Various mesh related information for a parallel run. Upon construction, constructs all info using parallel communication. More...

Inheritance diagram for globalMeshData:

[legend]

Collaboration diagram for globalMeshData:

[legend]

Classes
struct	ListPlusEqOp

Public Member Functions
	ClassName ("globalMeshData")

	globalMeshData (const polyMesh &mesh)

	~globalMeshData ()

void	clearOut ()

const polyMesh &	mesh () const noexcept

bool	parallel () const

label	nTotalPoints () const noexcept

label	nTotalFaces () const noexcept

label	nTotalCells () const noexcept

const labelList &	processorPatches () const noexcept

const labelList &	processorPatchIndices () const noexcept

const labelList &	processorPatchNeighbours () const noexcept

label	nGlobalPoints () const

const labelList &	sharedPointLabels () const

const labelList &	sharedPointAddr () const

const labelList &	sharedPointGlobalLabels () const

pointField	sharedPoints () const

pointField	geometricSharedPoints () const

label	nGlobalEdges () const

const labelList &	sharedEdgeLabels () const

const labelList &	sharedEdgeAddr () const

const indirectPrimitivePatch &	coupledPatch () const

const labelList &	coupledPatchMeshEdges () const

const Map< label > &	coupledPatchMeshEdgeMap () const

const globalIndexAndTransform &	globalTransforms () const

const globalIndex &	globalPointNumbering () const

const labelListList &	globalPointSlaves () const

const labelListList &	globalPointTransformedSlaves () const

const mapDistribute &	globalPointSlavesMap () const

template<class Type , class CombineOp , class TransformOp >
void	syncPointData (List< Type > &pointData, const CombineOp &cop, const TransformOp &top) const

const globalIndex &	globalEdgeNumbering () const

const labelListList &	globalEdgeSlaves () const

const labelListList &	globalEdgeTransformedSlaves () const

const mapDistribute &	globalEdgeSlavesMap () const

const bitSet &	globalEdgeOrientation () const

const labelListList &	globalCoPointSlaves () const

const mapDistribute &	globalCoPointSlavesMap () const

const globalIndex &	globalBoundaryFaceNumbering () const

const labelListList &	globalPointBoundaryFaces () const

const labelListList &	globalPointTransformedBoundaryFaces () const

const mapDistribute &	globalPointBoundaryFacesMap () const

const labelList &	boundaryCells () const

const globalIndex &	globalBoundaryCellNumbering () const

const labelListList &	globalPointBoundaryCells () const

const labelListList &	globalPointTransformedBoundaryCells () const

const mapDistribute &	globalPointBoundaryCellsMap () const

autoPtr< globalIndex >	mergePoints (labelList &pointToGlobal, labelList &uniquePoints) const

autoPtr< globalIndex >	mergePoints (const labelList &meshPoints, const Map< label > &meshPointMap, labelList &pointToGlobal, labelList &uniqueMeshPoints) const

void	movePoints (const pointField &newPoints)

void	updateMesh ()

Public Member Functions inherited from ProcessorTopology< Container, ProcPatch >
	ProcessorTopology (const Container &patches, const label comm)

const labelList &	procPatchMap () const

const lduSchedule &	patchSchedule () const

Public Member Functions inherited from List
constexpr	List () noexcept

	List (const label len)

	List (const label len, const T &val)

	List (const label len, const Foam::zero)

	List (const Foam::one, const T &val)

	List (const Foam::one, T &&val)

	List (const Foam::one, const Foam::zero)

	List (const List< T > &a)

	List (const UList< T > &a)

	List (List< T > &a, bool reuse)

	List (const UList< T > &list, const labelUList &indices)

template<unsigned N>
	List (const UList< T > &list, const FixedList< label, N > &indices)

template<unsigned N>
	List (const FixedList< T, N > &list)

	List (const PtrList< T > &list)

	List (const SLList< T > &list)

template<class Addr >
	List (const IndirectListBase< T, Addr > &list)

	List (std::initializer_list< T > list)

	List (List< T > &&list)

template<int SizeMin>
	List (DynamicList< T, SizeMin > &&list)

	List (SortableList< T > &&list)

	List (SLList< T > &&list)

	List (Istream &is)

autoPtr< List< T > >	clone () const

	~List ()

void	clear ()

void	resize (const label len)

void	resize (const label len, const T &val)

void	resize_nocopy (const label len)

void	setSize (const label n)

void	setSize (const label n, const T &val)

void	append (const T &val)

void	append (T &&val)

void	append (const UList< T > &list)

template<class Addr >
void	append (const IndirectListBase< T, Addr > &list)

label	appendUniq (const T &val)

void	transfer (List< T > &list)

template<int SizeMin>
void	transfer (DynamicList< T, SizeMin > &list)

void	transfer (SortableList< T > &list)

T &	newElmt (const label i)

void	operator= (const UList< T > &a)

void	operator= (const List< T > &list)

void	operator= (const SLList< T > &list)

template<class Addr >
void	operator= (const IndirectListBase< T, Addr > &list)

template<unsigned N>
void	operator= (const FixedList< T, N > &list)

void	operator= (std::initializer_list< T > list)

void	operator= (const T &val)

void	operator= (const Foam::zero)

void	operator= (List< T > &&list)

template<int SizeMin>
void	operator= (DynamicList< T, SizeMin > &&list)

void	operator= (SortableList< T > &&list)

void	operator= (SLList< T > &&list)

Istream &	readList (Istream &is)

void	shallowCopy (const UList< T > &)=delete

template<class TypeT = T>
std::enable_if< std::is_same< bool, TypeT >::value, bool >::type	set (const label i, bool val=true)

template<class T >
	List (const label len)

template<class T >
	List (const label len, const T &val)

template<class T >
	List (const label len, const Foam::zero)

template<class T >
	List (const Foam::one, const T &val)

template<class T >
	List (const Foam::one, T &&val)

template<class T >
	List (const Foam::one, const Foam::zero)

template<class T >
	List (const UList< T > &a)

template<class T >
	List (const List< T > &a)

template<class T >
	List (List< T > &a, bool reuse)

template<class T >
	List (const UList< T > &list, const labelUList &indices)

template<class T >
	List (const PtrList< T > &list)

template<class T >
	List (const SLList< T > &list)

template<class T >
	List (std::initializer_list< T > list)

template<class T >
	List (List< T > &&list)

template<class T >
	List (SortableList< T > &&list)

template<class T >
	List (SLList< T > &&list)

template<class T >
void	transfer (List< T > &list)

template<class T >
void	transfer (SortableList< T > &list)

template<class T >
void	operator= (const UList< T > &a)

template<class T >
void	operator= (const List< T > &list)

template<class T >
void	operator= (const SLList< T > &list)

template<class T >
void	operator= (std::initializer_list< T > list)

template<class T >
void	operator= (List< T > &&list)

template<class T >
void	operator= (SortableList< T > &&list)

template<class T >
void	operator= (SLList< T > &&list)

Istream &	readList (Istream &is)

template<class T >
constexpr	List () noexcept

void	resize (const label newLen)

template<class T >
void	append (const T &val)

template<class T >
void	append (T &&val)

template<class T >
void	append (const UList< T > &list)

template<class T >
void	operator= (const T &val)

template<class T >
void	operator= (const Foam::zero)

template<class T >
	List (Istream &is)

Istream &	readList (Istream &is)

Static Public Member Functions
template<class Type , class CombineOp , class TransformOp >
static void	syncData (List< Type > &elems, const labelListList &slaves, const labelListList &transformedSlaves, const mapDistribute &slavesMap, const globalIndexAndTransform &, const CombineOp &cop, const TransformOp &top)

template<class Type , class CombineOp >
static void	syncData (List< Type > &elems, const labelListList &slaves, const labelListList &transformedSlaves, const mapDistribute &slavesMap, const CombineOp &cop)

Static Public Member Functions inherited from ProcessorTopology< Container, ProcPatch >
static lduSchedule	nonBlockingSchedule (const Container &patches)

Static Public Member Functions inherited from List
static const List< T > &	null ()

Static Public Attributes
static const Foam::scalar	matchTol_ = 1e-8

Additional Inherited Members
Public Types inherited from List
typedef SubList< T >	subList

Detailed Description

Various mesh related information for a parallel run. Upon construction, constructs all info using parallel communication.

Requires:

all processor patches to have correct ordering.
all processorPatches to have their transforms set.

The shared point and edge addressing calculates addressing for points and edges on coupled patches. In the 'old' way a distinction was made between points/edges that are only on two processors and those that are on multiple processors. The problem is that those on multiple processors do not allow any transformations and require a global reduction on the master processor.

The alternative is to have an exchange schedule (through a 'mapDistribute') which sends all point/edge data (no distinction is made between those on two and those on more than two coupled patches) to the local 'master'. This master then does any calculation and sends the result back to the 'slave' points/edges. This only needs to be done on points on coupled faces. Any transformation is done using a predetermined set of transformations - since transformations have to be space filling only a certain number of transformation is supported.

The exchange needs

a field of data
a mapDistribute which does all parallel exchange and transformations This appends remote data to the end of the field.
a set of indices which indicate where to get untransformed data in the field
a set of indices which indicate where to get transformed data in the field

Note

compared to 17x nTotalFaces, nTotalPoints do not compensate for shared points since this would trigger full connectivity analysis
most calculation is demand driven and uses parallel communication so make sure to invoke on all processors at the same time
old sharedEdge calculation: currently an edge is considered shared if it uses two shared points and is used more than once. This is not correct on processor patches but it only slightly overestimates the number of shared edges. Doing full analysis of how many patches use the edge would be too complicated

See also: mapDistribute globalIndexAndTransform

Source files

Definition at line 103 of file globalMeshData.H.

Constructor & Destructor Documentation

◆ globalMeshData()

globalMeshData ( const polyMesh & mesh )

Definition at line 1739 of file globalMeshData.C.

References globalMeshData::updateMesh().

Here is the call graph for this function:

◆ ~globalMeshData()

~globalMeshData ( )

Definition at line 1763 of file globalMeshData.C.

Member Function Documentation

◆ ClassName()

ClassName ( "globalMeshData" )

◆ clearOut()

void clearOut ( )

Definition at line 1769 of file globalMeshData.C.

◆ mesh()

const polyMesh& mesh ( ) const

inlinenoexcept

Definition at line 340 of file globalMeshData.H.

◆ parallel()

bool parallel ( ) const

inline

Definition at line 347 of file globalMeshData.H.

◆ nTotalPoints()

label nTotalPoints ( ) const

inlinenoexcept

Definition at line 354 of file globalMeshData.H.

◆ nTotalFaces()

label nTotalFaces ( ) const

inlinenoexcept

Definition at line 361 of file globalMeshData.H.

◆ nTotalCells()

label nTotalCells ( ) const

inlinenoexcept

Definition at line 367 of file globalMeshData.H.

Referenced by velocityDampingConstraint::addDamping(), waveMethod::calculate(), structuredDecomp::decompose(), decompositionMethod::decompose(), meshRefinement::printMeshInfo(), and zoltanRenumber::renumber().

Here is the caller graph for this function:

◆ processorPatches()

const labelList& processorPatches ( ) const

inlinenoexcept

Definition at line 377 of file globalMeshData.H.

Referenced by FaceCellWave< Type, int >::handleProcPatches(), Cloud< passivePositionParticle >::move(), and patchInjection::patchInjection().

Here is the caller graph for this function:

◆ processorPatchIndices()

const labelList& processorPatchIndices ( ) const

inlinenoexcept

Definition at line 385 of file globalMeshData.H.

◆ processorPatchNeighbours()

const labelList& processorPatchNeighbours ( ) const

inlinenoexcept

Definition at line 392 of file globalMeshData.H.

Referenced by Cloud< passivePositionParticle >::move().

Here is the caller graph for this function:

◆ nGlobalPoints()

Foam::label nGlobalPoints ( ) const

Definition at line 1979 of file globalMeshData.C.

Referenced by syncTools::syncPointMap().

Here is the caller graph for this function:

◆ sharedPointLabels()

const Foam::labelList & sharedPointLabels ( ) const

Definition at line 1989 of file globalMeshData.C.

Referenced by polyMeshAdder::findSharedPoints(), syncTools::syncEdgeMap(), and syncTools::syncPointMap().

Here is the caller graph for this function:

◆ sharedPointAddr()

const Foam::labelList & sharedPointAddr ( ) const

Definition at line 1999 of file globalMeshData.C.

Referenced by polyMeshAdder::findSharedPoints(), syncTools::syncEdgeMap(), and syncTools::syncPointMap().

Here is the caller graph for this function:

◆ sharedPointGlobalLabels()

const Foam::labelList & sharedPointGlobalLabels ( ) const

Definition at line 1821 of file globalMeshData.C.

References Foam::endl(), forAll, IOobject::MUST_READ, pointLabels(), Foam::Pout, and IOobject::typeHeaderOk().

Here is the call graph for this function:

◆ sharedPoints()

Foam::pointField sharedPoints ( ) const

Definition at line 1872 of file globalMeshData.C.

References UPstream::blocking, forAll, UPstream::master(), UPstream::masterNo(), pointLabels(), and UPstream::subProcs().

Here is the call graph for this function:

◆ geometricSharedPoints()

Foam::pointField geometricSharedPoints ( ) const

Definition at line 1951 of file globalMeshData.C.

References Foam::combineReduce(), and Foam::mergePoints().

Here is the call graph for this function:

◆ nGlobalEdges()

Foam::label nGlobalEdges ( ) const

Definition at line 2009 of file globalMeshData.C.

◆ sharedEdgeLabels()

const Foam::labelList & sharedEdgeLabels ( ) const

Definition at line 2019 of file globalMeshData.C.

◆ sharedEdgeAddr()

const Foam::labelList & sharedEdgeAddr ( ) const

Definition at line 2029 of file globalMeshData.C.

◆ coupledPatch()

const Foam::indirectPrimitivePatch & coupledPatch ( ) const

Definition at line 2039 of file globalMeshData.C.

References polyPatch::coupled(), Foam::expressions::patchExpr::debug, Foam::endl(), forAll, Foam::Pout, and polyPatch::start().

Referenced by addPatchCellLayer::calcExtrudeInfo(), createShellMesh::calcPointRegions(), syncTools::getMasterPoints(), globalIndexAndTransform::globalIndexAndTransform(), PatchTools::pointNormals(), motionSmootherAlgo::setDisplacement(), syncTools::syncEdgeList(), syncTools::syncPointList(), and pointConstraints::syncUntransformedData().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ coupledPatchMeshEdges()

const Foam::labelList & coupledPatchMeshEdges ( ) const

Definition at line 2100 of file globalMeshData.C.

Referenced by syncTools::getMasterEdges(), and syncTools::syncEdgeList().

Here is the caller graph for this function:

◆ coupledPatchMeshEdgeMap()

const Foam::Map< Foam::label > & coupledPatchMeshEdgeMap ( ) const

Definition at line 2120 of file globalMeshData.C.

References forAll, and Foam::constant::atomic::me.

Referenced by syncTools::syncEdgeList().

Here is the caller graph for this function:

◆ globalTransforms()

const Foam::globalIndexAndTransform & globalTransforms ( ) const

Definition at line 2153 of file globalMeshData.C.

Referenced by addPatchCellLayer::calcExtrudeInfo(), PatchTools::edgeNormals(), PatchTools::pointNormals(), syncTools::syncEdgeList(), and syncTools::syncPointList().

Here is the caller graph for this function:

◆ syncData() [1/2]

void syncData	(	List< Type > &	elems,
		const labelListList &	slaves,
		const labelListList &	transformedSlaves,
		const mapDistribute &	slavesMap,
		const globalIndexAndTransform &	transforms,
		const CombineOp &	cop,
		const TransformOp &	top
	)

static

Definition at line 30 of file globalMeshDataTemplates.C.

References mapDistribute::distribute(), forAll, and mapDistribute::reverseDistribute().

Referenced by addPatchCellLayer::calcExtrudeInfo(), PatchTools::edgeNormals(), syncTools::syncEdgeList(), and syncTools::syncPointList().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ syncData() [2/2]

void syncData	(	List< Type > &	elems,
		const labelListList &	slaves,
		const labelListList &	transformedSlaves,
		const mapDistribute &	slavesMap,
		const CombineOp &	cop
	)

static

Definition at line 95 of file globalMeshDataTemplates.C.

References mapDistribute::distribute(), forAll, and mapDistribute::reverseDistribute().

Here is the call graph for this function:

◆ globalPointNumbering()

const Foam::globalIndex & globalPointNumbering ( ) const

Definition at line 2139 of file globalMeshData.C.

References nPoints, and globalIndex::reset().

Here is the call graph for this function:

◆ globalPointSlaves()

const Foam::labelListList & globalPointSlaves ( ) const

Definition at line 2163 of file globalMeshData.C.

Referenced by syncTools::getMasterPoints(), PatchTools::pointNormals(), and syncTools::syncPointList().

Here is the caller graph for this function:

◆ globalPointTransformedSlaves()

const Foam::labelListList & globalPointTransformedSlaves ( ) const

Definition at line 2173 of file globalMeshData.C.

Referenced by syncTools::getMasterPoints(), PatchTools::pointNormals(), and syncTools::syncPointList().

Here is the caller graph for this function:

◆ globalPointSlavesMap()

const Foam::mapDistribute & globalPointSlavesMap ( ) const

Definition at line 2184 of file globalMeshData.C.

Referenced by PatchTools::pointNormals(), and syncTools::syncPointList().

Here is the caller graph for this function:

◆ syncPointData()

void syncPointData	(	List< Type > &	pointData,
		const CombineOp &	cop,
		const TransformOp &	top
	)		const

Definition at line 152 of file globalMeshDataTemplates.C.

References Foam::abort(), Foam::FatalError, FatalErrorInFunction, forAll, and PrimitivePatch< FaceList, PointField >::meshPoints().

Referenced by syncTools::syncPointList().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ globalEdgeNumbering()

const Foam::globalIndex & globalEdgeNumbering ( ) const

Definition at line 2194 of file globalMeshData.C.

References globalIndex::reset().

Here is the call graph for this function:

◆ globalEdgeSlaves()

const Foam::labelListList & globalEdgeSlaves ( ) const

Definition at line 2207 of file globalMeshData.C.

Referenced by addPatchCellLayer::calcExtrudeInfo(), PatchTools::edgeNormals(), syncTools::getMasterEdges(), and syncTools::syncEdgeList().

Here is the caller graph for this function:

◆ globalEdgeTransformedSlaves()

const Foam::labelListList & globalEdgeTransformedSlaves ( ) const

Definition at line 2217 of file globalMeshData.C.

Referenced by addPatchCellLayer::calcExtrudeInfo(), PatchTools::edgeNormals(), syncTools::getMasterEdges(), and syncTools::syncEdgeList().

Here is the caller graph for this function:

◆ globalEdgeSlavesMap()

const Foam::mapDistribute & globalEdgeSlavesMap ( ) const

Definition at line 2238 of file globalMeshData.C.

Referenced by addPatchCellLayer::calcExtrudeInfo(), PatchTools::edgeNormals(), and syncTools::syncEdgeList().

Here is the caller graph for this function:

◆ globalEdgeOrientation()

const Foam::bitSet & globalEdgeOrientation ( ) const

Definition at line 2228 of file globalMeshData.C.

Referenced by syncTools::syncEdgeList().

Here is the caller graph for this function:

◆ globalCoPointSlaves()

const Foam::labelListList & globalCoPointSlaves ( ) const

Definition at line 2346 of file globalMeshData.C.

Referenced by globalIndexAndTransform::globalIndexAndTransform(), and pointConstraints::syncUntransformedData().

Here is the caller graph for this function:

◆ globalCoPointSlavesMap()

const Foam::mapDistribute & globalCoPointSlavesMap ( ) const

Definition at line 2356 of file globalMeshData.C.

Referenced by globalIndexAndTransform::globalIndexAndTransform(), and pointConstraints::syncUntransformedData().

Here is the caller graph for this function:

◆ globalBoundaryFaceNumbering()

const Foam::globalIndex & globalBoundaryFaceNumbering ( ) const

Definition at line 2248 of file globalMeshData.C.

◆ globalPointBoundaryFaces()

const Foam::labelListList & globalPointBoundaryFaces ( ) const

Definition at line 2259 of file globalMeshData.C.

◆ globalPointTransformedBoundaryFaces()

const Foam::labelListList & globalPointTransformedBoundaryFaces ( ) const

Definition at line 2271 of file globalMeshData.C.

◆ globalPointBoundaryFacesMap()

const Foam::mapDistribute & globalPointBoundaryFacesMap ( ) const

Definition at line 2281 of file globalMeshData.C.

◆ boundaryCells()

const Foam::labelList & boundaryCells ( ) const

Definition at line 2292 of file globalMeshData.C.

◆ globalBoundaryCellNumbering()

const Foam::globalIndex & globalBoundaryCellNumbering ( ) const

Definition at line 2302 of file globalMeshData.C.

◆ globalPointBoundaryCells()

const Foam::labelListList & globalPointBoundaryCells ( ) const

Definition at line 2313 of file globalMeshData.C.

◆ globalPointTransformedBoundaryCells()

const Foam::labelListList & globalPointTransformedBoundaryCells ( ) const

Definition at line 2325 of file globalMeshData.C.

◆ globalPointBoundaryCellsMap()

const Foam::mapDistribute & globalPointBoundaryCellsMap ( ) const

Definition at line 2335 of file globalMeshData.C.

◆ mergePoints() [1/2]

Foam::autoPtr< Foam::globalIndex > mergePoints	(	labelList &	pointToGlobal,
		labelList &	uniquePoints
	)		const

Definition at line 2367 of file globalMeshData.C.

References mapDistributeBase::constructSize(), forAll, PrimitivePatch< FaceList, PointField >::meshPoints(), PrimitivePatch< FaceList, PointField >::nPoints(), mapDistribute::reverseDistribute(), List::setSize(), globalIndex::toGlobal(), and bitSet::unset().

Here is the call graph for this function:

◆ mergePoints() [2/2]

Foam::autoPtr< Foam::globalIndex > mergePoints	(	const labelList &	meshPoints,
		const Map< label > &	meshPointMap,
		labelList &	pointToGlobal,
		labelList &	uniqueMeshPoints
	)		const

Parameters

meshPointMap currently unused

Definition at line 2501 of file globalMeshData.C.

References mapDistributeBase::constructSize(), mapDistribute::distribute(), forAll, Foam::labelMax, PrimitivePatch< FaceList, PointField >::meshPointMap(), PrimitivePatch< FaceList, PointField >::nPoints(), mapDistribute::reverseDistribute(), List::setSize(), and globalIndex::toGlobal().

Here is the call graph for this function:

◆ movePoints()

void movePoints ( const pointField & newPoints )

Definition at line 2715 of file globalMeshData.C.

◆ updateMesh()

void updateMesh ( )

Definition at line 2724 of file globalMeshData.C.

References UPstream::allocateCommunicator(), Foam::expressions::patchExpr::debug, Foam::endl(), UPstream::freeCommunicator(), Foam::identity(), UPstream::msgType(), UPstream::nProcs(), Foam::Pout, Foam::returnReduce(), UPstream::warnComm, and UPstream::worldComm.

Referenced by globalMeshData::globalMeshData().

Here is the call graph for this function:

Here is the caller graph for this function:

Member Data Documentation

◆ matchTol_

const scalar matchTol_ = 1e-8

static

Definition at line 319 of file globalMeshData.H.

The documentation for this class was generated from the following files:

src/OpenFOAM/meshes/polyMesh/globalMeshData/globalMeshData.H
src/OpenFOAM/meshes/polyMesh/globalMeshData/globalMeshData.C
src/OpenFOAM/meshes/polyMesh/globalMeshData/globalMeshDataTemplates.C

Classes

Public Member Functions

Static Public Member Functions

Static Public Attributes

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ globalMeshData()

◆ ~globalMeshData()

Member Function Documentation

◆ ClassName()

◆ clearOut()

◆ mesh()

◆ parallel()

◆ nTotalPoints()

◆ nTotalFaces()

◆ nTotalCells()

◆ processorPatches()

◆ processorPatchIndices()

◆ processorPatchNeighbours()

◆ nGlobalPoints()

◆ sharedPointLabels()

◆ sharedPointAddr()

◆ sharedPointGlobalLabels()

◆ sharedPoints()

◆ geometricSharedPoints()

◆ nGlobalEdges()

◆ sharedEdgeLabels()

◆ sharedEdgeAddr()

◆ coupledPatch()

◆ coupledPatchMeshEdges()

◆ coupledPatchMeshEdgeMap()

◆ globalTransforms()

◆ syncData() [1/2]

◆ syncData() [2/2]

◆ globalPointNumbering()

◆ globalPointSlaves()

◆ globalPointTransformedSlaves()

◆ globalPointSlavesMap()

◆ syncPointData()

◆ globalEdgeNumbering()

◆ globalEdgeSlaves()

◆ globalEdgeTransformedSlaves()

◆ globalEdgeSlavesMap()

◆ globalEdgeOrientation()

◆ globalCoPointSlaves()

◆ globalCoPointSlavesMap()

◆ globalBoundaryFaceNumbering()

◆ globalPointBoundaryFaces()

◆ globalPointTransformedBoundaryFaces()

◆ globalPointBoundaryFacesMap()

◆ boundaryCells()

◆ globalBoundaryCellNumbering()

◆ globalPointBoundaryCells()

◆ globalPointTransformedBoundaryCells()

◆ globalPointBoundaryCellsMap()

◆ mergePoints() [1/2]

◆ mergePoints() [2/2]

◆ movePoints()

◆ updateMesh()

Member Data Documentation

◆ matchTol_
