Cuts (splits) cells. More...

Inheritance diagram for meshCutter:

Collaboration diagram for meshCutter:

Public Member Functions
	ClassName ("meshCutter")

	meshCutter (const polyMesh &mesh)

	~meshCutter ()=default

void	setRefinement (const cellCuts &cuts, polyTopoChange &meshMod)

void	updateMesh (const mapPolyMesh &)

const Map< label > &	addedCells () const

const Map< label > &	addedFaces () const

const EdgeMap< label > &	addedPoints () const

Public Member Functions inherited from edgeVertex
	edgeVertex (const polyMesh &mesh)

const polyMesh &	mesh () const

bool	isEdge (const label eVert) const

label	getEdge (const label eVert) const

label	getVertex (const label eVert) const

label	vertToEVert (const label vertI) const

label	edgeToEVert (const label edgeI) const

point	coord (const label cut, const scalar weight) const

label	cutPairToEdge (const label cut0, const label cut1) const

Ostream &	writeCut (Ostream &os, const label cut, const scalar) const

Ostream &	writeCuts (Ostream &os, const labelList &, const scalarField &) const

Additional Inherited Members
Static Public Member Functions inherited from edgeVertex
static void	updateLabels (const labelList &map, List< refineCell > &)

static void	updateLabels (const labelList &map, Map< label > &)

static void	updateLabels (const labelList &map, labelHashSet &)

static bool	isEdge (const primitiveMesh &mesh, const label eVert)

static label	getEdge (const primitiveMesh &mesh, const label eVert)

static label	getVertex (const primitiveMesh &mesh, const label eVert)

static label	vertToEVert (const primitiveMesh &mesh, const label vertI)

static label	edgeToEVert (const primitiveMesh &mesh, const label edgeI)

static point	coord (const primitiveMesh &, const label cut, const scalar weight)

static label	cutPairToEdge (const primitiveMesh &, const label cut0, const label cut1)

Detailed Description

Cuts (splits) cells.

Description of cut is given as a loop of 'cuts' per cell (see cellCuts). setRefinement() takes this cut description and inserts the necessary topoActions (add points/faces/cells) into the polyTopoChange.

Stores added cells/faces/points.

Cut description gives orientation to cut by calculating 'anchorPoints'. The side of the cell that contains the anchorPoints is the master cell. Likewise the cells' edges will have the split added as a duplicate of the master (anchor) point. Think of it as the cell with the anchor points at the bottom. Add a face at the bottom to split the cell and then sweep this face up to be through the middle of the cell (inflation).

Start: cell with anchor points at bottom

+-------+
|       +
|       +
|       +
|       +
|       +
|       +
|       +
+-------+
anchor  anchor

Topo change: splitface introduced at bottom of cell, introducing a new cell and splitting the side faces into two.

+-------+
|       +
|       +
|       + <- addedCell
|       +
|       +
|       +
+-------+ <- splitFace
+-------+ <- original cell
anchor  anchor

Inflation: splitface shifted up to middle of cell (or wherever cut was)

+-------+
|       +
|       + <- addedCell
|       +
+-------+ <- splitFace
|       +
|       + <- original cell
|       +
+-------+
anchor  anchor

Anyway this was the original idea. Inflation was meant to handle conservative properties distribution without interpolation. (just face sweeping through space). But problem was that only if the introduced splitface was exactly the same shape as bottom face (so same 2D topo or perfectly flat) the volume between them was 0.

This meshCutting still uses anchorPoints though:

the master cell is the one without the anchor points. The added cell (on top of the splitFace) is the with.
the splitFace is owned by the master cell (since it has the lower number)
the side faces get split and get either the original cell as neighbour or the added cell (if the faces contain the cell anchor points)

Source files

Definition at line 134 of file meshCutter.H.
