.

Generated by   doxygen 1.8.17
