isoSurfacePoint Class Reference

A surface formed by the iso value. After "Regularised Marching Tetrahedra: improved iso-surface extraction", G.M. Treece, R.W. Prager and A.H. Gee. More...

Inheritance diagram for isoSurfacePoint:

Collaboration diagram for isoSurfacePoint:

Public Member Functions
	TypeName ("isoSurfacePoint")
	isoSurfacePoint (const volScalarField &cellValues, const scalarField &pointValues, const scalar iso, const isoSurfaceParams &params=isoSurfaceParams(), const bitSet &ignoreCells=bitSet())
virtual	~isoSurfacePoint ()=default
virtual tmp< Field< scalar > >	interpolate (const GeometricField< scalar, fvPatchField, volMesh > &cellValues, const Field< scalar > &pointValues) const
	interpolate scalar cellValues, pointValues on iso-surface More...
virtual tmp< Field< vector > >	interpolate (const GeometricField< vector, fvPatchField, volMesh > &cellValues, const Field< vector > &pointValues) const
	interpolate vector cellValues, pointValues on iso-surface More...
virtual tmp< Field< sphericalTensor > >	interpolate (const GeometricField< sphericalTensor, fvPatchField, volMesh > &cellValues, const Field< sphericalTensor > &pointValues) const
	interpolate sphericalTensor cellValues, pointValues on iso-surface More...
virtual tmp< Field< symmTensor > >	interpolate (const GeometricField< symmTensor, fvPatchField, volMesh > &cellValues, const Field< symmTensor > &pointValues) const
	interpolate symmTensor cellValues, pointValues on iso-surface More...
virtual tmp< Field< tensor > >	interpolate (const GeometricField< tensor, fvPatchField, volMesh > &cellValues, const Field< tensor > &pointValues) const
	interpolate tensor cellValues, pointValues on iso-surface More...
template<class Type >
Foam::tmp< Foam::SlicedGeometricField< Type, Foam::fvPatchField, Foam::slicedFvPatchField, Foam::volMesh > >	adaptPatchFields (const GeometricField< Type, fvPatchField, volMesh > &fld) const
template<class Type >
Foam::label	generateFaceTriPoints (const volScalarField &cVals, const scalarField &pVals, const GeometricField< Type, fvPatchField, volMesh > &cCoords, const Field< Type > &pCoords, const DynamicList< Type > &snappedPoints, const labelList &snappedCc, const labelList &snappedPoint, const label facei, const scalar neiVal, const Type &neiPt, const bool hasNeiSnap, const Type &neiSnapPt, DynamicList< Type > &triPoints, DynamicList< label > &triMeshCells) const
template<class Type >
Foam::tmp< Foam::Field< Type > >	interpolate (const label nPoints, const labelList &triPointMergeMap, const labelList &interpolatedPoints, const List< FixedList< label, 3 >> &interpolatedOldPoints, const List< FixedList< scalar, 3 >> &interpolationWeights, const DynamicList< Type > &unmergedValues)
template<class Type >
Foam::tmp< Foam::Field< Type > >	interpolateTemplate (const GeometricField< Type, fvPatchField, volMesh > &cCoords, const Field< Type > &pCoords) const
Public Member Functions inherited from isoSurfaceBase
	isoSurfaceBase (const polyMesh &mesh, const scalarField &cellValues, const scalarField &pointValues, const scalar iso, const isoSurfaceParams &params=isoSurfaceParams())
const polyMesh &	mesh () const noexcept
const scalarField &	cellValues () const noexcept
const scalarField &	pointValues () const noexcept
scalar	isoValue () const noexcept
const labelList &	meshCells () const noexcept
labelList &	meshCells () noexcept
label	blockCells (UList< cutType > &cuts, const bitSet &ignoreCells) const
label	blockCells (UList< cutType > &cuts, const boundBox &bb, const volumeType::type volType) const
void	ignoreCyclics ()
label	calcCellCuts (List< cutType > &cuts) const
cutType	getFaceCutType (const label facei) const
cutType	getCellCutType (const label celli) const
Public Member Functions inherited from MeshedSurface
	ClassName ("MeshedSurface")
	MeshedSurface ()
	MeshedSurface (const MeshedSurface &surf)
	MeshedSurface (const UnsortedMeshedSurface< Face > &surf)
	MeshedSurface (MeshedSurface &&surf)
	MeshedSurface (UnsortedMeshedSurface< Face > &&surf)
	MeshedSurface (const pointField &pointLst, const UList< Face > &faceLst, const UList< surfZone > &zoneLst)
	MeshedSurface (pointField &&pointLst, List< Face > &&faceLst, const UList< surfZone > &zoneLst)
	MeshedSurface (const pointField &pointLst, const UList< Face > &faceLst, const labelUList &zoneSizes=labelUList(), const UList< word > &zoneNames=UList< word >())
	MeshedSurface (pointField &&pointLst, List< Face > &&faceLst, const labelUList &zoneSizes=labelUList(), const UList< word > &zoneNames=UList< word >())
	MeshedSurface (const polyBoundaryMesh &bMesh, const bool globalPoints=false)
	MeshedSurface (const surfMesh &mesh)
	MeshedSurface (const fileName &name)
	MeshedSurface (const fileName &name, const word &fileType)
	MeshedSurface (Istream &is)
	MeshedSurface (const Time &runTime)
	MeshedSurface (const Time &runTime, const word &surfName)
	MeshedSurface (const IOobject &io, const dictionary &dict, const bool isGlobal=true)
	declareRunTimeSelectionTable (autoPtr, MeshedSurface, fileExtension,(const fileName &name),(name))
virtual	~MeshedSurface ()
	declareMemberFunctionSelectionTable (void, UnsortedMeshedSurface, write, fileExtension,(const fileName &name, const MeshedSurface< Face > &surf, IOstreamOption streamOpt, const dictionary &options),(name, surf, streamOpt, options))
label	size () const
const List< Face > &	surfFaces () const
const labelList &	faceIds () const
const surfZoneList &	surfZones () const
const vectorField &	Sf () const
const scalarField &	magSf () const
const vectorField &	Cf () const
virtual void	clear ()
virtual void	addZones (const UList< surfZone > &, const bool cullEmpty=false)
virtual void	addZones (const labelUList &sizes, const UList< word > &names, const bool cullEmpty=false)
virtual void	addZones (const labelUList &sizes, const bool cullEmpty=false)
bool	addZonesToFaces ()
virtual void	removeZones ()
virtual void	movePoints (const pointField &newPoints)
virtual void	scalePoints (const scalar scaleFactor)
virtual void	cleanup (const bool verbose)
virtual void	compactPoints (labelList &pointMap=const_cast< labelList & >(labelList::null()))
virtual bool	stitchFaces (const scalar tol=SMALL, const bool verbose=false)
virtual bool	checkFaces (const bool verbose=false)
virtual label	nTriangles () const
virtual label	nTriangles (labelList &faceMap) const
virtual label	triangulate ()
virtual label	triangulate (labelList &faceMap)
template<class BoolListType >
void	subsetMeshMap (const BoolListType &include, labelList &pointMap, labelList &faceMap) const
MeshedSurface	subsetMesh (const UList< bool > &include, labelList &pointMap, labelList &faceMap) const
MeshedSurface	subsetMesh (const bitSet &include, labelList &pointMap, labelList &faceMap) const
MeshedSurface	subsetMesh (const UList< bool > &include) const
MeshedSurface	subsetMesh (const bitSet &include) const
MeshedSurface	subsetMesh (const wordRes &includeNames, const wordRes &excludeNames=wordRes()) const
void	swap (MeshedSurface< Face > &surf)
void	transfer (pointField &pointLst, List< Face > &faceLst)
void	transfer (MeshedSurface< Face > &surf)
void	transfer (UnsortedMeshedSurface< Face > &surf)
autoPtr< MeshedSurface< Face > >	releaseGeom ()
void	swapFaces (List< Face > &faces)
void	swapPoints (pointField &points)
bool	read (const fileName &name, const word &fileType)
virtual bool	read (const fileName &name)
void	writeStats (Ostream &os) const
virtual void	write (const fileName &name, IOstreamOption streamOpt=IOstreamOption(), const dictionary &options=dictionary::null) const
virtual void	write (const fileName &name, const word &fileType, IOstreamOption streamOpt=IOstreamOption(), const dictionary &options=dictionary::null) const
void	write (const Time &runTime, const word &surfName=word::null) const
void	operator= (const MeshedSurface< Face > &surf)
void	operator= (MeshedSurface< Face > &&surf)
	operator MeshedSurfaceProxy< Face > () const
template<class Face >
	MeshedSurface ()
template<class Face >
	MeshedSurface (const MeshedSurface< Face > &surf)
template<class Face >
	MeshedSurface (const UnsortedMeshedSurface< Face > &surf)
template<class Face >
	MeshedSurface (MeshedSurface< Face > &&surf)
template<class Face >
	MeshedSurface (UnsortedMeshedSurface< Face > &&surf)
template<class Face >
	MeshedSurface (const pointField &pointLst, const UList< Face > &faceLst, const UList< surfZone > &zoneLst)
template<class Face >
	MeshedSurface (pointField &&pointLst, List< Face > &&faceLst, const UList< surfZone > &zoneLst)
template<class Face >
	MeshedSurface (const pointField &pointLst, const UList< Face > &faceLst, const labelUList &zoneSizes, const UList< word > &zoneNames)
template<class Face >
	MeshedSurface (pointField &&pointLst, List< Face > &&faceLst, const labelUList &zoneSizes, const UList< word > &zoneNames)
template<class Face >
	MeshedSurface (const surfMesh &mesh)
template<class Face >
	MeshedSurface (const polyBoundaryMesh &bMesh, const bool useGlobalPoints)
template<class Face >
	MeshedSurface (const fileName &name, const word &fileType)
template<class Face >
	MeshedSurface (const fileName &name)
template<class Face >
	MeshedSurface (Istream &is)
template<class Face >
	MeshedSurface (const Time &runTime)
template<class Face >
	MeshedSurface (const Time &runTime, const word &surfName)
template<class Face >
	MeshedSurface (const IOobject &io, const dictionary &dict, const bool isGlobal)
bool	addZonesToFaces ()
bool	addZonesToFaces ()
Public Member Functions inherited from isoSurfaceParams
	isoSurfaceParams (const algorithmType algo=algorithmType::ALGO_DEFAULT, const filterType filter=filterType::DIAGCELL) noexcept
	isoSurfaceParams (const dictionary &dict, const isoSurfaceParams &params=isoSurfaceParams())
	isoSurfaceParams (const dictionary &dict, const algorithmType algo, const filterType filter=filterType::DIAGCELL)
algorithmType	algorithm () const noexcept
void	algorithm (algorithmType algo) noexcept
filterType	filter () const noexcept
void	filter (filterType fltr) noexcept
bool	snap () const noexcept
void	snap (bool on) noexcept
scalar	mergeTol () const noexcept
void	mergeTol (const scalar relTol) noexcept
const boundBox &	getClipBounds () const noexcept
boundBox &	getClipBounds () noexcept
void	setClipBounds (const boundBox &bb)
void	print (Ostream &os) const

Friends
class	isoSurfaceCell
class	isoSurfaceTopo

Additional Inherited Members
Public Types inherited from isoSurfaceBase
enum	cutType : uint8_t {   NOTCUT = 0, CUT = 0x1, TETCUT = 0x2, SPHERE = 0x4,   ANYCUT = 0xF, UNVISITED = 0x10, BLOCKED = 0x20, SPECIAL = 0xF0 }
enum	algorithmType
enum	filterType
Public Types inherited from MeshedSurface
typedef Face	face_type
typedef point	point_type
Public Types inherited from isoSurfaceParams
enum	algorithmType : uint8_t { ALGO_DEFAULT = 0, ALGO_TOPO, ALGO_CELL, ALGO_POINT }
enum	filterType : uint8_t {   NONE = 0, CELL, DIAGCELL, NONMANIFOLD,   PARTIAL = CELL, FULL = DIAGCELL, CLEAN = NONMANIFOLD }
Static Public Member Functions inherited from isoSurfaceBase
static autoPtr< isoSurfaceBase >	New (const isoSurfaceParams &params, const volScalarField &cellValues, const scalarField &pointValues, const scalar iso, const bitSet &ignoreCells=bitSet())
static void	resetCuts (UList< cutType > &cuts)
Static Public Member Functions inherited from MeshedSurface
static wordHashSet	readTypes ()
static wordHashSet	writeTypes ()
static bool	canReadType (const word &fileType, bool verbose=false)
static bool	canWriteType (const word &fileType, bool verbose=false)
static bool	canRead (const fileName &name, bool verbose=false)
static autoPtr< MeshedSurface >	New (const fileName &name, const word &fileType, bool mandatory=true)
static autoPtr< MeshedSurface >	New (const fileName &name)
static void	write (const fileName &name, const MeshedSurface< Face > &surf, IOstreamOption streamOpt=IOstreamOption(), const dictionary &options=dictionary::null)
static void	write (const fileName &name, const word &fileType, const MeshedSurface< Face > &surf, IOstreamOption streamOpt=IOstreamOption(), const dictionary &options=dictionary::null)
Static Public Member Functions inherited from isoSurfaceParams
static algorithmType	getAlgorithmType (const dictionary &dict, const algorithmType deflt)
static filterType	getFilterType (const dictionary &dict, const filterType deflt)
Static Public Attributes inherited from isoSurfaceParams
static const Enum< algorithmType >	algorithmNames
static const Enum< filterType >	filterNames
Protected Types inherited from isoSurfaceBase
typedef meshedSurface	Mesh
typedef cutType	cellCutType
Protected Member Functions inherited from isoSurfaceBase
template<class Type >
tmp< Field< Type > >	interpolateTemplate (const GeometricField< Type, fvPatchField, volMesh > &cellValues, const Field< Type > &pointValues) const
	isoSurfaceBase (const isoSurfaceBase &)=delete
void	operator= (const isoSurfaceBase &)=delete
Protected Member Functions inherited from MeshedSurface
void	transcribe (MeshedSurface< face > &surf)
void	checkZones (const bool verbose=true)
pointField &	storedPoints ()
List< Face > &	storedFaces ()
labelList &	storedFaceIds ()
surfZoneList &	storedZones ()
void	sortFacesAndStore (DynamicList< Face > &unsortedFaces, DynamicList< label > &zoneIds, DynamicList< label > &elemIds, bool sorted)
virtual void	remapFaces (const labelUList &faceMapNewToOld)
void	transcribe (MeshedSurface< face > &surf)
void	transcribe (MeshedSurface< face > &surf)
void	transcribe (MeshedSurface< face > &surf)
Static Protected Member Functions inherited from isoSurfaceBase
static label	countCutType (const UList< cutType > &cuts, const uint8_t maskValue)
Protected Attributes inherited from isoSurfaceBase
const polyMesh &	mesh_
const scalarField &	cVals_
const scalarField &	pVals_
const scalar	iso_
bitSet	ignoreBoundaryFaces_
labelList	meshCells_

Detailed Description

A surface formed by the iso value. After "Regularised Marching Tetrahedra: improved iso-surface extraction", G.M. Treece, R.W. Prager and A.H. Gee.

Note:

• does tets without using cell centres/cell values. Not tested.
• regularisation can create duplicate triangles/non-manifold surfaces. Current handling of those is bit ad-hoc for now and not perfect.
• regularisation does not do boundary points so as to preserve the boundary perfectly.
• uses geometric merge with fraction of bounding box as distance.
• triangles can be between two cell centres so constant sampling does not make sense.
• on empty patches behaves like zero gradient.
• does not do 2D correctly, creates non-flat iso surface.
• on processor boundaries might two overlapping (identical) triangles (one from either side)

The handling on coupled patches is a bit complex. All fields (values and coordinates) get rewritten so

• empty patches get zerogradient (value) and facecentre (coordinates)
• separated processor patch faces get interpolate (value) and facecentre (coordinates). (this is already the default for cyclics)
• non-separated processor patch faces keep opposite value and cell centre

Now the triangle generation on non-separated processor patch faces can use the neighbouring value. Any separated processor face or cyclic face gets handled just like any boundary face.

Source files

• isoSurfacePoint.H
• isoSurfacePoint.C
• isoSurfacePointTemplates.C

Definition at line 83 of file isoSurfacePoint.H.

Constructor & Destructor Documentation

isoSurfacePoint()

isoSurfacePoint	(	const volScalarField &	cellValues,
		const scalarField &	pointValues,
		const scalar	iso,
		const isoSurfaceParams &	params = isoSurfaceParams(),
		const bitSet &	ignoreCells = bitSet()
	)

Parameters

ignoreCells

unused

Definition at line 1319 of file isoSurfacePoint.C.

References fvMesh::boundary(), primitiveMesh::cellCentres(), triSurface::clearOut(), polyPatch::coupled(), Foam::expressions::patchExpr::debug, Foam::dimLength, Foam::dimless, Foam::endl(), f(), primitiveMesh::faceCentres(), isoSurfaceParams::filter(), forAll, Foam::inplaceRenumber(), isoSurfaceParams::mergeTol(), polyMesh::meshSubDir, Foam::minMax(), Foam::nl, IOobject::NO_READ, IOobject::NO_WRITE, patches, polyPatch::patchSlice(), fileName::path(), polyMesh::pointsInstance(), Foam::Pout, GeometricField::primitiveFieldRef(), bitSet::set(), List::setSize(), FixedList::size(), polyPatch::start(), triSurface::swapPoints(), fvMesh::time(), Time::timeName(), List::transfer(), triSurface::triFaceFaces(), triSurfaceTools::validTri(), triSurface::write(), and Foam::Zero.

Here is the call graph for this function:

~isoSurfacePoint()

virtual ~isoSurfacePoint ( )

virtualdefault

Member Function Documentation

TypeName()

TypeName

(

"isoSurfacePoint"

)

interpolate() [1/6]

virtual tmp<Field< scalar > > interpolate ( const GeometricField< scalar, fvPatchField, volMesh > &  cellValues, const Field< scalar > &  pointValues  ) const

virtual

interpolate scalar cellValues, pointValues on iso-surface

Reimplemented from isoSurfaceBase.

interpolate() [2/6]

Foam::tmp< Foam::Field< Foam::vector > > interpolate ( const GeometricField< vector, fvPatchField, volMesh > &  cellValues, const Field< vector > &  pointValues  ) const

virtual

interpolate vector cellValues, pointValues on iso-surface

Reimplemented from isoSurfaceBase.

Definition at line 33 of file isoSurfacePoint.C.

interpolate() [3/6]

Foam::tmp< Foam::Field< Foam::sphericalTensor > > interpolate ( const GeometricField< sphericalTensor, fvPatchField, volMesh > &  cellValues, const Field< sphericalTensor > &  pointValues  ) const

virtual

interpolate sphericalTensor cellValues, pointValues on iso-surface

Reimplemented from isoSurfaceBase.

Definition at line 33 of file isoSurfacePoint.C.

interpolate() [4/6]

Foam::tmp< Foam::Field< Foam::symmTensor > > interpolate ( const GeometricField< symmTensor, fvPatchField, volMesh > &  cellValues, const Field< symmTensor > &  pointValues  ) const

virtual

interpolate symmTensor cellValues, pointValues on iso-surface

Reimplemented from isoSurfaceBase.

Definition at line 33 of file isoSurfacePoint.C.

interpolate() [5/6]

Foam::tmp< Foam::Field< Foam::tensor > > interpolate ( const GeometricField< tensor, fvPatchField, volMesh > &  cellValues, const Field< tensor > &  pointValues  ) const

virtual

interpolate tensor cellValues, pointValues on iso-surface

Reimplemented from isoSurfaceBase.

Definition at line 33 of file isoSurfacePoint.C.

adaptPatchFields()

Foam::tmp<Foam::SlicedGeometricField< Type, Foam::fvPatchField, Foam::slicedFvPatchField, Foam::volMesh> > adaptPatchFields

(

const GeometricField< Type, fvPatchField, volMesh > &

fld

)

const

Definition at line 40 of file isoSurfacePointTemplates.C.

References f(), fld, forAll, mesh, Foam::New(), patches, fvPatchField::patchInternalField(), and fvPatchField::patchNeighbourField().

Here is the call graph for this function:

generateFaceTriPoints()

Foam::label generateFaceTriPoints	(	const volScalarField &	cVals,
		const scalarField &	pVals,
		const GeometricField< Type, fvPatchField, volMesh > &	cCoords,
		const Field< Type > &	pCoords,
		const DynamicList< Type > &	snappedPoints,
		const labelList &	snappedCc,
		const labelList &	snappedPoint,
		const label	facei,
		const scalar	neiVal,
		const Type &	neiPt,
		const bool	hasNeiSnap,
		const Type &	neiSnapPt,
		DynamicList< Type > &	triPoints,
		DynamicList< label > &	triMeshCells
	)		const

Definition at line 440 of file isoSurfacePointTemplates.C.

References DynamicList::append(), f(), forAll, FixedList::size(), and Foam::Zero.

Here is the call graph for this function:

interpolate() [6/6]

Foam::tmp<Foam::Field<Type> > interpolate	(	const label	nPoints,
		const labelList &	triPointMergeMap,
		const labelList &	interpolatedPoints,
		const List< FixedList< label, 3 >> &	interpolatedOldPoints,
		const List< FixedList< scalar, 3 >> &	interpolationWeights,
		const DynamicList< Type > &	unmergedValues
	)

Definition at line 741 of file isoSurfacePointTemplates.C.

References forAll, Foam::New(), nPoints, Foam::HashTableOps::values(), and Foam::Zero.

Here is the call graph for this function:

interpolateTemplate()

Foam::tmp<Foam::Field<Type> > interpolateTemplate	(	const GeometricField< Type, fvPatchField, volMesh > &	cCoords,
		const Field< Type > &	pCoords
	)		const

Definition at line 804 of file isoSurfacePointTemplates.C.

References Foam::constant::physicoChemical::c2, Foam::interpolate(), and points.

Here is the call graph for this function:

Friends And Related Function Documentation

isoSurfaceCell

friend class isoSurfaceCell

friend

Definition at line 366 of file isoSurfacePoint.H.

isoSurfaceTopo

friend class isoSurfaceTopo

friend

Definition at line 367 of file isoSurfacePoint.H.

---

The documentation for this class was generated from the following files:

• src/sampling/surface/isoSurface/isoSurfacePoint.H
• src/sampling/surface/isoSurface/isoSurfacePoint.C
• src/sampling/surface/isoSurface/isoSurfacePointTemplates.C
