mappedVelocityFluxFixedValueFvPatchField Class Reference

This boundary condition maps the velocity and flux from a neighbour patch to this patch. More...

Inheritance diagram for mappedVelocityFluxFixedValueFvPatchField:

Collaboration diagram for mappedVelocityFluxFixedValueFvPatchField:

Public Member Functions
	TypeName ("mappedVelocityFlux")
	mappedVelocityFluxFixedValueFvPatchField (const fvPatch &, const DimensionedField< vector, volMesh > &)
	mappedVelocityFluxFixedValueFvPatchField (const fvPatch &, const DimensionedField< vector, volMesh > &, const dictionary &)
	mappedVelocityFluxFixedValueFvPatchField (const mappedVelocityFluxFixedValueFvPatchField &, const fvPatch &, const DimensionedField< vector, volMesh > &, const fvPatchFieldMapper &)
	mappedVelocityFluxFixedValueFvPatchField (const mappedVelocityFluxFixedValueFvPatchField &)
virtual tmp< fvPatchVectorField >	clone () const
	mappedVelocityFluxFixedValueFvPatchField (const mappedVelocityFluxFixedValueFvPatchField &, const DimensionedField< vector, volMesh > &)
virtual tmp< fvPatchVectorField >	clone (const DimensionedField< vector, volMesh > &iF) const
virtual void	updateCoeffs ()
virtual void	write (Ostream &) const

Detailed Description

This boundary condition maps the velocity and flux from a neighbour patch to this patch.

Usage

Property	Description	Required	Default value
phi	flux field name	no	phi

Example of the boundary condition specification:

    <patchName>
    {
        type            mappedVelocityFlux;
        phi             phi;
        value           uniform 0;  // place holder
    }

The underlying sample mode should be set to nearestPatchFace or nearestFace

Note

This boundary condition can only be applied to patches that are of the mappedPolyPatch type.

See also

Foam::mappedPatchBase Foam::mappedPolyPatch Foam::mappedFvPatch Foam::fixedValueFvPatchVectorField

Source files

• mappedVelocityFluxFixedValueFvPatchField.H
• mappedVelocityFluxFixedValueFvPatchField.C

Definition at line 90 of file mappedVelocityFluxFixedValueFvPatchField.H.

Constructor & Destructor Documentation

mappedVelocityFluxFixedValueFvPatchField() [1/5]

mappedVelocityFluxFixedValueFvPatchField	(	const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF
	)

Definition at line 34 of file mappedVelocityFluxFixedValueFvPatchField.C.

Referenced by mappedVelocityFluxFixedValueFvPatchField::clone().

Here is the caller graph for this function:

mappedVelocityFluxFixedValueFvPatchField() [2/5]

mappedVelocityFluxFixedValueFvPatchField	(	const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF,
		const dictionary &	dict
	)

Definition at line 71 of file mappedVelocityFluxFixedValueFvPatchField.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, mappedPatchBase::mode(), p, and Foam::foamVersion::patch.

Here is the call graph for this function:

mappedVelocityFluxFixedValueFvPatchField() [3/5]

mappedVelocityFluxFixedValueFvPatchField	(	const mappedVelocityFluxFixedValueFvPatchField &	ptf,
		const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)

Definition at line 46 of file mappedVelocityFluxFixedValueFvPatchField.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, p, and Foam::foamVersion::patch.

Here is the call graph for this function:

mappedVelocityFluxFixedValueFvPatchField() [4/5]

mappedVelocityFluxFixedValueFvPatchField

(

const mappedVelocityFluxFixedValueFvPatchField &

ptf

)

Definition at line 111 of file mappedVelocityFluxFixedValueFvPatchField.C.

mappedVelocityFluxFixedValueFvPatchField() [5/5]

mappedVelocityFluxFixedValueFvPatchField	(	const mappedVelocityFluxFixedValueFvPatchField &	ptf,
		const DimensionedField< vector, volMesh > &	iF
	)

Definition at line 122 of file mappedVelocityFluxFixedValueFvPatchField.C.

Member Function Documentation

TypeName()

TypeName

(

"mappedVelocityFlux"

)

clone() [1/2]

virtual tmp<fvPatchVectorField> clone ( ) const

inlinevirtual

Definition at line 140 of file mappedVelocityFluxFixedValueFvPatchField.H.

References mappedVelocityFluxFixedValueFvPatchField::mappedVelocityFluxFixedValueFvPatchField().

Here is the call graph for this function:

clone() [2/2]

virtual tmp<fvPatchVectorField> clone ( const DimensionedField< vector, volMesh > &  iF ) const

inlinevirtual

Definition at line 157 of file mappedVelocityFluxFixedValueFvPatchField.H.

References mappedVelocityFluxFixedValueFvPatchField::mappedVelocityFluxFixedValueFvPatchField().

Here is the call graph for this function:

updateCoeffs()

void updateCoeffs ( )

virtual

Definition at line 134 of file mappedVelocityFluxFixedValueFvPatchField.C.

References Foam::abort(), GeometricField::boundaryField(), polyMesh::boundaryMesh(), mappedPatchBase::distribute(), Foam::FatalError, FatalErrorInFunction, polyBoundaryMesh::findPatchID(), forAll, objectRegistry::lookupObject(), mappedPatchBase::mode(), UPstream::msgType(), mappedPatchBase::NEARESTFACE, mappedPatchBase::NEARESTPATCHFACE, mappedPatchBase::NEARESTPATCHFACEAMI, primitiveMesh::nFaces(), Foam::nl, Foam::operator==(), Foam::foamVersion::patch, fvPatchField::patch(), mappedPatchBase::sampleMesh(), mappedPatchBase::samplePatch(), fvPatch::start(), and Foam::Zero.

Here is the call graph for this function:

write()

void write ( Ostream &  os ) const

virtual

Definition at line 228 of file mappedVelocityFluxFixedValueFvPatchField.C.

References os(), fvPatchField::write(), and Ostream::writeEntryIfDifferent().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/finiteVolume/fields/fvPatchFields/derived/mappedVelocityFluxFixedValue/mappedVelocityFluxFixedValueFvPatchField.H
• src/finiteVolume/fields/fvPatchFields/derived/mappedVelocityFluxFixedValue/mappedVelocityFluxFixedValueFvPatchField.C
