Public Member Functions | Protected Member Functions | Protected Attributes | List of all members
qZeta Class Reference

Gibson and Dafa'Alla's q-zeta two-equation low-Re turbulence model for incompressible flows. More...

Inheritance diagram for qZeta:
Inheritance graph
[legend]
Collaboration diagram for qZeta:
Collaboration graph
[legend]

Public Member Functions

 TypeName ("qZeta")

 qZeta (const geometricOneField &alpha, const geometricOneField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName, const word &type=typeName)

virtual ~qZeta ()=default

virtual bool read ()

const dimensionedScalar & qMin () const

const dimensionedScalar & zetaMin () const

dimensionedScalar & qMin ()

dimensionedScalar & zetaMin ()

tmp< volScalarField > DqEff () const

tmp< volScalarField > DzetaEff () const

virtual tmp< volScalarField > k () const

virtual tmp< volScalarField > epsilon () const

virtual const volScalarField & q () const

virtual const volScalarField & zeta () const

virtual void correct ()

- Public Member Functions inherited from eddyViscosity< incompressible::RASModel >
 eddyViscosity (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)

virtual ~eddyViscosity ()=default

virtual tmp< volScalarField > nut () const

virtual tmp< scalarField > nut (const label patchi) const

virtual tmp< volScalarField > k () const=0

virtual tmp< volSymmTensorField > R () const

virtual void validate ()

- Public Member Functions inherited from linearViscousStress< incompressible::RASModel >
 linearViscousStress (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)

virtual ~linearViscousStress ()=default

virtual tmp< volSymmTensorField > devRhoReff () const

virtual tmp< volSymmTensorField > devRhoReff (const volVectorField &U) const

virtual tmp< fvVectorMatrix > divDevRhoReff (volVectorField &U) const

virtual tmp< fvVectorMatrix > divDevRhoReff (const volScalarField &rho, volVectorField &U) const


Protected Member Functions

tmp< volScalarField > fMu () const

tmp< volScalarField > f2 () const

virtual void correctNut ()


Protected Attributes

dimensionedScalar Cmu_

dimensionedScalar C1_

dimensionedScalar C2_

dimensionedScalar sigmaZeta_

Switch anisotropic_

dimensionedScalar qMin_

dimensionedScalar zetaMin_

volScalarField k_

volScalarField epsilon_

volScalarField q_

volScalarField zeta_

- Protected Attributes inherited from eddyViscosity< incompressible::RASModel >
volScalarField nut_


Additional Inherited Members

- Public Types inherited from eddyViscosity< incompressible::RASModel >
typedef incompressible::RASModel ::alphaField alphaField

typedef incompressible::RASModel ::rhoField rhoField

typedef incompressible::RASModel ::transportModel transportModel

- Public Types inherited from linearViscousStress< incompressible::RASModel >
typedef incompressible::RASModel ::alphaField alphaField

typedef incompressible::RASModel ::rhoField rhoField

typedef incompressible::RASModel ::transportModel transportModel


Detailed Description

Gibson and Dafa'Alla's q-zeta two-equation low-Re turbulence model for incompressible flows.

This turbulence model is described in:

    Dafa'Alla, A.A., Juntasaro, E. & Gibson, M.M. (1996).
    Calculation of oscillating boundary layers with the
    q-zeta turbulence model.
    Engineering Turbulence Modelling and Experiments 3:
    Proceedings of the Third International Symposium,
    Crete, Greece, May 27-29, 141.

which is a development of the original q-zeta model described in:

    Gibson, M. M., & Dafa'Alla, A. A. (1995).
    Two-equation model for turbulent wall flow.
    AIAA journal, 33(8), 1514-1518.
Source files

Definition at line 72 of file qZeta.H.

Constructor & Destructor Documentation

◆ qZeta()

qZeta ( const geometricOneField &  alpha,
const geometricOneField &  rho,
const volVectorField &  U,
const surfaceScalarField &  alphaRhoPhi,
const surfaceScalarField &  phi,
const transportModel &  transport,
const word &  propertiesName = turbulenceModel::propertiesName,
const word &  type = typeName
)

Definition at line 76 of file qZeta.C.

References Foam::bound(), and Foam::type().

Here is the call graph for this function:

◆ ~qZeta()

virtual ~qZeta ( )
virtualdefault

Member Function Documentation

◆ fMu()

tmp< volScalarField > fMu ( ) const
protected

Definition at line 42 of file qZeta.C.

References qZeta::anisotropic_, Foam::exp(), qZeta::k_, nu, Foam::pow3(), qZeta::q_, Foam::sqr(), and qZeta::zeta_.

Referenced by qZeta::correctNut().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ f2()

tmp< volScalarField > f2 ( ) const
protected

Definition at line 59 of file qZeta.C.

References Foam::exp(), qZeta::k_, nu, qZeta::q_, Foam::sqr(), and qZeta::zeta_.

Referenced by qZeta::correct().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ correctNut()

void correctNut ( )
protectedvirtual

Implements eddyViscosity< incompressible::RASModel >.

Definition at line 66 of file qZeta.C.

References qZeta::Cmu_, GeometricField::correctBoundaryConditions(), qZeta::epsilon_, qZeta::fMu(), qZeta::k_, eddyViscosity< incompressible::RASModel >::nut_, and Foam::sqr().

Referenced by qZeta::correct().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ TypeName()

TypeName ( "qZeta"  )

◆ read()

bool read ( )
virtual

Implements eddyViscosity< incompressible::RASModel >.

Definition at line 213 of file qZeta.C.

References qZeta::anisotropic_, qZeta::C1_, qZeta::C2_, qZeta::Cmu_, qZeta::qMin_, Switch::readIfPresent(), dimensioned::readIfPresent(), qZeta::sigmaZeta_, and qZeta::zetaMin_.

Here is the call graph for this function:

◆ qMin() [1/2]

const dimensionedScalar& qMin ( ) const
inline

Definition at line 142 of file qZeta.H.

References qZeta::qMin_.

◆ zetaMin() [1/2]

const dimensionedScalar& zetaMin ( ) const
inline

Definition at line 148 of file qZeta.H.

References qZeta::zetaMin_.

◆ qMin() [2/2]

dimensionedScalar& qMin ( )
inline

Definition at line 154 of file qZeta.H.

References qZeta::qMin_.

◆ zetaMin() [2/2]

dimensionedScalar& zetaMin ( )
inline

Definition at line 160 of file qZeta.H.

References qZeta::zetaMin_.

◆ DqEff()

tmp<volScalarField> DqEff ( ) const
inline

Definition at line 166 of file qZeta.H.

References nu, and eddyViscosity< incompressible::RASModel >::nut_.

Referenced by qZeta::correct().

Here is the caller graph for this function:

◆ DzetaEff()

tmp<volScalarField> DzetaEff ( ) const
inline

Definition at line 175 of file qZeta.H.

References nu, eddyViscosity< incompressible::RASModel >::nut_, and qZeta::sigmaZeta_.

Referenced by qZeta::correct().

Here is the caller graph for this function:

◆ k()

virtual tmp<volScalarField> k ( ) const
inlinevirtual

Definition at line 184 of file qZeta.H.

References qZeta::k_.

◆ epsilon()

virtual tmp<volScalarField> epsilon ( ) const
inlinevirtual

Definition at line 190 of file qZeta.H.

References qZeta::epsilon_.

◆ q()

virtual const volScalarField& q ( ) const
inlinevirtual

Definition at line 195 of file qZeta.H.

References qZeta::q_.

◆ zeta()

virtual const volScalarField& zeta ( ) const
inlinevirtual

Definition at line 200 of file qZeta.H.

References qZeta::zeta_.

◆ correct()

void correct ( )
virtual

Implements eddyViscosity< incompressible::RASModel >.

Definition at line 233 of file qZeta.C.

References Foam::bound(), qZeta::C1_, qZeta::C2_, eddyViscosity< BasicTurbulenceModel >::correct(), GeometricField::correctBoundaryConditions(), qZeta::correctNut(), Foam::fvm::ddt(), Foam::fvm::div(), qZeta::DqEff(), qZeta::DzetaEff(), qZeta::epsilon_, qZeta::f2(), Foam::constant::universal::G, Foam::fvc::grad(), qZeta::k_, Foam::fvm::laplacian(), Foam::magSqr(), Foam::fvc::magSqrGradGrad(), nu, eddyViscosity< incompressible::RASModel >::nut_, qZeta::q_, qZeta::qMin_, tmp::ref(), Foam::solve(), Foam::fvm::Sp(), Foam::sqr(), Foam::fvm::SuSp(), Foam::symm(), qZeta::zeta_, and qZeta::zetaMin_.

Here is the call graph for this function:

Member Data Documentation

◆ Cmu_

dimensionedScalar Cmu_
protected

Definition at line 83 of file qZeta.H.

Referenced by qZeta::correctNut(), and qZeta::read().

◆ C1_

dimensionedScalar C1_
protected

Definition at line 84 of file qZeta.H.

Referenced by qZeta::correct(), and qZeta::read().

◆ C2_

dimensionedScalar C2_
protected

Definition at line 85 of file qZeta.H.

Referenced by qZeta::correct(), and qZeta::read().

◆ sigmaZeta_

dimensionedScalar sigmaZeta_
protected

Definition at line 86 of file qZeta.H.

Referenced by qZeta::DzetaEff(), and qZeta::read().

◆ anisotropic_

Switch anisotropic_
protected

Definition at line 87 of file qZeta.H.

Referenced by qZeta::fMu(), and qZeta::read().

◆ qMin_

dimensionedScalar qMin_
protected

Definition at line 90 of file qZeta.H.

Referenced by qZeta::correct(), qZeta::qMin(), and qZeta::read().

◆ zetaMin_

dimensionedScalar zetaMin_
protected

Definition at line 93 of file qZeta.H.

Referenced by qZeta::correct(), qZeta::read(), and qZeta::zetaMin().

◆ k_

volScalarField k_
protected

Definition at line 97 of file qZeta.H.

Referenced by qZeta::correct(), qZeta::correctNut(), qZeta::f2(), qZeta::fMu(), and qZeta::k().

◆ epsilon_

volScalarField epsilon_
protected

Definition at line 98 of file qZeta.H.

Referenced by qZeta::correct(), qZeta::correctNut(), and qZeta::epsilon().

◆ q_

volScalarField q_
protected

Definition at line 100 of file qZeta.H.

Referenced by qZeta::correct(), qZeta::f2(), qZeta::fMu(), and qZeta::q().

◆ zeta_

volScalarField zeta_
protected

Definition at line 101 of file qZeta.H.

Referenced by qZeta::correct(), qZeta::f2(), qZeta::fMu(), and qZeta::zeta().

The documentation for this class was generated from the following files:
