This boundary condition provides a wall constraint on the turbulent kinetic energy, i.e. k, for low- and high-Reynolds number turbulence models. More...

Inheritance diagram for kLowReWallFunctionFvPatchScalarField:

[legend]

Collaboration diagram for kLowReWallFunctionFvPatchScalarField:

[legend]

Public Member Functions
	TypeName ("kLowReWallFunction")

	kLowReWallFunctionFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &)

	kLowReWallFunctionFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)

	kLowReWallFunctionFvPatchScalarField (const kLowReWallFunctionFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fvPatchFieldMapper &)

	kLowReWallFunctionFvPatchScalarField (const kLowReWallFunctionFvPatchScalarField &)

virtual tmp< fvPatchScalarField >	clone () const

	kLowReWallFunctionFvPatchScalarField (const kLowReWallFunctionFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)

virtual tmp< fvPatchScalarField >	clone (const DimensionedField< scalar, volMesh > &iF) const

virtual void	updateCoeffs ()

virtual void	write (Ostream &) const

Public Member Functions inherited from fixedValueFvPatchField< scalar >
	TypeName ("fixedValue")

	fixedValueFvPatchField (const fvPatch &, const DimensionedField< scalar, volMesh > &)

	fixedValueFvPatchField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const scalar &value)

	fixedValueFvPatchField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &, const bool valueRequired=true)

	fixedValueFvPatchField (const fixedValueFvPatchField< scalar > &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fvPatchFieldMapper &)

	fixedValueFvPatchField (const fixedValueFvPatchField< scalar > &)

	fixedValueFvPatchField (const fixedValueFvPatchField< scalar > &, const DimensionedField< scalar, volMesh > &)

virtual tmp< fvPatchField< scalar > >	clone () const

virtual bool	fixesValue () const

virtual bool	assignable () const

virtual tmp< Field< scalar > >	valueInternalCoeffs (const tmp< scalarField > &) const

virtual tmp< Field< scalar > >	valueBoundaryCoeffs (const tmp< scalarField > &) const

virtual tmp< Field< scalar > >	gradientInternalCoeffs () const

virtual tmp< Field< scalar > >	gradientBoundaryCoeffs () const

virtual void	operator= (const UList< scalar > &)

virtual void	operator= (const fvPatchField< scalar > &)

virtual void	operator= (const scalar &)

virtual void	operator+= (const fvPatchField< scalar > &)

virtual void	operator+= (const Field< scalar > &)

virtual void	operator+= (const scalar &)

virtual void	operator-= (const fvPatchField< scalar > &)

virtual void	operator-= (const Field< scalar > &)

virtual void	operator-= (const scalar &)

virtual void	operator*= (const fvPatchField< scalar > &)

virtual void	operator*= (const Field< scalar > &)

virtual void	operator*= (const scalar)

virtual void	operator/= (const fvPatchField< scalar > &)

virtual void	operator/= (const Field< scalar > &)

virtual void	operator/= (const scalar)

Public Member Functions inherited from fvPatchField< scalar >
	TypeName ("fvPatchField")

	declareRunTimeSelectionTable (tmp, fvPatchField, patch,(const fvPatch &p, const DimensionedField< Type, volMesh > &iF),(p, iF))

	declareRunTimeSelectionTable (tmp, fvPatchField, patchMapper,(const fvPatchField< Type > &ptf, const fvPatch &p, const DimensionedField< Type, volMesh > &iF, const fvPatchFieldMapper &m),(dynamic_cast< const fvPatchFieldType & >(ptf), p, iF, m))

	declareRunTimeSelectionTable (tmp, fvPatchField, dictionary,(const fvPatch &p, const DimensionedField< Type, volMesh > &iF, const dictionary &dict),(p, iF, dict))

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &)

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const Type &value)

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const word &patchType)

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const Field< Type > &)

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const dictionary &, const bool valueRequired=true)

	fvPatchField (const fvPatchField< Type > &, const fvPatch &, const DimensionedField< Type, volMesh > &, const fvPatchFieldMapper &)

	fvPatchField (const fvPatchField< Type > &)

	fvPatchField (const fvPatchField< Type > &, const DimensionedField< Type, volMesh > &)

virtual tmp< fvPatchField< Type > >	clone (const DimensionedField< Type, volMesh > &iF) const

Foam::tmp< Foam::fvPatchField< Type > >	NewCalculatedType (const fvPatch &p)

Foam::tmp< Foam::fvPatchField< Type > >	NewCalculatedType (const fvPatchField< Type2 > &pf)

virtual	~fvPatchField ()=default

bool	useImplicit () const noexcept

bool	useImplicit (bool on) noexcept

virtual bool	coupled () const

const objectRegistry &	db () const

const fvPatch &	patch () const

const DimensionedField< Type, volMesh > &	internalField () const

const Field< Type > &	primitiveField () const

const word &	patchType () const

word &	patchType ()

bool	updated () const

bool	manipulatedMatrix () const

virtual void	autoMap (const fvPatchFieldMapper &)

virtual void	rmap (const fvPatchField< Type > &, const labelList &)

virtual tmp< Field< Type > >	snGrad () const

virtual tmp< Field< Type > >	snGrad (const scalarField &deltaCoeffs) const

virtual void	updateWeightedCoeffs (const scalarField &weights)

virtual tmp< Field< Type > >	patchInternalField () const

virtual void	patchInternalField (Field< Type > &) const

virtual tmp< Field< Type > >	patchNeighbourField () const

virtual void	initEvaluate (const Pstream::commsTypes commsType=Pstream::commsTypes::blocking)

virtual void	evaluate (const Pstream::commsTypes commsType=Pstream::commsTypes::blocking)

virtual tmp< Field< Type > >	valueInternalCoeffs (const tmp< Field< scalar >> &) const

virtual tmp< Field< Type > >	valueBoundaryCoeffs (const tmp< Field< scalar >> &) const

virtual tmp< Field< Type > >	gradientInternalCoeffs (const scalarField &deltaCoeffs) const

virtual tmp< Field< Type > >	gradientBoundaryCoeffs (const scalarField &deltaCoeffs) const

virtual void	manipulateMatrix (fvMatrix< Type > &matrix)

virtual void	manipulateMatrix (fvMatrix< Type > &matrix, const scalarField &weights)

virtual void	manipulateMatrix (fvMatrix< Type > &matrix, const label iMatrix, const direction cmp)

void	check (const fvPatchField< Type > &) const

virtual void	operator= (const UList< Type > &)

virtual void	operator= (const fvPatchField< Type > &)

virtual void	operator= (const Type &)

virtual void	operator+= (const fvPatchField< Type > &)

virtual void	operator+= (const Field< Type > &)

virtual void	operator+= (const Type &)

virtual void	operator-= (const fvPatchField< Type > &)

virtual void	operator-= (const Field< Type > &)

virtual void	operator-= (const Type &)

virtual void	operator== (const fvPatchField< Type > &)

virtual void	operator== (const Field< Type > &)

virtual void	operator== (const Type &)

Protected Attributes
scalar	Ceps2_

scalar	Ck_

scalar	Bk_

scalar	C_

Additional Inherited Members
Public Types inherited from fvPatchField< scalar >
typedef fvPatch	Patch

typedef calculatedFvPatchField< Type >	Calculated

Static Public Member Functions inherited from fvPatchField< scalar >
static tmp< fvPatchField< Type > >	New (const word &, const fvPatch &, const DimensionedField< Type, volMesh > &)

static tmp< fvPatchField< Type > >	New (const word &, const word &actualPatchType, const fvPatch &, const DimensionedField< Type, volMesh > &)

static tmp< fvPatchField< Type > >	New (const fvPatchField< Type > &, const fvPatch &, const DimensionedField< Type, volMesh > &, const fvPatchFieldMapper &)

static tmp< fvPatchField< Type > >	New (const fvPatch &, const DimensionedField< Type, volMesh > &, const dictionary &)

static tmp< fvPatchField< Type > >	NewCalculatedType (const fvPatch &)

static tmp< fvPatchField< Type > >	NewCalculatedType (const fvPatchField< Type2 > &)

static const word &	calculatedType ()

Static Public Attributes inherited from fvPatchField< scalar >
static int	disallowGenericFvPatchField

Detailed Description

This boundary condition provides a wall constraint on the turbulent kinetic energy, i.e. k, for low- and high-Reynolds number turbulence models.

Usage

Example of the boundary condition specification:

<patchName>
{
    // Mandatory entries (unmodifiable)
    type            kLowReWallFunction;

    // Optional entries (unmodifiable)
    Ceps2           1.9;
    Ck              -0.416;
    Bk              8.366;
    C               11.0;

    // Optional (inherited) entries
    ...
}

where the entries mean:

Property	Description	Type	Req'd	Dflt
`type`	Type name: kLowReWallFunction	word	yes	-
`Ceps2`	Model coefficient	scalar	no	1.9
`Ck`	Model coefficient	scalar	no	-0.416
`Bk`	Model coefficient	scalar	no	8.366
`C`	Model coefficient	scalar	no	11.0

The inherited entries are elaborated in:

fixedValueFvPatchField.H

Viscous and inertial sublayer predictions for k are blended in a stepwise manner:

$k = k_{log} \qquad if \quad y^+ > y^+_{lam}$

$k = k_{vis} \qquad if \quad y^+ <= y^+_{lam}$

where

$k_{vis}$	=	k prediction in the viscous sublayer
$k_{log}$	=	k prediction in the inertial sublayer
	=	estimated wall-normal height of the cell centre in wall units
$y^+_{lam}$	=	estimated intersection of the viscous and inertial sublayers

Note: The coefficients Cmu, kappa, and E are obtained from the specified nutWallFunction in order to ensure that each patch possesses the same set of values for these coefficients.

See also

Foam::fixedValueFvPatchField
Foam::kqRWallFunctionFvPatchScalarField

Source files

Definition at line 161 of file kLowReWallFunctionFvPatchScalarField.H.

Constructor & Destructor Documentation

◆ kLowReWallFunctionFvPatchScalarField() [1/5]

kLowReWallFunctionFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF
	)

Definition at line 31 of file kLowReWallFunctionFvPatchScalarField.C.

Referenced by kLowReWallFunctionFvPatchScalarField::clone().

Here is the caller graph for this function:

◆ kLowReWallFunctionFvPatchScalarField() [2/5]

kLowReWallFunctionFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const dictionary &	dict
	)

Definition at line 61 of file kLowReWallFunctionFvPatchScalarField.C.

◆ kLowReWallFunctionFvPatchScalarField() [3/5]

kLowReWallFunctionFvPatchScalarField	(	const kLowReWallFunctionFvPatchScalarField &	ptf,
		const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)

Definition at line 45 of file kLowReWallFunctionFvPatchScalarField.C.

◆ kLowReWallFunctionFvPatchScalarField() [4/5]

kLowReWallFunctionFvPatchScalarField ( const kLowReWallFunctionFvPatchScalarField & kwfpsf )

Definition at line 84 of file kLowReWallFunctionFvPatchScalarField.C.

◆ kLowReWallFunctionFvPatchScalarField() [5/5]

kLowReWallFunctionFvPatchScalarField	(	const kLowReWallFunctionFvPatchScalarField &	kwfpsf,
		const DimensionedField< scalar, volMesh > &	iF
	)

Definition at line 97 of file kLowReWallFunctionFvPatchScalarField.C.

Member Function Documentation

◆ TypeName()

TypeName ( "kLowReWallFunction" )

◆ clone() [1/2]

virtual tmp<fvPatchScalarField> clone ( ) const

inlinevirtual

Definition at line 222 of file kLowReWallFunctionFvPatchScalarField.H.

References kLowReWallFunctionFvPatchScalarField::kLowReWallFunctionFvPatchScalarField().

Here is the call graph for this function:

◆ clone() [2/2]

virtual tmp<fvPatchScalarField> clone ( const DimensionedField< scalar, volMesh > & iF ) const

inlinevirtual

Reimplemented from fixedValueFvPatchField< scalar >.

Definition at line 239 of file kLowReWallFunctionFvPatchScalarField.H.

References kLowReWallFunctionFvPatchScalarField::kLowReWallFunctionFvPatchScalarField().

Here is the call graph for this function:

◆ updateCoeffs()

void updateCoeffs ( )

virtual

Reimplemented from fvPatchField< scalar >.

Definition at line 112 of file kLowReWallFunctionFvPatchScalarField.C.

References kLowReWallFunctionFvPatchScalarField::Bk_, kLowReWallFunctionFvPatchScalarField::C_, kLowReWallFunctionFvPatchScalarField::Ceps2_, kLowReWallFunctionFvPatchScalarField::Ck_, fvPatchField< scalar >::db(), fvPatch::faceCells(), forAll, Foam::constant::atomic::group, IOobject::groupName(), fvPatch::index(), fvPatchField< scalar >::internalField(), k, turbulenceModel::k(), Foam::log(), objectRegistry::lookupObject(), Foam::max(), turbulenceModel::nu(), nutWallFunctionFvPatchScalarField::nutw(), fvPatchField< scalar >::patch(), Foam::pow025(), Foam::pow3(), turbulenceModel::propertiesName, Foam::sqr(), Foam::sqrt(), fvPatchField< Type >::updateCoeffs(), fvPatchField< scalar >::updated(), uTau, y, turbulenceModel::y(), and yPlus.

Here is the call graph for this function:

◆ write()

void write ( Ostream & os ) const

virtual

Reimplemented from fixedValueFvPatchField< scalar >.

Definition at line 176 of file kLowReWallFunctionFvPatchScalarField.C.

References os(), fixedValueFvPatchField< Type >::write(), and Ostream::writeEntry().

Here is the call graph for this function:

Member Data Documentation

◆ Ceps2_

scalar Ceps2_

protected

Definition at line 170 of file kLowReWallFunctionFvPatchScalarField.H.

Referenced by kLowReWallFunctionFvPatchScalarField::updateCoeffs().

◆ Ck_

scalar Ck_

protected

Definition at line 173 of file kLowReWallFunctionFvPatchScalarField.H.

Referenced by kLowReWallFunctionFvPatchScalarField::updateCoeffs().

◆ Bk_

scalar Bk_

protected

Definition at line 176 of file kLowReWallFunctionFvPatchScalarField.H.

Referenced by kLowReWallFunctionFvPatchScalarField::updateCoeffs().

◆ C_

scalar C_

protected

Definition at line 179 of file kLowReWallFunctionFvPatchScalarField.H.

Referenced by kLowReWallFunctionFvPatchScalarField::updateCoeffs().

The documentation for this class was generated from the following files:

src/TurbulenceModels/turbulenceModels/derivedFvPatchFields/wallFunctions/kqRWallFunctions/kLowReWallFunction/kLowReWallFunctionFvPatchScalarField.H
src/TurbulenceModels/turbulenceModels/derivedFvPatchFields/wallFunctions/kqRWallFunctions/kLowReWallFunction/kLowReWallFunctionFvPatchScalarField.C

Public Member Functions

Protected Attributes

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ kLowReWallFunctionFvPatchScalarField() [1/5]

◆ kLowReWallFunctionFvPatchScalarField() [2/5]

◆ kLowReWallFunctionFvPatchScalarField() [3/5]

◆ kLowReWallFunctionFvPatchScalarField() [4/5]

◆ kLowReWallFunctionFvPatchScalarField() [5/5]

Member Function Documentation

◆ TypeName()

◆ clone() [1/2]

◆ clone() [2/2]

◆ updateCoeffs()

◆ write()

Member Data Documentation

◆ Ceps2_

◆ Ck_

◆ Bk_

◆ C_
