Public Member Functions | Static Public Member Functions | Protected Member Functions | Protected Attributes | Static Protected Attributes | List of all members
lduMatrix::solver Class Referenceabstract
Inheritance diagram for lduMatrix::solver:
Inheritance graph
[legend]
Collaboration diagram for lduMatrix::solver:
Collaboration graph
[legend]

Public Member Functions

virtual const word & type () const =0

 declareRunTimeSelectionTable (autoPtr, solver, symMatrix,(const word &fieldName, const lduMatrix &matrix, const FieldField< Field, scalar > &interfaceBouCoeffs, const FieldField< Field, scalar > &interfaceIntCoeffs, const lduInterfaceFieldPtrsList &interfaces, const dictionary &solverControls),(fieldName, matrix, interfaceBouCoeffs, interfaceIntCoeffs, interfaces, solverControls))

 declareRunTimeSelectionTable (autoPtr, solver, asymMatrix,(const word &fieldName, const lduMatrix &matrix, const FieldField< Field, scalar > &interfaceBouCoeffs, const FieldField< Field, scalar > &interfaceIntCoeffs, const lduInterfaceFieldPtrsList &interfaces, const dictionary &solverControls),(fieldName, matrix, interfaceBouCoeffs, interfaceIntCoeffs, interfaces, solverControls))

 solver (const word &fieldName, const lduMatrix &matrix, const FieldField< Field, scalar > &interfaceBouCoeffs, const FieldField< Field, scalar > &interfaceIntCoeffs, const lduInterfaceFieldPtrsList &interfaces, const dictionary &solverControls)

virtual ~solver ()=default

const word & fieldName () const noexcept

const lduMatrix & matrix () const noexcept

const FieldField< Field, scalar > & interfaceBouCoeffs () const noexcept

const FieldField< Field, scalar > & interfaceIntCoeffs () const noexcept

const lduInterfaceFieldPtrsList & interfaces () const noexcept

virtual void read (const dictionary &)

virtual solverPerformance solve (scalarField &psi, const scalarField &source, const direction cmpt=0) const =0

virtual solverPerformance scalarSolve (solveScalarField &psi, const solveScalarField &source, const direction cmpt=0) const

solveScalarField::cmptType normFactor (const solveScalarField &psi, const solveScalarField &source, const solveScalarField &Apsi, solveScalarField &tmpField) const


Static Public Member Functions

static autoPtr< solver > New (const word &fieldName, const lduMatrix &matrix, const FieldField< Field, scalar > &interfaceBouCoeffs, const FieldField< Field, scalar > &interfaceIntCoeffs, const lduInterfaceFieldPtrsList &interfaces, const dictionary &solverControls)


Protected Member Functions

virtual void readControls ()


Protected Attributes

word fieldName_

const lduMatrix & matrix_

const FieldField< Field, scalar > & interfaceBouCoeffs_

const FieldField< Field, scalar > & interfaceIntCoeffs_

lduInterfaceFieldPtrsList interfaces_

dictionary controlDict_

int log_

label minIter_

label maxIter_

scalar tolerance_

scalar relTol_

profilingTrigger profiling_


Static Protected Attributes

static const label defaultMaxIter_ = 1000


Detailed Description

Definition at line 94 of file lduMatrix.H.

Constructor & Destructor Documentation

◆ solver()

solver ( const word &  fieldName,
const lduMatrix &  matrix,
const FieldField< Field, scalar > &  interfaceBouCoeffs,
const FieldField< Field, scalar > &  interfaceIntCoeffs,
const lduInterfaceFieldPtrsList &  interfaces,
const dictionary &  solverControls
)

Definition at line 133 of file lduMatrixSolver.C.

◆ ~solver()

virtual ~solver ( )
virtualdefault

Member Function Documentation

◆ readControls()

void readControls ( )
protectedvirtual

Reimplemented in smoothSolver, and GAMGPreconditioner.

Definition at line 156 of file lduMatrixSolver.C.

References lduMatrix::solver::controlDict_, lduMatrix::solver::defaultMaxIter_, Foam::constant::electromagnetic::e, dictionary::getOrDefault(), lduMatrix::solver::log_, lduMatrix::solver::maxIter_, lduMatrix::solver::minIter_, lduMatrix::solver::relTol_, and lduMatrix::solver::tolerance_.

Referenced by smoothSolver::readControls().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ type()

virtual const word& type ( ) const
pure virtual

◆ declareRunTimeSelectionTable() [1/2]

declareRunTimeSelectionTable ( autoPtr  ,
solver  ,
symMatrix  ,
(const word &fieldName, const lduMatrix &matrix, const FieldField< Field, scalar > &interfaceBouCoeffs, const FieldField< Field, scalar > &interfaceIntCoeffs, const lduInterfaceFieldPtrsList &interfaces, const dictionary &solverControls)  ,
(fieldName, matrix, interfaceBouCoeffs, interfaceIntCoeffs, interfaces, solverControls)
)

◆ declareRunTimeSelectionTable() [2/2]

declareRunTimeSelectionTable ( autoPtr  ,
solver  ,
asymMatrix  ,
(const word &fieldName, const lduMatrix &matrix, const FieldField< Field, scalar > &interfaceBouCoeffs, const FieldField< Field, scalar > &interfaceIntCoeffs, const lduInterfaceFieldPtrsList &interfaces, const dictionary &solverControls)  ,
(fieldName, matrix, interfaceBouCoeffs, interfaceIntCoeffs, interfaces, solverControls)
)

◆ New()

Foam::autoPtr< Foam::lduMatrix::solver > New ( const word &  fieldName,
const lduMatrix &  matrix,
const FieldField< Field, scalar > &  interfaceBouCoeffs,
const FieldField< Field, scalar > &  interfaceIntCoeffs,
const lduInterfaceFieldPtrsList &  interfaces,
const dictionary &  solverControls
)
static

Definition at line 38 of file lduMatrixSolver.C.

References lduMatrix::asymmetric(), lduMatrix::diagonal(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, FatalIOErrorInLookup, dictionary::get(), Foam::name(), and lduMatrix::symmetric().

Here is the call graph for this function:

◆ fieldName()

const word& fieldName ( ) const
inlinenoexcept

Definition at line 224 of file lduMatrix.H.

References lduMatrix::solver::fieldName_.

◆ matrix()

const lduMatrix& matrix ( ) const
inlinenoexcept

Definition at line 229 of file lduMatrix.H.

References lduMatrix::solver::matrix_.

Referenced by DICPreconditioner::DICPreconditioner(), DILUPreconditioner::DILUPreconditioner(), FDICPreconditioner::FDICPreconditioner(), and lduMatrix::preconditioner::New().

Here is the caller graph for this function:

◆ interfaceBouCoeffs()

const FieldField<Field, scalar>& interfaceBouCoeffs ( ) const
inlinenoexcept

Definition at line 234 of file lduMatrix.H.

References lduMatrix::solver::interfaceBouCoeffs_.

◆ interfaceIntCoeffs()

const FieldField<Field, scalar>& interfaceIntCoeffs ( ) const
inlinenoexcept

Definition at line 239 of file lduMatrix.H.

References lduMatrix::solver::interfaceIntCoeffs_.

◆ interfaces()

const lduInterfaceFieldPtrsList& interfaces ( ) const
inlinenoexcept

Definition at line 244 of file lduMatrix.H.

References lduMatrix::solver::interfaces_.

◆ read()

void read ( const dictionary &  solverControls)
virtual

Reimplemented in diagonalSolver.

Definition at line 166 of file lduMatrixSolver.C.

◆ solve()

virtual solverPerformance solve ( scalarField &  psi,
const scalarField &  source,
const direction  cmpt = 0
) const
pure virtual

Implemented in GAMGSolver, PPCG, PBiCGStab, PPCR, PCG, smoothSolver, diagonalSolver, and PBiCG.

◆ scalarSolve()

Foam::solverPerformance scalarSolve ( solveScalarField &  psi,
const solveScalarField &  source,
const direction  cmpt = 0
) const
virtual

Reimplemented in PBiCGStab, and PCG.

Definition at line 174 of file lduMatrixSolver.C.

References psi, refPtr< Field< Type > >::ref(), and Foam::solve().

Here is the call graph for this function:

◆ normFactor()

Foam::solveScalarField::cmptType normFactor ( const solveScalarField &  psi,
const solveScalarField &  source,
const solveScalarField &  Apsi,
solveScalarField &  tmpField
) const

Definition at line 191 of file lduMatrixSolver.C.

References Foam::gAverage(), Foam::gSum(), Foam::mag(), psi, and SolverPerformance::small_.

Here is the call graph for this function:

Member Data Documentation

◆ defaultMaxIter_

const Foam::label defaultMaxIter_ = 1000
staticprotected

Definition at line 101 of file lduMatrix.H.

Referenced by lduMatrix::solver::readControls().

◆ fieldName_

word fieldName_
protected

Definition at line 103 of file lduMatrix.H.

Referenced by lduMatrix::solver::fieldName().

◆ matrix_

const lduMatrix& matrix_
protected

Definition at line 104 of file lduMatrix.H.

Referenced by lduMatrix::solver::matrix().

◆ interfaceBouCoeffs_

const FieldField<Field, scalar>& interfaceBouCoeffs_
protected

Definition at line 105 of file lduMatrix.H.

Referenced by lduMatrix::solver::interfaceBouCoeffs().

◆ interfaceIntCoeffs_

const FieldField<Field, scalar>& interfaceIntCoeffs_
protected

Definition at line 106 of file lduMatrix.H.

Referenced by lduMatrix::solver::interfaceIntCoeffs().

◆ interfaces_

lduInterfaceFieldPtrsList interfaces_
protected

Definition at line 107 of file lduMatrix.H.

Referenced by lduMatrix::solver::interfaces().

◆ controlDict_

dictionary controlDict_
protected

Definition at line 110 of file lduMatrix.H.

Referenced by smoothSolver::readControls(), and lduMatrix::solver::readControls().

◆ log_

int log_
protected

Definition at line 113 of file lduMatrix.H.

Referenced by lduMatrix::solver::readControls().

◆ minIter_

label minIter_
protected

Definition at line 116 of file lduMatrix.H.

Referenced by lduMatrix::solver::readControls().

◆ maxIter_

label maxIter_
protected

Definition at line 119 of file lduMatrix.H.

Referenced by lduMatrix::solver::readControls().

◆ tolerance_

scalar tolerance_
protected

Definition at line 122 of file lduMatrix.H.

Referenced by lduMatrix::solver::readControls().

◆ relTol_

scalar relTol_
protected

Definition at line 125 of file lduMatrix.H.

Referenced by lduMatrix::solver::readControls().

◆ profiling_

profilingTrigger profiling_
protected

Definition at line 127 of file lduMatrix.H.

The documentation for this class was generated from the following files:
