meshReader Class Reference

This class supports creating polyMeshes with baffles. More...

Inheritance diagram for meshReader:

Collaboration diagram for meshReader:

Classes
class	cellFaceIdentifier

Public Member Functions
	meshReader (const fileName &, const scalar scaling=1.0)
virtual	~meshReader ()=default
virtual autoPtr< polyMesh >	mesh (const objectRegistry &)
void	writeAux (const objectRegistry &) const
void	writeMesh (const polyMesh &, IOstreamOption streamOpt=IOstreamOption(IOstreamOption::BINARY)) const

Static Public Member Functions
static void	warnDuplicates (const word &context, const wordList &)

Protected Member Functions
virtual bool	readGeometry (const scalar scaleFactor=1.0)=0

Protected Attributes
fileName	geometryFile_
scalar	scaleFactor_
pointField	points_
labelList	origCellId_
List< List< cellFaceIdentifier > >	boundaryIds_
wordList	patchTypes_
wordList	patchNames_
wordList	patchPhysicalTypes_
labelList	patchStarts_
labelList	patchSizes_
label	nInternalFaces_
faceList	meshFaces_
faceListList	cellFaces_
faceList	baffleFaces_
labelList	cellTableId_
cellTable	cellTable_

Detailed Description

This class supports creating polyMeshes with baffles.

The derived classes are responsible for providing the protected data. This implementation is somewhat messy, but could/should be restructured to provide a more generalized reader (at the moment it has been written for converting PROSTAR data).

The meshReader supports cellTable information (see new user's guide entry).

Note

The boundary definitions are given as cell/face.

Source files

• meshReader.H
• calcPointCells.C
• createPolyBoundary.C
• createPolyCells.C
• meshReader.C
• meshReaderAux.C

Definition at line 64 of file meshReader.H.

Constructor & Destructor Documentation

meshReader()

meshReader	(	const fileName &	fileOrPrefix,
		const scalar	scaling = 1.0
	)

Definition at line 145 of file meshReader.C.

~meshReader()

virtual ~meshReader ( )

virtualdefault

Member Function Documentation

readGeometry()

virtual bool readGeometry ( const scalar  scaleFactor = 1.0 )

protectedpure virtual

Implemented in STARCDMeshReader, and FIREMeshReader.

warnDuplicates()

void warnDuplicates ( const word &  context, const wordList &  list  )

static

Definition at line 30 of file meshReaderAux.C.

References Foam::endl(), HashTable::find(), forAllConstIters(), Foam::Info, HashTable::insert(), and Foam::nl.

Here is the call graph for this function:

mesh()

Foam::autoPtr< Foam::polyMesh > mesh ( const objectRegistry &  registry )

virtual

Reimplemented in FIREMeshReader.

Definition at line 75 of file meshReader.C.

References polyMesh::addPatches(), IOobject::AUTO_WRITE, polyMesh::boundaryMesh(), TimePaths::constant(), polyMesh::defaultRegion, Foam::endl(), Foam::Info, mesh, meshPtr, polyBoundaryMesh::names(), autoPtr::New(), IOobject::NO_READ, and objectRegistry::time().

Here is the call graph for this function:

writeAux()

void writeAux

(

const objectRegistry &

registry

)

const

Definition at line 138 of file meshReaderAux.C.

References IOstreamOption::ASCII, and IOstreamOption::BINARY.

writeMesh()

void writeMesh	(	const polyMesh &	mesh,
		IOstreamOption	streamOpt = IOstreamOption(IOstreamOption::BINARY)
	)		const

Definition at line 118 of file meshReader.C.

References Foam::endl(), Foam::Info, mesh, polyMesh::removeFiles(), and fvMesh::writeObject().

Here is the call graph for this function:

Member Data Documentation

geometryFile_

fileName geometryFile_

protected

Definition at line 206 of file meshReader.H.

scaleFactor_

scalar scaleFactor_

protected

Definition at line 209 of file meshReader.H.

points_

pointField points_

protected

Definition at line 212 of file meshReader.H.

origCellId_

labelList origCellId_

protected

Definition at line 215 of file meshReader.H.

Referenced by STARCDMeshReader::readCells().

boundaryIds_

List<List<cellFaceIdentifier> > boundaryIds_

protected

Definition at line 219 of file meshReader.H.

patchTypes_

wordList patchTypes_

protected

Definition at line 222 of file meshReader.H.

patchNames_

wordList patchNames_

protected

Definition at line 225 of file meshReader.H.

patchPhysicalTypes_

wordList patchPhysicalTypes_

protected

Definition at line 228 of file meshReader.H.

patchStarts_

labelList patchStarts_

protected

Definition at line 231 of file meshReader.H.

patchSizes_

labelList patchSizes_

protected

Definition at line 232 of file meshReader.H.

nInternalFaces_

label nInternalFaces_

protected

Definition at line 235 of file meshReader.H.

meshFaces_

faceList meshFaces_

protected

Definition at line 238 of file meshReader.H.

Referenced by FIREMeshReader::readFaces().

cellFaces_

faceListList cellFaces_

protected

Definition at line 241 of file meshReader.H.

Referenced by STARCDMeshReader::readCells().

baffleFaces_

faceList baffleFaces_

protected

Definition at line 244 of file meshReader.H.

Referenced by STARCDMeshReader::readCells().

cellTableId_

labelList cellTableId_

protected

Definition at line 247 of file meshReader.H.

Referenced by STARCDMeshReader::readCells().

cellTable_

cellTable cellTable_

protected

Definition at line 250 of file meshReader.H.

Referenced by STARCDMeshReader::readCells().

---

The documentation for this class was generated from the following files:

• src/conversion/common/reader/meshReader.H
• src/conversion/common/reader/calcPointCells.C
• src/conversion/common/reader/createPolyBoundary.C
• src/conversion/common/reader/createPolyCells.C
• src/conversion/common/reader/meshReader.C
• src/conversion/common/reader/meshReaderAux.C
