Class containing mesh-to-mesh mapping information after a mesh distribution where we send parts of meshes (using subsetting) to other processors and receive and reconstruct mesh. More...

Inheritance diagram for mapDistributePolyMesh:

[legend]

Public Member Functions
	mapDistributePolyMesh ()

	mapDistributePolyMesh (mapDistributePolyMesh &&map)

	mapDistributePolyMesh (const polyMesh &mesh, const label nOldPoints, const label nOldFaces, const label nOldCells, labelList &&oldPatchStarts, labelList &&oldPatchNMeshPoints, labelListList &&subPointMap, labelListList &&subFaceMap, labelListList &&subCellMap, labelListList &&subPatchMap, labelListList &&constructPointMap, labelListList &&constructFaceMap, labelListList &&constructCellMap, labelListList &&constructPatchMap, const bool subFaceHasFlip=false, const bool constructFaceHasFlip=false)

	mapDistributePolyMesh (const label nOldPoints, const label nOldFaces, const label nOldCells, labelList &&oldPatchStarts, labelList &&oldPatchNMeshPoints, mapDistribute &&pointMap, mapDistribute &&faceMap, mapDistribute &&cellMap, mapDistribute &&patchMap)

	mapDistributePolyMesh (Istream &is)

label	nOldPoints () const

label	nOldFaces () const

label	nOldCells () const

const labelList &	oldPatchSizes () const

const labelList &	oldPatchStarts () const

const labelList &	oldPatchNMeshPoints () const

const mapDistribute &	pointMap () const

const mapDistribute &	faceMap () const

const mapDistribute &	cellMap () const

const mapDistribute &	patchMap () const

void	transfer (mapDistributePolyMesh &map)

template<class T >
void	distributePointData (List< T > &lst) const

template<class T >
void	distributeFaceData (List< T > &lst) const

template<class T >
void	distributeCellData (List< T > &lst) const

template<class T >
void	distributePatchData (List< T > &lst) const

void	distributePointIndices (labelList &pointIDs) const

void	distributeFaceIndices (labelList &faceIDs) const

void	distributeCellIndices (labelList &cellIDs) const

void	distributePatchIndices (labelList &patchIDs) const

void	updateMesh (const mapPolyMesh &)

void	operator= (const mapDistributePolyMesh &map)

void	operator= (mapDistributePolyMesh &&map)

Friends
Istream &	operator>> (Istream &, mapDistributePolyMesh &)

Ostream &	operator<< (Ostream &, const mapDistributePolyMesh &)

Detailed Description

Class containing mesh-to-mesh mapping information after a mesh distribution where we send parts of meshes (using subsetting) to other processors and receive and reconstruct mesh.

We store mapping from the bits-to-send to the complete starting mesh (subXXXMap) and from the received bits to their location in the new mesh (constructXXXMap).

Source files

Definition at line 62 of file mapDistributePolyMesh.H.

Constructor & Destructor Documentation

◆ mapDistributePolyMesh() [1/5]

mapDistributePolyMesh ( )

Definition at line 57 of file mapDistributePolyMesh.C.

◆ mapDistributePolyMesh() [2/5]

mapDistributePolyMesh ( mapDistributePolyMesh && map )

Definition at line 73 of file mapDistributePolyMesh.C.

◆ mapDistributePolyMesh() [3/5]

mapDistributePolyMesh	(	const polyMesh &	mesh,
		const label	nOldPoints,
		const label	nOldFaces,
		const label	nOldCells,
		labelList &&	oldPatchStarts,
		labelList &&	oldPatchNMeshPoints,
		labelListList &&	subPointMap,
		labelListList &&	subFaceMap,
		labelListList &&	subCellMap,
		labelListList &&	subPatchMap,
		labelListList &&	constructPointMap,
		labelListList &&	constructFaceMap,
		labelListList &&	constructCellMap,
		labelListList &&	constructPatchMap,
		const bool	subFaceHasFlip = `false`,
		const bool	constructFaceHasFlip = `false`
	)

Definition at line 84 of file mapDistributePolyMesh.C.

◆ mapDistributePolyMesh() [4/5]

mapDistributePolyMesh	(	const label	nOldPoints,
		const label	nOldFaces,
		const label	nOldCells,
		labelList &&	oldPatchStarts,
		labelList &&	oldPatchNMeshPoints,
		mapDistribute &&	pointMap,
		mapDistribute &&	faceMap,
		mapDistribute &&	cellMap,
		mapDistribute &&	patchMap
	)
