Given triSurface and intersection creates the intersected (properly triangulated) surface. (note: intersection is the list of points and edges 'shared' by two surfaces) More...

Inheritance diagram for intersectedSurface:

[legend]

Collaboration diagram for intersectedSurface:

[legend]

Public Member Functions
	ClassName ("intersectedSurface")

	intersectedSurface ()

	intersectedSurface (const triSurface &surf)

	intersectedSurface (const triSurface &surf, const bool isFirstSurface, const surfaceIntersection &inter)

const labelList &	intersectionEdges () const

const labelList &	faceMap () const

label	nSurfacePoints () const

bool	isSurfacePoint (const label pointi) const

Public Member Functions inherited from triSurface
	ClassName ("triSurface")

	triSurface ()

	triSurface (const triSurface &surf)

	triSurface (triSurface &&surf)

	triSurface (const List< labelledTri > &triangles, const geometricSurfacePatchList &patches, const pointField &pts)

	triSurface (List< labelledTri > &triangles, const geometricSurfacePatchList &patches, pointField &pts, const bool reuse)

	triSurface (const List< labelledTri > &triangles, const pointField &pts)

	triSurface (const triFaceList &triangles, const pointField &pts)

	triSurface (const fileName &name, const scalar scaleFactor=-1)

	triSurface (const fileName &name, const word &fileType, const scalar scaleFactor=-1)

	triSurface (Istream &is)

	triSurface (const Time &d)

	triSurface (const IOobject &io, const dictionary &dict, const bool isGlobal=true)

virtual	~triSurface ()

void	clearOut ()

void	clearTopology ()

void	clearPatchMeshAddr ()

void	swap (triSurface &surf)

const geometricSurfacePatchList &	patches () const noexcept

geometricSurfacePatchList &	patches () noexcept

const List< labelledTri > &	surfFaces () const noexcept

const labelListList &	sortedEdgeFaces () const

const labelList &	edgeOwner () const

const vectorField &	Sf () const

const scalarField &	magSf () const

const vectorField &	Cf () const

List< surfZone >	sortedZones (labelList &faceMap) const

void	triFaceFaces (List< face > &plainFaceList) const

virtual void	movePoints (const pointField &pts)

virtual void	swapPoints (pointField &pts)

virtual void	scalePoints (const scalar scaleFactor)

void	checkTriangles (const bool verbose)

void	checkEdges (const bool verbose)

void	cleanup (const bool verbose)

void	compactPoints (labelList &pointMap=const_cast< labelList & >(labelList::null()))

void	markZone (const boolList &borderEdge, const label facei, const label currentZone, labelList &faceZone) const

label	markZones (const boolList &borderEdge, labelList &faceZone) const

template<class BoolListType >
void	subsetMeshMap (const BoolListType &include, labelList &pointMap, labelList &faceMap) const

triSurface	subsetMesh (const UList< bool > &include, labelList &pointMap, labelList &faceMap) const

triSurface	subsetMesh (const bitSet &include, labelList &pointMap, labelList &faceMap) const

triSurface	subsetMesh (const UList< bool > &include) const

triSurface	subsetMesh (const bitSet &include) const

triSurface	subsetMesh (const wordRes &includeNames, const wordRes &excludeNames=wordRes()) const

void	swapFaces (List< labelledTri > &faceLst)

void	transfer (triSurface &surf)

void	transfer (MeshedSurface< labelledTri > &surf)

void	write (Ostream &os) const

void	write (const fileName &, const bool sortByRegion=false) const

void	write (const fileName &filename, const word &fileType, const bool sortByRegion=false) const

void	write (const Time &d) const

void	writeStats (Ostream &os) const

void	operator= (const triSurface &surf)

void	operator= (triSurface &&surf)

void	operator= (MeshedSurface< labelledTri > &&surf)

Public Member Functions inherited from PrimitivePatch<::Foam::List< labelledTri >, pointField >
	PrimitivePatch (const ::Foam::List< labelledTri > &faces, const pointField &points)

	PrimitivePatch (::Foam::List< labelledTri > &&faces, const pointField &points)

	PrimitivePatch (::Foam::List< labelledTri > &faces, pointField &points, const bool reuse)

	PrimitivePatch (const PrimitivePatch< ::Foam::List< labelledTri >, pointField > &pp)

virtual	~PrimitivePatch ()

void	clearOut ()

void	clearGeom ()

void	clearTopology ()

void	clearPatchMeshAddr ()

void	swap (PrimitivePatch &)=delete

const Field< point_type > &	points () const noexcept

label	nFaces () const noexcept

label	nPoints () const

label	nEdges () const

const edgeList &	edges () const

const edgeList::subList	internalEdges () const

const edgeList::subList	boundaryEdges () const

label	nInternalEdges () const

label	nBoundaryEdges () const

bool	isInternalEdge (const label edgei) const

const labelList &	boundaryPoints () const

const labelListList &	faceFaces () const

const labelListList &	edgeFaces () const

const labelListList &	faceEdges () const

const labelListList &	pointEdges () const

const labelListList &	pointFaces () const

const List< face_type > &	localFaces () const

labelList	boundaryFaces () const

labelList	uniqBoundaryFaces () const

const labelList &	meshPoints () const

const Map< label > &	meshPointMap () const

const Field< point_type > &	localPoints () const

const labelList &	localPointOrder () const

label	whichPoint (const label gp) const

edge	meshEdge (const label edgei) const

edge	meshEdge (const edge &e) const

label	meshEdge (const label edgei, const edgeList &allEdges, const labelListList &pointEdges) const

label	findEdge (const edge &e) const

labelList	meshEdges (const edgeList &allEdges, const labelListList &cellEdges, const labelList &faceCells) const

labelList	meshEdges (const edgeList &allEdges, const labelListList &pointEdges) const

labelList	meshEdges (const labelUList &edgeLabels, const edgeList &allEdges, const labelListList &pointEdges) const

const Field< point_type > &	faceCentres () const

const Field< point_type > &	faceAreas () const

const Field< scalar > &	magFaceAreas () const

const Field< point_type > &	faceNormals () const

const Field< point_type > &	pointNormals () const

bool	hasFaceAreas () const

bool	hasFaceCentres () const

bool	hasFaceNormals () const

bool	hasPointNormals () const

bool	hasBoundaryPoints () const

bool	hasFaceFaces () const

bool	hasEdgeFaces () const

bool	hasFaceEdges () const

bool	hasPointEdges () const

bool	hasPointFaces () const

bool	hasMeshPointMap () const

List< objectHit >	projectPoints (const ToPatch &targetPatch, const Field< point_type > &projectionDirection, const intersection::algorithm=intersection::FULL_RAY, const intersection::direction=intersection::VECTOR) const

Foam::List< Foam::objectHit >	projectPoints (const ToPatch &targetPatch, const Field< typename Foam::PrimitivePatch< ::Foam::List< labelledTri >, pointField >::point_type > &projectionDirection, const intersection::algorithm alg, const intersection::direction dir) const

List< objectHit >	projectFaceCentres (const ToPatch &targetPatch, const Field< point_type > &projectionDirection, const intersection::algorithm=intersection::FULL_RAY, const intersection::direction=intersection::VECTOR) const

Foam::List< Foam::objectHit >	projectFaceCentres (const ToPatch &targetPatch, const Field< typename Foam::PrimitivePatch< ::Foam::List< labelledTri >, pointField >::point_type > &projectionDirection, const intersection::algorithm alg, const intersection::direction dir) const

const labelListList &	edgeLoops () const

surfaceTopo	surfaceType () const

bool	checkTopology (const bool report=false, labelHashSet *setPtr=nullptr) const

bool	checkPointManifold (const bool report=false, labelHashSet *setPtr=nullptr) const

virtual void	movePoints (const Field< point_type > &)

void	operator= (const PrimitivePatch< ::Foam::List< labelledTri >, pointField > &rhs)

void	operator= (PrimitivePatch< ::Foam::List< labelledTri >, pointField > &&rhs)

label	whichEdge (const edge &e) const

Public Member Functions inherited from PrimitivePatchBase
	ClassName ("PrimitivePatch")

	PrimitivePatchBase ()=default

Public Member Functions inherited from List< labelledTri >
constexpr	List () noexcept

	List (const label len)

	List (const label len, const T &val)

	List (const label len, const Foam::zero)

	List (const Foam::one, const T &val)

	List (const Foam::one, T &&val)

	List (const Foam::one, const Foam::zero)

	List (const List< T > &a)

	List (const UList< T > &a)

	List (List< T > &a, bool reuse)

	List (const UList< T > &list, const labelUList &indices)

	List (const UList< T > &list, const FixedList< label, N > &indices)

	List (const FixedList< T, N > &list)

	List (const PtrList< T > &list)

	List (const SLList< T > &list)

	List (const IndirectListBase< T, Addr > &list)

	List (std::initializer_list< T > list)

	List (List< T > &&list)

	List (DynamicList< T, SizeMin > &&list)

	List (SortableList< T > &&list)

	List (SLList< T > &&list)

	List (Istream &is)

	List (const label len)

	List (const label len, const T &val)

	List (const label len, const Foam::zero)

	List (const Foam::one, const T &val)

	List (const Foam::one, T &&val)

	List (const Foam::one, const Foam::zero)

	List (const UList< T > &a)

	List (const List< T > &a)

	List (List< T > &a, bool reuse)

	List (const UList< T > &list, const labelUList &indices)

	List (const PtrList< T > &list)

	List (const SLList< T > &list)

	List (std::initializer_list< T > list)

	List (List< T > &&list)

	List (SortableList< T > &&list)

	List (SLList< T > &&list)

constexpr	List () noexcept

	List (Istream &is)

autoPtr< List< T > >	clone () const

	~List ()

void	clear ()

void	resize (const label len)

void	resize (const label len, const T &val)

void	resize (const label newLen)

void	resize_nocopy (const label len)

void	setSize (const label n)

void	setSize (const label n, const T &val)

void	append (const T &val)

void	append (T &&val)

void	append (const UList< T > &list)

void	append (const IndirectListBase< T, Addr > &list)

void	append (const T &val)

void	append (T &&val)

void	append (const UList< T > &list)

label	appendUniq (const T &val)

void	transfer (List< T > &list)

void	transfer (DynamicList< T, SizeMin > &list)

void	transfer (SortableList< T > &list)

void	transfer (List< T > &list)

void	transfer (SortableList< T > &list)

T &	newElmt (const label i)

void	operator= (const UList< T > &a)

void	operator= (const List< T > &list)

void	operator= (const SLList< T > &list)

void	operator= (const IndirectListBase< T, Addr > &list)

void	operator= (const FixedList< T, N > &list)

void	operator= (std::initializer_list< T > list)

void	operator= (const T &val)

void	operator= (const Foam::zero)

void	operator= (List< T > &&list)

void	operator= (DynamicList< T, SizeMin > &&list)

void	operator= (SortableList< T > &&list)

void	operator= (SLList< T > &&list)

void	operator= (const UList< T > &a)

void	operator= (const List< T > &list)

void	operator= (const SLList< T > &list)

void	operator= (std::initializer_list< T > list)

void	operator= (List< T > &&list)

void	operator= (SortableList< T > &&list)

void	operator= (SLList< T > &&list)

void	operator= (const T &val)

void	operator= (const Foam::zero)

Istream &	readList (Istream &is)

Istream &	readList (Istream &is)

Istream &	readList (Istream &is)

void	shallowCopy (const UList< T > &)=delete

std::enable_if< std::is_same< bool, TypeT >::value, bool >::type	set (const label i, bool val=true)

Static Public Attributes
static const label	UNVISITED = 0

static const label	STARTTOEND = 1

static const label	ENDTOSTART = 2

static const label	BOTH = STARTTOEND \| ENDTOSTART

Additional Inherited Members
Public Types inherited from triSurface
typedef bool	BoundaryMesh

typedef labelledTri	face_type

typedef point	point_type

Public Types inherited from PrimitivePatch<::Foam::List< labelledTri >, pointField >
enum	surfaceTopo

typedef std::remove_reference< ::Foam::List< labelledTri > >::type::value_type	face_type

typedef std::remove_reference< pointField >::type::value_type	point_type

typedef ::Foam::List< labelledTri >	FaceListType

typedef pointField	PointFieldType

typedef face_type	FaceType

Public Types inherited from List< labelledTri >
typedef SubList< T >	subList

Static Public Member Functions inherited from triSurface
static fileName	triSurfInstance (const Time &)

static wordHashSet	readTypes ()

static wordHashSet	writeTypes ()

static bool	canReadType (const word &fileType, bool verbose=false)

static bool	canWriteType (const word &fileType, bool verbose=false)

static bool	canRead (const fileName &name, bool verbose=false)

static fileName	relativeFilePath (const IOobject &io, const fileName &f, const bool isGlobal=true)

static fileName	checkFile (const IOobject &io, const bool isGlobal=true)

static fileName	checkFile (const IOobject &io, const dictionary &dict, const bool isGlobal=true)

static fileName	findFile (const IOobject &io, const bool isGlobal=true)

static fileName	findFile (const IOobject &io, const dictionary &dict, const bool isGlobal=true)

static autoPtr< triSurface >	New (const fileName &name, const word &fileType)

static autoPtr< triSurface >	New (const fileName &name)

Static Public Member Functions inherited from List< labelledTri >
static const List< T > &	null ()

Protected Member Functions inherited from triSurface
pointField &	storedPoints ()

List< labelledTri > &	storedFaces ()

Detailed Description

Given triSurface and intersection creates the intersected (properly triangulated) surface. (note: intersection is the list of points and edges 'shared' by two surfaces)

Algorithm:

from the intersection get the points created on the edges of the surface
split the edges of the surface
construct a new edgeList with (in this order) the edges from the intersection ('cuts', i.e. the edges shared with the other surface) and the (split) edges from the original triangles (from 0 .. nSurfaceEdges)
construct face-edge addressing for above edges
for each face do a right-handed walk to reconstruct faces (splitFace)
retriangulate resulting faces (might be non-convex so use faceTriangulation which does proper bisection)

The resulting surface will have the points from the surface first in the point list (0 .. nSurfacePoints-1)

Note: problematic are the cut-edges which are completely inside a face. These will not be visited by a edge-point-edge walk. These are handled by resplitFace which first connects the 'floating' edges to triangle edges with two extra edges and then tries the splitting again. Seems to work (mostly). Will probably fail for boundary edge (edge with only face).

Note: points are compact, i.e. points().size() == localPoints().size() (though points() probably not localPoints())

Source files

Definition at line 79 of file intersectedSurface.H.

Constructor & Destructor Documentation

◆ intersectedSurface() [1/3]

intersectedSurface ( )

Definition at line 994 of file intersectedSurface.C.

◆ intersectedSurface() [2/3]

intersectedSurface ( const triSurface & surf )

Definition at line 1003 of file intersectedSurface.C.

◆ intersectedSurface() [3/3]

intersectedSurface	(	const triSurface &	surf,
		const bool	isFirstSurface,
		const surfaceIntersection &	inter
	)

Member Function Documentation

◆ ClassName()

ClassName ( "intersectedSurface" )

◆ intersectionEdges()

const labelList& intersectionEdges ( ) const

inline

Definition at line 266 of file intersectedSurface.H.

Referenced by booleanSurface::booleanSurface().

Here is the caller graph for this function:

◆ faceMap()

const labelList& faceMap ( ) const

inline

Definition at line 272 of file intersectedSurface.H.

Referenced by booleanSurface::booleanSurface().

Here is the caller graph for this function:

◆ nSurfacePoints()

label nSurfacePoints ( ) const

inline

Definition at line 278 of file intersectedSurface.H.

Referenced by booleanSurface::booleanSurface().

Here is the caller graph for this function:

◆ isSurfacePoint()

bool isSurfacePoint ( const label pointi ) const

inline

Definition at line 284 of file intersectedSurface.H.

Referenced by booleanSurface::booleanSurface().

Here is the caller graph for this function:

Member Data Documentation

◆ UNVISITED

const Foam::label UNVISITED = 0

static

Definition at line 85 of file intersectedSurface.H.

◆ STARTTOEND

const Foam::label STARTTOEND = 1

static

Definition at line 86 of file intersectedSurface.H.

◆ ENDTOSTART

const Foam::label ENDTOSTART = 2

static

Definition at line 87 of file intersectedSurface.H.

◆ BOTH

const Foam::label BOTH = STARTTOEND | ENDTOSTART

static

Definition at line 88 of file intersectedSurface.H.

The documentation for this class was generated from the following files:

src/meshTools/triSurface/booleanOps/intersectedSurface/intersectedSurface.H
src/meshTools/triSurface/booleanOps/intersectedSurface/intersectedSurface.C
