interpolationCellPatchConstrained< Type > Class Template Reference

Uses the cell value for any point in the cell apart from a boundary face where it uses the boundary value directly. Note: will not work on an empty patch. More...

Inheritance diagram for interpolationCellPatchConstrained< Type >:

Collaboration diagram for interpolationCellPatchConstrained< Type >:

Public Member Functions
	TypeName ("cellPatchConstrained")
	interpolationCellPatchConstrained (const GeometricField< Type, fvPatchField, volMesh > &psi)
Type	interpolate (const vector &position, const label celli, const label facei=-1) const
Type	interpolate (const barycentric &coordinates, const tetIndices &tetIs, const label facei=-1) const
Public Member Functions inherited from interpolation< Type >
virtual const word &	type () const=0
	declareRunTimeSelectionTable (autoPtr, interpolation, dictionary,(const GeometricField< Type, fvPatchField, volMesh > &psi),(psi))
	interpolation (const GeometricField< Type, fvPatchField, volMesh > &psi)
virtual	~interpolation ()=default
const GeometricField< Type, fvPatchField, volMesh > &	psi () const

Additional Inherited Members
Static Public Member Functions inherited from interpolation< Type >
static autoPtr< interpolation< Type > >	New (const word &interpolationType, const GeometricField< Type, fvPatchField, volMesh > &psi)
static autoPtr< interpolation< Type > >	New (const dictionary &interpolationSchemes, const GeometricField< Type, fvPatchField, volMesh > &psi)
Protected Attributes inherited from interpolation< Type >
const GeometricField< Type, fvPatchField, volMesh > &	psi_
const polyMesh &	pMesh_
const vectorField &	pMeshPoints_
const faceList &	pMeshFaces_
const vectorField &	pMeshFaceCentres_
const vectorField &	pMeshFaceAreas_

Detailed Description

template<class Type>
class Foam::interpolationCellPatchConstrained< Type >

Uses the cell value for any point in the cell apart from a boundary face where it uses the boundary value directly. Note: will not work on an empty patch.

Definition at line 46 of file interpolationCellPatchConstrained.H.

Constructor & Destructor Documentation

interpolationCellPatchConstrained()

interpolationCellPatchConstrained

(

const GeometricField< Type, fvPatchField, volMesh > &

psi

)

Definition at line 28 of file interpolationCellPatchConstrained.C.

Member Function Documentation

TypeName()

TypeName

(

"cellPatchConstrained"

)

interpolate() [1/2]

Type interpolate ( const vector &  position, const label  celli, const label  facei = -1  ) const

virtual

Implements interpolation< Type >.

Definition at line 40 of file interpolationCellPatchConstrained.C.

References polyMesh::boundaryMesh(), polyBoundaryMesh::mesh(), and polyBoundaryMesh::patchID().

Referenced by interpolationCellPatchConstrained< Type >::interpolate().

Here is the call graph for this function:

Here is the caller graph for this function:

interpolate() [2/2]

Type interpolate ( const barycentric &  coordinates, const tetIndices &  tetIs, const label  facei = -1  ) const

inlinevirtual

Reimplemented from interpolation< Type >.

Definition at line 80 of file interpolationCellPatchConstrained.H.

References tetIndices::cell(), interpolationCellPatchConstrained< Type >::interpolate(), and VectorSpace< Vector< scalar >, scalar, 3 >::zero.

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/finiteVolume/interpolation/interpolation/interpolationCellPatchConstrained/interpolationCellPatchConstrained.H
• src/finiteVolume/interpolation/interpolation/interpolationCellPatchConstrained/interpolationCellPatchConstrained.C
