Determines a mapping between patch face centres and mesh cell or face centres and processors they're on. More...

Inheritance diagram for mappedPatchBase:

[legend]

Collaboration diagram for mappedPatchBase:

[legend]

Classes
class	maxProcEqOp

class	nearestEqOp

class	nearestWorldEqOp

Public Types
enum	sampleMode { NEARESTCELL, NEARESTPATCHFACE, NEARESTPATCHFACEAMI, NEARESTPATCHPOINT, NEARESTFACE, NEARESTONLYCELL }

enum	offsetMode { UNIFORM, NONUNIFORM, NORMAL }

typedef Tuple2< pointIndexHit, Tuple2< scalar, label > >	nearInfo

typedef Tuple2< nearInfo, label >	nearInfoWorld

Public Member Functions
	TypeName ("mappedPatchBase")

	mappedPatchBase (const polyPatch &)

	mappedPatchBase (const polyPatch &pp, const word &sampleRegion, const sampleMode sampleMode, const word &samplePatch, const vectorField &offsets)

	mappedPatchBase (const polyPatch &pp, const word &sampleRegion, const sampleMode sampleMode, const word &samplePatch, const vector &uniformOffset)

	mappedPatchBase (const polyPatch &pp, const word &sampleRegion, const sampleMode sampleMode, const word &samplePatch, const scalar normalDistance)

	mappedPatchBase (const polyPatch &, const dictionary &)

	mappedPatchBase (const polyPatch &, const sampleMode, const dictionary &)

	mappedPatchBase (const polyPatch &, const mappedPatchBase &)

	mappedPatchBase (const polyPatch &, const mappedPatchBase &, const labelUList &mapAddressing)

virtual	~mappedPatchBase ()

void	clearOut ()

void	setOffset (const scalar normalDist)

void	setOffset (const vector &uniformOffset)

void	setOffset (const vectorField &offsets)

sampleMode	mode () const noexcept

const word &	sampleWorld () const noexcept

const word &	sampleRegion () const

const word &	samplePatch () const

const word &	coupleGroup () const

label	sampleSize () const

const vector &	offset () const noexcept

const vectorField &	offsets () const noexcept

label	getCommunicator () const

label	comm () const

bool	sameWorld () const

bool	masterWorld () const

bool	sameRegion () const noexcept

const mapDistribute &	map () const

const AMIPatchToPatchInterpolation &	AMI (const bool forceUpdate=false) const

bool	owner () const

const autoPtr< Foam::searchableSurface > &	surfPtr () const

const polyMesh &	sampleMesh () const

const polyPatch &	samplePolyPatch () const

tmp< pointField >	samplePoints () const

const fileName &	sampleDatabasePath () const

bool	sampleDatabase () const

virtual fileName	sendPath (const label proci) const

virtual fileName	receivePath (const label proci) const

template<class Type >
void	distribute (List< Type > &lst) const

template<class Type , class CombineOp >
void	distribute (List< Type > &lst, const CombineOp &cop) const

template<class Type >
void	reverseDistribute (List< Type > &lst) const

template<class Type , class CombineOp >
void	reverseDistribute (List< Type > &lst, const CombineOp &cop) const

virtual void	write (Ostream &os) const

Static Public Member Functions
static pointIndexHit	facePoint (const polyMesh &, const label facei, const polyMesh::cellDecomposition)

static fileName	sendPath (const fileName &root, const label proci)

static fileName	receivePath (const fileName &root, const label proci)

static const objectRegistry &	subRegistry (const objectRegistry &obr, const fileName &path)

template<class Type >
static void	storeField (objectRegistry &obr, const word &fieldName, const Field< Type > &values)

static void	writeDict (const objectRegistry &obr, dictionary &dict)

static void	readDict (const dictionary &d, objectRegistry &obr)

Static Public Attributes
static const Enum< sampleMode >	sampleModeNames_

static const Enum< offsetMode >	offsetModeNames_

Protected Member Functions
bool	addWorldConnection ()

label	getWorldCommunicator () const

const polyMesh &	lookupMesh (const word &region) const

const polyPatch &	lookupPatch (const word &sampleRegion, const word &samplePatch) const

tmp< pointField >	facePoints (const polyPatch &) const

void	collectSamples (const label mySampleWorld, const pointField &facePoints, pointField &samples, labelList &patchFaceWorlds, labelList &patchFaceProcs, labelList &patchFaces, pointField &patchFc) const

void	findLocalSamples (const sampleMode mode, const label sampleWorld, const word &sampleRegion, const word &samplePatch, const pointField &samplePoints, List< nearInfoWorld > &nearest) const

void	findSamples (const sampleMode mode, const label myWorldIndex, const pointField &, const labelList &wantedWorlds, const labelList &origProcs, labelList &sampleProcs, labelList &sampleIndices, pointField &sampleLocations) const

tmp< pointField >	samplePoints (const pointField &) const

void	calcMapping () const

void	calcAMI () const

Static Protected Member Functions
static autoPtr< fileName >	readDatabase (const dictionary &dict)

static const objectRegistry &	subRegistry (const objectRegistry &obr, const wordList &names, const label index)

template<class Type >
static bool	writeIOField (const regIOobject &obj, dictionary &dict)

template<class Type >
static bool	constructIOField (const word &name, token &tok, Istream &is, objectRegistry &obr)

Protected Attributes
const polyPatch &	patch_

word	sampleWorld_

word	sampleRegion_

const sampleMode	mode_

word	samplePatch_

const coupleGroupIdentifier	coupleGroup_

const autoPtr< fileName >	sampleDatabasePtr_

offsetMode	offsetMode_

vector	offset_

vectorField	offsets_

scalar	distance_

label	communicator_

bool	sameRegion_

autoPtr< mapDistribute >	mapPtr_

const bool	AMIReverse_

autoPtr< AMIPatchToPatchInterpolation >	AMIPtr_

autoPtr< searchableSurface >	surfPtr_

dictionary	surfDict_

Detailed Description

Determines a mapping between patch face centres and mesh cell or face centres and processors they're on.

If constructed from dictionary:

    // Optional world to sample (default is all)
    //sampleWorld solidSim;

    // Optional explicit coupling (requires functionObject to synchronise
    // databases. Default is close coupling (bc to bc)
    //sampleDatabase true;

    // Region to sample (default is region0)
    sampleRegion region0;

    // What to sample:
    // - nearestCell         : sample cell containing point
    // - nearestOnlyCell     : nearest sample cell (even if not containing
    //                         point)
    // - nearestPatchFace    : nearest face on selected patch
    // - nearestPatchFaceAMI : nearest face on selected patch
                               - patches need not conform
                               - uses AMI interpolation
    // - nearestFace         : nearest boundary face on any patch
    // - nearestPatchPoint   : nearest patch point (for coupled points
    //                         this might be any of the points so you have
    //                         to guarantee the point data is synchronised
    //                         beforehand)
    sampleMode nearestCell;

    // If sampleMode is nearestPatchFace : patch to find faces of
    samplePatch movingWall;

    // If sampleMode is nearestPatchFace : specify patchgroup to find
    // samplePatch and sampleRegion (if not provided)
    coupleGroup baffleGroup;

    // How to supply offset (w.r.t. my patch face centres):
    // - uniform : single offset vector
    // - nonuniform : per-face offset vector
    // - normal : using supplied distance and face normal
    offsetMode uniform;

    // According to offsetMode (see above) supply one of
    // offset, offsets or distance
    offset  (1 0 0);

Note: if offsetMode is normal it uses outwards pointing normals. So supply a negative distance if sampling inside the domain.

Note: Storage is not optimal. It temporary collects all (patch)face centres on all processors to keep the addressing calculation simple.

Source files

Definition at line 108 of file mappedPatchBase.H.

Member Typedef Documentation

◆ nearInfo

typedef Tuple2<pointIndexHit, Tuple2<scalar, label> > nearInfo

Definition at line 143 of file mappedPatchBase.H.

◆ nearInfoWorld

typedef Tuple2<nearInfo, label> nearInfoWorld

Definition at line 188 of file mappedPatchBase.H.

Member Enumeration Documentation

◆ sampleMode

enum sampleMode

Enumerator
NEARESTCELL	nearest cell containing sample
NEARESTPATCHFACE	nearest face on selected patch
NEARESTPATCHFACEAMI	nearest patch face + AMI interpolation
NEARESTPATCHPOINT	nearest point on selected patch
NEARESTFACE	nearest face
NEARESTONLYCELL	nearest cell (even if not containing cell)

Definition at line 115 of file mappedPatchBase.H.

◆ offsetMode

enum offsetMode

Enumerator
UNIFORM	single offset vector
NONUNIFORM	per-face offset vector
NORMAL	use face normal + distance

Definition at line 126 of file mappedPatchBase.H.

Constructor & Destructor Documentation

◆ mappedPatchBase() [1/8]

mappedPatchBase ( const polyPatch & pp )

explicit

Definition at line 1208 of file mappedPatchBase.C.

◆ mappedPatchBase() [2/8]

mappedPatchBase	(	const polyPatch &	pp,
		const word &	sampleRegion,
		const sampleMode	sampleMode,
		const word &	samplePatch,
		const vectorField &	offsets
	)

Definition at line 1234 of file mappedPatchBase.C.

References mappedPatchBase::setOffset().

Here is the call graph for this function:

◆ mappedPatchBase() [3/8]

mappedPatchBase	(	const polyPatch &	pp,
		const word &	sampleRegion,
		const sampleMode	sampleMode,
		const word &	samplePatch,
		const vector &	uniformOffset
	)

Definition at line 1256 of file mappedPatchBase.C.

References mappedPatchBase::setOffset().

Here is the call graph for this function:

◆ mappedPatchBase() [4/8]

mappedPatchBase	(	const polyPatch &	pp,
		const word &	sampleRegion,
		const sampleMode	sampleMode,
		const word &	samplePatch,
		const scalar	normalDistance
	)

Definition at line 1278 of file mappedPatchBase.C.

◆ mappedPatchBase() [5/8]

mappedPatchBase	(	const polyPatch &	pp,
		const dictionary &	dict
	)

Definition at line 1314 of file mappedPatchBase.C.

References dict, Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, dictionary::found(), dictionary::readEntry(), and dictionary::readIfPresent().

Here is the call graph for this function:

◆ mappedPatchBase() [6/8]

mappedPatchBase	(	const polyPatch &	pp,
		const sampleMode	mode,
		const dictionary &	dict
	)

Definition at line 1416 of file mappedPatchBase.C.

References dict, Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, and Foam::mode().

Here is the call graph for this function:

◆ mappedPatchBase() [7/8]

mappedPatchBase	(	const polyPatch &	pp,
		const mappedPatchBase &	mpb
	)

Definition at line 1489 of file mappedPatchBase.C.

◆ mappedPatchBase() [8/8]

mappedPatchBase	(	const polyPatch &	pp,
		const mappedPatchBase &	mpb,
		const labelUList &	mapAddressing
	)

Definition at line 1521 of file mappedPatchBase.C.

◆ ~mappedPatchBase()

~mappedPatchBase ( )

virtual

Definition at line 1560 of file mappedPatchBase.C.

Member Function Documentation

◆ addWorldConnection()

bool addWorldConnection ( )

protected

Definition at line 116 of file mappedPatchBase.C.

References polyPatch::boundaryMesh(), polyBoundaryMesh::mesh(), multiWorldConnections::New(), mappedPatchBase::patch_, runTime, mappedPatchBase::sameWorld(), mappedPatchBase::sampleWorld_, and objectRegistry::time().

Here is the call graph for this function:

◆ getWorldCommunicator()

Foam::label getWorldCommunicator ( ) const

protected

Definition at line 131 of file mappedPatchBase.C.

References multiWorldConnections::getCommByName(), multiWorldConnections::New(), runTime, objectRegistry::time(), and UPstream::worldComm.

Here is the call graph for this function:

◆ lookupMesh()

const Foam::polyMesh & lookupMesh ( const word & region ) const

protected

Definition at line 1607 of file mappedPatchBase.C.

References polyMesh::boundaryMesh(), objectRegistry::lookupObject(), polyBoundaryMesh::mesh(), IOobject::name(), and objectRegistry::time().

Here is the call graph for this function:

◆ lookupPatch()

const Foam::polyPatch & lookupPatch	(	const word &	sampleRegion,
		const word &	samplePatch
	)		const

protected

Definition at line 1622 of file mappedPatchBase.C.

References polyMesh::boundaryMesh(), Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, and polyBoundaryMesh::findPatchID().

Referenced by mappedPolyPatch::nbrCells(), mappedWallPolyPatch::nbrCells(), mappedPolyPatch::neighbPolyPatchID(), mappedWallPolyPatch::neighbPolyPatchID(), mappedPolyPatch::newInternalProcFaces(), and mappedWallPolyPatch::newInternalProcFaces().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ facePoints()

Foam::tmp< Foam::pointField > facePoints ( const polyPatch & pp ) const

protected

Definition at line 145 of file mappedPatchBase.C.

References polyPatch::boundaryMesh(), polyMesh::FACE_DIAG_TRIS, Foam::facePoint(), forAll, mesh, polyBoundaryMesh::mesh(), tmp::New(), polyPatch::start(), and polyMesh::tetBasePtIs().

Here is the call graph for this function:

◆ collectSamples()

void collectSamples	(	const label	mySampleWorld,
		const pointField &	facePoints,
		pointField &	samples,
		labelList &	patchFaceWorlds,
		labelList &	patchFaceProcs,
		labelList &	patchFaces,
		pointField &	patchFc
	)		const

protected

Definition at line 173 of file mappedPatchBase.C.

References Foam::expressions::patchExpr::debug, DebugInFunction, Foam::endl(), forAll, Pstream::gatherList(), Foam::identity(), UPstream::msgType(), UPstream::myProcNo(), OSstream::name(), Foam::nl, UPstream::nProcs(), Foam::Perr, samples(), Pstream::scatterList(), List::setSize(), and UPstream::warnComm.

Here is the call graph for this function:

◆ findLocalSamples()

void findLocalSamples	(	const sampleMode	mode,
		const label	sampleWorld,
		const word &	sampleRegion,
		const word &	samplePatch,
		const pointField &	samplePoints,
		List< nearInfoWorld > &	nearest
	)		const

protected

Definition at line 273 of file mappedPatchBase.C.

References Foam::abort(), primitiveMesh::cellCentres(), polyMesh::cellTree(), DebugInFunction, Foam::constant::electromagnetic::e, Foam::exit(), treeBoundBox::extend(), primitiveMesh::faceCentres(), Foam::FatalError, FatalErrorInFunction, indexedOctree::findInside(), meshSearch::findNearestFace(), Tuple2::first(), forAll, Foam::identity(), Foam::magSqr(), boundBox::max(), mesh, PrimitivePatch< FaceList, PointField >::meshPoints(), boundBox::min(), Foam::mode(), UPstream::myProcNo(), MeshObject< polyMesh, GeometricMeshObject, meshSearchMeshObject >::New(), Foam::nl, PrimitivePatch< FaceList, PointField >::points(), polyMesh::points(), polyPatch::range(), rndGen, samples(), Tuple2::second(), List::setSize(), boundBox::span(), Foam::sqr(), and VectorSpace< Vector< scalar >, scalar, 3 >::uniform().

Here is the call graph for this function:

◆ findSamples()

void findSamples	(	const sampleMode	mode,
		const label	myWorldIndex,
		const pointField &	samples,
		const labelList &	wantedWorlds,
		const labelList &	origProcs,
		labelList &	sampleProcs,
		labelList &	sampleIndices,
		pointField &	sampleLocations
	)		const

protected

Definition at line 580 of file mappedPatchBase.C.

References DynamicList::append(), Foam::expressions::patchExpr::debug, DebugInFunction, Foam::endl(), Tuple2::first(), forAll, Pstream::gatherList(), Pstream::listCombineGather(), Pstream::listCombineScatter(), VectorSpace< Vector< scalar >, scalar, 3 >::max, Foam::mode(), UPstream::msgType(), UPstream::myProcNo(), Foam::nl, UPstream::nProcs(), Foam::Pout, samples(), Pstream::scatterList(), Tuple2::second(), List::setSize(), Foam::sqr(), and UPstream::warnComm.

Here is the call graph for this function:

◆ samplePoints() [1/2]

Foam::tmp< Foam::pointField > samplePoints ( const pointField & fc ) const

protected

Definition at line 1675 of file mappedPatchBase.C.

References fld, Foam::mag(), n, and tmp::New().

Here is the call graph for this function:

◆ calcMapping()

void calcMapping ( ) const

protected

Definition at line 728 of file mappedPatchBase.C.

References Foam::abort(), UPstream::allWorlds(), DynamicList::append(), Foam::expressions::patchExpr::debug, DebugInFunction, Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, forAll, Foam::gAverage(), Foam::mag(), UPstream::master(), UPstream::msgType(), UPstream::myWorld(), UPstream::myWorldID(), OFstream::name(), IOstream::name(), Foam::nl, Foam::Pout, Foam::reduce(), samples(), HashSet::set(), HashSet::test(), Foam::type(), Foam::HashSetOps::used(), WarningInFunction, and Foam::meshTools::writeOBJ().

Here is the call graph for this function:

◆ calcAMI()

void calcAMI ( ) const

protected

Definition at line 1086 of file mappedPatchBase.C.

References Foam::expressions::patchExpr::debug, DebugInFunction, Foam::endl(), PrimitivePatch< FaceList, PointField >::localFaces(), PrimitivePatch< FaceList, PointField >::localPoints(), Foam::nl, os(), UPstream::warnComm, UPstream::worldComm, and Foam::meshTools::writeOBJ().

Here is the call graph for this function:

◆ readDatabase()

Foam::autoPtr< Foam::fileName > readDatabase ( const dictionary & dict )

staticprotected

Definition at line 83 of file mappedPatchBase.C.

References dict, and autoPtr::set().

Here is the call graph for this function:

◆ subRegistry() [1/2]

const Foam::objectRegistry & subRegistry	(	const objectRegistry &	obr,
		const wordList &	names,
		const label	index
	)

staticprotected

Definition at line 1188 of file mappedPatchBase.C.

References Foam::PtrListOps::names(), and objectRegistry::subRegistry().

Referenced by syncObjects::sync().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ writeIOField()

bool writeIOField	(	const regIOobject &	obj,
		dictionary &	dict
	)

staticprotected

Definition at line 218 of file mappedPatchBaseTemplates.C.

References dict, fld, and dictionary::set().

Here is the call graph for this function:

◆ constructIOField()

bool constructIOField	(	const word &	name,
		token &	tok,
		Istream &	is,
		objectRegistry &	obr
	)

staticprotected

Definition at line 253 of file mappedPatchBaseTemplates.C.

References token::compoundToken(), Foam::dynamicCast(), objectRegistry::findObject(), token::isCompound(), Foam::name(), IOobject::NO_READ, IOobject::NO_WRITE, regIOobject::store(), and token::transferCompoundToken().

Here is the call graph for this function:

◆ TypeName()

TypeName ( "mappedPatchBase" )

◆ clearOut()

void clearOut ( )

Definition at line 1566 of file mappedPatchBase.C.

Referenced by thermalBaffle1DFvPatchScalarField< solidType >::autoMap(), mappedPolyPatch::calcGeometry(), mappedWallPolyPatch::calcGeometry(), mappedWallPolyPatch::movePoints(), mappedPolyPatch::movePoints(), mappedWallPolyPatch::updateMesh(), mappedPolyPatch::updateMesh(), mappedPolyPatch::~mappedPolyPatch(), and mappedWallPolyPatch::~mappedWallPolyPatch().

Here is the caller graph for this function:

◆ setOffset() [1/3]

void setOffset ( const scalar normalDist )

Definition at line 1576 of file mappedPatchBase.C.

References Foam::Zero.

Referenced by mappedPatchBase::mappedPatchBase().

Here is the caller graph for this function:

◆ setOffset() [2/3]

void setOffset ( const vector & uniformOffset )

Definition at line 1586 of file mappedPatchBase.C.

References Foam::Zero.

◆ setOffset() [3/3]

void setOffset ( const vectorField & offsets )

Definition at line 1596 of file mappedPatchBase.C.

References Foam::Zero.

◆ mode()

Foam::mappedPatchBase::sampleMode mode ( ) const

inlinenoexcept

Definition at line 23 of file mappedPatchBaseI.H.

References mappedPatchBase::mode_.

Referenced by mappedVelocityFluxFixedValueFvPatchField::mappedVelocityFluxFixedValueFvPatchField(), mappedVelocityFluxFixedValueFvPatchField::updateCoeffs(), and mappedFixedInternalValueFvPatchField< Type >::updateCoeffs().

Here is the caller graph for this function:

◆ sampleWorld()

const Foam::word & sampleWorld ( ) const

inlinenoexcept

Definition at line 29 of file mappedPatchBaseI.H.

◆ sampleRegion()

const Foam::word & sampleRegion ( ) const

inline

Definition at line 35 of file mappedPatchBaseI.H.

References Foam::exit(), Foam::FatalError, and FatalErrorInFunction.

Referenced by turbulentTemperatureCoupledBaffleMixedFvPatchScalarField::updateCoeffs(), and turbulentTemperatureRadCoupledMixedFvPatchScalarField::updateCoeffs().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ samplePatch()

const Foam::word & samplePatch ( ) const

inline

Definition at line 61 of file mappedPatchBaseI.H.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, and Foam::nl.

Referenced by regionModel::nbrCoupledPatchID(), mappedVelocityFluxFixedValueFvPatchField::updateCoeffs(), turbulentTemperatureCoupledBaffleMixedFvPatchScalarField::updateCoeffs(), and turbulentTemperatureRadCoupledMixedFvPatchScalarField::updateCoeffs().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ coupleGroup()

const Foam::word & coupleGroup ( ) const

inline

Definition at line 87 of file mappedPatchBaseI.H.

◆ sampleSize()

Foam::label sampleSize ( ) const

inline

Definition at line 93 of file mappedPatchBaseI.H.

References Foam::abort(), Foam::FatalError, FatalErrorInFunction, mesh, and primitiveMesh::nBoundaryFaces().

Here is the call graph for this function:

◆ offset()

const Foam::vector & offset ( ) const

inlinenoexcept

Definition at line 128 of file mappedPatchBaseI.H.

◆ offsets()

const Foam::vectorField & offsets ( ) const

inlinenoexcept

Definition at line 134 of file mappedPatchBaseI.H.

◆ getCommunicator()

Foam::label getCommunicator ( ) const

inline

Definition at line 140 of file mappedPatchBaseI.H.

Referenced by mappedPatchBase::distribute().

Here is the caller graph for this function:

◆ comm()

Foam::label comm ( ) const

inline

Definition at line 151 of file mappedPatchBaseI.H.

◆ sameWorld()

bool sameWorld ( ) const

inline

Definition at line 162 of file mappedPatchBaseI.H.

References UPstream::allWorlds(), and UPstream::myWorld().

Referenced by mappedPatchBase::addWorldConnection(), mappedPatchBase::distribute(), turbulentTemperatureCoupledBaffleMixedFvPatchScalarField::updateCoeffs(), and turbulentTemperatureRadCoupledMixedFvPatchScalarField::updateCoeffs().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ masterWorld()

bool masterWorld ( ) const

inline

Definition at line 173 of file mappedPatchBaseI.H.

References UPstream::allWorlds(), and UPstream::myWorldID().

Referenced by mappedPatchBase::distribute().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ sameRegion()

bool sameRegion ( ) const

inlinenoexcept

Definition at line 186 of file mappedPatchBaseI.H.

◆ map()

const Foam::mapDistribute & map ( ) const

inline

Definition at line 192 of file mappedPatchBaseI.H.

References polyMesh::boundaryMesh(), polyBoundaryMesh::mesh(), and polyMesh::topoChanging().

Referenced by mappedPatchBase::distribute(), mappedPolyPatch::mapCollocatedFaces(), mappedWallPolyPatch::mapCollocatedFaces(), semiPermeableBaffleMassFractionFvPatchScalarField::phiY(), and thermalBaffle1DFvPatchScalarField< solidType >::updateCoeffs().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ AMI()

const Foam::AMIPatchToPatchInterpolation & AMI ( const bool forceUpdate = false ) const

inline

Definition at line 214 of file mappedPatchBaseI.H.

References polyMesh::boundaryMesh(), polyBoundaryMesh::mesh(), and polyMesh::topoChanging().

Referenced by mappedPatchBase::distribute().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ owner()

bool owner ( ) const

inline

Definition at line 234 of file mappedPatchBaseI.H.

Referenced by mappedPolyPatch::masterImplicit(), and mappedWallPolyPatch::masterImplicit().

Here is the caller graph for this function:

◆ surfPtr()

const Foam::autoPtr< Foam::searchableSurface > & surfPtr ( ) const

Definition at line 1054 of file mappedPatchBase.C.

References polyMesh::boundaryMesh(), TimePaths::constant(), mesh, polyBoundaryMesh::mesh(), IOobject::MUST_READ, searchableSurface::New(), IOobject::NO_WRITE, and fvMesh::time().

Here is the call graph for this function:

◆ sampleMesh()

const Foam::polyMesh & sampleMesh ( ) const

Definition at line 1642 of file mappedPatchBase.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, and UPstream::myWorld().

Referenced by mappedVelocityFluxFixedValueFvPatchField::updateCoeffs(), mappedFixedInternalValueFvPatchField< Type >::updateCoeffs(), mappedFlowRateFvPatchVectorField::updateCoeffs(), filmPyrolysisRadiativeCoupledMixedFvPatchScalarField::updateCoeffs(), turbulentTemperatureCoupledBaffleMixedFvPatchScalarField::updateCoeffs(), turbulentTemperatureRadCoupledMixedFvPatchScalarField::updateCoeffs(), and humidityTemperatureCoupledMixedFvPatchScalarField::updateCoeffs().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ samplePolyPatch()

const Foam::polyPatch & samplePolyPatch ( ) const

Definition at line 1655 of file mappedPatchBase.C.

References polyMesh::boundaryMesh(), Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, polyBoundaryMesh::findPatchID(), and polyBoundaryMesh::names().

Referenced by semiPermeableBaffleMassFractionFvPatchScalarField::phiY(), mappedFixedInternalValueFvPatchField< Type >::updateCoeffs(), mappedFlowRateFvPatchVectorField::updateCoeffs(), filmPyrolysisRadiativeCoupledMixedFvPatchScalarField::updateCoeffs(), turbulentTemperatureCoupledBaffleMixedFvPatchScalarField::updateCoeffs(), turbulentTemperatureRadCoupledMixedFvPatchScalarField::updateCoeffs(), and humidityTemperatureCoupledMixedFvPatchScalarField::updateCoeffs().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ samplePoints() [2/2]

Foam::tmp< Foam::pointField > samplePoints ( ) const

Definition at line 1709 of file mappedPatchBase.C.

◆ facePoint()

Foam::pointIndexHit facePoint	(	const polyMesh &	mesh,
		const label	facei,
		const polyMesh::cellDecomposition	decompMode
	)

static

Definition at line 1716 of file mappedPatchBase.C.

References Foam::abort(), polyMesh::CELL_TETS, primitiveMesh::cellCentres(), PointHit< PointType >::distance(), f(), polyMesh::FACE_CENTRE_TRIS, polyMesh::FACE_DIAG_TRIS, polyMesh::FACE_PLANES, primitiveMesh::faceCentres(), polyMesh::faceOwner(), polyMesh::faces(), Foam::FatalError, FatalErrorInFunction, intersection::HALF_RAY, PointHit< PointType >::hit(), PointHit< PointType >::hitPoint(), triangle::intersection(), mesh, p, polyMesh::points(), and polyMesh::tetBasePtIs().

Referenced by nearWallFields::calcAddressing().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ sampleDatabasePath()

const fileName& sampleDatabasePath ( ) const

inline

Definition at line 556 of file mappedPatchBase.H.

References mappedPatchBase::sampleDatabasePtr_.

◆ sampleDatabase()

bool sampleDatabase ( ) const

inline

Definition at line 561 of file mappedPatchBase.H.

References bool, and mappedPatchBase::sampleDatabasePtr_.

◆ sendPath() [1/2]

Foam::fileName sendPath	(	const fileName &	root,
		const label	proci
	)

static

Definition at line 1821 of file mappedPatchBase.C.

References Foam::name().

Referenced by syncObjects::sync().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ sendPath() [2/2]

Foam::fileName sendPath ( const label proci ) const

virtual

Definition at line 1831 of file mappedPatchBase.C.

◆ receivePath() [1/2]

Foam::fileName receivePath	(	const fileName &	root,
		const label	proci
	)

static

Definition at line 1838 of file mappedPatchBase.C.

References Foam::name().

Referenced by syncObjects::sync().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ receivePath() [2/2]

Foam::fileName receivePath ( const label proci ) const

virtual

Definition at line 1848 of file mappedPatchBase.C.

◆ subRegistry() [2/2]

const Foam::objectRegistry & subRegistry	(	const objectRegistry &	obr,
		const fileName &	path
	)

static

Definition at line 1797 of file mappedPatchBase.C.

References fileName::clean(), fileName::components(), Foam::PtrListOps::names(), and path().

Here is the call graph for this function:

◆ storeField()

void storeField	(	objectRegistry &	obr,
		const word &	fieldName,
		const Field< Type > &	values
	)

static

Definition at line 308 of file mappedPatchBaseTemplates.C.

References objectRegistry::findObject(), IOobject::NO_READ, IOobject::NO_WRITE, regIOobject::store(), and Foam::HashTableOps::values().

Here is the call graph for this function:

◆ writeDict()

void writeDict	(	const objectRegistry &	obr,
		dictionary &	dict
	)

static

Definition at line 1855 of file mappedPatchBase.C.

References dictionary::add(), dict, forAllIters, IOobject::name(), os(), dictionary::subDictOrAdd(), and regIOobject::writeData().

Referenced by syncObjects::sync().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ readDict()

void readDict	(	const dictionary &	d,
		objectRegistry &	obr
	)

static

Definition at line 1894 of file mappedPatchBase.C.

References Foam::constant::electromagnetic::e, Foam::exit(), Foam::FatalError, FatalErrorInFunction, and objectRegistry::subRegistry().

Referenced by syncObjects::sync().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ distribute() [1/2]

void distribute ( List< Type > & lst ) const

Definition at line 23 of file mappedPatchBaseTemplates.C.

References mappedPatchBase::AMI(), mapDistribute::distribute(), mappedPatchBase::getCommunicator(), AMIInterpolation::interpolateToSource(), AMIInterpolation::interpolateToTarget(), mappedPatchBase::map(), mappedPatchBase::masterWorld(), mappedPatchBase::mode_, mappedPatchBase::NEARESTPATCHFACEAMI, mappedPatchBase::sameWorld(), UPstream::warnComm, and UPstream::worldComm.

Referenced by solidAbsorption::a(), solidAbsorption::e(), regionModel::toRegion(), mappedVelocityFluxFixedValueFvPatchField::updateCoeffs(), mappedFixedInternalValueFvPatchField< Type >::updateCoeffs(), mappedFlowRateFvPatchVectorField::updateCoeffs(), filmPyrolysisRadiativeCoupledMixedFvPatchScalarField::updateCoeffs(), turbulentTemperatureRadCoupledMixedFvPatchScalarField::updateCoeffs(), and humidityTemperatureCoupledMixedFvPatchScalarField::updateCoeffs().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ distribute() [2/2]

void distribute	(	List< Type > &	lst,
		const CombineOp &	cop
	)		const

Definition at line 96 of file mappedPatchBaseTemplates.C.

References UPstream::defaultCommsType, mapDistributeBase::distribute(), UPstream::msgType(), UPstream::warnComm, UPstream::worldComm, and Foam::Zero.

Here is the call graph for this function:

◆ reverseDistribute() [1/2]

void reverseDistribute ( List< Type > & lst ) const

Definition at line 141 of file mappedPatchBaseTemplates.C.

References UPstream::warnComm, and UPstream::worldComm.

Referenced by regionModel::toPrimary().

Here is the caller graph for this function:

◆ reverseDistribute() [2/2]

void reverseDistribute	(	List< Type > &	lst,
		const CombineOp &	cop
	)		const

Definition at line 170 of file mappedPatchBaseTemplates.C.

References UPstream::defaultCommsType, mapDistributeBase::distribute(), UPstream::msgType(), UPstream::warnComm, UPstream::worldComm, and Foam::Zero.

Here is the call graph for this function:

◆ write()

void write ( Ostream & os ) const

virtual

Reimplemented in mappedWallPolyPatch, mappedPolyPatch, thermalBaffle1DFvPatchScalarField< solidType >, mappedFieldFvPatchField< Type >, mappedMixedFieldFvPatchField< Type >, mappedVariableThicknessWallPolyPatch, and semiPermeableBaffleMassFractionFvPatchScalarField.

Definition at line 1935 of file mappedPatchBase.C.

References Switch::name(), word::null, fileName::null, os(), Ostream::write(), Ostream::writeEntry(), Ostream::writeEntryIfDifferent(), and VectorSpace< Vector< scalar >, scalar, 3 >::zero.

Referenced by semiPermeableBaffleMassFractionFvPatchScalarField::write(), thermalBaffle1DFvPatchScalarField< solidType >::write(), mappedPolyPatch::write(), and mappedWallPolyPatch::write().

Here is the call graph for this function:

Here is the caller graph for this function:

Member Data Documentation

◆ sampleModeNames_

const Foam::Enum< Foam::mappedPatchBase::sampleMode > sampleModeNames_

static

Definition at line 133 of file mappedPatchBase.H.

◆ offsetModeNames_

const Foam::Enum< Foam::mappedPatchBase::offsetMode > offsetModeNames_

static

Definition at line 135 of file mappedPatchBase.H.

◆ patch_

const polyPatch& patch_

protected

Definition at line 222 of file mappedPatchBase.H.

Referenced by mappedPatchBase::addWorldConnection(), mappedPolyPatch::mapCollocatedFaces(), mappedWallPolyPatch::mapCollocatedFaces(), mappedPolyPatch::newInternalProcFaces(), and mappedWallPolyPatch::newInternalProcFaces().

◆ sampleWorld_

word sampleWorld_

mutableprotected

Definition at line 225 of file mappedPatchBase.H.

Referenced by mappedPatchBase::addWorldConnection().

◆ sampleRegion_

word sampleRegion_

mutableprotected

Definition at line 228 of file mappedPatchBase.H.

Referenced by mappedPolyPatch::nbrCells(), mappedWallPolyPatch::nbrCells(), mappedPolyPatch::neighbPolyPatchID(), mappedWallPolyPatch::neighbPolyPatchID(), mappedPolyPatch::neighbRegionID(), mappedWallPolyPatch::neighbRegionID(), mappedPolyPatch::newInternalProcFaces(), and mappedWallPolyPatch::newInternalProcFaces().

◆ mode_

const sampleMode mode_

protected

Definition at line 231 of file mappedPatchBase.H.

Referenced by mappedPatchBase::distribute(), and mappedPatchBase::mode().

◆ samplePatch_

word samplePatch_

mutableprotected

Definition at line 234 of file mappedPatchBase.H.

Referenced by mappedPolyPatch::nbrCells(), mappedWallPolyPatch::nbrCells(), mappedPolyPatch::neighbPolyPatchID(), mappedWallPolyPatch::neighbPolyPatchID(), mappedPolyPatch::newInternalProcFaces(), and mappedWallPolyPatch::newInternalProcFaces().

◆ coupleGroup_

const coupleGroupIdentifier coupleGroup_

protected

Definition at line 237 of file mappedPatchBase.H.

◆ sampleDatabasePtr_

const autoPtr<fileName> sampleDatabasePtr_

protected

Definition at line 240 of file mappedPatchBase.H.

Referenced by mappedPatchBase::sampleDatabase(), and mappedPatchBase::sampleDatabasePath().

◆ offsetMode_

offsetMode offsetMode_

protected

Definition at line 243 of file mappedPatchBase.H.

◆ offset_

vector offset_

protected

Definition at line 246 of file mappedPatchBase.H.

◆ offsets_

vectorField offsets_

protected

Definition at line 249 of file mappedPatchBase.H.

◆ distance_

scalar distance_

protected

Definition at line 252 of file mappedPatchBase.H.

◆ communicator_

label communicator_

protected

Definition at line 255 of file mappedPatchBase.H.

◆ sameRegion_

bool sameRegion_

mutableprotected

Definition at line 258 of file mappedPatchBase.H.

◆ mapPtr_

autoPtr<mapDistribute> mapPtr_

mutableprotected

Definition at line 268 of file mappedPatchBase.H.

◆ AMIReverse_

const bool AMIReverse_

protected

Definition at line 274 of file mappedPatchBase.H.

◆ AMIPtr_

autoPtr<AMIPatchToPatchInterpolation> AMIPtr_

mutableprotected

Definition at line 277 of file mappedPatchBase.H.

◆ surfPtr_

autoPtr<searchableSurface> surfPtr_

mutableprotected

Definition at line 280 of file mappedPatchBase.H.

◆ surfDict_

dictionary surfDict_

protected

Definition at line 283 of file mappedPatchBase.H.

The documentation for this class was generated from the following files:

src/meshTools/mappedPatches/mappedPolyPatch/mappedPatchBase.H
src/meshTools/mappedPatches/mappedPolyPatch/mappedPatchBase.C
src/meshTools/mappedPatches/mappedPolyPatch/mappedPatchBaseI.H
src/meshTools/mappedPatches/mappedPolyPatch/mappedPatchBaseTemplates.C

Classes

Public Types

Public Member Functions

Static Public Member Functions

Static Public Attributes

Protected Member Functions

Static Protected Member Functions

Protected Attributes

Detailed Description

Member Typedef Documentation

◆ nearInfo

◆ nearInfoWorld

Member Enumeration Documentation

◆ sampleMode

◆ offsetMode

Constructor & Destructor Documentation

◆ mappedPatchBase() [1/8]

◆ mappedPatchBase() [2/8]

◆ mappedPatchBase() [3/8]

◆ mappedPatchBase() [4/8]

◆ mappedPatchBase() [5/8]

◆ mappedPatchBase() [6/8]

◆ mappedPatchBase() [7/8]

◆ mappedPatchBase() [8/8]

◆ ~mappedPatchBase()

Member Function Documentation

◆ addWorldConnection()

◆ getWorldCommunicator()

◆ lookupMesh()

◆ lookupPatch()

◆ facePoints()

◆ collectSamples()

◆ findLocalSamples()

◆ findSamples()

◆ samplePoints() [1/2]

◆ calcMapping()

◆ calcAMI()

◆ readDatabase()

◆ subRegistry() [1/2]

◆ writeIOField()

◆ constructIOField()

◆ TypeName()

◆ clearOut()

◆ setOffset() [1/3]

◆ setOffset() [2/3]

◆ setOffset() [3/3]

◆ mode()

◆ sampleWorld()

◆ sampleRegion()

◆ samplePatch()

◆ coupleGroup()

◆ sampleSize()

◆ offset()

◆ offsets()

◆ getCommunicator()

◆ comm()

◆ sameWorld()

◆ masterWorld()

◆ sameRegion()

◆ map()

◆ AMI()

◆ owner()

◆ surfPtr()

◆ sampleMesh()

◆ samplePolyPatch()

◆ samplePoints() [2/2]

◆ facePoint()

◆ sampleDatabasePath()

◆ sampleDatabase()

◆ sendPath() [1/2]

◆ sendPath() [2/2]

◆ receivePath() [1/2]

◆ receivePath() [2/2]

◆ subRegistry() [2/2]

◆ storeField()

◆ writeDict()

◆ readDict()

◆ distribute() [1/2]

◆ distribute() [2/2]

◆ reverseDistribute() [1/2]
