loopControl Class Reference

A class for managing arbitrary loops with the ability to invoke function object execution. More...

Inheritance diagram for loopControl:

Collaboration diagram for loopControl:

Public Member Functions
	loopControl (Time &runTime, const label nCycles, const word &dictName="loop")
	loopControl (Time &runTime, const word &algorithmName, const word &dictName="loop")
	loopControl (Time &runTime, const dictionary &algorithmDict, const word &dictName="loop")
	~loopControl ()
const word &	name () const
label	interval () const
bool	loop ()
Public Member Functions inherited from subLoopTime
	subLoopTime (Time &runTime, const label nCycles)
	~subLoopTime ()
label	index () const
label	nCycles () const
bool	status () const
void	stop ()
bool	loop ()
subLoopTime &	operator++ ()

Protected Attributes
word	name_
label	interval_
dictionary	convergenceDict_
wordRes	onLoop_
wordRes	onConverged_
wordRes	onEnd_
bool	converged_
Protected Attributes inherited from subLoopTime
Time &	time_
label	index_
label	total_

Detailed Description

A class for managing arbitrary loops with the ability to invoke function object execution.

Usage

Examples of function object specification:

SIMPLE
{
    energyCoupling
    {
        iterations  100;
        onLoop      ();
        onConverged ( externalCoupled  "loopThings.*" );

        convergence
        {
            "h"     1e-3;
        }
    }
}

Where the loop entries comprise:

Property	Description	Required	Default
enabled	activate/deactivate loop	no	true
iteration	times to loop	no	0
timeStart	begin time for loop activation	no	-VGREAT
timeEnd	end time of loop activation	no	VGREAT
interval	sub-interval to execute onLoop	no	0
onLoop	function object names to call at executeInterval	no
onConverged	function object names to call when converged	no
onEnd	function object names to call when loop ends	no
convergence	dictionary of convergence values to check	no

The function object names listed by onLoop, onConverged, onEnd must implement an execute(int) method. If the time controls timeStart or timeEnd are used for the loop, these values are only inspected upon creation, not during execution.

See also

fvSolution

Source files

• loopControl.H
• loopControl.C

Definition at line 136 of file loopControl.H.

Constructor & Destructor Documentation

loopControl() [1/3]

loopControl	(	Time &	runTime,
		const label	nCycles,
		const word &	dictName = "loop"
	)

Definition at line 138 of file loopControl.C.

loopControl() [2/3]

loopControl	(	Time &	runTime,
		const word &	algorithmName,
		const word &	dictName = "loop"
	)

Definition at line 176 of file loopControl.C.

References dictName(), dictionary::findDict(), Foam::read(), and solution::solutionDict().

Here is the call graph for this function:

loopControl() [3/3]

loopControl	(	Time &	runTime,
		const dictionary &	algorithmDict,
		const word &	dictName = "loop"
	)

Definition at line 156 of file loopControl.C.

References dictName(), dictionary::findDict(), and Foam::read().

Here is the call graph for this function:

~loopControl()

~loopControl

(

)

Definition at line 205 of file loopControl.C.

Member Function Documentation

name()

const word& name ( ) const

inline

Definition at line 233 of file loopControl.H.

References loopControl::name_.

Referenced by Foam::operator<<().

Here is the caller graph for this function:

interval()

label interval ( ) const

inline

Definition at line 239 of file loopControl.H.

References loopControl::interval_.

loop()

bool loop

(

)

Definition at line 213 of file loopControl.C.

Member Data Documentation

name_

word name_

protected

Definition at line 163 of file loopControl.H.

Referenced by loopControl::name().

interval_

label interval_

protected

Definition at line 166 of file loopControl.H.

Referenced by loopControl::interval().

convergenceDict_

dictionary convergenceDict_

protected

Definition at line 169 of file loopControl.H.

onLoop_

wordRes onLoop_

protected

Definition at line 172 of file loopControl.H.

onConverged_

wordRes onConverged_

protected

Definition at line 175 of file loopControl.H.

onEnd_

wordRes onEnd_

protected

Definition at line 179 of file loopControl.H.

converged_

bool converged_

protected

Definition at line 182 of file loopControl.H.

---

The documentation for this class was generated from the following files:

• src/finiteVolume/cfdTools/general/solutionControl/loopControl/loopControl.H
• src/finiteVolume/cfdTools/general/solutionControl/loopControl/loopControl.C
