messageStream Class Reference

Handle output messages in a simple, consistent stream-based manner. More...

Inheritance diagram for messageStream:

Collaboration diagram for messageStream:

Public Types
enum	errorSeverity {   INFO = 1, INFO_STDERR, WARNING, SERIOUS,   FATAL }

Public Member Functions
	messageStream (const string &title, const errorSeverity severity, const int maxErrors=0)
	messageStream (const dictionary &dict)
const string &	title () const noexcept
int	maxErrors () const noexcept
int	maxErrors (int nErrors) noexcept
OSstream &	stream (OSstream *alternative=nullptr)
OSstream &	masterStream (const label communicator)
std::ostream &	stdStream ()
	operator OSstream & ()
OSstream &	operator() ()
OSstream &	operator() (const string &functionName)
OSstream &	operator() (const char *functionName, const char *sourceFileName, const int sourceFileLineNumber=0)
OSstream &	operator() (const string &functionName, const char *sourceFileName, const int sourceFileLineNumber=0)
OSstream &	operator() (const char *functionName, const char *sourceFileName, const int sourceFileLineNumber, const string &ioFileName, const label ioStartLineNumber=-1, const label ioEndLineNumber=-1)
OSstream &	operator() (const char *functionName, const char *sourceFileName, const int sourceFileLineNumber, const IOstream &)
OSstream &	operator() (const char *functionName, const char *sourceFileName, const int sourceFileLineNumber, const dictionary &)

Static Public Attributes
static int	level
static int	redirect

Protected Attributes
string	title_
errorSeverity	severity_
int	maxErrors_
int	errorCount_

Detailed Description

Handle output messages in a simple, consistent stream-based manner.

The messageStream class is globally instantiated with a title string and a severity (which controls the program termination), optionally with a max number of errors before termination.

Errors, messages and other data are sent to the messageStream class in the standard manner.

For parallel applications, the output for 'standard' messages (Info, Warnings) is effectively suppressed on all sub-processes, which results in a single output message instead of a flood of output messages from each process. The error type of messages do, however, retain output on all processes, which ensures that parallel termination occurs correctly and the source of the problem is properly traceable to the originating processor.

Source files

• messageStream.H
• messageStream.C

Definition at line 69 of file messageStream.H.

Member Enumeration Documentation

errorSeverity

enum errorSeverity

Enumerator
INFO	General information output (stdout)
INFO_STDERR	General information output (stderr)
WARNING	Warning of possible problem.
SERIOUS	A serious problem - eg, data corruption.
FATAL	A fatal error.

Definition at line 74 of file messageStream.H.

Constructor & Destructor Documentation

messageStream() [1/2]

messageStream	(	const string &	title,
		const errorSeverity	severity,
		const int	maxErrors = 0
	)

Definition at line 40 of file messageStream.C.

messageStream() [2/2]

messageStream ( const dictionary &  dict )

explicit

Definition at line 53 of file messageStream.C.

Member Function Documentation

title()

const string& title ( ) const

inlinenoexcept

Definition at line 133 of file messageStream.H.

References messageStream::title_.

maxErrors() [1/2]

int maxErrors ( ) const

inlinenoexcept

Definition at line 139 of file messageStream.H.

References messageStream::maxErrors_.

maxErrors() [2/2]

int maxErrors ( int  nErrors )

inlinenoexcept

Definition at line 146 of file messageStream.H.

References messageStream::maxErrors_.

stream()

Foam::OSstream & stream

(

OSstream *

alternative = nullptr

)

Definition at line 64 of file messageStream.C.

References Foam::abort(), Foam::FatalError, FatalErrorInFunction, Foam::infoDetailLevel, UPstream::master(), UPstream::parRun(), Foam::Perr, Foam::Pout, Foam::Serr, Foam::Snull, and Foam::Sout.

Referenced by GAMGAgglomeration::compactLevels(), messageStream::operator OSstream &(), and messageStream::operator()().

Here is the call graph for this function:

Here is the caller graph for this function:

masterStream()

Foam::OSstream & masterStream

(

const label

communicator

)

Definition at line 133 of file messageStream.C.

References Foam::endl(), UPstream::master(), Foam::Pout, error::printStack(), Foam::Snull, UPstream::warnComm, and UPstream::worldComm.

Referenced by smoothSolver::solve(), fvMatrix::fvSolver::solve(), GAMGSolver::solve(), fvMatrix< Type >::solveCoupled(), fvMatrix< Type >::solver(), fvMatrix< Type >::solveSegregated(), and fvMatrix< Type >::solveSegregatedOrCoupled().

Here is the call graph for this function:

Here is the caller graph for this function:

stdStream()

std::ostream & stdStream

(

)

Definition at line 150 of file messageStream.C.

Referenced by argList::argList(), argList::parse(), and argList::printUsage().

Here is the caller graph for this function:

operator OSstream &()

operator OSstream & ( )

inline

Definition at line 169 of file messageStream.H.

References messageStream::stream().

Here is the call graph for this function:

operator()() [1/7]

OSstream& operator() ( )

inline

Definition at line 175 of file messageStream.H.

References messageStream::stream().

Here is the call graph for this function:

operator()() [2/7]

Foam::OSstream & operator()

(

const string &

functionName

)

Definition at line 159 of file messageStream.C.

References Foam::nl, and os().

Here is the call graph for this function:

operator()() [3/7]

Foam::OSstream & operator()	(	const char *	functionName,
		const char *	sourceFileName,
		const int	sourceFileLineNumber = 0
	)

Definition at line 176 of file messageStream.C.

References Foam::endl(), Foam::nl, and os().

Here is the call graph for this function:

operator()() [4/7]

Foam::OSstream & operator()	(	const string &	functionName,
		const char *	sourceFileName,
		const int	sourceFileLineNumber = 0
	)

Definition at line 195 of file messageStream.C.

operator()() [5/7]

Foam::OSstream & operator()	(	const char *	functionName,
		const char *	sourceFileName,
		const int	sourceFileLineNumber,
		const string &	ioFileName,
		const label	ioStartLineNumber = -1,
		const label	ioEndLineNumber = -1
	)

Definition at line 211 of file messageStream.C.

References Foam::endl(), Foam::nl, and os().

Here is the call graph for this function:

operator()() [6/7]

Foam::OSstream & operator()	(	const char *	functionName,
		const char *	sourceFileName,
		const int	sourceFileLineNumber,
		const IOstream &	ioStream
	)

Parameters

ioStream

Provides name and lineNumber

Definition at line 245 of file messageStream.C.

operator()() [7/7]

Foam::OSstream & operator()	(	const char *	functionName,
		const char *	sourceFileName,
		const int	sourceFileLineNumber,
		const dictionary &	dict
	)

Parameters

dict	Provides name, startLine, endLine

Definition at line 265 of file messageStream.C.

References dict, dictionary::endLineNumber(), dictionary::relativeName(), and dictionary::startLineNumber().

Here is the call graph for this function:

Member Data Documentation

title_

string title_

protected

Definition at line 91 of file messageStream.H.

Referenced by messageStream::title().

severity_

errorSeverity severity_

protected

Definition at line 92 of file messageStream.H.

maxErrors_

int maxErrors_

protected

Definition at line 93 of file messageStream.H.

Referenced by messageStream::maxErrors().

errorCount_

int errorCount_

protected

Definition at line 94 of file messageStream.H.

level

int level

static

Definition at line 108 of file messageStream.H.

Referenced by IOobject::setBad(), error::write(), and IOerror::write().

redirect

int redirect

static

Definition at line 113 of file messageStream.H.

---

The documentation for this class was generated from the following files:

• src/OpenFOAM/db/error/messageStream.H
• src/OpenFOAM/db/error/messageStream.C
