interstitialInletVelocityFvPatchVectorField Class Reference

Inlet velocity in which the actual interstitial velocity is calculated by dividing the specified inletVelocity field with the local phase-fraction. More...

Inheritance diagram for interstitialInletVelocityFvPatchVectorField:

Collaboration diagram for interstitialInletVelocityFvPatchVectorField:

Public Member Functions
	TypeName ("interstitialInletVelocity")
	interstitialInletVelocityFvPatchVectorField (const fvPatch &, const DimensionedField< vector, volMesh > &)
	interstitialInletVelocityFvPatchVectorField (const fvPatch &, const DimensionedField< vector, volMesh > &, const dictionary &)
	interstitialInletVelocityFvPatchVectorField (const interstitialInletVelocityFvPatchVectorField &, const fvPatch &, const DimensionedField< vector, volMesh > &, const fvPatchFieldMapper &)
	interstitialInletVelocityFvPatchVectorField (const interstitialInletVelocityFvPatchVectorField &)
virtual tmp< fvPatchVectorField >	clone () const
	interstitialInletVelocityFvPatchVectorField (const interstitialInletVelocityFvPatchVectorField &, const DimensionedField< vector, volMesh > &)
virtual tmp< fvPatchVectorField >	clone (const DimensionedField< vector, volMesh > &iF) const
virtual void	autoMap (const fvPatchFieldMapper &)
virtual void	rmap (const fvPatchVectorField &, const labelList &)
virtual void	updateCoeffs ()
virtual void	write (Ostream &) const

Detailed Description

Inlet velocity in which the actual interstitial velocity is calculated by dividing the specified inletVelocity field with the local phase-fraction.

Example of the boundary condition specification:

inlet
{
    type              interstitialInletVelocity;
    inletVelocity     uniform (0 0.2 0);// Non-interstitial inlet velocity
    alpha             alpha.particles;  // Name of the phase-fraction field
    value             uniform (0 0 0);
}

Source files

• interstitialInletVelocityFvPatchVectorField.H
• interstitialInletVelocityFvPatchVectorField.C

Definition at line 57 of file interstitialInletVelocityFvPatchVectorField.H.

Constructor & Destructor Documentation

interstitialInletVelocityFvPatchVectorField() [1/5]

interstitialInletVelocityFvPatchVectorField	(	const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF
	)

Definition at line 32 of file interstitialInletVelocityFvPatchVectorField.C.

Referenced by interstitialInletVelocityFvPatchVectorField::clone().

Here is the caller graph for this function:

interstitialInletVelocityFvPatchVectorField() [2/5]

interstitialInletVelocityFvPatchVectorField	(	const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF,
		const dictionary &	dict
	)

Definition at line 60 of file interstitialInletVelocityFvPatchVectorField.C.

interstitialInletVelocityFvPatchVectorField() [3/5]

interstitialInletVelocityFvPatchVectorField	(	const interstitialInletVelocityFvPatchVectorField &	ptf,
		const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)

Definition at line 45 of file interstitialInletVelocityFvPatchVectorField.C.

interstitialInletVelocityFvPatchVectorField() [4/5]

interstitialInletVelocityFvPatchVectorField

(

const interstitialInletVelocityFvPatchVectorField &

ptf

)

Definition at line 74 of file interstitialInletVelocityFvPatchVectorField.C.

interstitialInletVelocityFvPatchVectorField() [5/5]

interstitialInletVelocityFvPatchVectorField	(	const interstitialInletVelocityFvPatchVectorField &	ptf,
		const DimensionedField< vector, volMesh > &	iF
	)

Definition at line 86 of file interstitialInletVelocityFvPatchVectorField.C.

Member Function Documentation

TypeName()

TypeName

(

"interstitialInletVelocity"

)

clone() [1/2]

virtual tmp<fvPatchVectorField> clone ( ) const

inlinevirtual

Definition at line 111 of file interstitialInletVelocityFvPatchVectorField.H.

References interstitialInletVelocityFvPatchVectorField::interstitialInletVelocityFvPatchVectorField().

Here is the call graph for this function:

clone() [2/2]

virtual tmp<fvPatchVectorField> clone ( const DimensionedField< vector, volMesh > &  iF ) const

inlinevirtual

Definition at line 128 of file interstitialInletVelocityFvPatchVectorField.H.

References interstitialInletVelocityFvPatchVectorField::interstitialInletVelocityFvPatchVectorField().

Here is the call graph for this function:

autoMap()

void autoMap ( const fvPatchFieldMapper &  m )

virtual

Definition at line 100 of file interstitialInletVelocityFvPatchVectorField.C.

rmap()

void rmap ( const fvPatchVectorField &  ptf, const labelList &  addr  )

virtual

Definition at line 110 of file interstitialInletVelocityFvPatchVectorField.C.

updateCoeffs()

void updateCoeffs ( )

virtual

Definition at line 124 of file interstitialInletVelocityFvPatchVectorField.C.

References Foam::operator==(), and Foam::foamVersion::patch.

Here is the call graph for this function:

write()

void write ( Ostream &  os ) const

virtual

Definition at line 139 of file interstitialInletVelocityFvPatchVectorField.C.

References os(), fvPatchField::write(), and Ostream::writeEntryIfDifferent().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/finiteVolume/fields/fvPatchFields/derived/interstitialInletVelocity/interstitialInletVelocityFvPatchVectorField.H
• src/finiteVolume/fields/fvPatchFields/derived/interstitialInletVelocity/interstitialInletVelocityFvPatchVectorField.C
