Functionality for sampling fields using mappedPatchBase. Every call to mappedField() returns a sampled field, optionally scaled to maintain an area-weighted average. More...

Inheritance diagram for mappedPatchFieldBase< Type >:

[legend]

Collaboration diagram for mappedPatchFieldBase< Type >:

[legend]

Public Member Functions
	mappedPatchFieldBase (const mappedPatchBase &mapper, const fvPatchField< Type > &patchField, const word &fieldName, const bool setAverage, const Type average, const word &interpolationScheme)

	mappedPatchFieldBase (const mappedPatchBase &mapper, const fvPatchField< Type > &patchField, const dictionary &dict)

	mappedPatchFieldBase (const mappedPatchBase &mapper, const fvPatchField< Type > &patchField, const dictionary &dict, const Field< Type > &fld)

	mappedPatchFieldBase (const mappedPatchBase &mapper, const fvPatchField< Type > &patchField)

	mappedPatchFieldBase (const mappedPatchFieldBase< Type > &mapper)

	mappedPatchFieldBase (const mappedPatchBase &mapper, const fvPatchField< Type > &patchField, const mappedPatchFieldBase< Type > &base)

virtual	~mappedPatchFieldBase ()=default

template<class T >
const GeometricField< T, fvPatchField, volMesh > &	sampleField (const word &fieldName) const

const GeometricField< Type, fvPatchField, volMesh > &	sampleField () const

virtual tmp< Field< Type > >	mappedField () const

virtual tmp< Field< Type > >	mappedInternalField () const

virtual tmp< scalarField >	mappedWeightField () const

virtual void	mappedWeightField (const word &weightFieldName, tmp< scalarField > &thisWeights, tmp< scalarField > &nbrWeights) const

virtual void	write (Ostream &os) const

template<class T >
void	distribute (const word &fieldName, Field< T > &newValues) const

template<class Type2 >
const Foam::GeometricField< Type2, Foam::fvPatchField, Foam::volMesh > &	sampleField (const word &fieldName) const

Static Public Member Functions
static const mappedPatchBase &	mapper (const fvPatch &p, const DimensionedField< Type, volMesh > &iF)

Protected Member Functions
template<class T >
void	initRetrieveField (const objectRegistry &obr, const word &region, const word &patch, const labelListList &map, const word &fieldName, const Field< T > &fld) const

template<class T >
bool	storeAndRetrieveField (const word &fieldName, const label myComm, const labelListList &subMap, const label constructSize, const labelListList &constructMap, const labelListList &address, const scalarListList &weights, Field< T > &fld) const

template<class T >
void	initRetrieveField (const word &fieldName, const Field< T > &fld) const

template<class T >
void	storeField (const objectRegistry &obr, const word &region, const word &patch, const label myComm, const labelListList &procToMap, const word &fieldName, const Field< T > &fld) const

template<class T >
bool	retrieveField (const bool allowUnset, const objectRegistry &obr, const word &region, const word &patch, const label myComm, const labelListList &procToMap, const word &fieldName, Field< T > &fld) const

Protected Attributes
const mappedPatchBase &	mapper_

const fvPatchField< Type > &	patchField_

word	fieldName_

const bool	setAverage_

const Type	average_

word	interpolationScheme_

Detailed Description

template<class Type>
class Foam::mappedPatchFieldBase< Type >

Functionality for sampling fields using mappedPatchBase. Every call to mappedField() returns a sampled field, optionally scaled to maintain an area-weighted average.

Example usage:

{
    field               T;          // default is same as fvPatchField
    setAverage          false;
    average             1.0;        // only if setAverage=true
    interpolationScheme cellPoint;  // default is cell
}

Property	Description	Required	Default
`field`	name of field to be mapped	no	this field name
`setAverage`	use average value	no	false
`average`	average value to apply if `setAverage` = yes	partly
`interpolationScheme`	interpolation scheme	partly	cell

Source files

Definition at line 101 of file mappedPatchFieldBase.H.

Constructor & Destructor Documentation

◆ mappedPatchFieldBase() [1/6]

mappedPatchFieldBase	(	const mappedPatchBase &	mapper,
		const fvPatchField< Type > &	patchField,
		const word &	fieldName,
		const bool	setAverage,
		const Type	average,
		const word &	interpolationScheme
	)

Definition at line 314 of file mappedPatchFieldBase.C.

◆ mappedPatchFieldBase() [2/6]

mappedPatchFieldBase	(	const mappedPatchBase &	mapper,
		const fvPatchField< Type > &	patchField,
		const dictionary &	dict
	)

Definition at line 334 of file mappedPatchFieldBase.C.

◆ mappedPatchFieldBase() [3/6]

mappedPatchFieldBase	(	const mappedPatchBase &	mapper,
		const fvPatchField< Type > &	patchField,
		const dictionary &	dict,
		const Field< Type > &	fld
	)

Definition at line 390 of file mappedPatchFieldBase.C.

◆ mappedPatchFieldBase() [4/6]

mappedPatchFieldBase	(	const mappedPatchBase &	mapper,
		const fvPatchField< Type > &	patchField
	)

Definition at line 428 of file mappedPatchFieldBase.C.

◆ mappedPatchFieldBase() [5/6]

mappedPatchFieldBase ( const mappedPatchFieldBase< Type > & mapper )

explicit

Definition at line 444 of file mappedPatchFieldBase.C.

◆ mappedPatchFieldBase() [6/6]

mappedPatchFieldBase	(	const mappedPatchBase &	mapper,
		const fvPatchField< Type > &	patchField,
		const mappedPatchFieldBase< Type > &	base
	)

Definition at line 459 of file mappedPatchFieldBase.C.

◆ ~mappedPatchFieldBase()

virtual ~mappedPatchFieldBase ( )

virtualdefault

Member Function Documentation

◆ initRetrieveField() [1/2]

void initRetrieveField	(	const objectRegistry &	obr,
		const word &	region,
		const word &	patch,
		const labelListList &	map,
		const word &	fieldName,
		const Field< T > &	fld
	)		const

protected

Definition at line 194 of file mappedPatchFieldBase.C.

◆ storeAndRetrieveField()

bool storeAndRetrieveField	(	const word &	fieldName,
		const label	myComm,
		const labelListList &	subMap,
		const label	constructSize,
		const labelListList &	constructMap,
		const labelListList &	address,
		const scalarListList &	weights,
		Field< T > &	fld
	)		const

protected

Definition at line 245 of file mappedPatchFieldBase.C.

◆ initRetrieveField() [2/2]

void initRetrieveField	(	const word &	fieldName,
		const Field< T > &	fld
	)		const

protected

Definition at line 974 of file mappedPatchFieldBase.C.

◆ storeField()

void storeField	(	const objectRegistry &	obr,
		const word &	region,
		const word &	patch,
		const label	myComm,
		const labelListList &	procToMap,
		const word &	fieldName,
		const Field< T > &	fld
	)		const

protected

Definition at line 47 of file mappedPatchFieldBase.C.

◆ retrieveField()

bool retrieveField	(	const bool	allowUnset,
		const objectRegistry &	obr,
		const word &	region,
		const word &	patch,
		const label	myComm,
		const labelListList &	procToMap,
		const word &	fieldName,
		Field< T > &	fld
	)		const

protected

Definition at line 98 of file mappedPatchFieldBase.C.

◆ sampleField() [1/3]

const GeometricField<T, fvPatchField, volMesh>& sampleField ( const word & fieldName ) const

◆ sampleField() [2/3]

const Foam::GeometricField< Type, Foam::fvPatchField, Foam::volMesh > & sampleField

Definition at line 508 of file mappedPatchFieldBase.C.

◆ mappedField()

Foam::tmp< Foam::Field< Type > > mappedField

virtual

Definition at line 607 of file mappedPatchFieldBase.C.

◆ mappedInternalField()

Foam::tmp< Foam::Field< Type > > mappedInternalField

virtual

Definition at line 816 of file mappedPatchFieldBase.C.

◆ mappedWeightField() [1/2]

Foam::tmp< Foam::scalarField > mappedWeightField

virtual

Definition at line 852 of file mappedPatchFieldBase.C.

◆ mappedWeightField() [2/2]

void mappedWeightField	(	const word &	weightFieldName,
		tmp< scalarField > &	thisWeights,
		tmp< scalarField > &	nbrWeights
	)		const

virtual

Definition at line 890 of file mappedPatchFieldBase.C.

◆ write()

void write ( Ostream & os ) const

virtual

Reimplemented in turbulentTemperatureRadCoupledMixedFvPatchScalarField, turbulentTemperatureCoupledBaffleMixedFvPatchScalarField, mappedFixedInternalValueFvPatchField< Type >, thermalBaffleFvPatchScalarField, mappedFieldFvPatchField< Type >, mappedMixedFieldFvPatchField< Type >, mappedMixedFvPatchField< Type >, mappedFixedValueFvPatchField< Type >, and mappedFixedPushedInternalValueFvPatchField< Type >.

Definition at line 1000 of file mappedPatchFieldBase.C.

Referenced by turbulentTemperatureCoupledBaffleMixedFvPatchScalarField::write(), and turbulentTemperatureRadCoupledMixedFvPatchScalarField::write().

Here is the caller graph for this function:

◆ mapper()

const Foam::mappedPatchBase & mapper	(	const fvPatch &	p,
		const DimensionedField< Type, volMesh > &	iF
	)

static

Definition at line 952 of file mappedPatchFieldBase.C.

Referenced by turbulentTemperatureCoupledBaffleMixedFvPatchScalarField::updateCoeffs(), and turbulentTemperatureRadCoupledMixedFvPatchScalarField::updateCoeffs().

Here is the caller graph for this function:

◆ distribute()

void distribute	(	const word &	fieldName,
		Field< T > &	newValues
	)		const

Definition at line 517 of file mappedPatchFieldBase.C.

◆ sampleField() [3/3]

const Foam::GeometricField<Type2, Foam::fvPatchField, Foam::volMesh>& sampleField ( const word & fieldName ) const

Definition at line 479 of file mappedPatchFieldBase.C.

Member Data Documentation

◆ mapper_

const mappedPatchBase& mapper_

protected

Definition at line 114 of file mappedPatchFieldBase.H.

◆ patchField_

const fvPatchField<Type>& patchField_

protected

Definition at line 117 of file mappedPatchFieldBase.H.

◆ fieldName_

word fieldName_

protected

Definition at line 120 of file mappedPatchFieldBase.H.

◆ setAverage_

const bool setAverage_

protected

Definition at line 123 of file mappedPatchFieldBase.H.

◆ average_

const Type average_

protected

Definition at line 127 of file mappedPatchFieldBase.H.

◆ interpolationScheme_

word interpolationScheme_

protected

Definition at line 130 of file mappedPatchFieldBase.H.

The documentation for this class was generated from the following files:

src/finiteVolume/fields/fvPatchFields/derived/mappedField/mappedPatchFieldBase.H
src/finiteVolume/fields/fvPatchFields/derived/mappedField/mappedPatchFieldBase.C
