Public Member Functions | Protected Member Functions | Protected Attributes | List of all members
LienLeschziner Class Reference

Lien and Leschziner low-Reynolds number k-epsilon turbulence model for incompressible flows. More...

Inheritance diagram for LienLeschziner:
Inheritance graph
[legend]
Collaboration diagram for LienLeschziner:
Collaboration graph
[legend]

Public Member Functions

 TypeName ("LienLeschziner")

 LienLeschziner (const geometricOneField &alpha, const geometricOneField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName, const word &type=typeName)

virtual ~LienLeschziner ()=default

virtual bool read ()

tmp< volScalarField > DkEff () const

tmp< volScalarField > DepsilonEff () const

virtual tmp< volScalarField > k () const

virtual tmp< volScalarField > epsilon () const

virtual void correct ()

- Public Member Functions inherited from eddyViscosity< incompressible::RASModel >
 eddyViscosity (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)

virtual ~eddyViscosity ()=default

virtual tmp< volScalarField > nut () const

virtual tmp< scalarField > nut (const label patchi) const

virtual tmp< volScalarField > k () const=0

virtual tmp< volSymmTensorField > R () const

virtual void validate ()

- Public Member Functions inherited from linearViscousStress< incompressible::RASModel >
 linearViscousStress (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)

virtual ~linearViscousStress ()=default

virtual tmp< volSymmTensorField > devRhoReff () const

virtual tmp< volSymmTensorField > devRhoReff (const volVectorField &U) const

virtual tmp< fvVectorMatrix > divDevRhoReff (volVectorField &U) const

virtual tmp< fvVectorMatrix > divDevRhoReff (const volScalarField &rho, volVectorField &U) const


Protected Member Functions

tmp< volScalarField > fMu () const

tmp< volScalarField > f2 () const

tmp< volScalarField > E (const volScalarField &f2) const

virtual void correctNut ()


Protected Attributes

dimensionedScalar Ceps1_

dimensionedScalar Ceps2_

dimensionedScalar sigmak_

dimensionedScalar sigmaEps_

dimensionedScalar Cmu_

dimensionedScalar kappa_

dimensionedScalar Anu_

dimensionedScalar Aeps_

dimensionedScalar AE_

volScalarField k_

volScalarField epsilon_

const volScalarField & y_

- Protected Attributes inherited from eddyViscosity< incompressible::RASModel >
volScalarField nut_


Additional Inherited Members

- Public Types inherited from eddyViscosity< incompressible::RASModel >
typedef incompressible::RASModel ::alphaField alphaField

typedef incompressible::RASModel ::rhoField rhoField

typedef incompressible::RASModel ::transportModel transportModel

- Public Types inherited from linearViscousStress< incompressible::RASModel >
typedef incompressible::RASModel ::alphaField alphaField

typedef incompressible::RASModel ::rhoField rhoField

typedef incompressible::RASModel ::transportModel transportModel


Detailed Description

Lien and Leschziner low-Reynolds number k-epsilon turbulence model for incompressible flows.

This turbulence model is described in:

    Lien, F. S., & Leschziner, M. A. (1993).
    A pressure-velocity solution strategy for compressible flow
    and its application to shock/boundary-layer interaction
    using second-moment turbulence closure.
    Journal of fluids engineering, 115(4), 717-725.

Implemented according to the specification in: Apsley: Turbulence Models 2002

In addition to the low-Reynolds number damping functions support for wall-functions is also included to allow for low- and high-Reynolds number operation.

Source files

Definition at line 74 of file LienLeschziner.H.

Constructor & Destructor Documentation

◆ LienLeschziner()

LienLeschziner ( const geometricOneField &  alpha,
const geometricOneField &  rho,
const volVectorField &  U,
const surfaceScalarField &  alphaRhoPhi,
const surfaceScalarField &  phi,
const transportModel &  transport,
const word &  propertiesName = turbulenceModel::propertiesName,
const word &  type = typeName
)

Definition at line 85 of file LienLeschziner.C.

References Foam::bound(), and Foam::type().

Here is the call graph for this function:

◆ ~LienLeschziner()

virtual ~LienLeschziner ( )
virtualdefault

Member Function Documentation

◆ fMu()

tmp< volScalarField > fMu ( ) const
protected

Definition at line 43 of file LienLeschziner.C.

References LienLeschziner::Aeps_, LienLeschziner::Anu_, Foam::exp(), LienLeschziner::k_, nu, Foam::sqrt(), and LienLeschziner::y_.

Referenced by LienLeschziner::correctNut().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ f2()

tmp< volScalarField > f2 ( ) const
protected

Definition at line 53 of file LienLeschziner.C.

References LienLeschziner::epsilon_, Foam::exp(), LienLeschziner::k_, nu, and Foam::sqr().

Referenced by LienLeschziner::correct(), and LienLeschziner::E().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ E()

tmp< volScalarField > E ( const volScalarField &  f2) const
protected

Definition at line 61 of file LienLeschziner.C.

References LienLeschziner::AE_, LienLeschziner::Aeps_, LienLeschziner::Ceps2_, LienLeschziner::Cmu_, LienLeschziner::epsilon_, Foam::exp(), LienLeschziner::f2(), LienLeschziner::k_, LienLeschziner::kappa_, nu, Foam::pow(), Foam::sqr(), Foam::sqrt(), and LienLeschziner::y_.

Referenced by LienLeschziner::correct().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ correctNut()

void correctNut ( )
protectedvirtual

Implements eddyViscosity< incompressible::RASModel >.

Definition at line 75 of file LienLeschziner.C.

References LienLeschziner::Cmu_, GeometricField::correctBoundaryConditions(), LienLeschziner::epsilon_, LienLeschziner::fMu(), LienLeschziner::k_, eddyViscosity< incompressible::RASModel >::nut_, and Foam::sqr().

Referenced by LienLeschziner::correct().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ TypeName()

TypeName ( "LienLeschziner"  )

◆ read()

bool read ( )
virtual

Implements eddyViscosity< incompressible::RASModel >.

Definition at line 230 of file LienLeschziner.C.

References LienLeschziner::AE_, LienLeschziner::Aeps_, LienLeschziner::Anu_, LienLeschziner::Ceps1_, LienLeschziner::Ceps2_, LienLeschziner::Cmu_, LienLeschziner::kappa_, dimensioned::readIfPresent(), LienLeschziner::sigmaEps_, and LienLeschziner::sigmak_.

Here is the call graph for this function:

◆ DkEff()

tmp<volScalarField> DkEff ( ) const
inline

Definition at line 148 of file LienLeschziner.H.

References nu, eddyViscosity< incompressible::RASModel >::nut_, and LienLeschziner::sigmak_.

Referenced by LienLeschziner::correct().

Here is the caller graph for this function:

◆ DepsilonEff()

tmp<volScalarField> DepsilonEff ( ) const
inline

Definition at line 157 of file LienLeschziner.H.

References nu, eddyViscosity< incompressible::RASModel >::nut_, and LienLeschziner::sigmaEps_.

Referenced by LienLeschziner::correct().

Here is the caller graph for this function:

◆ k()

virtual tmp<volScalarField> k ( ) const
inlinevirtual

Definition at line 166 of file LienLeschziner.H.

References LienLeschziner::k_.

◆ epsilon()

virtual tmp<volScalarField> epsilon ( ) const
inlinevirtual

Definition at line 172 of file LienLeschziner.H.

References LienLeschziner::epsilon_.

◆ correct()

void correct ( )
virtual

Implements eddyViscosity< incompressible::RASModel >.

Definition at line 251 of file LienLeschziner.C.

References Foam::bound(), GeometricField::boundaryFieldRef(), LienLeschziner::Ceps1_, LienLeschziner::Ceps2_, tmp::clear(), eddyViscosity< BasicTurbulenceModel >::correct(), LienLeschziner::correctNut(), Foam::fvm::ddt(), LienLeschziner::DepsilonEff(), Foam::fvm::div(), LienLeschziner::DkEff(), LienLeschziner::E(), LienLeschziner::epsilon_, LienLeschziner::f2(), Foam::constant::universal::G, Foam::fvc::grad(), LienLeschziner::k_, Foam::fvm::laplacian(), eddyViscosity< incompressible::RASModel >::nut_, tmp::ref(), Foam::solve(), Foam::fvm::Sp(), Foam::twoSymm(), and GeometricField::Boundary::updateCoeffs().

Here is the call graph for this function:

Member Data Documentation

◆ Ceps1_

dimensionedScalar Ceps1_
protected

Definition at line 85 of file LienLeschziner.H.

Referenced by LienLeschziner::correct(), and LienLeschziner::read().

◆ Ceps2_

dimensionedScalar Ceps2_
protected

Definition at line 86 of file LienLeschziner.H.

Referenced by LienLeschziner::correct(), LienLeschziner::E(), and LienLeschziner::read().

◆ sigmak_

dimensionedScalar sigmak_
protected

Definition at line 87 of file LienLeschziner.H.

Referenced by LienLeschziner::DkEff(), and LienLeschziner::read().

◆ sigmaEps_

dimensionedScalar sigmaEps_
protected

Definition at line 88 of file LienLeschziner.H.

Referenced by LienLeschziner::DepsilonEff(), and LienLeschziner::read().

◆ Cmu_

dimensionedScalar Cmu_
protected

Definition at line 90 of file LienLeschziner.H.

Referenced by LienLeschziner::correctNut(), LienLeschziner::E(), and LienLeschziner::read().

◆ kappa_

dimensionedScalar kappa_
protected

Definition at line 91 of file LienLeschziner.H.

Referenced by LienLeschziner::E(), and LienLeschziner::read().

◆ Anu_

dimensionedScalar Anu_
protected

Definition at line 93 of file LienLeschziner.H.

Referenced by LienLeschziner::fMu(), and LienLeschziner::read().

◆ Aeps_

dimensionedScalar Aeps_
protected

Definition at line 94 of file LienLeschziner.H.

Referenced by LienLeschziner::E(), LienLeschziner::fMu(), and LienLeschziner::read().

◆ AE_

dimensionedScalar AE_
protected

Definition at line 95 of file LienLeschziner.H.

Referenced by LienLeschziner::E(), and LienLeschziner::read().

◆ k_

volScalarField k_
protected

Definition at line 100 of file LienLeschziner.H.

Referenced by LienLeschziner::correct(), LienLeschziner::correctNut(), LienLeschziner::E(), LienLeschziner::f2(), LienLeschziner::fMu(), and LienLeschziner::k().

◆ epsilon_

volScalarField epsilon_
protected

Definition at line 101 of file LienLeschziner.H.

Referenced by LienLeschziner::correct(), LienLeschziner::correctNut(), LienLeschziner::E(), LienLeschziner::epsilon(), and LienLeschziner::f2().

◆ y_

const volScalarField& y_
protected

Definition at line 106 of file LienLeschziner.H.

Referenced by LienLeschziner::E(), and LienLeschziner::fMu().

The documentation for this class was generated from the following files:
