The state of lumped points corresponds to positions and rotations. More...

Collaboration diagram for lumpedPointState:

Public Types
enum	inputFormatType { PLAIN, DICTIONARY }

Public Member Functions
	lumpedPointState ()

	lumpedPointState (const lumpedPointState &rhs)

	lumpedPointState (const pointField &pts, const vectorField &ang, const quaternion::eulerOrder rotOrder=quaternion::eulerOrder::ZXZ, const bool degrees=false)

	lumpedPointState (const pointField &pts, const quaternion::eulerOrder rotOrder=quaternion::eulerOrder::ZXZ, const bool degrees=false)

	lumpedPointState (tmp< pointField > &pts, const quaternion::eulerOrder rotOrder=quaternion::eulerOrder::ZXZ, const bool degrees=false)

	lumpedPointState (const dictionary &dict, const quaternion::eulerOrder rotOrder=quaternion::eulerOrder::ZXZ, const bool degrees=false)

virtual	~lumpedPointState ()=default

bool	valid () const

bool	empty () const

label	size () const

const pointField &	points () const

const vectorField &	angles () const

const tensorField &	rotations () const

void	scalePoints (const scalar scaleFactor)

quaternion::eulerOrder	rotationOrder () const

bool	degrees () const

void	relax (const scalar alpha, const lumpedPointState &prev)

bool	readData (Istream &is, const quaternion::eulerOrder rotOrder=quaternion::eulerOrder::ZXZ, const bool degrees=false)

bool	writeData (Ostream &os) const

void	writeDict (Ostream &os) const

bool	readPlain (Istream &is, const quaternion::eulerOrder rotOrder=quaternion::eulerOrder::ZXZ, const bool degrees=false)

void	writePlain (Ostream &os) const

bool	readData (const inputFormatType fmt, const fileName &file, const quaternion::eulerOrder rotOrder=quaternion::eulerOrder::ZXZ, const bool degrees=false)

void	writeVTP (const fileName &outputFile, const labelListList &lines=labelListList(), const labelList &pointIds=labelList::null()) const

void	operator= (const lumpedPointState &rhs)

void	operator+= (const point &origin)

Static Public Attributes
static const Enum< inputFormatType >	formatNames

static bool	visUnused = true

static scalar	visLength = 0.1

Detailed Description

The state of lumped points corresponds to positions and rotations.

This class encapsulates the response from the external application and serves as the entry point for applying relaxation, sub-stepping etc.

Dictionary input format

Property	Description	Required	Default
`points`	List of points	yes
`angles`	List of Euler rotation angles	yes
`rotationOrder`	The Euler-angle rotation order	no	zxz
`degrees`	Rotation angles in degrees	no	false

Plain input format. Blank and comment lines starting with a '#' character are ignored. The angles are always in radians.

    NumPoints
    x0 y0 z0 eulerz0 eulerx'0 eulerz''0
    x1 y1 z1 eulerz1 eulerx'1 eulerz''1
    ...

See also: Foam::coordinateRotations::euler, Foam::quaternion

Source files

Definition at line 108 of file lumpedPointState.H.

Member Enumeration Documentation

◆ inputFormatType

enum inputFormatType

strong

Enumerator
PLAIN	"plain" is a simple ASCII format
DICTIONARY	"dictionary" is the OpenFOAM dictionary format

Definition at line 115 of file lumpedPointState.H.

Constructor & Destructor Documentation

◆ lumpedPointState() [1/6]

lumpedPointState ( )

Definition at line 108 of file lumpedPointState.C.

◆ lumpedPointState() [2/6]

lumpedPointState ( const lumpedPointState & rhs )

Definition at line 118 of file lumpedPointState.C.

◆ lumpedPointState() [3/6]

lumpedPointState	(	const pointField &	pts,
		const vectorField &	ang,
		const quaternion::eulerOrder	rotOrder = `quaternion::eulerOrder::ZXZ`,
		const bool	degrees = `false`
	)

Definition at line 129 of file lumpedPointState.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::nl, WarningInFunction, and Foam::Zero.

Here is the call graph for this function:

◆ lumpedPointState() [4/6]

lumpedPointState	(	const pointField &	pts,
		const quaternion::eulerOrder	rotOrder = `quaternion::eulerOrder::ZXZ`,
		const bool	degrees = `false`
	)

explicit

Definition at line 161 of file lumpedPointState.C.

◆ lumpedPointState() [5/6]

lumpedPointState	(	tmp< pointField > &	pts,
		const quaternion::eulerOrder	rotOrder = `quaternion::eulerOrder::ZXZ`,
		const bool	degrees = `false`
	)

explicit

Definition at line 176 of file lumpedPointState.C.

◆ lumpedPointState() [6/6]

lumpedPointState	(	const dictionary &	dict,
		const quaternion::eulerOrder	rotOrder = `quaternion::eulerOrder::ZXZ`,
		const bool	degrees = `false`
	)

explicit

Definition at line 191 of file lumpedPointState.C.

References dict.

◆ ~lumpedPointState()

virtual ~lumpedPointState ( )

virtualdefault

Member Function Documentation

◆ valid()

bool valid ( ) const

inline

Definition at line 21 of file lumpedPointStateI.H.

◆ empty()

bool empty ( ) const

inline

Definition at line 27 of file lumpedPointStateI.H.

Referenced by lumpedPointMovement::empty().

Here is the caller graph for this function:

◆ size()

Foam::label size ( ) const

inline

Definition at line 33 of file lumpedPointStateI.H.

Referenced by lumpedPointMovement::writeStateVTP().

Here is the caller graph for this function:

◆ points()

const Foam::pointField & points ( ) const

inline

Definition at line 39 of file lumpedPointStateI.H.

Referenced by lumpedPointMovement::pointsDisplacement(), lumpedPointMovement::pointsPosition(), and lumpedPointMovement::writeForcesAndMomentsVTP().

Here is the caller graph for this function:

◆ angles()

const Foam::vectorField & angles ( ) const

inline

Definition at line 45 of file lumpedPointStateI.H.

◆ rotations()

const Foam::tensorField & rotations ( ) const

inline

Definition at line 51 of file lumpedPointStateI.H.

Referenced by lumpedPointMovement::pointsDisplacement(), and lumpedPointMovement::pointsPosition().

Here is the caller graph for this function:

◆ scalePoints()

void scalePoints ( const scalar scaleFactor )

Definition at line 229 of file lumpedPointState.C.

Referenced by lumpedPointMovement::scalePoints().

Here is the caller graph for this function:

◆ rotationOrder()

Foam::quaternion::eulerOrder rotationOrder ( ) const

inline

Definition at line 63 of file lumpedPointStateI.H.

◆ degrees()

bool degrees ( ) const

inline

Definition at line 69 of file lumpedPointStateI.H.

◆ relax()

void relax	(	const scalar	alpha,
		const lumpedPointState &	prev
	)

Definition at line 239 of file lumpedPointState.C.

References Foam::constant::atomic::alpha, Foam::degToRad(), and Foam::radToDeg().

Here is the call graph for this function:

◆ readData() [1/2]

bool readData	(	Istream &	is,
		const quaternion::eulerOrder	rotOrder = `quaternion::eulerOrder::ZXZ`,
		const bool	degrees = `false`
	)

Definition at line 313 of file lumpedPointState.C.

References dict.

Referenced by lumpedPointMovement::readState().

Here is the caller graph for this function:

◆ writeData()

bool writeData ( Ostream & os ) const

Definition at line 326 of file lumpedPointState.C.

References os().

Here is the call graph for this function:

◆ writeDict()

void writeDict ( Ostream & os ) const

Definition at line 333 of file lumpedPointState.C.

References quaternion::eulerOrderNames, os(), and Ostream::writeEntry().

Here is the call graph for this function:

◆ readPlain()

bool readPlain	(	Istream &	is,
		const quaternion::eulerOrder	rotOrder = `quaternion::eulerOrder::ZXZ`,
		const bool	degrees = `false`
	)

Definition at line 268 of file lumpedPointState.C.

References Foam::BitOps::count(), forAll, and ISstream::getLine().

Here is the call graph for this function:

◆ writePlain()

void writePlain ( Ostream & os ) const

Definition at line 348 of file lumpedPointState.C.

References forAll, os(), and p.

Here is the call graph for this function:

◆ readData() [2/2]

bool readData	(	const inputFormatType	fmt,
		const fileName &	file,
		const quaternion::eulerOrder	rotOrder = `quaternion::eulerOrder::ZXZ`,
		const bool	degrees = `false`
	)

Definition at line 375 of file lumpedPointState.C.

References UPstream::commsStruct::above(), UPstream::commsStruct::below(), forAllReverse, UPstream::linearCommunication(), UPstream::master(), UPstream::msgType(), UPstream::myProcNo(), UPstream::nProcs(), UPstream::nProcsSimpleSum, UPstream::parRun(), Pstream::scatter(), UPstream::scheduled, UPstream::treeCommunication(), and UPstream::worldComm.

Here is the call graph for this function:

◆ writeVTP()

void writeVTP	(	const fileName &	outputFile,
		const labelListList &	lines = `labelListList()`,
		const labelList &	pointIds = `labelList::null()`
	)		const

Definition at line 29 of file lumpedPointStateWriter.C.

References Tensor::cx(), Tensor::cy(), forAll, format(), Foam::vtk::newFormatter(), nPoints, os(), OFstream::stdStream(), Foam::vtk::write(), Foam::vtk::writeIdentity(), and Foam::vtk::writeList().

Referenced by lumpedPointMovement::writeStateVTP().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ operator=()

void operator= ( const lumpedPointState & rhs )

Definition at line 209 of file lumpedPointState.C.

◆ operator+=()

void operator+= ( const point & origin )

Definition at line 220 of file lumpedPointState.C.

References p.

Member Data Documentation

◆ formatNames

const Foam::Enum< Foam::lumpedPointState::inputFormatType > formatNames

static

Definition at line 125 of file lumpedPointState.H.

Referenced by lumpedPointMovement::readDict().

◆ visUnused

bool visUnused = true

static

Definition at line 164 of file lumpedPointState.H.

◆ visLength

Foam::scalar visLength = 0.1

static

Definition at line 167 of file lumpedPointState.H.

The documentation for this class was generated from the following files:

src/lumpedPointMotion/state/lumpedPointState.H
src/lumpedPointMotion/state/lumpedPointState.C
src/lumpedPointMotion/state/lumpedPointStateI.H
src/lumpedPointMotion/state/lumpedPointStateWriter.C
