hierarchGeomDecomp Class Reference

Does hierarchical decomposition of points, selectable as hierarchical. More...

Inheritance diagram for hierarchGeomDecomp:

Collaboration diagram for hierarchGeomDecomp:

Public Member Functions
	hierarchGeomDecomp (const hierarchGeomDecomp &)=delete
void	operator= (const hierarchGeomDecomp &)=delete
	TypeName ("hierarchical")
	hierarchGeomDecomp (const dictionary &decompDict, const word &regionName="")
virtual	~hierarchGeomDecomp ()=default
virtual bool	parallelAware () const
virtual labelList	decompose (const pointField &, const scalarField &weights) const
virtual labelList	decompose (const pointField &) const
virtual labelList	decompose (const polyMesh &mesh, const pointField &cc, const scalarField &cWeights) const
virtual labelList	decompose (const polyMesh &mesh, const pointField &cc) const
virtual labelList	decompose (const labelListList &globalCellCells, const pointField &cc, const scalarField &cWeights) const
virtual labelList	decompose (const labelListList &globalCellCells, const pointField &cc) const
Public Member Functions inherited from geomDecomp
	geomDecomp (const word &derivedType, const dictionary &decompDict, int select=selectionType::DEFAULT)
	geomDecomp (const word &derivedType, const dictionary &decompDict, const word &regionName, int select=selectionType::DEFAULT)
Public Member Functions inherited from decompositionMethod
	TypeName ("decompositionMethod")
	declareRunTimeSelectionTable (autoPtr, decompositionMethod, dictionary,(const dictionary &decompDict, const word &regionName),(decompDict, regionName))
	decompositionMethod (const dictionary &decompDict, const word &regionName="")
virtual	~decompositionMethod ()=default
label	nDomains () const noexcept
virtual labelList	decompose (const polyMesh &mesh, const labelList &cellToRegion, const pointField &regionPoints, const scalarField &regionWeights) const
virtual labelList	decompose (const polyMesh &mesh, const labelList &cellToRegion, const pointField &regionPoints) const
void	setConstraints (const polyMesh &mesh, boolList &blockedFace, PtrList< labelList > &specifiedProcessorFaces, labelList &specifiedProcessor, List< labelPair > &explicitConnections) const
void	applyConstraints (const polyMesh &mesh, const boolList &blockedFace, const PtrList< labelList > &specifiedProcessorFaces, const labelList &specifiedProcessor, const List< labelPair > &explicitConnections, labelList &finalDecomp) const
virtual labelList	decompose (const polyMesh &mesh, const scalarField &cellWeights, const boolList &blockedFace, const PtrList< labelList > &specifiedProcessorFaces, const labelList &specifiedProcessor, const List< labelPair > &explicitConnections) const
labelList	decompose (const polyMesh &mesh, const scalarField &cWeights) const

Additional Inherited Members
Static Public Member Functions inherited from decompositionMethod
static label	nDomains (const dictionary &decompDict, const word &regionName="")
static const dictionary &	optionalRegionDict (const dictionary &decompDict, const word &regionName)
static autoPtr< decompositionMethod >	New (const dictionary &decompDict, const word &regionName="")
static void	calcCellCells (const polyMesh &mesh, const labelList &agglom, const label nLocalCoarse, const bool global, CompactListList< label > &cellCells)
static void	calcCellCells (const polyMesh &mesh, const labelList &agglom, const label nLocalCoarse, const bool parallel, CompactListList< label > &cellCells, CompactListList< scalar > &cellCellWeights)
Protected Types inherited from decompositionMethod
enum	selectionType { DEFAULT = 0, EXACT = 1, MANDATORY = 2, NULL_DICT = 4 }
Protected Member Functions inherited from geomDecomp
tmp< pointField >	adjustPoints (const pointField &) const
void	checkDecompositionDirections (const Vector< label > &) const
Protected Member Functions inherited from decompositionMethod
const dictionary &	findCoeffsDict (const word &coeffsName, int select=selectionType::DEFAULT) const
Static Protected Member Functions inherited from decompositionMethod
static const dictionary &	findCoeffsDict (const dictionary &dict, const word &coeffsName, int select=selectionType::DEFAULT)
Protected Attributes inherited from geomDecomp
Vector< label >	n_
Vector< direction >	order_
const dictionary &	coeffsDict_
Protected Attributes inherited from decompositionMethod
const dictionary &	decompDict_
const dictionary &	decompRegionDict_
label	nDomains_
PtrList< decompositionConstraint >	constraints_

Detailed Description

Does hierarchical decomposition of points, selectable as hierarchical.

Works by first sorting the points in x direction into equal sized bins, then in y direction and finally in z direction.

Uses single array to hold decomposition which is indexed as if it is a 3 dimensional array:

finalDecomp[i,j,k] is indexed as

i*n[0]*n[1] + j*n[1] + k

E.g. if we're sorting 'xyz': the first sort (over the x-component) determines in which x-domain the point goes. Then for each of the x-domains the points are sorted in y direction and each individual x-domain gets split into three y-domains. And similar for the z-direction.

Since the domains are of equal size the maximum difference in size is n[0]*n[1] (or n[1]*n[2]?) (small anyway)

Method coefficients:

Property	Description	Required	Default
n	(nx ny nz)	yes
order	order of operation	no	xyz
delta	delta (jitter) for rotation matrix	no	0.001
transform	cartesian coordinate transformation	no

Source files

• hierarchGeomDecomp.H
• hierarchGeomDecomp.C

Definition at line 97 of file hierarchGeomDecomp.H.

Constructor & Destructor Documentation

hierarchGeomDecomp() [1/2]

hierarchGeomDecomp ( const hierarchGeomDecomp &  )

delete

hierarchGeomDecomp() [2/2]

hierarchGeomDecomp ( const dictionary &  decompDict, const word &  regionName = ""  )

explicit

Definition at line 671 of file hierarchGeomDecomp.C.

~hierarchGeomDecomp()

virtual ~hierarchGeomDecomp ( )

virtualdefault

Member Function Documentation

operator=()

void operator= ( const hierarchGeomDecomp &  )

delete

TypeName()

TypeName

(

"hierarchical"

)

parallelAware()

virtual bool parallelAware ( ) const

inlinevirtual

Implements decompositionMethod.

Definition at line 213 of file hierarchGeomDecomp.H.

decompose() [1/6]

Foam::labelList decompose ( const pointField &  points, const scalarField &  weights  ) const

virtual

Implements geomDecomp.

Definition at line 724 of file hierarchGeomDecomp.C.

References Foam::constant::electromagnetic::e, Foam::endl(), Foam::identity(), Foam::max(), points, Foam::returnReduce(), WarningInFunction, and Foam::Zero.

Referenced by hierarchGeomDecomp::decompose().

Here is the call graph for this function:

Here is the caller graph for this function:

decompose() [2/6]

Foam::labelList decompose ( const pointField &  points ) const

virtual

Implements geomDecomp.

Definition at line 683 of file hierarchGeomDecomp.C.

References Foam::constant::electromagnetic::e, Foam::endl(), Foam::identity(), Foam::max(), points, Foam::returnReduce(), WarningInFunction, and Foam::Zero.

Here is the call graph for this function:

decompose() [3/6]

virtual labelList decompose ( const polyMesh &  mesh, const pointField &  cc, const scalarField &  cWeights  ) const

inlinevirtual

Implements decompositionMethod.

Definition at line 234 of file hierarchGeomDecomp.H.

References geomDecomp::checkDecompositionDirections(), hierarchGeomDecomp::decompose(), and mesh.

Here is the call graph for this function:

decompose() [4/6]

virtual labelList decompose ( const polyMesh &  mesh, const pointField &  cc  ) const

inlinevirtual

Reimplemented from decompositionMethod.

Definition at line 248 of file hierarchGeomDecomp.H.

References geomDecomp::checkDecompositionDirections(), hierarchGeomDecomp::decompose(), and mesh.

Here is the call graph for this function:

decompose() [5/6]

virtual labelList decompose ( const labelListList &  globalCellCells, const pointField &  cc, const scalarField &  cWeights  ) const

inlinevirtual

Implements decompositionMethod.

Definition at line 265 of file hierarchGeomDecomp.H.

References hierarchGeomDecomp::decompose().

Here is the call graph for this function:

decompose() [6/6]

virtual labelList decompose ( const labelListList &  globalCellCells, const pointField &  cc  ) const

inlinevirtual

Reimplemented from decompositionMethod.

Definition at line 275 of file hierarchGeomDecomp.H.

References hierarchGeomDecomp::decompose().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/parallel/decompose/decompositionMethods/hierarchGeomDecomp/hierarchGeomDecomp.H
• src/parallel/decompose/decompositionMethods/hierarchGeomDecomp/hierarchGeomDecomp.C
