interpolationCellPointWallModified< Type > Class Template Reference

Same as interpolationCellPoint, but if interpolating a wall face, uses cell centre value instead. More...

Inheritance diagram for interpolationCellPointWallModified< Type >:

Collaboration diagram for interpolationCellPointWallModified< Type >:

Public Member Functions
	TypeName ("cellPointWallModified")
	interpolationCellPointWallModified (const GeometricField< Type, fvPatchField, volMesh > &psi)
Type	interpolate (const cellPointWeightWallModified &cpw) const
Type	interpolate (const vector &position, const label celli, const label facei=-1) const
Type	interpolate (const barycentric &coordinates, const tetIndices &tetIs, const label facei=-1) const
Public Member Functions inherited from interpolationCellPoint< Type >
	TypeName ("cellPoint")
	interpolationCellPoint (const GeometricField< Type, fvPatchField, volMesh > &psi)
Type	interpolate (const cellPointWeight &cpw) const
Public Member Functions inherited from interpolation< Type >
virtual const word &	type () const=0
	declareRunTimeSelectionTable (autoPtr, interpolation, dictionary,(const GeometricField< Type, fvPatchField, volMesh > &psi),(psi))
	interpolation (const GeometricField< Type, fvPatchField, volMesh > &psi)
virtual	~interpolation ()=default
const GeometricField< Type, fvPatchField, volMesh > &	psi () const

Additional Inherited Members
Static Public Member Functions inherited from interpolation< Type >
static autoPtr< interpolation< Type > >	New (const word &interpolationType, const GeometricField< Type, fvPatchField, volMesh > &psi)
static autoPtr< interpolation< Type > >	New (const dictionary &interpolationSchemes, const GeometricField< Type, fvPatchField, volMesh > &psi)
Protected Attributes inherited from interpolationCellPoint< Type >
const GeometricField< Type, pointPatchField, pointMesh >	psip_
Protected Attributes inherited from interpolation< Type >
const GeometricField< Type, fvPatchField, volMesh > &	psi_
const polyMesh &	pMesh_
const vectorField &	pMeshPoints_
const faceList &	pMeshFaces_
const vectorField &	pMeshFaceCentres_
const vectorField &	pMeshFaceAreas_

Detailed Description

template<class Type>
class Foam::interpolationCellPointWallModified< Type >

Same as interpolationCellPoint, but if interpolating a wall face, uses cell centre value instead.

Definition at line 44 of file interpolationCellPointWallModified.H.

Constructor & Destructor Documentation

interpolationCellPointWallModified()

interpolationCellPointWallModified

(

const GeometricField< Type, fvPatchField, volMesh > &

psi

)

Definition at line 28 of file interpolationCellPointWallModified.C.

Member Function Documentation

TypeName()

TypeName

(

"cellPointWallModified"

)

interpolate() [1/3]

Type interpolate ( const cellPointWeightWallModified &  cpw ) const

inline

Definition at line 25 of file interpolationCellPointWallModifiedI.H.

References cellPointWeight::cell(), cellPointWeight::faceVertices(), and cellPointWeight::weights().

Here is the call graph for this function:

interpolate() [2/3]

Type interpolate ( const vector &  position, const label  celli, const label  facei = -1  ) const

inlinevirtual

Reimplemented from interpolationCellPoint< Type >.

Definition at line 43 of file interpolationCellPointWallModifiedI.H.

References Foam::fac::interpolate().

Here is the call graph for this function:

interpolate() [3/3]

Type interpolate ( const barycentric &  coordinates, const tetIndices &  tetIs, const label  facei = -1  ) const

inlinevirtual

Reimplemented from interpolationCellPoint< Type >.

Definition at line 64 of file interpolationCellPointWallModifiedI.H.

References tetIndices::cell(), coordinates(), Foam::exit(), tetIndices::face(), Foam::FatalError, FatalErrorInFunction, Foam::fac::interpolate(), and polyBoundaryMesh::whichPatch().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/finiteVolume/interpolation/interpolation/interpolationCellPointWallModified/interpolationCellPointWallModified.H
• src/finiteVolume/interpolation/interpolation/interpolationCellPointWallModified/interpolationCellPointWallModified.C
• src/finiteVolume/interpolation/interpolation/interpolationCellPointWallModified/interpolationCellPointWallModifiedI.H
