humidityTemperatureCoupledMixedFvPatchScalarField Class Reference

Inheritance diagram for humidityTemperatureCoupledMixedFvPatchScalarField:

Collaboration diagram for humidityTemperatureCoupledMixedFvPatchScalarField:

Public Types
enum	massTransferMode { mtConstantMass, mtCondensation, mtEvaporation, mtCondensationAndEvaporation }
Public Types inherited from temperatureCoupledBase
enum	KMethodType {   mtFluidThermo, mtSolidThermo, mtDirectionalSolidThermo, mtLookup,   mtFunction }

Public Member Functions
	TypeName ("humidityTemperatureCoupledMixed")
	humidityTemperatureCoupledMixedFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &)
	humidityTemperatureCoupledMixedFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
	humidityTemperatureCoupledMixedFvPatchScalarField (const humidityTemperatureCoupledMixedFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fvPatchFieldMapper &)
virtual tmp< fvPatchScalarField >	clone () const
	humidityTemperatureCoupledMixedFvPatchScalarField (const humidityTemperatureCoupledMixedFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
virtual tmp< fvPatchScalarField >	clone (const DimensionedField< scalar, volMesh > &iF) const
virtual void	autoMap (const fvPatchFieldMapper &)
virtual void	rmap (const fvPatchScalarField &, const labelList &)
const scalarField	myKDelta () const
const scalarField	mpCpTp () const
const scalarField	dmHfg () const
virtual void	updateCoeffs ()
virtual void	write (Ostream &) const
Public Member Functions inherited from temperatureCoupledBase
	temperatureCoupledBase (const fvPatch &patch, const word &calculationMethod, const word &kappaName, const word &alphaAniName, const word &alphaName)
	temperatureCoupledBase (const fvPatch &patch, const dictionary &dict)
	temperatureCoupledBase (const fvPatch &patch, const temperatureCoupledBase &base)
	temperatureCoupledBase (const temperatureCoupledBase &)
virtual	~temperatureCoupledBase ()=default
word	KMethod () const
const word &	kappaName () const
const word &	alphaName () const
virtual tmp< scalarField >	kappa (const scalarField &Tp) const
virtual tmp< scalarField >	alpha (const scalarField &Tp) const
void	write (Ostream &os) const

Additional Inherited Members
Protected Attributes inherited from temperatureCoupledBase
const fvPatch &	patch_
const KMethodType	method_
const word	kappaName_
const word	alphaAniName_
const word	alphaName_
autoPtr< PatchFunction1< scalar > >	kappaFunction1_
autoPtr< PatchFunction1< scalar > >	alphaFunction1_
Static Protected Attributes inherited from temperatureCoupledBase
static const Enum< KMethodType >	KMethodTypeNames_

Detailed Description

Definition at line 193 of file humidityTemperatureCoupledMixedFvPatchScalarField.H.

Member Enumeration Documentation

massTransferMode

enum massTransferMode

Enumerator
mtConstantMass
mtCondensation
mtEvaporation
mtCondensationAndEvaporation

Definition at line 203 of file humidityTemperatureCoupledMixedFvPatchScalarField.H.

Constructor & Destructor Documentation

humidityTemperatureCoupledMixedFvPatchScalarField() [1/4]

humidityTemperatureCoupledMixedFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF
	)

Definition at line 121 of file humidityTemperatureCoupledMixedFvPatchScalarField.C.

humidityTemperatureCoupledMixedFvPatchScalarField() [2/4]

humidityTemperatureCoupledMixedFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const dictionary &	dict
	)

Definition at line 206 of file humidityTemperatureCoupledMixedFvPatchScalarField.C.

References dict, Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, forAll, dictionary::found(), liquidProperties::New(), Foam::nl, fvPatchField::operator=(), p, Foam::foamVersion::patch, dictionary::readEntry(), dictionary::readIfPresent(), and dictionary::subDict().

Here is the call graph for this function:

humidityTemperatureCoupledMixedFvPatchScalarField() [3/4]

humidityTemperatureCoupledMixedFvPatchScalarField	(	const humidityTemperatureCoupledMixedFvPatchScalarField &	psf,
		const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)

Definition at line 168 of file humidityTemperatureCoupledMixedFvPatchScalarField.C.

humidityTemperatureCoupledMixedFvPatchScalarField() [4/4]

humidityTemperatureCoupledMixedFvPatchScalarField	(	const humidityTemperatureCoupledMixedFvPatchScalarField &	psf,
		const DimensionedField< scalar, volMesh > &	iF
	)

Definition at line 337 of file humidityTemperatureCoupledMixedFvPatchScalarField.C.

Member Function Documentation

TypeName()

TypeName

(

"humidityTemperatureCoupledMixed"

)

clone() [1/2]

virtual tmp<fvPatchScalarField> clone ( ) const

inlinevirtual

Definition at line 343 of file humidityTemperatureCoupledMixedFvPatchScalarField.H.

clone() [2/2]

virtual tmp<fvPatchScalarField> clone ( const DimensionedField< scalar, volMesh > &  iF ) const

inlinevirtual

Definition at line 363 of file humidityTemperatureCoupledMixedFvPatchScalarField.H.

autoMap()

void autoMap ( const fvPatchFieldMapper &  m )

virtual

Implements temperatureCoupledBase.

Definition at line 374 of file humidityTemperatureCoupledMixedFvPatchScalarField.C.

References temperatureCoupledBase::autoMap().

Here is the call graph for this function:

rmap()

void rmap ( const fvPatchScalarField &  ptf, const labelList &  addr  )

virtual

Implements temperatureCoupledBase.

Definition at line 395 of file humidityTemperatureCoupledMixedFvPatchScalarField.C.

References temperatureCoupledBase::rmap().

Here is the call graph for this function:

myKDelta()

const scalarField myKDelta ( ) const

inline

Definition at line 397 of file humidityTemperatureCoupledMixedFvPatchScalarField.H.

mpCpTp()

const scalarField mpCpTp ( ) const

inline

Definition at line 403 of file humidityTemperatureCoupledMixedFvPatchScalarField.H.

Referenced by humidityTemperatureCoupledMixedFvPatchScalarField::updateCoeffs().

Here is the caller graph for this function:

dmHfg()

const scalarField dmHfg ( ) const

inline

Definition at line 409 of file humidityTemperatureCoupledMixedFvPatchScalarField.H.

Referenced by humidityTemperatureCoupledMixedFvPatchScalarField::updateCoeffs().

Here is the caller graph for this function:

updateCoeffs()

void updateCoeffs ( )

virtual

Definition at line 422 of file humidityTemperatureCoupledMixedFvPatchScalarField.C.

References Foam::constant::atomic::alpha, Foam::constant::physicoChemical::b, Foam::constant::universal::c, Foam::cp(), Foam::expressions::patchExpr::debug, fvPatch::deltaCoeffs(), TimeState::deltaTValue(), mappedPatchBase::distribute(), humidityTemperatureCoupledMixedFvPatchScalarField::dmHfg(), Foam::endl(), forAll, Foam::gAverage(), Foam::gMax(), Foam::gMin(), fixedGradientFvPatchField< Type >::gradient(), Foam::gSum(), patchIdentifier::index(), Foam::Info, Foam::constant::electromagnetic::kappa, temperatureCoupledBase::kappa(), Foam::log(), fvPatch::lookupPatchField(), Foam::mag(), Foam::max(), mesh, Foam::min(), humidityTemperatureCoupledMixedFvPatchScalarField::mpCpTp(), fvPatch::name(), fvMesh::name(), IOobject::name(), Foam::nl, Foam::foamVersion::patch, fvPatchField< Type >::patchInternalField(), Foam::Re(), Foam::refCast(), rhof(), mappedPatchBase::sampleMesh(), mappedPatchBase::samplePolyPatch(), Foam::T(), fvMesh::time(), Uf, and Foam::Zero.

Here is the call graph for this function:

write()

void write ( Ostream &  os ) const

virtual

Definition at line 770 of file humidityTemperatureCoupledMixedFvPatchScalarField.C.

References os(), token::TAB, Foam::vtk::write(), temperatureCoupledBase::write(), Ostream::writeEntry(), and Ostream::writeEntryIfDifferent().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/thermophysicalModels/thermophysicalPropertiesFvPatchFields/liquidProperties/humidityTemperatureCoupledMixed/humidityTemperatureCoupledMixedFvPatchScalarField.H
• src/thermophysicalModels/thermophysicalPropertiesFvPatchFields/liquidProperties/humidityTemperatureCoupledMixed/humidityTemperatureCoupledMixedFvPatchScalarField.C
