Class containing processor-to-processor mapping information. More...

Inheritance diagram for mapDistribute:

Collaboration diagram for mapDistribute:

Classes
class	transform

class	transformPosition

Public Member Functions
	ClassName ("mapDistribute")

	mapDistribute (const label comm=UPstream::worldComm)

	mapDistribute (const mapDistribute &map)

	mapDistribute (mapDistribute &&map)

	mapDistribute (const label constructSize, labelListList &&subMap, labelListList &&constructMap, const bool subHasFlip=false, const bool constructHasFlip=false, const label comm=UPstream::worldComm)

	mapDistribute (const label constructSize, labelListList &&subMap, labelListList &&constructMap, labelListList &&transformElements, labelList &&transformStart, const bool subHasFlip=false, const bool constructHasFlip=false, const label comm=UPstream::worldComm)

	mapDistribute (const labelUList &sendProcs, const labelUList &recvProcs, const label comm=UPstream::worldComm)

	mapDistribute (const globalIndex &, labelList &elements, List< Map< label >> &compactMap, const int tag=Pstream::msgType(), const label comm=UPstream::worldComm)

	mapDistribute (const globalIndex &, labelListList &cellCells, List< Map< label >> &compactMap, const int tag=Pstream::msgType(), const label comm=UPstream::worldComm)

	mapDistribute (const globalIndex &, labelList &untransformedElements, const globalIndexAndTransform &, const labelPairList &transformedElements, labelList &transformedIndices, List< Map< label >> &compactMap, const int tag=Pstream::msgType(), const label comm=UPstream::worldComm)

	mapDistribute (const globalIndex &, labelListList &cellCells, const globalIndexAndTransform &, const List< labelPairList > &transformedElements, labelListList &transformedIndices, List< Map< label >> &compactMap, const int tag=Pstream::msgType(), const label comm=UPstream::worldComm)

	mapDistribute (labelListList &&subMap, const bool subHasFlip=false, const bool constructHasFlip=false, const label comm=UPstream::worldComm)

	mapDistribute (Istream &is)

autoPtr< mapDistribute >	clone () const

virtual	~mapDistribute ()=default

const labelListList &	transformElements () const

const labelList &	transformStart () const

label	whichTransform (const label index) const

void	transfer (mapDistribute &map)

template<class T >
void	distribute (List< T > &fld, const bool dummyTransform=true, const int tag=UPstream::msgType()) const

template<class T , class negateOp >
void	distribute (List< T > &fld, const negateOp &negOp, const bool dummyTransform=true, const int tag=UPstream::msgType()) const

template<class T >
void	distribute (DynamicList< T > &fld, const bool dummyTransform=true, const int tag=UPstream::msgType()) const

template<class T >
void	reverseDistribute (const label constructSize, List< T > &, const bool dummyTransform=true, const int tag=UPstream::msgType()) const

template<class T >
void	reverseDistribute (const label constructSize, const T &nullValue, List< T > &fld, const bool dummyTransform=true, const int tag=UPstream::msgType()) const

template<class T , class TransformOp >
void	distribute (const globalIndexAndTransform &, List< T > &fld, const TransformOp &top, const int tag=UPstream::msgType()) const

template<class T , class TransformOp >
void	reverseDistribute (const globalIndexAndTransform &, const label constructSize, List< T > &fld, const TransformOp &top, const int tag=UPstream::msgType()) const

template<class T , class TransformOp >
void	reverseDistribute (const globalIndexAndTransform &, const label constructSize, const T &nullValue, List< T > &fld, const TransformOp &top, const int tag=UPstream::msgType()) const

void	printLayout (Ostream &os) const

void	updateMesh (const mapPolyMesh &)

void	operator= (const mapDistribute &rhs)

void	operator= (mapDistribute &&rhs)

Public Member Functions inherited from mapDistributeBase
	ClassName ("mapDistributeBase")

	mapDistributeBase (const label comm=UPstream::worldComm)

	mapDistributeBase (const mapDistributeBase &map)

	mapDistributeBase (mapDistributeBase &&map)

	mapDistributeBase (const label constructSize, labelListList &&subMap, labelListList &&constructMap, const bool subHasFlip=false, const bool constructHasFlip=false, const label comm=UPstream::worldComm)

	mapDistributeBase (const labelUList &sendProcs, const labelUList &recvProcs, const label comm=UPstream::worldComm)

	mapDistributeBase (const globalIndex &, labelList &elements, List< Map< label >> &compactMap, const int tag=Pstream::msgType(), const label comm=UPstream::worldComm)

	mapDistributeBase (const globalIndex &, labelListList &cellCells, List< Map< label >> &compactMap, const int tag=Pstream::msgType(), const label comm=UPstream::worldComm)

	mapDistributeBase (labelListList &&subMap, const bool subHasFlip=false, const bool constructHasFlip=false, const label comm=UPstream::worldComm)

	mapDistributeBase (Istream &is)

label	constructSize () const

label &	constructSize ()

const labelListList &	subMap () const

labelListList &	subMap ()

const labelListList &	constructMap () const

labelListList &	constructMap ()

bool	subHasFlip () const

bool &	subHasFlip ()

bool	constructHasFlip () const

bool &	constructHasFlip ()

label	comm () const

const List< labelPair > &	schedule () const

void	transfer (mapDistributeBase &rhs)

void	compact (const boolList &elemIsUsed, const int tag=UPstream::msgType())

void	compact (const boolList &elemIsUsed, const label localSize, labelList &oldToNewSub, labelList &oldToNewConstruct, const int tag=UPstream::msgType())

template<class T >
void	distribute (List< T > &fld, const int tag=UPstream::msgType()) const

template<class T , class negateOp >
void	distribute (List< T > &fld, const negateOp &negOp, const int tag=UPstream::msgType()) const

template<class T >
void	distribute (DynamicList< T > &fld, const int tag=UPstream::msgType()) const

template<class T >
void	reverseDistribute (const label constructSize, List< T > &, const int tag=UPstream::msgType()) const

template<class T >
void	reverseDistribute (const label constructSize, const T &nullValue, List< T > &fld, const int tag=UPstream::msgType()) const

template<class T >
void	send (PstreamBuffers &, const List< T > &) const

template<class T >
void	receive (PstreamBuffers &, List< T > &) const

void	printLayout (Ostream &os) const

void	updateMesh (const mapPolyMesh &)

void	operator= (const mapDistributeBase &rhs)

void	operator= (mapDistributeBase &&rhs)

Friends
Istream &	operator>> (Istream &, mapDistribute &)

Ostream &	operator<< (Ostream &, const mapDistribute &)

Additional Inherited Members
Static Public Member Functions inherited from mapDistributeBase
static List< labelPair >	schedule (const labelListList &subMap, const labelListList &constructMap, const int tag, const label comm=UPstream::worldComm)

static label	renumber (const globalIndex &, const List< Map< label >> &compactMap, const label globalElement)

template<class T , class negateOp >
static void	distribute (const Pstream::commsTypes commsType, const List< labelPair > &schedule, const label constructSize, const labelListList &subMap, const bool subHasFlip, const labelListList &constructMap, const bool constructHasFlip, List< T > &, const negateOp &negOp, const int tag=UPstream::msgType(), const label comm=UPstream::worldComm)

template<class T , class CombineOp , class negateOp >
static void	distribute (const Pstream::commsTypes commsType, const List< labelPair > &schedule, const label constructSize, const labelListList &subMap, const bool subHasFlip, const labelListList &constructMap, const bool constructHasFlip, List< T > &, const T &nullValue, const CombineOp &cop, const negateOp &negOp, const int tag=UPstream::msgType(), const label comm=UPstream::worldComm)

Protected Member Functions inherited from mapDistributeBase
void	calcCompactAddressing (const globalIndex &globalNumbering, const labelUList &elements, List< Map< label >> &compactMap) const

void	calcCompactAddressing (const globalIndex &globalNumbering, const labelListList &elements, List< Map< label >> &compactMap) const

void	exchangeAddressing (const int tag, const globalIndex &globalNumbering, labelList &elements, List< Map< label >> &compactMap, labelList &compactStart)

void	exchangeAddressing (const int tag, const globalIndex &globalNumbering, labelListList &elements, List< Map< label >> &compactMap, labelList &compactStart)

Static Protected Member Functions inherited from mapDistributeBase
static void	checkReceivedSize (const label proci, const label expectedSize, const label receivedSize)

template<class T , class CombineOp , class negateOp >
static void	flipAndCombine (const labelUList &map, const bool hasFlip, const UList< T > &rhs, const CombineOp &cop, const negateOp &negOp, List< T > &lhs)

template<class T , class negateOp >
static T	accessAndFlip (const UList< T > &fld, const label index, const bool hasFlip, const negateOp &negOp)

Protected Attributes inherited from mapDistributeBase
label	constructSize_

labelListList	subMap_

labelListList	constructMap_

bool	subHasFlip_

bool	constructHasFlip_

label	comm_

autoPtr< List< labelPair > >	schedulePtr_

Detailed Description

Class containing processor-to-processor mapping information.

We store mapping from the bits-to-send to the complete starting list (subXXXMap) and from the received bits to their location in the new list (constructXXXMap).

Note: Schedule is a list of processor pairs (one send, one receive. One of them will be myself) which forms a scheduled (i.e. non-buffered) exchange. See distribute on how to use it. Note2: number of items sent on one processor have to equal the number of items received on the other processor.

To aid constructing these maps there are the constructors from global numbering, either with or without transforms.

without transforms: Constructors using compact numbering: layout is
all my own elements first (whether used or not)
followed by used-only remote elements sorted by remote processor. So e.g 4 procs and on proc 1 the compact table will first have all globalIndex.localSize() elements from proc1 followed by used-only elements of proc0, proc2, proc3. The constructed mapDistribute sends the local elements from and receives the remote elements into their compact position. compactMap[proci] is the position of elements from proci in the compact map. compactMap[myProcNo()] is empty since trivial addressing.

It rewrites the input global indices into indices into the constructed data.

with transforms: This requires the precalculated set of possible transforms (globalIndexAndTransform). These are given as permutations (+, -, or none) of up to 3 independent transforms. The layout of the data is
all my own elements first (whether used or not)
followed by used-only remote elements sorted by remote processor.
followed by - for each transformation index - the set of local or remote elements with that transformation. The inputs for the constructor are
the set of untransformed local or remote indices in globalIndex numbering. These get rewritten to be indices into the layout of the data.
the set of transformed local or remote indices in globalIndexAndTransform encoding. These are labelPairs.

Any distribute with transforms is now done as: 1. exchange data with other processors and receive these into the slots for that processor 2. for all transformations transform a subset of the data according to transformElements_[transformI] and store this starting from transformStart_[transformI]

In the same way a reverse distribute will 1. apply the inverse transform to the data starting at transformStart_[transformI] and copy the result back into the transformElements_[transformI]. These might be local or remote slots. 2. the data in the remote slots will now be sent back to the correct location in the originating processor.

E.g. a map to handle

mesh points on a mesh with
1 cyclic so 3 permutations (+,-,none) will have layout
on e.g. processor 1 out of 2:

+——+ <- transformStart[2] | | | | <- transform2 applied to data in local or remote slots | | +——+ <- transformStart[1] | | | | <- transform1 applied to data in local or remote slots | | +——+ <- transformStart[1] | | | | <- transform0 applied to data in local or remote slots | | +——+ <- transformStart[0] | | | | <- data from proc2 | | +——+ | | | | <- data from proc0 | | +——+ <- mesh.nPoints() | | | | | | +——+ 0

When constructing from components optionally a 'flip' on the maps can be specified. This will interpret the map values as index+flip, similar to e.g. faceProcAddressing. The flip will only be applied to fieldTypes (scalar, vector, .. triad)

Source files

Definition at line 159 of file mapDistribute.H.

Constructor & Destructor Documentation

◆ mapDistribute() [1/12]

mapDistribute ( const label comm = UPstream::worldComm )

Definition at line 144 of file mapDistribute.C.

◆ mapDistribute() [2/12]

mapDistribute ( const mapDistribute & map )

explicit

Definition at line 150 of file mapDistribute.C.

◆ mapDistribute() [3/12]

mapDistribute ( mapDistribute && map )

explicit

Definition at line 158 of file mapDistribute.C.

References mapDistribute::transfer().

Here is the call graph for this function:

◆ mapDistribute() [4/12]

mapDistribute	(	const label	constructSize,
		labelListList &&	subMap,
		labelListList &&	constructMap,
		const bool	subHasFlip = `false`,
		const bool	constructHasFlip = `false`,
		const label	comm = `UPstream::worldComm`
	)

Definition at line 167 of file mapDistribute.C.

◆ mapDistribute() [5/12]

mapDistribute	(	const label	constructSize,
		labelListList &&	subMap,
		labelListList &&	constructMap,
		labelListList &&	transformElements,
		labelList &&	transformStart,
		const bool	subHasFlip = `false`,
		const bool	constructHasFlip = `false`,
		const label	comm = `UPstream::worldComm`
	)

Definition at line 189 of file mapDistribute.C.

◆ mapDistribute() [6/12]

mapDistribute	(	const labelUList &	sendProcs,
		const labelUList &	recvProcs,
		const label	comm = `UPstream::worldComm`
	)

Definition at line 215 of file mapDistribute.C.

◆ mapDistribute() [7/12]

mapDistribute	(	const globalIndex &	globalNumbering,
		labelList &	elements,
		List< Map< label >> &	compactMap,
		const int	tag = `Pstream::msgType()`,
		const label	comm = `UPstream::worldComm`
	)

Definition at line 226 of file mapDistribute.C.

◆ mapDistribute() [8/12]

mapDistribute	(	const globalIndex &	globalNumbering,
		labelListList &	cellCells,
		List< Map< label >> &	compactMap,
		const int	tag = `Pstream::msgType()`,
		const label	comm = `UPstream::worldComm`
	)

Definition at line 246 of file mapDistribute.C.

◆ mapDistribute() [9/12]

mapDistribute	(	const globalIndex &	globalNumbering,
		labelList &	untransformedElements,
		const globalIndexAndTransform &	globalTransforms,
		const labelPairList &	transformedElements,
		labelList &	transformedIndices,
		List< Map< label >> &	compactMap,
		const int	tag = `Pstream::msgType()`,
		const label	comm = `UPstream::worldComm`
	)

Definition at line 266 of file mapDistribute.C.

References Foam::expressions::patchExpr::debug, forAll, globalIndexAndTransform::index(), UPstream::myProcNo(), n, Foam::Pout, globalIndexAndTransform::processor(), List::setSize(), globalIndexAndTransform::transformIndex(), globalIndexAndTransform::transformPermutations(), and Foam::Zero.

Here is the call graph for this function:

◆ mapDistribute() [10/12]

mapDistribute	(	const globalIndex &	globalNumbering,
		labelListList &	cellCells,
		const globalIndexAndTransform &	globalTransforms,
		const List< labelPairList > &	transformedElements,
		labelListList &	transformedIndices,
		List< Map< label >> &	compactMap,
		const int	tag = `Pstream::msgType()`,
		const label	comm = `UPstream::worldComm`
	)

Definition at line 374 of file mapDistribute.C.

References Foam::expressions::patchExpr::debug, forAll, globalIndexAndTransform::index(), UPstream::myProcNo(), n, Foam::Pout, globalIndexAndTransform::processor(), List::setSize(), globalIndexAndTransform::transformIndex(), globalIndexAndTransform::transformPermutations(), and Foam::Zero.

Here is the call graph for this function:

◆ mapDistribute() [11/12]

mapDistribute	(	labelListList &&	subMap,
		const bool	subHasFlip = `false`,
		const bool	constructHasFlip = `false`,
		const label	comm = `UPstream::worldComm`
	)

explicit

Definition at line 495 of file mapDistribute.C.

◆ mapDistribute() [12/12]

mapDistribute ( Istream & is )

explicit

Definition at line 506 of file mapDistribute.C.

◆ ~mapDistribute()

virtual ~mapDistribute ( )

virtualdefault

Member Function Documentation

◆ ClassName()

ClassName ( "mapDistribute" )

◆ clone()

Foam::autoPtr< Foam::mapDistribute > clone ( ) const

Definition at line 512 of file mapDistribute.C.

References autoPtr::New().

Here is the call graph for this function:

◆ transformElements()

const labelListList& transformElements ( ) const

inline

Definition at line 455 of file mapDistribute.H.

◆ transformStart()

const labelList& transformStart ( ) const

inline

Definition at line 461 of file mapDistribute.H.

◆ whichTransform()

Foam::label whichTransform ( const label index ) const

Definition at line 520 of file mapDistribute.C.

References Foam::findLower().

Here is the call graph for this function:

◆ transfer()

void transfer ( mapDistribute & map )

Definition at line 526 of file mapDistribute.C.

References mapDistributeBase::transfer().

Referenced by IOmapDistribute::IOmapDistribute(), and mapDistribute::mapDistribute().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ distribute() [1/4]

void distribute	(	List< T > &	fld,
		const bool	dummyTransform = `true`,
		const int	tag = `UPstream::msgType()`
	)		const

Definition at line 147 of file mapDistributeTemplates.C.

References fld.

Referenced by AMIInterpolation::agglomerate(), extendedFaceToCellStencil::collectData(), extendedCellToFaceStencil::collectData(), hexRef8Data::distribute(), mappedPatchBase::distribute(), mapDistributePolyMesh::distributeCellData(), mapDistributePolyMesh::distributeFaceData(), mapDistributeLagrangian::distributeLagrangianData(), mapDistributePolyMesh::distributePatchData(), mapDistributePolyMesh::distributePointData(), cellVolumeWeight::findHoles(), inverseDistance::findHoles(), distributedTriSurfaceMesh::findNearest(), distributedTriSurfaceMesh::getVolumeType(), globalIndexAndTransform::globalIndexAndTransform(), AMIInterpolation::interpolateToSource(), AMIInterpolation::interpolateToTarget(), distributedTriSurfaceMesh::localQueries(), meshToMesh::mapSrcToTgt(), meshToMesh::mapTgtToSrc(), globalMeshData::mergePoints(), semiPermeableBaffleMassFractionFvPatchScalarField::phiY(), PatchTools::pointNormals(), sampledPatchInternalField::sampleOnPoints(), globalMeshData::syncData(), pointConstraints::syncUntransformedData(), thermalBaffle1DFvPatchScalarField< solidType >::updateCoeffs(), Sampled< Type >::value(), and dynamicOversetFvMesh::writeObject().

Here is the caller graph for this function:

◆ distribute() [2/4]

void distribute	(	List< T > &	fld,
		const negateOp &	negOp,
		const bool	dummyTransform = `true`,
		const int	tag = `UPstream::msgType()`
	)		const

Definition at line 125 of file mapDistributeTemplates.C.

References mapDistributeBase::distribute(), and fld.

Here is the call graph for this function:

◆ distribute() [3/4]

void distribute	(	DynamicList< T > &	fld,
		const bool	dummyTransform = `true`,
		const int	tag = `UPstream::msgType()`
	)		const

Definition at line 159 of file mapDistributeTemplates.C.

References fld.

◆ reverseDistribute() [1/4]

void reverseDistribute	(	const label	constructSize,
		List< T > &	fld,
		const bool	dummyTransform = `true`,
		const int	tag = `UPstream::msgType()`
	)		const

Definition at line 177 of file mapDistributeTemplates.C.

References fld, and mapDistributeBase::reverseDistribute().

Referenced by distributedTriSurfaceMesh::findNearest(), distributedTriSurfaceMesh::getField(), distributedTriSurfaceMesh::getNormal(), distributedTriSurfaceMesh::getRegion(), mappedPatchFieldBase< scalar >::mappedField(), globalMeshData::mergePoints(), PatchTools::pointNormals(), sampledPatchInternalField::sampleOnPoints(), globalMeshData::syncData(), pointConstraints::syncUntransformedData(), and Sampled< Type >::value().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ reverseDistribute() [2/4]

void reverseDistribute	(	const label	constructSize,
		const T &	nullValue,
		List< T > &	fld,
		const bool	dummyTransform = `true`,
		const int	tag = `UPstream::msgType()`
	)		const

Definition at line 195 of file mapDistributeTemplates.C.

References fld, and mapDistributeBase::reverseDistribute().

Here is the call graph for this function:

◆ distribute() [4/4]

void distribute	(	const globalIndexAndTransform &	git,
		List< T > &	fld,
		const TransformOp &	top,
		const int	tag = `UPstream::msgType()`
	)		const

Definition at line 214 of file mapDistributeTemplates.C.

References fld.

◆ reverseDistribute() [3/4]

void reverseDistribute	(	const globalIndexAndTransform &	git,
		const label	constructSize,
		List< T > &	fld,
		const TransformOp &	top,
		const int	tag = `UPstream::msgType()`
	)		const

Definition at line 230 of file mapDistributeTemplates.C.

References fld.

◆ reverseDistribute() [4/4]

void reverseDistribute	(	const globalIndexAndTransform &	git,
		const label	constructSize,
		const T &	nullValue,
		List< T > &	fld,
		const TransformOp &	top,
		const int	tag = `UPstream::msgType()`
	)		const

Definition at line 250 of file mapDistributeTemplates.C.

References fld.

◆ printLayout()

void printLayout ( Ostream & os ) const

Definition at line 126 of file mapDistribute.C.

References Foam::endl(), forAll, os(), and mapDistributeBase::printLayout().

Here is the call graph for this function:

◆ updateMesh()

void updateMesh ( const mapPolyMesh & )

inline

Definition at line 564 of file mapDistribute.H.

References NotImplemented.

◆ operator=() [1/2]

void operator= ( const mapDistribute & rhs )

Definition at line 541 of file mapDistribute.C.

References mapDistributeBase::operator=().

Referenced by IOmapDistribute::IOmapDistribute().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ operator=() [2/2]

void operator= ( mapDistribute && rhs )

Definition at line 554 of file mapDistribute.C.

Friends And Related Function Documentation

◆ operator>>

Istream& operator>>	(	Istream &	,
		mapDistribute &
	)

friend

◆ operator<<

Ostream& operator<<	(	Ostream &	,
		const mapDistribute &
	)

friend

The documentation for this class was generated from the following files:

src/OpenFOAM/meshes/polyMesh/mapPolyMesh/mapDistribute/mapDistribute.H
src/OpenFOAM/meshes/polyMesh/mapPolyMesh/mapDistribute/mapDistribute.C
src/OpenFOAM/meshes/polyMesh/mapPolyMesh/mapDistribute/mapDistributeTemplates.C

Classes

Public Member Functions

Friends

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ mapDistribute() [1/12]

◆ mapDistribute() [2/12]

◆ mapDistribute() [3/12]

◆ mapDistribute() [4/12]

◆ mapDistribute() [5/12]

◆ mapDistribute() [6/12]

◆ mapDistribute() [7/12]

◆ mapDistribute() [8/12]

◆ mapDistribute() [9/12]

◆ mapDistribute() [10/12]

◆ mapDistribute() [11/12]

◆ mapDistribute() [12/12]

◆ ~mapDistribute()

Member Function Documentation

◆ ClassName()

◆ clone()

◆ transformElements()

◆ transformStart()

◆ whichTransform()

◆ transfer()

◆ distribute() [1/4]

◆ distribute() [2/4]

◆ distribute() [3/4]

◆ reverseDistribute() [1/4]

◆ reverseDistribute() [2/4]

◆ distribute() [4/4]

◆ reverseDistribute() [3/4]

◆ reverseDistribute() [4/4]

◆ printLayout()

◆ updateMesh()

◆ operator=() [1/2]

◆ operator=() [2/2]

Friends And Related Function Documentation

◆ operator>>

◆ operator<<
