interfaceHeatResistance< Thermo, OtherThermo > Class Template Reference

Interface Heat Resistance type of condensation/saturation model using spread source distribution following: More...

Inheritance diagram for interfaceHeatResistance< Thermo, OtherThermo >:

Collaboration diagram for interfaceHeatResistance< Thermo, OtherThermo >:

Public Member Functions
	TypeName ("interfaceHeatResistance")
	interfaceHeatResistance (const dictionary &dict, const phasePair &pair)
virtual	~interfaceHeatResistance ()=default
virtual tmp< volScalarField >	Kexp (const volScalarField &field)
virtual tmp< volScalarField >	KSp (label modelVariable, const volScalarField &field)
virtual tmp< volScalarField >	KSu (label modelVariable, const volScalarField &field)
virtual const dimensionedScalar &	Tactivate () const noexcept
virtual bool	includeDivU () const noexcept
Public Member Functions inherited from InterfaceCompositionModel< Thermo, OtherThermo >
	InterfaceCompositionModel (const dictionary &dict, const phasePair &pair)
	~InterfaceCompositionModel ()=default
virtual tmp< volScalarField >	dY (const word &speciesName, const volScalarField &Tf) const
virtual tmp< volScalarField >	Yf (const word &speciesName, const volScalarField &Tf) const
virtual tmp< volScalarField >	D (const word &speciesName) const
virtual tmp< volScalarField >	L (const word &speciesName, const volScalarField &Tf) const
	InterfaceCompositionModel (const dictionary &dict, const phasePair &pair)
	~InterfaceCompositionModel ()=default
virtual tmp< volScalarField >	dY (const word &speciesName, const volScalarField &Tf) const
virtual tmp< volScalarField >	D (const word &speciesName) const
virtual tmp< volScalarField >	L (const word &speciesName, const volScalarField &Tf) const
virtual void	addMDotL (const volScalarField &K, const volScalarField &Tf, volScalarField &mDotL, volScalarField &mDotLPrime) const
template<class ThermoType >
const Foam::multiComponentMixture< ThermoType >::thermoType &	getLocalThermo (const word &speciesName, const multiComponentMixture< ThermoType > &globalThermo) const
template<class ThermoType >
const Foam::pureMixture< ThermoType >::thermoType &	getLocalThermo (const word &speciesName, const pureMixture< ThermoType > &globalThermo) const
template<class ThermoType >
Foam::tmp< Foam::volScalarField >	getSpecieMassFraction (const word &speciesName, const multiComponentMixture< ThermoType > &mixture) const
template<class ThermoType >
Foam::tmp< Foam::volScalarField >	getSpecieMassFraction (const word &speciesName, const pureMixture< ThermoType > &mixture) const
template<class ThermoType >
Foam::tmp< Foam::volScalarField >	MwMixture (const pureMixture< ThermoType > &mixture) const
template<class ThermoType >
Foam::tmp< Foam::volScalarField >	MwMixture (const multiComponentMixture< ThermoType > &mixture) const
Public Member Functions inherited from interfaceCompositionModel
	TypeName ("interfaceCompositionModel")
	declareRunTimeSelectionTable (autoPtr, interfaceCompositionModel, dictionary,(const dictionary &dict, const phasePair &pair),(dict, pair))
	interfaceCompositionModel (const dictionary &dict, const phasePair &pair)
virtual	~interfaceCompositionModel ()=default
const word	transferSpecie () const
const phasePair &	pair () const
bool	includeVolChange ()
const word &	variable () const
	TypeName ("interfaceCompositionModel")
	declareRunTimeSelectionTable (autoPtr, interfaceCompositionModel, dictionary,(const dictionary &dict, const phasePair &pair),(dict, pair))
	interfaceCompositionModel (const dictionary &dict, const phasePair &pair)
virtual	~interfaceCompositionModel ()=default
virtual void	update (const volScalarField &Tf)=0
const hashedWordList &	species () const
bool	transports (word &speciesName) const
virtual tmp< volScalarField >	YfPrime (const word &speciesName, const volScalarField &Tf) const =0

Additional Inherited Members
Public Types inherited from interfaceCompositionModel
enum	modelVariable { T, P, Y, alpha }
Static Public Member Functions inherited from interfaceCompositionModel
static autoPtr< interfaceCompositionModel >	New (const dictionary &dict, const phasePair &pair)
static autoPtr< interfaceCompositionModel >	New (const dictionary &dict, const phasePair &pair)
Protected Member Functions inherited from InterfaceCompositionModel< Thermo, OtherThermo >
template<class ThermoType >
const pureMixture< ThermoType >::thermoType &	getLocalThermo (const word &speciesName, const pureMixture< ThermoType > &globalThermo) const
template<class ThermoType >
const multiComponentMixture< ThermoType >::thermoType &	getLocalThermo (const word &speciesName, const multiComponentMixture< ThermoType > &globalThermo) const
template<class ThermoType >
tmp< volScalarField >	getSpecieMassFraction (const word &speciesName, const pureMixture< ThermoType > &thermo) const
template<class ThermoType >
tmp< volScalarField >	getSpecieMassFraction (const word &speciesName, const multiComponentMixture< ThermoType > &thermo) const
template<class ThermoType >
tmp< volScalarField >	MwMixture (const pureMixture< ThermoType > &thermo) const
template<class ThermoType >
tmp< volScalarField >	MwMixture (const multiComponentMixture< ThermoType > &) const
template<class ThermoType >
const pureMixture< ThermoType >::thermoType &	getLocalThermo (const word &speciesName, const pureMixture< ThermoType > &globalThermo) const
template<class ThermoType >
const multiComponentMixture< ThermoType >::thermoType &	getLocalThermo (const word &speciesName, const multiComponentMixture< ThermoType > &globalThermo) const
Protected Attributes inherited from InterfaceCompositionModel< Thermo, OtherThermo >
const Thermo &	fromThermo_
const OtherThermo &	toThermo_
const dimensionedScalar	Le_
const Thermo &	thermo_
const OtherThermo &	otherThermo_
Protected Attributes inherited from interfaceCompositionModel
modelVariable	modelVariable_
bool	includeVolChange_
const phasePair &	pair_
word	speciesName_
const fvMesh &	mesh_
const hashedWordList	speciesNames_
Static Protected Attributes inherited from interfaceCompositionModel
static const Enum< modelVariable >	modelVariableNames_

Detailed Description

template<class Thermo, class OtherThermo>
class Foam::meltingEvaporationModels::interfaceHeatResistance< Thermo, OtherThermo >

Interface Heat Resistance type of condensation/saturation model using spread source distribution following:

References:

    Hardt, S., Wondra, F. (2008).
    Evaporation model for interfacial flows based on a continuum-
    field representation of the source term
    Journal of Computational Physics 227 (2008), 5871-5895

Usage

Example usage:

massTransferModel
(
    (liquid to gas)
    {
        type                interfaceHeatResistance;
        R                   2e6;
        Tactivate           373;
    }
);

where:

Property	Description	Required	Default value
R	Heat transfer coefficient	yes
includeVolChange	Volumen change	no	yes
isoAlpha	iso-alpha for interface	no	0.5
Tactivate	Saturation temperature	yes
species	Specie name on the other phase	no	none
spread	Cells to spread the source for pEq	no	3

Source files

• interfaceHeatResistance.H
• interfaceHeatResistance.C

Definition at line 123 of file interfaceHeatResistance.H.

Constructor & Destructor Documentation

interfaceHeatResistance()

interfaceHeatResistance	(	const dictionary &	dict,
		const phasePair &	pair
	)

Definition at line 114 of file interfaceHeatResistance.C.

~interfaceHeatResistance()

virtual ~interfaceHeatResistance ( )

virtualdefault

Member Function Documentation

TypeName()

TypeName

(

"interfaceHeatResistance< Thermo, OtherThermo >"

)

Kexp()

Foam::tmp< Foam::volScalarField > Kexp ( const volScalarField &  field )

virtual

Implements interfaceCompositionModel.

Definition at line 184 of file interfaceHeatResistance.C.

References D, Foam::dimArea, Foam::dimTemperature, Foam::constant::electromagnetic::e, phasePair::from(), Foam::gAverage(), L(), Foam::max(), mesh, tmp::New(), Foam::sign(), Foam::fvc::spreadSource(), Foam::sqr(), Foam::T(), T0, phasePair::to(), and Foam::Zero.

Here is the call graph for this function:

KSp()

Foam::tmp< Foam::volScalarField > KSp ( label  modelVariable, const volScalarField &  field  )

virtual

Implements interfaceCompositionModel.

Definition at line 258 of file interfaceHeatResistance.C.

References Foam::pos(), and Foam::sign().

Here is the call graph for this function:

KSu()

Foam::tmp< Foam::volScalarField > KSu ( label  modelVariable, const volScalarField &  field  )

virtual

Implements interfaceCompositionModel.

Definition at line 285 of file interfaceHeatResistance.C.

References tmp::New(), interfaceCompositionModel::P, Foam::pos(), and Foam::sign().

Here is the call graph for this function:

Tactivate()

virtual const dimensionedScalar& Tactivate ( ) const

inlinevirtualnoexcept

Implements interfaceCompositionModel.

Definition at line 202 of file interfaceHeatResistance.H.

includeDivU()

virtual bool includeDivU ( ) const

inlinevirtualnoexcept

Reimplemented from interfaceCompositionModel.

Definition at line 209 of file interfaceHeatResistance.H.

---

The documentation for this class was generated from the following files:

• src/phaseSystemModels/multiphaseInter/phasesSystem/massTransferModels/interfaceHeatResistance/interfaceHeatResistance.H
• src/phaseSystemModels/multiphaseInter/phasesSystem/massTransferModels/interfaceHeatResistance/interfaceHeatResistance.C
