gradientEnergyFvPatchScalarField Class Reference

This boundary condition provides a gradient condition for internal energy, where the gradient is calculated using: More...

Inheritance diagram for gradientEnergyFvPatchScalarField:

Collaboration diagram for gradientEnergyFvPatchScalarField:

Public Member Functions
	TypeName ("gradientEnergy")
	gradientEnergyFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &)
	gradientEnergyFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
	gradientEnergyFvPatchScalarField (const gradientEnergyFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fvPatchFieldMapper &)
	gradientEnergyFvPatchScalarField (const gradientEnergyFvPatchScalarField &)
virtual tmp< fvPatchScalarField >	clone () const
	gradientEnergyFvPatchScalarField (const gradientEnergyFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
virtual tmp< fvPatchScalarField >	clone (const DimensionedField< scalar, volMesh > &iF) const
virtual void	updateCoeffs ()
virtual void	write (Ostream &) const

Detailed Description

This boundary condition provides a gradient condition for internal energy, where the gradient is calculated using:

where

	=	energy at patch faces [J]
	=	energy at patch internal cells [J]
	=	pressure [bar]
	=	temperature [K]
	=	specific heat [J/kg/K]
	=	distance between patch face and internal cell centres [m]

Usage

Example of the boundary condition specification:

<patchName>
{
    type            gradientEnergy;
    gradient        uniform 10;
}

See also

Foam::fixedGradientFvPatchField

Source files

• gradientEnergyFvPatchScalarField.H
• gradientEnergyFvPatchScalarField.C

Definition at line 101 of file gradientEnergyFvPatchScalarField.H.

Constructor & Destructor Documentation

gradientEnergyFvPatchScalarField() [1/5]

gradientEnergyFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF
	)

Definition at line 31 of file gradientEnergyFvPatchScalarField.C.

Referenced by gradientEnergyFvPatchScalarField::clone().

Here is the caller graph for this function:

gradientEnergyFvPatchScalarField() [2/5]

gradientEnergyFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const dictionary &	dict
	)

Definition at line 55 of file gradientEnergyFvPatchScalarField.C.

gradientEnergyFvPatchScalarField() [3/5]

gradientEnergyFvPatchScalarField	(	const gradientEnergyFvPatchScalarField &	ptf,
		const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)

Definition at line 42 of file gradientEnergyFvPatchScalarField.C.

gradientEnergyFvPatchScalarField() [4/5]

gradientEnergyFvPatchScalarField

(

const gradientEnergyFvPatchScalarField &

tppsf

)

Definition at line 67 of file gradientEnergyFvPatchScalarField.C.

gradientEnergyFvPatchScalarField() [5/5]

gradientEnergyFvPatchScalarField	(	const gradientEnergyFvPatchScalarField &	tppsf,
		const DimensionedField< scalar, volMesh > &	iF
	)

Definition at line 77 of file gradientEnergyFvPatchScalarField.C.

Member Function Documentation

TypeName()

TypeName

(

"gradientEnergy"

)

clone() [1/2]

virtual tmp<fvPatchScalarField> clone ( ) const

inlinevirtual

Definition at line 146 of file gradientEnergyFvPatchScalarField.H.

References gradientEnergyFvPatchScalarField::gradientEnergyFvPatchScalarField().

Here is the call graph for this function:

clone() [2/2]

virtual tmp<fvPatchScalarField> clone ( const DimensionedField< scalar, volMesh > &  iF ) const

inlinevirtual

Definition at line 163 of file gradientEnergyFvPatchScalarField.H.

References gradientEnergyFvPatchScalarField::gradientEnergyFvPatchScalarField().

Here is the call graph for this function:

updateCoeffs()

void updateCoeffs ( )

virtual

Definition at line 88 of file gradientEnergyFvPatchScalarField.C.

References fvPatchField::evaluate(), basicThermo::lookupThermo(), Foam::foamVersion::patch, and fvPatchField::snGrad().

Here is the call graph for this function:

write()

void write ( Ostream &  os ) const

virtual

Definition at line 115 of file gradientEnergyFvPatchScalarField.C.

References os(), and Foam::vtk::write().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/thermophysicalModels/basic/derivedFvPatchFields/gradientEnergy/gradientEnergyFvPatchScalarField.H
• src/thermophysicalModels/basic/derivedFvPatchFields/gradientEnergy/gradientEnergyFvPatchScalarField.C
