lduMatrix Class Reference

lduMatrix is a general matrix class in which the coefficients are stored as three arrays, one for the upper triangle, one for the lower triangle and a third for the diagonal. More...

Classes
class	preconditioner
class	smoother
class	solver

Public Member Functions
	ClassName ("lduMatrix")
	lduMatrix (const lduMesh &)
	lduMatrix (const lduMatrix &)
	lduMatrix (lduMatrix &, bool reuse)
	lduMatrix (const lduMesh &, Istream &)
	~lduMatrix ()
const lduMesh &	mesh () const
void	setLduMesh (const lduMesh &m)
const lduAddressing &	lduAddr () const
const lduSchedule &	patchSchedule () const
scalarField &	lower ()
scalarField &	diag ()
scalarField &	upper ()
scalarField &	lower (const label size)
scalarField &	diag (const label nCoeffs)
scalarField &	upper (const label nCoeffs)
const scalarField &	lower () const
const scalarField &	diag () const
const scalarField &	upper () const
bool	hasDiag () const
bool	hasUpper () const
bool	hasLower () const
bool	diagonal () const
bool	symmetric () const
bool	asymmetric () const
void	sumDiag ()
void	negSumDiag ()
void	sumMagOffDiag (scalarField &sumOff) const
void	Amul (solveScalarField &, const tmp< solveScalarField > &, const FieldField< Field, scalar > &, const lduInterfaceFieldPtrsList &, const direction cmpt) const
void	Tmul (solveScalarField &, const tmp< solveScalarField > &, const FieldField< Field, scalar > &, const lduInterfaceFieldPtrsList &, const direction cmpt) const
void	sumA (solveScalarField &, const FieldField< Field, scalar > &, const lduInterfaceFieldPtrsList &) const
void	residual (solveScalarField &rA, const solveScalarField &psi, const scalarField &source, const FieldField< Field, scalar > &interfaceBouCoeffs, const lduInterfaceFieldPtrsList &interfaces, const direction cmpt) const
tmp< solveScalarField >	residual (const solveScalarField &psi, const scalarField &source, const FieldField< Field, scalar > &interfaceBouCoeffs, const lduInterfaceFieldPtrsList &interfaces, const direction cmpt) const
void	initMatrixInterfaces (const bool add, const FieldField< Field, scalar > &interfaceCoeffs, const lduInterfaceFieldPtrsList &interfaces, const solveScalarField &psiif, solveScalarField &result, const direction cmpt) const
void	updateMatrixInterfaces (const bool add, const FieldField< Field, scalar > &interfaceCoeffs, const lduInterfaceFieldPtrsList &interfaces, const solveScalarField &psiif, solveScalarField &result, const direction cmpt, const label startRequest) const
void	setResidualField (const scalarField &residual, const word &fieldName, const bool initial) const
template<class Type >
tmp< Field< Type > >	H (const Field< Type > &) const
template<class Type >
tmp< Field< Type > >	H (const tmp< Field< Type >> &) const
tmp< scalarField >	H1 () const
template<class Type >
tmp< Field< Type > >	faceH (const Field< Type > &) const
template<class Type >
tmp< Field< Type > >	faceH (const tmp< Field< Type >> &) const
InfoProxy< lduMatrix >	info () const
void	operator= (const lduMatrix &)
void	negate ()
void	operator+= (const lduMatrix &)
void	operator-= (const lduMatrix &)
void	operator*= (const scalarField &)
void	operator*= (scalar)
template<class Type >
Foam::tmp< Foam::Field< Type > >	H (const Field< Type > &psi) const
template<class Type >
Foam::tmp< Foam::Field< Type > >	H (const tmp< Field< Type >> &tpsi) const
template<class Type >
Foam::tmp< Foam::Field< Type > >	faceH (const Field< Type > &psi) const
template<class Type >
Foam::tmp< Foam::Field< Type > >	faceH (const tmp< Field< Type >> &tpsi) const

Friends
Ostream &	operator<< (Ostream &, const lduMatrix &)
Ostream &	operator<< (Ostream &, const InfoProxy< lduMatrix > &)

Detailed Description

lduMatrix is a general matrix class in which the coefficients are stored as three arrays, one for the upper triangle, one for the lower triangle and a third for the diagonal.

Addressing arrays must be supplied for the upper and lower triangles.

It might be better if this class were organised as a hierarchy starting from an empty matrix, then deriving diagonal, symmetric and asymmetric matrices.

Source files

• lduMatrix.H
• lduMatrixATmul.C
• lduMatrix.C
• lduMatrixTemplates.C
• lduMatrixOperations.C
• lduMatrixSolver.C
• lduMatrixPreconditioner.C
• lduMatrixTests.C
• lduMatrixUpdateMatrixInterfaces.C

Definition at line 79 of file lduMatrix.H.

Constructor & Destructor Documentation

lduMatrix() [1/4]

lduMatrix

(

const lduMesh &

mesh

)

Definition at line 42 of file lduMatrix.C.

lduMatrix() [2/4]

lduMatrix

(

const lduMatrix &

A

)

Definition at line 51 of file lduMatrix.C.

References A.

lduMatrix() [3/4]

lduMatrix	(	lduMatrix &	A,
		bool	reuse
	)

Definition at line 75 of file lduMatrix.C.

References A.

lduMatrix() [4/4]

lduMatrix	(	const lduMesh &	mesh,
		Istream &	is
	)

Definition at line 122 of file lduMatrix.C.

References lduMatrix::hasDiag().

Here is the call graph for this function:

~lduMatrix()

~lduMatrix

(

)

Definition at line 148 of file lduMatrix.C.

Member Function Documentation

ClassName()

ClassName

(

"lduMatrix"

)

mesh()

const lduMesh& mesh ( ) const

inline

Definition at line 562 of file lduMatrix.H.

Referenced by algebraicPairGAMGAgglomeration::algebraicPairGAMGAgglomeration(), assemblyFaceAreaPairGAMGAgglomeration::assemblyFaceAreaPairGAMGAgglomeration(), lduMatrix::lduAddr(), and GAMGAgglomeration::New().

Here is the caller graph for this function:

setLduMesh()

void setLduMesh ( const lduMesh &  m )

inline

Definition at line 568 of file lduMatrix.H.

lduAddr()

const lduAddressing& lduAddr ( ) const

inline

Definition at line 574 of file lduMatrix.H.

References lduMesh::lduAddr(), and lduMatrix::mesh().

Referenced by DICPreconditioner::calcReciprocalD(), DILUPreconditioner::calcReciprocalD(), lduMatrix::H(), lduMatrix::H1(), LUscalarMatrix::LUscalarMatrix(), lduMatrix::patchSchedule(), symGaussSeidelSmoother::smooth(), GaussSeidelSmoother::smooth(), nonBlockingGaussSeidelSmoother::smooth(), and lduMatrix::sumDiag().

Here is the call graph for this function:

Here is the caller graph for this function:

patchSchedule()

const lduSchedule& patchSchedule ( ) const

inline

Definition at line 580 of file lduMatrix.H.

References lduMatrix::lduAddr(), and lduAddressing::patchSchedule().

Here is the call graph for this function:

lower() [1/3]

const Foam::scalarField & lower

(

)

Definition at line 167 of file lduMatrix.C.

References Foam::Zero.

Referenced by algebraicPairGAMGAgglomeration::algebraicPairGAMGAgglomeration(), DILUPreconditioner::calcReciprocalD(), lduMatrix::faceH(), GAMGSolver::GAMGSolver(), lduMatrix::H(), lduMatrix::H1(), lduMatrix::negSumDiag(), Foam::operator<<(), symGaussSeidelSmoother::smooth(), GaussSeidelSmoother::smooth(), nonBlockingGaussSeidelSmoother::smooth(), lduMatrix::sumDiag(), and lduMatrix::sumMagOffDiag().

Here is the caller graph for this function:

diag() [1/3]

const Foam::scalarField & diag

(

)

Definition at line 185 of file lduMatrix.C.

References Foam::Zero.

Referenced by DICPreconditioner::DICPreconditioner(), DILUPreconditioner::DILUPreconditioner(), FDICPreconditioner::FDICPreconditioner(), GAMGSolver::GAMGSolver(), nonBlockingGaussSeidelSmoother::nonBlockingGaussSeidelSmoother(), Foam::operator<<(), symGaussSeidelSmoother::smooth(), GaussSeidelSmoother::smooth(), nonBlockingGaussSeidelSmoother::smooth(), and lduMatrix::sumDiag().

Here is the caller graph for this function:

upper() [1/3]

const Foam::scalarField & upper

(

)

Definition at line 196 of file lduMatrix.C.

References Foam::Zero.

Referenced by algebraicPairGAMGAgglomeration::algebraicPairGAMGAgglomeration(), DILUPreconditioner::calcReciprocalD(), DICPreconditioner::calcReciprocalD(), lduMatrix::faceH(), lduMatrix::H(), lduMatrix::H1(), lduMatrix::negSumDiag(), Foam::operator<<(), GaussSeidelSmoother::smooth(), symGaussSeidelSmoother::smooth(), nonBlockingGaussSeidelSmoother::smooth(), lduMatrix::sumDiag(), and lduMatrix::sumMagOffDiag().

Here is the caller graph for this function:

lower() [2/3]

Foam::scalarField & lower

(

const label

size

)

Definition at line 214 of file lduMatrix.C.

References Foam::Zero.

diag() [2/3]

Foam::scalarField & diag

(

const label

nCoeffs

)

Definition at line 232 of file lduMatrix.C.

References Foam::Zero.

upper() [2/3]

Foam::scalarField & upper

(

const label

nCoeffs

)

Definition at line 243 of file lduMatrix.C.

References Foam::Zero.

lower() [3/3]

const scalarField& lower

(

)

const

diag() [3/3]

const scalarField& diag

(

)

const

upper() [3/3]

const scalarField& upper

(

)

const

hasDiag()

bool hasDiag ( ) const

inline

Definition at line 604 of file lduMatrix.H.

Referenced by lduMatrix::lduMatrix(), and Foam::operator<<().

Here is the caller graph for this function:

hasUpper()

bool hasUpper ( ) const

inline

Definition at line 609 of file lduMatrix.H.

Referenced by Foam::operator<<().

Here is the caller graph for this function:

hasLower()

bool hasLower ( ) const

inline

Definition at line 614 of file lduMatrix.H.

Referenced by algebraicPairGAMGAgglomeration::algebraicPairGAMGAgglomeration(), and Foam::operator<<().

Here is the caller graph for this function:

diagonal()

bool diagonal ( ) const

inline

Definition at line 619 of file lduMatrix.H.

Referenced by lduMatrix::solver::New().

Here is the caller graph for this function:

symmetric()

bool symmetric ( ) const

inline

Definition at line 624 of file lduMatrix.H.

Referenced by lduMatrix::solver::New(), lduMatrix::smoother::New(), and lduMatrix::preconditioner::New().

Here is the caller graph for this function:

asymmetric()

bool asymmetric ( ) const

inline

Definition at line 629 of file lduMatrix.H.

Referenced by lduMatrix::solver::New(), lduMatrix::smoother::New(), and lduMatrix::preconditioner::New().

Here is the caller graph for this function:

sumDiag()

void sumDiag

(

)

Definition at line 30 of file lduMatrixOperations.C.

References lduMatrix::diag(), lduMatrix::lduAddr(), lduMatrix::lower(), lduAddressing::lowerAddr(), UList::size(), lduMatrix::upper(), and lduAddressing::upperAddr().

Here is the call graph for this function:

negSumDiag()

void negSumDiag

(

)

Definition at line 47 of file lduMatrixOperations.C.

References Foam::diag(), lduMatrix::lower(), UList::size(), and lduMatrix::upper().

Here is the call graph for this function:

sumMagOffDiag()

void sumMagOffDiag

(

scalarField &

sumOff

)

const

Definition at line 65 of file lduMatrixOperations.C.

References lduMatrix::lower(), Foam::mag(), UList::size(), and lduMatrix::upper().

Here is the call graph for this function:

Amul()

void Amul	(	solveScalarField &	Apsi,
		const tmp< solveScalarField > &	tpsi,
		const FieldField< Field, scalar > &	interfaceBouCoeffs,
		const lduInterfaceFieldPtrsList &	interfaces,
		const direction	cmpt
	)		const

Definition at line 32 of file lduMatrixATmul.C.

References tmp::clear(), Foam::diag(), Foam::stringOps::lower(), psi, and Foam::stringOps::upper().

Here is the call graph for this function:

Tmul()

void Tmul	(	solveScalarField &	Tpsi,
		const tmp< solveScalarField > &	tpsi,
		const FieldField< Field, scalar > &	interfaceIntCoeffs,
		const lduInterfaceFieldPtrsList &	interfaces,
		const direction	cmpt
	)		const

Definition at line 98 of file lduMatrixATmul.C.

References tmp::clear(), Foam::diag(), Foam::stringOps::lower(), psi, and Foam::stringOps::upper().

Here is the call graph for this function:

sumA()

void sumA	(	solveScalarField &	sumA,
		const FieldField< Field, scalar > &	interfaceBouCoeffs,
		const lduInterfaceFieldPtrsList &	interfaces
	)		const

Definition at line 162 of file lduMatrixATmul.C.

References Foam::diag(), forAll, Foam::stringOps::lower(), UPtrList::set(), and Foam::stringOps::upper().

Here is the call graph for this function:

residual() [1/2]

void residual	(	solveScalarField &	rA,
		const solveScalarField &	psi,
		const scalarField &	source,
		const FieldField< Field, scalar > &	interfaceBouCoeffs,
		const lduInterfaceFieldPtrsList &	interfaces,
		const direction	cmpt
	)		const

Definition at line 211 of file lduMatrixATmul.C.

References Foam::diag(), Foam::stringOps::lower(), psi, and Foam::stringOps::upper().

Referenced by faMatrix< Type >::residual(), and fvMatrix< Type >::residual().

Here is the call graph for this function:

Here is the caller graph for this function:

residual() [2/2]

Foam::tmp< Foam::Field< Foam::solveScalar > > residual	(	const solveScalarField &	psi,
		const scalarField &	source,
		const FieldField< Field, scalar > &	interfaceBouCoeffs,
		const lduInterfaceFieldPtrsList &	interfaces,
		const direction	cmpt
	)		const

Definition at line 286 of file lduMatrixATmul.C.

References psi, and tmp::ref().

Here is the call graph for this function:

initMatrixInterfaces()

void initMatrixInterfaces	(	const bool	add,
		const FieldField< Field, scalar > &	interfaceCoeffs,
		const lduInterfaceFieldPtrsList &	interfaces,
		const solveScalarField &	psiif,
		solveScalarField &	result,
		const direction	cmpt
	)		const

Definition at line 27 of file lduMatrixUpdateMatrixInterfaces.C.

References Foam::add(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, forAll, mesh, UPtrList::set(), and UPtrList::size().

Referenced by GaussSeidelSmoother::smooth(), symGaussSeidelSmoother::smooth(), and nonBlockingGaussSeidelSmoother::smooth().

Here is the call graph for this function:

Here is the caller graph for this function:

updateMatrixInterfaces()

void updateMatrixInterfaces	(	const bool	add,
		const FieldField< Field, scalar > &	interfaceCoeffs,
		const lduInterfaceFieldPtrsList &	interfaces,
		const solveScalarField &	psiif,
		solveScalarField &	result,
		const direction	cmpt,
		const label	startRequest
	)		const

Definition at line 100 of file lduMatrixUpdateMatrixInterfaces.C.

References Foam::add(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, forAll, mesh, UPtrList::set(), and UPtrList::size().

Referenced by GaussSeidelSmoother::smooth(), symGaussSeidelSmoother::smooth(), and nonBlockingGaussSeidelSmoother::smooth().

Here is the call graph for this function:

Here is the caller graph for this function:

setResidualField()

void setResidualField	(	const scalarField &	residual,
		const word &	fieldName,
		const bool	initial
	)		const

Definition at line 315 of file lduMatrix.C.

References DebugInfo, Foam::endl(), objectRegistry::findObject(), dictionary::found(), objectRegistry::getObjectPtr(), mesh, IOobject::scopedName(), and fvMesh::thisDb().

Referenced by PCG::scalarSolve(), PBiCGStab::scalarSolve(), PBiCG::solve(), and smoothSolver::solve().

Here is the call graph for this function:

Here is the caller graph for this function:

H() [1/4]

tmp<Field<Type> > H

(

const Field< Type > &

)

const

H() [2/4]

tmp<Field<Type> > H

(

const tmp< Field< Type >> &

)

const

H1()

Foam::tmp< Foam::scalarField > H1

(

)

const

Definition at line 300 of file lduMatrixATmul.C.

References UList::begin(), lduMatrix::lduAddr(), lduMatrix::lower(), lduAddressing::lowerAddr(), tmp::New(), lduMatrix::upper(), lduAddressing::upperAddr(), and Foam::Zero.

Here is the call graph for this function:

faceH() [1/4]

tmp<Field<Type> > faceH

(

const Field< Type > &

)

const

faceH() [2/4]

tmp<Field<Type> > faceH

(

const tmp< Field< Type >> &

)

const

info()

InfoProxy<lduMatrix> info ( ) const

inline

Definition at line 744 of file lduMatrix.H.

operator=()

void operator=

(

const lduMatrix &

A

)

Definition at line 85 of file lduMatrixOperations.C.

References A, Foam::diag(), Foam::stringOps::lower(), and Foam::stringOps::upper().

Here is the call graph for this function:

negate()

void negate

(

)

Definition at line 119 of file lduMatrixOperations.C.

operator+=()

void operator+=

(

const lduMatrix &

A

)

Definition at line 138 of file lduMatrixOperations.C.

References A, Foam::expressions::patchExpr::debug, Foam::diag(), Foam::endl(), Foam::stringOps::lower(), Foam::nl, Foam::stringOps::upper(), and WarningInFunction.

Here is the call graph for this function:

operator-=()

void operator-=

(

const lduMatrix &

A

)

Definition at line 217 of file lduMatrixOperations.C.

References A, Foam::expressions::patchExpr::debug, Foam::diag(), Foam::endl(), Foam::stringOps::lower(), Foam::nl, Foam::stringOps::upper(), and WarningInFunction.

Here is the call graph for this function:

operator*=() [1/2]

void operator*=

(

const scalarField &

sf

)

Definition at line 296 of file lduMatrixOperations.C.

References Foam::stringOps::lower(), and Foam::stringOps::upper().

Here is the call graph for this function:

operator*=() [2/2]

void operator*=

(

scalar

s

)

Definition at line 326 of file lduMatrixOperations.C.

References s.

H() [3/4]

Foam::tmp<Foam::Field<Type> > H

(

const Field< Type > &

psi

)

const

Definition at line 30 of file lduMatrixTemplates.C.

References UList::begin(), lduMatrix::lduAddr(), lduMatrix::lower(), lduAddressing::lowerAddr(), psi, tmp::ref(), lduMatrix::upper(), lduAddressing::upperAddr(), and Foam::Zero.

Here is the call graph for this function:

H() [4/4]

Foam::tmp<Foam::Field<Type> > H

(

const tmp< Field< Type >> &

tpsi

)

const

Definition at line 65 of file lduMatrixTemplates.C.

References H().

Here is the call graph for this function:

faceH() [3/4]

Foam::tmp<Foam::Field<Type> > faceH

(

const Field< Type > &

psi

)

const

Definition at line 75 of file lduMatrixTemplates.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, lduMatrix::lower(), psi, tmp::ref(), UList::size(), and lduMatrix::upper().

Here is the call graph for this function:

faceH() [4/4]

Foam::tmp<Foam::Field<Type> > faceH

(

const tmp< Field< Type >> &

tpsi

)

const

Definition at line 109 of file lduMatrixTemplates.C.

Friends And Related Function Documentation

operator<< [1/2]

Ostream& operator<< ( Ostream &  , const lduMatrix &    )

friend

operator<< [2/2]

Ostream& operator<< ( Ostream &  , const InfoProxy< lduMatrix > &    )

friend

---

The documentation for this class was generated from the following files:

• src/OpenFOAM/matrices/lduMatrix/lduMatrix/lduMatrix.H
• src/OpenFOAM/matrices/lduMatrix/lduMatrix/lduMatrix.C
• src/OpenFOAM/matrices/lduMatrix/lduMatrix/lduMatrixATmul.C
• src/OpenFOAM/matrices/lduMatrix/lduMatrix/lduMatrixOperations.C
• src/OpenFOAM/matrices/lduMatrix/lduMatrix/lduMatrixTemplates.C
• src/OpenFOAM/matrices/lduMatrix/lduMatrix/lduMatrixUpdateMatrixInterfaces.C
