meshToMesh Class Reference

Class to calculate the cell-addressing between two overlapping meshes. More...

Collaboration diagram for meshToMesh:

Public Types
enum	interpolationMethod { imDirect, imMapNearest, imCellVolumeWeight, imCorrectedCellVolumeWeight }
enum	procMapMethod { pmAABB, pmLOD }

Public Member Functions
	TypeName ("meshToMesh")
	meshToMesh (const polyMesh &src, const polyMesh &tgt, const interpolationMethod &method, const procMapMethod &mapMethod=procMapMethod::pmAABB, const bool interpAllPatches=true)
	meshToMesh (const polyMesh &src, const polyMesh &tgt, const word &methodName, const word &AMIMethodName, const procMapMethod &mapMethod=procMapMethod::pmAABB, const bool interpAllPatches=true)
	meshToMesh (const polyMesh &src, const polyMesh &tgt, const interpolationMethod &method, const HashTable< word > &patchMap, const wordList &cuttingPatches, const procMapMethod &mapMethod=procMapMethod::pmAABB, const bool normalise=true)
	meshToMesh (const polyMesh &src, const polyMesh &tgt, const word &methodName, const word &AMIMethodName, const HashTable< word > &patchMap, const wordList &cuttingPatches, const procMapMethod &mapMethod=procMapMethod::pmAABB, const bool normalise=true)
virtual	~meshToMesh ()
const polyMesh &	srcRegion () const
const polyMesh &	tgtRegion () const
const labelListList &	srcToTgtCellAddr () const
const labelListList &	tgtToSrcCellAddr () const
const scalarListList &	srcToTgtCellWght () const
const scalarListList &	tgtToSrcCellWght () const
const pointListList &	srcToTgtCellVec () const
const pointListList &	tgtToSrcCellVec () const
scalar	V () const
const PtrList< AMIPatchToPatchInterpolation > &	patchAMIs () const
const autoPtr< mapDistribute > &	srcMap () const
const autoPtr< mapDistribute > &	tgtMap () const
template<class Type , class CombineOp >
void	mapSrcToTgt (const UList< Type > &srcFld, const CombineOp &cop, List< Type > &result) const
template<class Type , class CombineOp >
void	mapSrcToTgt (const UList< Type > &srcField, const UList< typename outerProduct< vector, Type >::type > &, const CombineOp &cop, List< Type > &result) const
template<class Type , class CombineOp >
tmp< Field< Type > >	mapSrcToTgt (const Field< Type > &srcFld, const CombineOp &cop) const
template<class Type , class CombineOp >
tmp< Field< Type > >	mapSrcToTgt (const tmp< Field< Type >> &tsrcFld, const CombineOp &cop) const
template<class Type >
tmp< Field< Type > >	mapSrcToTgt (const Field< Type > &srcFld) const
template<class Type >
tmp< Field< Type > >	mapSrcToTgt (const tmp< Field< Type >> &tsrcFld) const
template<class Type , class CombineOp >
void	mapTgtToSrc (const UList< Type > &tgtFld, const CombineOp &cop, List< Type > &result) const
template<class Type , class CombineOp >
void	mapTgtToSrc (const UList< Type > &srcField, const UList< typename outerProduct< vector, Type >::type > &, const CombineOp &cop, List< Type > &result) const
template<class Type , class CombineOp >
tmp< Field< Type > >	mapTgtToSrc (const Field< Type > &tgtFld, const CombineOp &cop) const
template<class Type , class CombineOp >
tmp< Field< Type > >	mapTgtToSrc (const tmp< Field< Type >> &ttgtFld, const CombineOp &cop) const
template<class Type >
tmp< Field< Type > >	mapTgtToSrc (const Field< Type > &tgtFld) const
template<class Type >
tmp< Field< Type > >	mapTgtToSrc (const tmp< Field< Type >> &ttgtFld) const
template<class Type , class CombineOp >
void	mapSrcToTgt (const GeometricField< Type, fvPatchField, volMesh > &field, const CombineOp &cop, GeometricField< Type, fvPatchField, volMesh > &result, const bool secondOrder=true) const
template<class Type , class CombineOp >
tmp< GeometricField< Type, fvPatchField, volMesh > >	mapSrcToTgt (const GeometricField< Type, fvPatchField, volMesh > &field, const CombineOp &cop, const bool secondOrder=true) const
template<class Type , class CombineOp >
tmp< GeometricField< Type, fvPatchField, volMesh > >	mapSrcToTgt (const tmp< GeometricField< Type, fvPatchField, volMesh >> &tfield, const CombineOp &cop, const bool secondOrder=true) const
template<class Type >
tmp< GeometricField< Type, fvPatchField, volMesh > >	mapSrcToTgt (const GeometricField< Type, fvPatchField, volMesh > &field, const bool secondOrder=true) const
template<class Type >
tmp< GeometricField< Type, fvPatchField, volMesh > >	mapSrcToTgt (const tmp< GeometricField< Type, fvPatchField, volMesh >> &tfield, const bool secondOrder=true) const
template<class Type , class CombineOp >
void	mapTgtToSrc (const GeometricField< Type, fvPatchField, volMesh > &field, const CombineOp &cop, GeometricField< Type, fvPatchField, volMesh > &result, const bool secondOrder=true) const
template<class Type , class CombineOp >
tmp< GeometricField< Type, fvPatchField, volMesh > >	mapTgtToSrc (const GeometricField< Type, fvPatchField, volMesh > &field, const CombineOp &cop, const bool secondOrder=true) const
template<class Type , class CombineOp >
tmp< GeometricField< Type, fvPatchField, volMesh > >	mapTgtToSrc (const tmp< GeometricField< Type, fvPatchField, volMesh >> &tfield, const CombineOp &cop, const bool secondOrder=true) const
template<class Type >
tmp< GeometricField< Type, fvPatchField, volMesh > >	mapTgtToSrc (const GeometricField< Type, fvPatchField, volMesh > &field, const bool secondOrder=true) const
template<class Type >
tmp< GeometricField< Type, fvPatchField, volMesh > >	mapTgtToSrc (const tmp< GeometricField< Type, fvPatchField, volMesh >> &tfield, const bool secondOrder=true) const
template<>
void	mapInternalSrcToTgt (const GeometricField< sphericalTensor, fvPatchField, volMesh > &field, const plusEqOp< sphericalTensor > &cop, GeometricField< sphericalTensor, fvPatchField, volMesh > &result, const bool secondOrder) const
template<>
void	mapInternalSrcToTgt (const GeometricField< sphericalTensor, fvPatchField, volMesh > &field, const minusEqOp< sphericalTensor > &cop, GeometricField< sphericalTensor, fvPatchField, volMesh > &result, const bool secondOrder) const
template<>
void	mapInternalSrcToTgt (const GeometricField< symmTensor, fvPatchField, volMesh > &field, const plusEqOp< symmTensor > &cop, GeometricField< symmTensor, fvPatchField, volMesh > &result, const bool secondOrder) const
template<>
void	mapInternalSrcToTgt (const GeometricField< symmTensor, fvPatchField, volMesh > &field, const minusEqOp< symmTensor > &cop, GeometricField< symmTensor, fvPatchField, volMesh > &result, const bool secondOrder) const
template<>
void	mapInternalSrcToTgt (const GeometricField< tensor, fvPatchField, volMesh > &field, const plusEqOp< tensor > &cop, GeometricField< tensor, fvPatchField, volMesh > &result, const bool secondOrder) const
template<>
void	mapInternalSrcToTgt (const GeometricField< tensor, fvPatchField, volMesh > &field, const minusEqOp< tensor > &cop, GeometricField< tensor, fvPatchField, volMesh > &result, const bool secondOrder) const
template<>
void	mapInternalTgtToSrc (const GeometricField< sphericalTensor, fvPatchField, volMesh > &field, const plusEqOp< sphericalTensor > &cop, GeometricField< sphericalTensor, fvPatchField, volMesh > &result, const bool secondOrder) const
template<>
void	mapInternalTgtToSrc (const GeometricField< sphericalTensor, fvPatchField, volMesh > &field, const minusEqOp< sphericalTensor > &cop, GeometricField< sphericalTensor, fvPatchField, volMesh > &result, const bool secondOrder) const
template<>
void	mapInternalTgtToSrc (const GeometricField< symmTensor, fvPatchField, volMesh > &field, const plusEqOp< symmTensor > &cop, GeometricField< symmTensor, fvPatchField, volMesh > &result, const bool secondOrder) const
template<>
void	mapInternalTgtToSrc (const GeometricField< symmTensor, fvPatchField, volMesh > &field, const minusEqOp< symmTensor > &cop, GeometricField< symmTensor, fvPatchField, volMesh > &result, const bool secondOrder) const
template<>
void	mapInternalTgtToSrc (const GeometricField< tensor, fvPatchField, volMesh > &field, const plusEqOp< tensor > &cop, GeometricField< tensor, fvPatchField, volMesh > &result, const bool secondOrder) const
template<>
void	mapInternalTgtToSrc (const GeometricField< tensor, fvPatchField, volMesh > &field, const minusEqOp< tensor > &cop, GeometricField< tensor, fvPatchField, volMesh > &result, const bool secondOrder) const
template<>
void	mapAndOpSrcToTgt (const AMIPatchToPatchInterpolation &AMI, const Field< scalar > &srcField, Field< scalar > &tgtField, const plusEqOp< scalar > &cop) const
template<>
void	mapAndOpSrcToTgt (const AMIPatchToPatchInterpolation &AMI, const Field< vector > &srcField, Field< vector > &tgtField, const plusEqOp< vector > &cop) const
template<>
void	mapAndOpSrcToTgt (const AMIPatchToPatchInterpolation &AMI, const Field< sphericalTensor > &srcField, Field< sphericalTensor > &tgtField, const plusEqOp< sphericalTensor > &cop) const
template<>
void	mapAndOpSrcToTgt (const AMIPatchToPatchInterpolation &AMI, const Field< symmTensor > &srcField, Field< symmTensor > &tgtField, const plusEqOp< symmTensor > &cop) const
template<>
void	mapAndOpSrcToTgt (const AMIPatchToPatchInterpolation &AMI, const Field< tensor > &srcField, Field< tensor > &tgtField, const plusEqOp< tensor > &cop) const
template<>
void	mapAndOpTgtToSrc (const AMIPatchToPatchInterpolation &AMI, Field< scalar > &srcField, const Field< scalar > &tgtField, const plusEqOp< scalar > &cop) const
template<>
void	mapAndOpTgtToSrc (const AMIPatchToPatchInterpolation &AMI, Field< vector > &srcField, const Field< vector > &tgtField, const plusEqOp< vector > &cop) const
template<>
void	mapAndOpTgtToSrc (const AMIPatchToPatchInterpolation &AMI, Field< sphericalTensor > &srcField, const Field< sphericalTensor > &tgtField, const plusEqOp< sphericalTensor > &cop) const
template<>
void	mapAndOpTgtToSrc (const AMIPatchToPatchInterpolation &AMI, Field< symmTensor > &srcField, const Field< symmTensor > &tgtField, const plusEqOp< symmTensor > &cop) const
template<>
void	mapAndOpTgtToSrc (const AMIPatchToPatchInterpolation &AMI, Field< tensor > &srcField, const Field< tensor > &tgtField, const plusEqOp< tensor > &cop) const
template<class Type , class CombineOp >
Foam::tmp< Foam::Field< Type > >	mapSrcToTgt (const Field< Type > &srcField, const CombineOp &cop) const
template<class Type , class CombineOp >
Foam::tmp< Foam::Field< Type > >	mapSrcToTgt (const tmp< Field< Type >> &tsrcField, const CombineOp &cop) const
template<class Type >
Foam::tmp< Foam::Field< Type > >	mapSrcToTgt (const Field< Type > &srcField) const
template<class Type >
Foam::tmp< Foam::Field< Type > >	mapSrcToTgt (const tmp< Field< Type >> &tsrcField) const
template<class Type , class CombineOp >
Foam::tmp< Foam::Field< Type > >	mapTgtToSrc (const Field< Type > &tgtField, const CombineOp &cop) const
template<class Type , class CombineOp >
Foam::tmp< Foam::Field< Type > >	mapTgtToSrc (const tmp< Field< Type >> &ttgtField, const CombineOp &cop) const
template<class Type >
Foam::tmp< Foam::Field< Type > >	mapTgtToSrc (const Field< Type > &tgtField) const
template<class Type >
Foam::tmp< Foam::Field< Type > >	mapTgtToSrc (const tmp< Field< Type >> &ttgtField) const
template<class Type , class CombineOp >
Foam::tmp< Foam::GeometricField< Type, Foam::fvPatchField, Foam::volMesh > >	mapSrcToTgt (const GeometricField< Type, fvPatchField, volMesh > &field, const CombineOp &cop, const bool secondOrder) const
template<class Type , class CombineOp >
Foam::tmp< Foam::GeometricField< Type, Foam::fvPatchField, Foam::volMesh > >	mapSrcToTgt (const tmp< GeometricField< Type, fvPatchField, volMesh >> &tfield, const CombineOp &cop, const bool secondOrder) const
template<class Type >
Foam::tmp< Foam::GeometricField< Type, Foam::fvPatchField, Foam::volMesh > >	mapSrcToTgt (const GeometricField< Type, fvPatchField, volMesh > &field, const bool secondOrder) const
template<class Type >
Foam::tmp< Foam::GeometricField< Type, Foam::fvPatchField, Foam::volMesh > >	mapSrcToTgt (const tmp< GeometricField< Type, fvPatchField, volMesh >> &tfield, const bool secondOrder) const
template<class Type , class CombineOp >
Foam::tmp< Foam::GeometricField< Type, Foam::fvPatchField, Foam::volMesh > >	mapTgtToSrc (const GeometricField< Type, fvPatchField, volMesh > &field, const CombineOp &cop, const bool secondOrder) const
template<class Type , class CombineOp >
Foam::tmp< Foam::GeometricField< Type, Foam::fvPatchField, Foam::volMesh > >	mapTgtToSrc (const tmp< GeometricField< Type, fvPatchField, volMesh >> &tfield, const CombineOp &cop, const bool secondOrder) const
template<class Type >
Foam::tmp< Foam::GeometricField< Type, Foam::fvPatchField, Foam::volMesh > >	mapTgtToSrc (const GeometricField< Type, fvPatchField, volMesh > &field, const bool secondOrder) const
template<class Type >
Foam::tmp< Foam::GeometricField< Type, Foam::fvPatchField, Foam::volMesh > >	mapTgtToSrc (const tmp< GeometricField< Type, fvPatchField, volMesh >> &tfield, const bool secondOrder) const

Static Public Member Functions
static word	interpolationMethodAMI (const interpolationMethod method)

Static Public Attributes
static const Enum< interpolationMethod >	interpolationMethodNames_
static const Enum< procMapMethod >	procMapMethodNames_

Detailed Description

Class to calculate the cell-addressing between two overlapping meshes.

Mapping is performed using a run-time selectable interpolation mothod

See also

meshToMeshMethod

Source files

• meshToMesh.H
• meshToMesh.C
• meshToMeshParallelOps.C
• meshToMeshTemplates.C

Definition at line 60 of file meshToMesh.H.

Member Enumeration Documentation

interpolationMethod

enum interpolationMethod

strong

Enumerator
imDirect
imMapNearest
imCellVolumeWeight
imCorrectedCellVolumeWeight

Definition at line 67 of file meshToMesh.H.

procMapMethod

enum procMapMethod

strong

Enumerator
pmAABB
pmLOD

Definition at line 78 of file meshToMesh.H.

Constructor & Destructor Documentation

meshToMesh() [1/4]

meshToMesh	(	const polyMesh &	src,
		const polyMesh &	tgt,
		const interpolationMethod &	method,
		const procMapMethod &	mapMethod = procMapMethod::pmAABB,
		const bool	interpAllPatches = true
	)

Definition at line 836 of file meshToMesh.C.

meshToMesh() [2/4]

meshToMesh	(	const polyMesh &	src,
		const polyMesh &	tgt,
		const word &	methodName,
		const word &	AMIMethodName,
		const procMapMethod &	mapMethod = procMapMethod::pmAABB,
		const bool	interpAllPatches = true
	)

Definition at line 872 of file meshToMesh.C.

meshToMesh() [3/4]

meshToMesh	(	const polyMesh &	src,
		const polyMesh &	tgt,
		const interpolationMethod &	method,
		const HashTable< word > &	patchMap,
		const wordList &	cuttingPatches,
		const procMapMethod &	mapMethod = procMapMethod::pmAABB,
		const bool	normalise = true
	)

Definition at line 904 of file meshToMesh.C.

meshToMesh() [4/4]

meshToMesh	(	const polyMesh &	src,
		const polyMesh &	tgt,
		const word &	methodName,
		const word &	AMIMethodName,
		const HashTable< word > &	patchMap,
		const wordList &	cuttingPatches,
		const procMapMethod &	mapMethod = procMapMethod::pmAABB,
		const bool	normalise = true
	)

Definition at line 942 of file meshToMesh.C.

~meshToMesh()

~meshToMesh ( )

virtual

Definition at line 982 of file meshToMesh.C.

Member Function Documentation

TypeName()

TypeName

(

"meshToMesh"

)

srcRegion()

const Foam::polyMesh & srcRegion ( ) const

inline

Definition at line 26 of file meshToMeshI.H.

Referenced by Foam::MapMesh(), and Foam::MapVolFields().

Here is the caller graph for this function:

tgtRegion()

const Foam::polyMesh & tgtRegion ( ) const

inline

Definition at line 32 of file meshToMeshI.H.

Referenced by Foam::MapMesh(), and Foam::MapVolFields().

Here is the caller graph for this function:

srcToTgtCellAddr()

const Foam::labelListList & srcToTgtCellAddr ( ) const

inline

Definition at line 38 of file meshToMeshI.H.

Referenced by cellVolumeWeight::update().

Here is the caller graph for this function:

tgtToSrcCellAddr()

const Foam::labelListList & tgtToSrcCellAddr ( ) const

inline

Definition at line 44 of file meshToMeshI.H.

Referenced by cellVolumeWeight::update().

Here is the caller graph for this function:

srcToTgtCellWght()

const Foam::scalarListList & srcToTgtCellWght ( ) const

inline

Definition at line 50 of file meshToMeshI.H.

Referenced by cellVolumeWeight::update().

Here is the caller graph for this function:

tgtToSrcCellWght()

const Foam::scalarListList & tgtToSrcCellWght ( ) const

inline

Definition at line 56 of file meshToMeshI.H.

Referenced by cellVolumeWeight::update().

Here is the caller graph for this function:

srcToTgtCellVec()

const Foam::pointListList & srcToTgtCellVec ( ) const

inline

Definition at line 62 of file meshToMeshI.H.

tgtToSrcCellVec()

const Foam::pointListList & tgtToSrcCellVec ( ) const

inline

Definition at line 68 of file meshToMeshI.H.

V()

Foam::scalar V ( ) const

inline

Definition at line 74 of file meshToMeshI.H.

interpolationMethodAMI()

Foam::word interpolationMethodAMI ( const interpolationMethod  method )

static

Definition at line 636 of file meshToMesh.C.

References Foam::abort(), Foam::FatalError, and FatalErrorInFunction.

Here is the call graph for this function:

patchAMIs()

const Foam::PtrList< Foam::AMIPatchToPatchInterpolation > & patchAMIs ( ) const

inline

Definition at line 95 of file meshToMeshI.H.

srcMap()

const Foam::autoPtr< Foam::mapDistribute > & srcMap ( ) const

inline

Definition at line 81 of file meshToMeshI.H.

Referenced by cellVolumeWeight::update().

Here is the caller graph for this function:

tgtMap()

const Foam::autoPtr< Foam::mapDistribute > & tgtMap ( ) const

inline

Definition at line 88 of file meshToMeshI.H.

Referenced by cellVolumeWeight::update().

Here is the caller graph for this function:

mapSrcToTgt() [1/19]

void mapSrcToTgt	(	const UList< Type > &	srcFld,
		const CombineOp &	cop,
		List< Type > &	result
	)		const

Definition at line 47 of file meshToMeshTemplates.C.

References Foam::abort(), mapDistribute::distribute(), Foam::FatalError, FatalErrorInFunction, forAll, Foam::nl, and Foam::sum().

Referenced by interRegionHeatTransferModel::interpolate(), and Foam::MapVolFields().

Here is the call graph for this function:

Here is the caller graph for this function:

mapSrcToTgt() [2/19]

void mapSrcToTgt	(	const UList< Type > &	srcField,
		const UList< typename outerProduct< vector, Type >::type > &	srcGradField,
		const CombineOp &	cop,
		List< Type > &	result
	)		const

Definition at line 115 of file meshToMeshTemplates.C.

References Foam::abort(), mapDistribute::distribute(), Foam::FatalError, FatalErrorInFunction, forAll, Foam::nl, Foam::returnReduce(), and Foam::sum().

Here is the call graph for this function:

mapSrcToTgt() [3/19]

tmp<Field<Type> > mapSrcToTgt	(	const Field< Type > &	srcFld,
		const CombineOp &	cop
	)		const

mapSrcToTgt() [4/19]

tmp<Field<Type> > mapSrcToTgt	(	const tmp< Field< Type >> &	tsrcFld,
		const CombineOp &	cop
	)		const

mapSrcToTgt() [5/19]

tmp<Field<Type> > mapSrcToTgt

(

const Field< Type > &

srcFld

)

const

mapSrcToTgt() [6/19]

tmp<Field<Type> > mapSrcToTgt

(

const tmp< Field< Type >> &

tsrcFld

)

const

mapTgtToSrc() [1/19]

void mapTgtToSrc	(	const UList< Type > &	tgtFld,
		const CombineOp &	cop,
		List< Type > &	result
	)		const

Definition at line 262 of file meshToMeshTemplates.C.

References Foam::abort(), mapDistribute::distribute(), Foam::FatalError, FatalErrorInFunction, forAll, Foam::nl, and Foam::sum().

Here is the call graph for this function:

mapTgtToSrc() [2/19]

void mapTgtToSrc	(	const UList< Type > &	srcField,
		const UList< typename outerProduct< vector, Type >::type > &	tgtGradField,
		const CombineOp &	cop,
		List< Type > &	result
	)		const

Definition at line 328 of file meshToMeshTemplates.C.

References Foam::abort(), mapDistribute::distribute(), Foam::FatalError, FatalErrorInFunction, forAll, Foam::nl, Foam::returnReduce(), and Foam::sum().

Here is the call graph for this function:

mapTgtToSrc() [3/19]

tmp<Field<Type> > mapTgtToSrc	(	const Field< Type > &	tgtFld,
		const CombineOp &	cop
	)		const

mapTgtToSrc() [4/19]

tmp<Field<Type> > mapTgtToSrc	(	const tmp< Field< Type >> &	ttgtFld,
		const CombineOp &	cop
	)		const

mapTgtToSrc() [5/19]

tmp<Field<Type> > mapTgtToSrc

(

const Field< Type > &

tgtFld

)

const

mapTgtToSrc() [6/19]

tmp<Field<Type> > mapTgtToSrc

(

const tmp< Field< Type >> &

ttgtFld

)

const

mapSrcToTgt() [7/19]

void mapSrcToTgt	(	const GeometricField< Type, fvPatchField, volMesh > &	field,
		const CombineOp &	cop,
		GeometricField< Type, fvPatchField, volMesh > &	result,
		const bool	secondOrder = true
	)		const

Definition at line 514 of file meshToMeshTemplates.C.

References GeometricField::boundaryFieldRef(), field(), forAll, Foam::identity(), fvPatchField::patch(), fvPatchField::patchInternalField(), and fvPatchField::rmap().

Here is the call graph for this function:

mapSrcToTgt() [8/19]

tmp<GeometricField<Type, fvPatchField, volMesh> > mapSrcToTgt	(	const GeometricField< Type, fvPatchField, volMesh > &	field,
		const CombineOp &	cop,
		const bool	secondOrder = true
	)		const

mapSrcToTgt() [9/19]

tmp<GeometricField<Type, fvPatchField, volMesh> > mapSrcToTgt	(	const tmp< GeometricField< Type, fvPatchField, volMesh >> &	tfield,
		const CombineOp &	cop,
		const bool	secondOrder = true
	)		const

mapSrcToTgt() [10/19]

tmp<GeometricField<Type, fvPatchField, volMesh> > mapSrcToTgt	(	const GeometricField< Type, fvPatchField, volMesh > &	field,
		const bool	secondOrder = true
	)		const

mapSrcToTgt() [11/19]

tmp<GeometricField<Type, fvPatchField, volMesh> > mapSrcToTgt	(	const tmp< GeometricField< Type, fvPatchField, volMesh >> &	tfield,
		const bool	secondOrder = true
	)		const

mapTgtToSrc() [7/19]

void mapTgtToSrc	(	const GeometricField< Type, fvPatchField, volMesh > &	field,
		const CombineOp &	cop,
		GeometricField< Type, fvPatchField, volMesh > &	result,
		const bool	secondOrder = true
	)		const

Definition at line 753 of file meshToMeshTemplates.C.

References GeometricField::boundaryFieldRef(), field(), forAll, Foam::identity(), fvPatchField::patch(), fvPatchField::patchInternalField(), and fvPatchField::rmap().

Here is the call graph for this function:

mapTgtToSrc() [8/19]

tmp<GeometricField<Type, fvPatchField, volMesh> > mapTgtToSrc	(	const GeometricField< Type, fvPatchField, volMesh > &	field,
		const CombineOp &	cop,
		const bool	secondOrder = true
	)		const

mapTgtToSrc() [9/19]

tmp<GeometricField<Type, fvPatchField, volMesh> > mapTgtToSrc	(	const tmp< GeometricField< Type, fvPatchField, volMesh >> &	tfield,
		const CombineOp &	cop,
		const bool	secondOrder = true
	)		const

mapTgtToSrc() [10/19]

tmp<GeometricField<Type, fvPatchField, volMesh> > mapTgtToSrc	(	const GeometricField< Type, fvPatchField, volMesh > &	field,
		const bool	secondOrder = true
	)		const

mapTgtToSrc() [11/19]

tmp<GeometricField<Type, fvPatchField, volMesh> > mapTgtToSrc	(	const tmp< GeometricField< Type, fvPatchField, volMesh >> &	tfield,
		const bool	secondOrder = true
	)		const

mapInternalSrcToTgt() [1/6]

void mapInternalSrcToTgt	(	const GeometricField< sphericalTensor, fvPatchField, volMesh > &	field,
		const plusEqOp< sphericalTensor > &	cop,
		GeometricField< sphericalTensor, fvPatchField, volMesh > &	result,
		const bool	secondOrder
	)		const

Definition at line 68 of file meshToMesh.C.

References field(), and GeometricField::primitiveFieldRef().

Here is the call graph for this function:

mapInternalSrcToTgt() [2/6]

void mapInternalSrcToTgt	(	const GeometricField< sphericalTensor, fvPatchField, volMesh > &	field,
		const minusEqOp< sphericalTensor > &	cop,
		GeometricField< sphericalTensor, fvPatchField, volMesh > &	result,
		const bool	secondOrder
	)		const

Definition at line 81 of file meshToMesh.C.

References field(), and GeometricField::primitiveFieldRef().

Here is the call graph for this function:

mapInternalSrcToTgt() [3/6]

void mapInternalSrcToTgt	(	const GeometricField< symmTensor, fvPatchField, volMesh > &	field,
		const plusEqOp< symmTensor > &	cop,
		GeometricField< symmTensor, fvPatchField, volMesh > &	result,
		const bool	secondOrder
	)		const

Definition at line 94 of file meshToMesh.C.

References field(), and GeometricField::primitiveFieldRef().

Here is the call graph for this function:

mapInternalSrcToTgt() [4/6]

void mapInternalSrcToTgt	(	const GeometricField< symmTensor, fvPatchField, volMesh > &	field,
		const minusEqOp< symmTensor > &	cop,
		GeometricField< symmTensor, fvPatchField, volMesh > &	result,
		const bool	secondOrder
	)		const

Definition at line 107 of file meshToMesh.C.

References field(), and GeometricField::primitiveFieldRef().

Here is the call graph for this function:

mapInternalSrcToTgt() [5/6]

void mapInternalSrcToTgt	(	const GeometricField< tensor, fvPatchField, volMesh > &	field,
		const plusEqOp< tensor > &	cop,
		GeometricField< tensor, fvPatchField, volMesh > &	result,
		const bool	secondOrder
	)		const

Definition at line 120 of file meshToMesh.C.

References field(), and GeometricField::primitiveFieldRef().

Here is the call graph for this function:

mapInternalSrcToTgt() [6/6]

void mapInternalSrcToTgt	(	const GeometricField< tensor, fvPatchField, volMesh > &	field,
		const minusEqOp< tensor > &	cop,
		GeometricField< tensor, fvPatchField, volMesh > &	result,
		const bool	secondOrder
	)		const

Definition at line 133 of file meshToMesh.C.

References field(), and GeometricField::primitiveFieldRef().

Here is the call graph for this function:

mapInternalTgtToSrc() [1/6]

void mapInternalTgtToSrc	(	const GeometricField< sphericalTensor, fvPatchField, volMesh > &	field,
		const plusEqOp< sphericalTensor > &	cop,
		GeometricField< sphericalTensor, fvPatchField, volMesh > &	result,
		const bool	secondOrder
	)		const

Definition at line 146 of file meshToMesh.C.

References field(), and GeometricField::primitiveFieldRef().

Here is the call graph for this function:

mapInternalTgtToSrc() [2/6]

void mapInternalTgtToSrc	(	const GeometricField< sphericalTensor, fvPatchField, volMesh > &	field,
		const minusEqOp< sphericalTensor > &	cop,
		GeometricField< sphericalTensor, fvPatchField, volMesh > &	result,
		const bool	secondOrder
	)		const

Definition at line 159 of file meshToMesh.C.

References field(), and GeometricField::primitiveFieldRef().

Here is the call graph for this function:

mapInternalTgtToSrc() [3/6]

void mapInternalTgtToSrc	(	const GeometricField< symmTensor, fvPatchField, volMesh > &	field,
		const plusEqOp< symmTensor > &	cop,
		GeometricField< symmTensor, fvPatchField, volMesh > &	result,
		const bool	secondOrder
	)		const

Definition at line 172 of file meshToMesh.C.

References field(), and GeometricField::primitiveFieldRef().

Here is the call graph for this function:

mapInternalTgtToSrc() [4/6]

void mapInternalTgtToSrc	(	const GeometricField< symmTensor, fvPatchField, volMesh > &	field,
		const minusEqOp< symmTensor > &	cop,
		GeometricField< symmTensor, fvPatchField, volMesh > &	result,
		const bool	secondOrder
	)		const

Definition at line 185 of file meshToMesh.C.

References field(), and GeometricField::primitiveFieldRef().

Here is the call graph for this function:

mapInternalTgtToSrc() [5/6]

void mapInternalTgtToSrc	(	const GeometricField< tensor, fvPatchField, volMesh > &	field,
		const plusEqOp< tensor > &	cop,
		GeometricField< tensor, fvPatchField, volMesh > &	result,
		const bool	secondOrder
	)		const

Definition at line 198 of file meshToMesh.C.

References field(), and GeometricField::primitiveFieldRef().

Here is the call graph for this function:

mapInternalTgtToSrc() [6/6]

void mapInternalTgtToSrc	(	const GeometricField< tensor, fvPatchField, volMesh > &	field,
		const minusEqOp< tensor > &	cop,
		GeometricField< tensor, fvPatchField, volMesh > &	result,
		const bool	secondOrder
	)		const

Definition at line 211 of file meshToMesh.C.

References field(), and GeometricField::primitiveFieldRef().

Here is the call graph for this function:

mapAndOpSrcToTgt() [1/5]

void mapAndOpSrcToTgt	(	const AMIPatchToPatchInterpolation &	AMI,
		const Field< scalar > &	srcField,
		Field< scalar > &	tgtField,
		const plusEqOp< scalar > &	cop
	)		const

Definition at line 224 of file meshToMesh.C.

mapAndOpSrcToTgt() [2/5]

void mapAndOpSrcToTgt	(	const AMIPatchToPatchInterpolation &	AMI,
		const Field< vector > &	srcField,
		Field< vector > &	tgtField,
		const plusEqOp< vector > &	cop
	)		const

Definition at line 235 of file meshToMesh.C.

mapAndOpSrcToTgt() [3/5]

void mapAndOpSrcToTgt	(	const AMIPatchToPatchInterpolation &	AMI,
		const Field< sphericalTensor > &	srcField,
		Field< sphericalTensor > &	tgtField,
		const plusEqOp< sphericalTensor > &	cop
	)		const

Definition at line 246 of file meshToMesh.C.

mapAndOpSrcToTgt() [4/5]

void mapAndOpSrcToTgt	(	const AMIPatchToPatchInterpolation &	AMI,
		const Field< symmTensor > &	srcField,
		Field< symmTensor > &	tgtField,
		const plusEqOp< symmTensor > &	cop
	)		const

Definition at line 257 of file meshToMesh.C.

mapAndOpSrcToTgt() [5/5]

void mapAndOpSrcToTgt	(	const AMIPatchToPatchInterpolation &	AMI,
		const Field< tensor > &	srcField,
		Field< tensor > &	tgtField,
		const plusEqOp< tensor > &	cop
	)		const

Definition at line 268 of file meshToMesh.C.

mapAndOpTgtToSrc() [1/5]

void mapAndOpTgtToSrc	(	const AMIPatchToPatchInterpolation &	AMI,
		Field< scalar > &	srcField,
		const Field< scalar > &	tgtField,
		const plusEqOp< scalar > &	cop
	)		const

Definition at line 279 of file meshToMesh.C.

mapAndOpTgtToSrc() [2/5]

void mapAndOpTgtToSrc	(	const AMIPatchToPatchInterpolation &	AMI,
		Field< vector > &	srcField,
		const Field< vector > &	tgtField,
		const plusEqOp< vector > &	cop
	)		const

Definition at line 290 of file meshToMesh.C.

mapAndOpTgtToSrc() [3/5]

void mapAndOpTgtToSrc	(	const AMIPatchToPatchInterpolation &	AMI,
		Field< sphericalTensor > &	srcField,
		const Field< sphericalTensor > &	tgtField,
		const plusEqOp< sphericalTensor > &	cop
	)		const

Definition at line 301 of file meshToMesh.C.

mapAndOpTgtToSrc() [4/5]

void mapAndOpTgtToSrc	(	const AMIPatchToPatchInterpolation &	AMI,
		Field< symmTensor > &	srcField,
		const Field< symmTensor > &	tgtField,
		const plusEqOp< symmTensor > &	cop
	)		const

Definition at line 312 of file meshToMesh.C.

mapAndOpTgtToSrc() [5/5]

void mapAndOpTgtToSrc	(	const AMIPatchToPatchInterpolation &	AMI,
		Field< tensor > &	srcField,
		const Field< tensor > &	tgtField,
		const plusEqOp< tensor > &	cop
	)		const

Definition at line 323 of file meshToMesh.C.

mapSrcToTgt() [12/19]

Foam::tmp<Foam::Field<Type> > mapSrcToTgt	(	const Field< Type > &	srcField,
		const CombineOp &	cop
	)		const

Definition at line 209 of file meshToMeshTemplates.C.

References tmp::ref(), and Foam::Zero.

Here is the call graph for this function:

mapSrcToTgt() [13/19]

Foam::tmp<Foam::Field<Type> > mapSrcToTgt	(	const tmp< Field< Type >> &	tsrcField,
		const CombineOp &	cop
	)		const

Definition at line 231 of file meshToMeshTemplates.C.

mapSrcToTgt() [14/19]

Foam::tmp<Foam::Field<Type> > mapSrcToTgt

(

const Field< Type > &

srcField

)

const

Definition at line 242 of file meshToMeshTemplates.C.

mapSrcToTgt() [15/19]

Foam::tmp<Foam::Field<Type> > mapSrcToTgt

(

const tmp< Field< Type >> &

tsrcField

)

const

Definition at line 252 of file meshToMeshTemplates.C.

mapTgtToSrc() [12/19]

Foam::tmp<Foam::Field<Type> > mapTgtToSrc	(	const Field< Type > &	tgtField,
		const CombineOp &	cop
	)		const

Definition at line 414 of file meshToMeshTemplates.C.

References tmp::ref(), and Foam::Zero.

Here is the call graph for this function:

mapTgtToSrc() [13/19]

Foam::tmp<Foam::Field<Type> > mapTgtToSrc	(	const tmp< Field< Type >> &	ttgtField,
		const CombineOp &	cop
	)		const

Definition at line 436 of file meshToMeshTemplates.C.

mapTgtToSrc() [14/19]

Foam::tmp<Foam::Field<Type> > mapTgtToSrc

(

const Field< Type > &

tgtField

)

const

Definition at line 447 of file meshToMeshTemplates.C.

mapTgtToSrc() [15/19]

Foam::tmp<Foam::Field<Type> > mapTgtToSrc

(

const tmp< Field< Type >> &

ttgtField

)

const

Definition at line 457 of file meshToMeshTemplates.C.

mapSrcToTgt() [16/19]

Foam::tmp<Foam::GeometricField<Type, Foam::fvPatchField, Foam::volMesh> > mapSrcToTgt	(	const GeometricField< Type, fvPatchField, volMesh > &	field,
		const CombineOp &	cop,
		const bool	secondOrder
	)		const

Definition at line 579 of file meshToMeshTemplates.C.

References fvMesh::boundary(), field(), forAll, primitiveMesh::nCells(), IOobject::NO_READ, IOobject::NO_WRITE, tmp::ref(), PtrList::set(), fvMesh::time(), Time::timeName(), Foam::type(), and Foam::Zero.

Here is the call graph for this function:

mapSrcToTgt() [17/19]

Foam::tmp<Foam::GeometricField<Type, Foam::fvPatchField, Foam::volMesh> > mapSrcToTgt	(	const tmp< GeometricField< Type, fvPatchField, volMesh >> &	tfield,
		const CombineOp &	cop,
		const bool	secondOrder
	)		const

Definition at line 670 of file meshToMeshTemplates.C.

mapSrcToTgt() [18/19]

Foam::tmp<Foam::GeometricField<Type, Foam::fvPatchField, Foam::volMesh> > mapSrcToTgt	(	const GeometricField< Type, fvPatchField, volMesh > &	field,
		const bool	secondOrder
	)		const

Definition at line 683 of file meshToMeshTemplates.C.

References field().

Here is the call graph for this function:

mapSrcToTgt() [19/19]

Foam::tmp<Foam::GeometricField<Type, Foam::fvPatchField, Foam::volMesh> > mapSrcToTgt	(	const tmp< GeometricField< Type, fvPatchField, volMesh >> &	tfield,
		const bool	secondOrder
	)		const

Definition at line 695 of file meshToMeshTemplates.C.

mapTgtToSrc() [16/19]

Foam::tmp<Foam::GeometricField<Type, Foam::fvPatchField, Foam::volMesh> > mapTgtToSrc	(	const GeometricField< Type, fvPatchField, volMesh > &	field,
		const CombineOp &	cop,
		const bool	secondOrder
	)		const

Definition at line 815 of file meshToMeshTemplates.C.

References fvMesh::boundary(), field(), forAll, primitiveMesh::nCells(), IOobject::NO_READ, IOobject::NO_WRITE, tmp::ref(), PtrList::set(), fvMesh::time(), Time::timeName(), Foam::type(), and Foam::Zero.

Here is the call graph for this function:

mapTgtToSrc() [17/19]

Foam::tmp<Foam::GeometricField<Type, Foam::fvPatchField, Foam::volMesh> > mapTgtToSrc	(	const tmp< GeometricField< Type, fvPatchField, volMesh >> &	tfield,
		const CombineOp &	cop,
		const bool	secondOrder
	)		const

Definition at line 906 of file meshToMeshTemplates.C.

mapTgtToSrc() [18/19]

Foam::tmp<Foam::GeometricField<Type, Foam::fvPatchField, Foam::volMesh> > mapTgtToSrc	(	const GeometricField< Type, fvPatchField, volMesh > &	field,
		const bool	secondOrder
	)		const

Definition at line 919 of file meshToMeshTemplates.C.

References field().

Here is the call graph for this function:

mapTgtToSrc() [19/19]

Foam::tmp<Foam::GeometricField<Type, Foam::fvPatchField, Foam::volMesh> > mapTgtToSrc	(	const tmp< GeometricField< Type, fvPatchField, volMesh >> &	tfield,
		const bool	secondOrder
	)		const

Definition at line 931 of file meshToMeshTemplates.C.

Member Data Documentation

interpolationMethodNames_

const Foam::Enum< Foam::meshToMesh::interpolationMethod > interpolationMethodNames_

static

Definition at line 75 of file meshToMesh.H.

Referenced by interRegionOption::setMapper().

procMapMethodNames_

const Foam::Enum< Foam::meshToMesh::procMapMethod > procMapMethodNames_

static

Initial value:

{
    { procMapMethod::pmAABB, "AABB" },
    { procMapMethod::pmLOD, "LOD" },
}

Definition at line 84 of file meshToMesh.H.

Referenced by interRegionOption::setMapper().

---

The documentation for this class was generated from the following files:

• src/sampling/meshToMesh/meshToMesh.H
• src/sampling/meshToMesh/meshToMesh.C
• src/sampling/meshToMesh/meshToMeshI.H
• src/sampling/meshToMesh/meshToMeshParallelOps.C
• src/sampling/meshToMesh/meshToMeshTemplates.C
