meshWriter Class Reference

Write OpenFOAM meshes and/or results to another CFD format. More...

Inheritance diagram for meshWriter:

Collaboration diagram for meshWriter:

Public Member Functions
	meshWriter (const polyMesh &, const scalar scaling=1.0)
virtual	~meshWriter ()
virtual bool	write (const fileName &timeName=fileName::null) const =0

Static Public Attributes
static string	defaultMeshName = "meshExport"

Protected Attributes
const polyMesh &	mesh_
scalar	scaleFactor_
boundaryRegion	boundaryRegion_
cellTable	cellTable_
labelList	cellTableId_

Detailed Description

Write OpenFOAM meshes and/or results to another CFD format.

Files

"constant/boundaryRegion" is an IOMap<dictionary> that contains the boundary type and names. eg,

        (
            0
            {
                BoundaryType    wall;
                Label           Default_Boundary_Region;
            }

            1
            {
                BoundaryType    inlet;
                Label           inlet_1;
            }

            ...

            4
            {
                BoundaryType    pressure;
                Label           outlet;
            }
        )

Source files

• meshWriter.H
• meshWriter.C

Definition at line 78 of file meshWriter.H.

Constructor & Destructor Documentation

meshWriter()

meshWriter	(	const polyMesh &	mesh,
		const scalar	scaling = 1.0
	)

Definition at line 32 of file meshWriter.C.

~meshWriter()

~meshWriter ( )

virtual

Definition at line 53 of file meshWriter.C.

Member Function Documentation

write()

virtual bool write ( const fileName &  timeName = fileName::null ) const

pure virtual

Implemented in FIREMeshWriter, and STARCDMeshWriter.

Member Data Documentation

mesh_

const polyMesh& mesh_

protected

Definition at line 94 of file meshWriter.H.

scaleFactor_

scalar scaleFactor_

protected

Definition at line 97 of file meshWriter.H.

boundaryRegion_

boundaryRegion boundaryRegion_

protected

Definition at line 100 of file meshWriter.H.

cellTable_

cellTable cellTable_

protected

Definition at line 103 of file meshWriter.H.

cellTableId_

labelList cellTableId_

protected

Definition at line 106 of file meshWriter.H.

defaultMeshName

Foam::string defaultMeshName = "meshExport"

static

Definition at line 113 of file meshWriter.H.

Referenced by STARCDMeshWriter::write(), and FIREMeshWriter::write().

---

The documentation for this class was generated from the following files:

• src/conversion/common/writer/meshWriter.H
• src/conversion/common/writer/meshWriter.C
