Base class implementation of the k-omega-SST turbulence model for incompressible and compressible flows. More...

Inheritance diagram for kOmegaSSTBase< BasicEddyViscosityModel >:

[legend]

Collaboration diagram for kOmegaSSTBase< BasicEddyViscosityModel >:

[legend]

Public Types
typedef BasicEddyViscosityModel::alphaField	alphaField

typedef BasicEddyViscosityModel::rhoField	rhoField

typedef BasicEddyViscosityModel::transportModel	transportModel

Public Member Functions
	kOmegaSSTBase (const word &type, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName)

virtual	~kOmegaSSTBase ()=default

virtual bool	read ()

tmp< volScalarField >	DkEff (const volScalarField &F1) const

tmp< volScalarField >	DomegaEff (const volScalarField &F1) const

virtual tmp< volScalarField >	k () const

virtual tmp< volScalarField >	omega () const

virtual void	correct ()

Protected Member Functions
void	setDecayControl (const dictionary &dict)

virtual tmp< volScalarField >	F1 (const volScalarField &CDkOmega) const

virtual tmp< volScalarField >	F2 () const

virtual tmp< volScalarField >	F3 () const

virtual tmp< volScalarField >	F23 () const

tmp< volScalarField >	blend (const volScalarField &F1, const dimensionedScalar &psi1, const dimensionedScalar &psi2) const

tmp< volScalarField::Internal >	blend (const volScalarField::Internal &F1, const dimensionedScalar &psi1, const dimensionedScalar &psi2) const

tmp< volScalarField >	alphaK (const volScalarField &F1) const

tmp< volScalarField >	alphaOmega (const volScalarField &F1) const

tmp< volScalarField::Internal >	beta (const volScalarField::Internal &F1) const

tmp< volScalarField::Internal >	gamma (const volScalarField::Internal &F1) const

virtual void	correctNut (const volScalarField &S2)

virtual void	correctNut ()

virtual tmp< volScalarField::Internal >	Pk (const volScalarField::Internal &G) const

virtual tmp< volScalarField::Internal >	epsilonByk (const volScalarField &F1, const volTensorField &gradU) const

virtual tmp< volScalarField::Internal >	GbyNu (const volScalarField::Internal &GbyNu0, const volScalarField::Internal &F2, const volScalarField::Internal &S2) const

virtual tmp< fvScalarMatrix >	kSource () const

virtual tmp< fvScalarMatrix >	omegaSource () const

virtual tmp< fvScalarMatrix >	Qsas (const volScalarField::Internal &S2, const volScalarField::Internal &gamma, const volScalarField::Internal &beta) const

Detailed Description

template<class BasicEddyViscosityModel>
class Foam::kOmegaSSTBase< BasicEddyViscosityModel >

Base class implementation of the k-omega-SST turbulence model for incompressible and compressible flows.

Turbulence model described in:

    Menter, F. R. & Esch, T. (2001).
    Elements of Industrial Heat Transfer Prediction.
    16th Brazilian Congress of Mechanical Engineering (COBEM).

with updated coefficients from

    Menter, F. R., Kuntz, M., and Langtry, R. (2003).
    Ten Years of Industrial Experience with the SST Turbulence Model.
    Turbulence, Heat and Mass Transfer 4, ed: K. Hanjalic, Y. Nagano,
    & M. Tummers, Begell House, Inc., 625 - 632.

but with the consistent production terms from the 2001 paper as form in the 2003 paper is a typo, see

    http://turbmodels.larc.nasa.gov/sst.html

and the addition of the optional F3 term for rough walls from

    Hellsten, A. (1998).
    Some Improvements in Menter's k-omega-SST turbulence model
    29th AIAA Fluid Dynamics Conference, AIAA-98-2554.

and the optional decay control from:

    Spalart, P. R. and Rumsey, C. L. (2007).
    Effective Inflow Conditions for Turbulence Models in Aerodynamic
    Calculations
    AIAA Journal, 45(10), 2544 - 2553.

Note that this implementation is written in terms of alpha diffusion coefficients rather than the more traditional sigma (alpha = 1/sigma) so that the blending can be applied to all coefficients in a consistent manner. The paper suggests that sigma is blended but this would not be consistent with the blending of the k-epsilon and k-omega models.

Also note that the error in the last term of equation (2) relating to sigma has been corrected.

Wall-functions are applied in this implementation by using equations (14) to specify the near-wall omega as appropriate.

The blending functions (15) and (16) are not currently used because of the uncertainty in their origin, range of applicability and that if y+ becomes sufficiently small blending u_tau in this manner clearly becomes nonsense.

The default model coefficients are

    kOmegaSSTBaseCoeffs
    {
        alphaK1         0.85;
        alphaK2         1.0;
        alphaOmega1     0.5;
        alphaOmega2     0.856;
        beta1           0.075;
        beta2           0.0828;
        betaStar        0.09;
        gamma1          5/9;
        gamma2          0.44;
        a1              0.31;
        b1              1.0;
        c1              10.0;
        F3              no;

        // Optional decay control
        decayControl    yes;
        kInf            \<far-field k value\>;
        omegaInf        \<far-field omega value\>;
    }

Source files

Definition at line 124 of file kOmegaSSTBase.H.

Member Typedef Documentation

◆ alphaField

typedef BasicEddyViscosityModel::alphaField alphaField

Definition at line 286 of file kOmegaSSTBase.H.

◆ rhoField

typedef BasicEddyViscosityModel::rhoField rhoField

Definition at line 287 of file kOmegaSSTBase.H.

◆ transportModel

typedef BasicEddyViscosityModel::transportModel transportModel

Definition at line 288 of file kOmegaSSTBase.H.

Constructor & Destructor Documentation

◆ kOmegaSSTBase()

kOmegaSSTBase	(	const word &	type,
		const alphaField &	alpha,
		const rhoField &	rho,
		const volVectorField &	U,
		const surfaceScalarField &	alphaRhoPhi,
		const surfaceScalarField &	phi,
		const transportModel &	transport,
		const word &	propertiesName = `turbulenceModel::propertiesName`
	)

Definition at line 218 of file kOmegaSSTBase.C.

◆ ~kOmegaSSTBase()

virtual ~kOmegaSSTBase ( )

virtualdefault

Member Function Documentation

◆ setDecayControl()

void setDecayControl ( const dictionary & dict )

protected

Definition at line 426 of file kOmegaSSTBase.C.

◆ F1()

tmp< volScalarField > F1 ( const volScalarField & CDkOmega ) const

protectedvirtual

Reimplemented in kOmegaSSTLM< BasicTurbulenceModel >.

Definition at line 36 of file kOmegaSSTBase.C.

Referenced by kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >::alphaK(), kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >::alphaOmega(), kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >::blend(), kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >::DkEff(), and kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >::DomegaEff().

Here is the caller graph for this function:

◆ F2()

tmp< volScalarField > F2

protectedvirtual

Definition at line 65 of file kOmegaSSTBase.C.

◆ F3()

tmp< volScalarField > F3

protectedvirtual

Definition at line 82 of file kOmegaSSTBase.C.

◆ F23()

tmp< volScalarField > F23

protectedvirtual

Definition at line 95 of file kOmegaSSTBase.C.

◆ blend() [1/2]

tmp<volScalarField> blend	(	const volScalarField &	F1,
		const dimensionedScalar &	psi1,
		const dimensionedScalar &	psi2
	)		const

inlineprotected

Definition at line 194 of file kOmegaSSTBase.H.

Referenced by kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >::alphaK(), kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >::alphaOmega(), kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >::beta(), and kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >::gamma().

Here is the caller graph for this function:

◆ blend() [2/2]

tmp<volScalarField::Internal> blend	(	const volScalarField::Internal &	F1,
		const dimensionedScalar &	psi1,
		const dimensionedScalar &	psi2
	)		const

inlineprotected

Definition at line 204 of file kOmegaSSTBase.H.

◆ alphaK()

tmp<volScalarField> alphaK ( const volScalarField & F1 ) const

inlineprotected

Definition at line 213 of file kOmegaSSTBase.H.

Referenced by kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >::DkEff().

Here is the caller graph for this function:

◆ alphaOmega()

tmp<volScalarField> alphaOmega ( const volScalarField & F1 ) const

inlineprotected

Definition at line 218 of file kOmegaSSTBase.H.

Referenced by kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >::DomegaEff().

Here is the caller graph for this function:

◆ beta()

tmp<volScalarField::Internal> beta ( const volScalarField::Internal & F1 ) const

inlineprotected

Definition at line 224 of file kOmegaSSTBase.H.

◆ gamma()

tmp<volScalarField::Internal> gamma ( const volScalarField::Internal & F1 ) const

inlineprotected

Definition at line 236 of file kOmegaSSTBase.H.

◆ correctNut() [1/2]

void correctNut ( const volScalarField & S2 )

protectedvirtual

Reimplemented in kOmegaSSTSato< BasicTurbulenceModel >, kOmegaSST< BasicTurbulenceModel >, and kOmegaSSTDES< BasicTurbulenceModel >.

Definition at line 110 of file kOmegaSSTBase.C.

◆ correctNut() [2/2]

void correctNut

protectedvirtual

Reimplemented in kOmegaSST< BasicTurbulenceModel >, and kOmegaSSTDES< BasicTurbulenceModel >.

Definition at line 122 of file kOmegaSSTBase.C.

◆ Pk()

tmp< volScalarField::Internal > Pk ( const volScalarField::Internal & G ) const

protectedvirtual

Reimplemented in kOmegaSSTLM< BasicTurbulenceModel >.

Definition at line 130 of file kOmegaSSTBase.C.

◆ epsilonByk()

tmp< volScalarField::Internal > epsilonByk	(	const volScalarField &	F1,
		const volTensorField &	gradU
	)		const

protectedvirtual

Reimplemented in kOmegaSSTLM< BasicTurbulenceModel >, and kOmegaSSTDES< BasicTurbulenceModel >.

Definition at line 141 of file kOmegaSSTBase.C.

◆ GbyNu()

tmp< volScalarField::Internal > GbyNu	(	const volScalarField::Internal &	GbyNu0,
		const volScalarField::Internal &	F2,
		const volScalarField::Internal &	S2
	)		const

protectedvirtual

Reimplemented in kOmegaSSTDES< BasicTurbulenceModel >.

Definition at line 152 of file kOmegaSSTBase.C.

◆ kSource()

tmp< fvScalarMatrix > kSource

protectedvirtual

Definition at line 168 of file kOmegaSSTBase.C.

◆ omegaSource()

tmp< fvScalarMatrix > omegaSource

protectedvirtual

Definition at line 182 of file kOmegaSSTBase.C.

◆ Qsas()

tmp< fvScalarMatrix > Qsas	(	const volScalarField::Internal &	S2,
		const volScalarField::Internal &	gamma,
		const volScalarField::Internal &	beta
	)		const

protectedvirtual

Reimplemented in kOmegaSSTSAS< BasicTurbulenceModel >.

Definition at line 197 of file kOmegaSSTBase.C.

◆ read()

bool read

virtual

Reimplemented in kOmegaSSTLM< BasicTurbulenceModel >, kOmegaSSTSato< BasicTurbulenceModel >, kOmegaSSTSAS< BasicTurbulenceModel >, kOmegaSSTDES< BasicTurbulenceModel >, kOmegaSSTIDDES< BasicTurbulenceModel >, and kOmegaSSTDDES< BasicTurbulenceModel >.

Definition at line 449 of file kOmegaSSTBase.C.

◆ DkEff()

tmp<volScalarField> DkEff ( const volScalarField & F1 ) const

inline

Definition at line 317 of file kOmegaSSTBase.H.

◆ DomegaEff()

tmp<volScalarField> DomegaEff ( const volScalarField & F1 ) const

inline

Definition at line 326 of file kOmegaSSTBase.H.

◆ k()

virtual tmp<volScalarField> k ( ) const

inlinevirtual

Definition at line 339 of file kOmegaSSTBase.H.

◆ omega()

virtual tmp<volScalarField> omega ( ) const

inlinevirtual

Definition at line 345 of file kOmegaSSTBase.H.

◆ correct()

void correct

virtual

Reimplemented in kOmegaSSTLM< BasicTurbulenceModel >, and kOmegaSSTSato< BasicTurbulenceModel >.

Definition at line 477 of file kOmegaSSTBase.C.

Member Data Documentation

◆ alphaK1_

dimensionedScalar alphaK1_

protected

Definition at line 143 of file kOmegaSSTBase.H.

Referenced by kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >::alphaK().

◆ alphaK2_

dimensionedScalar alphaK2_

protected

Definition at line 144 of file kOmegaSSTBase.H.

Referenced by kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >::alphaK().

◆ alphaOmega1_

dimensionedScalar alphaOmega1_

protected

Definition at line 146 of file kOmegaSSTBase.H.

Referenced by kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >::alphaOmega().

◆ alphaOmega2_

dimensionedScalar alphaOmega2_

protected

Definition at line 147 of file kOmegaSSTBase.H.

Referenced by kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >::alphaOmega().

◆ gamma1_

dimensionedScalar gamma1_

protected

Definition at line 149 of file kOmegaSSTBase.H.

Referenced by kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >::gamma().

◆ gamma2_

dimensionedScalar gamma2_

protected

Definition at line 150 of file kOmegaSSTBase.H.

Referenced by kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >::gamma().

◆ beta1_

dimensionedScalar beta1_

protected

Definition at line 152 of file kOmegaSSTBase.H.

Referenced by kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >::beta().

◆ beta2_

dimensionedScalar beta2_

protected

Definition at line 153 of file kOmegaSSTBase.H.

Referenced by kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >::beta().

◆ betaStar_

dimensionedScalar betaStar_

protected

Definition at line 155 of file kOmegaSSTBase.H.

◆ a1_

dimensionedScalar a1_

protected

Definition at line 157 of file kOmegaSSTBase.H.

◆ b1_

dimensionedScalar b1_

protected

Definition at line 158 of file kOmegaSSTBase.H.

◆ c1_

dimensionedScalar c1_

protected

Definition at line 159 of file kOmegaSSTBase.H.

◆ F3_

Switch F3_

protected

Definition at line 162 of file kOmegaSSTBase.H.

◆ y_

const volScalarField& y_

protected

Definition at line 170 of file kOmegaSSTBase.H.

◆ k_

volScalarField k_

protected

Definition at line 172 of file kOmegaSSTBase.H.

Referenced by kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >::k().

◆ omega_

volScalarField omega_

protected

Definition at line 173 of file kOmegaSSTBase.H.

Referenced by kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >::omega().

◆ decayControl_

Switch decayControl_

protected

Definition at line 179 of file kOmegaSSTBase.H.

◆ kInf_

dimensionedScalar kInf_

protected

Definition at line 180 of file kOmegaSSTBase.H.

◆ omegaInf_

dimensionedScalar omegaInf_

protected

Definition at line 181 of file kOmegaSSTBase.H.

The documentation for this class was generated from the following files:

src/TurbulenceModels/turbulenceModels/Base/kOmegaSST/kOmegaSSTBase.H
src/TurbulenceModels/turbulenceModels/Base/kOmegaSST/kOmegaSSTBase.C

Protected Attributes
dimensionedScalar	alphaK1_

dimensionedScalar	alphaK2_

dimensionedScalar	alphaOmega1_

dimensionedScalar	alphaOmega2_

dimensionedScalar	gamma1_

dimensionedScalar	gamma2_

dimensionedScalar	beta1_

dimensionedScalar	beta2_

dimensionedScalar	betaStar_

dimensionedScalar	a1_

dimensionedScalar	b1_

dimensionedScalar	c1_

Switch	F3_

const volScalarField &	y_

volScalarField	k_

volScalarField	omega_

Switch	decayControl_

dimensionedScalar	kInf_

dimensionedScalar	omegaInf_

Public Types

Public Member Functions

Protected Member Functions

Protected Attributes

Detailed Description

template<class BasicEddyViscosityModel> class Foam::kOmegaSSTBase< BasicEddyViscosityModel >

Member Typedef Documentation

◆ alphaField

◆ rhoField

◆ transportModel

Constructor & Destructor Documentation

◆ kOmegaSSTBase()

◆ ~kOmegaSSTBase()

Member Function Documentation

◆ setDecayControl()

◆ F1()

◆ F2()

◆ F3()

◆ F23()

◆ blend() [1/2]

◆ blend() [2/2]

◆ alphaK()

◆ alphaOmega()

◆ beta()

◆ gamma()

◆ correctNut() [1/2]

◆ correctNut() [2/2]

◆ Pk()

◆ epsilonByk()

◆ GbyNu()

◆ kSource()

◆ omegaSource()

◆ Qsas()

◆ read()

◆ DkEff()

◆ DomegaEff()

◆ k()

◆ omega()

◆ correct()

Member Data Documentation

◆ alphaK1_

◆ alphaK2_

◆ alphaOmega1_

◆ alphaOmega2_

◆ gamma1_

◆ gamma2_

◆ beta1_

◆ beta2_

◆ betaStar_

◆ a1_

◆ b1_

◆ c1_

◆ F3_

◆ y_

◆ k_

◆ omega_

◆ decayControl_

◆ kInf_

◆ omegaInf_

template<class BasicEddyViscosityModel>
class Foam::kOmegaSSTBase< BasicEddyViscosityModel >
