accessor Class Reference

glTF accessor More...

Inheritance diagram for accessor:

Collaboration diagram for accessor:

Public Member Functions
	accessor ()
	accessor (const word &name)
	~accessor ()=default
label &	bufferViewId () noexcept
label &	byteOffset () noexcept
label &	componentType () noexcept
label &	count () noexcept
string &	type () noexcept
template<class Type >
void	set (const Field< Type > &fld, bool calcMinMax=true)
void	write (Ostream &os) const
template<class Type >
Foam::string	getValueType ()
template<class Type >
Foam::string	toString (const Type &val)
Public Member Functions inherited from base
	base ()
	base (const word &name)
	~base ()=default
label &	id () noexcept
const word &	name () const noexcept
void	write (Ostream &os) const
void	operator= (const base &gltf)

Static Protected Member Functions
template<class Type >
static string	getValueType ()
template<class Type >
static string	toString (const Type &val)

Protected Attributes
label	bufferViewId_
label	byteOffset_
label	componentType_
label	count_
string	type_
string	max_
string	min_
bool	minMax_
Protected Attributes inherited from base
word	name_
label	id_

Detailed Description

glTF accessor

Note

Implements the glTF v2 specification

Source files

• foamGltfAccessor.H
• foamGltfAccessor.C
• foamGltfAccessorTemplates.C

Definition at line 62 of file foamGltfAccessor.H.

Constructor & Destructor Documentation

accessor() [1/2]

accessor

(

)

Definition at line 25 of file foamGltfAccessor.C.

accessor() [2/2]

accessor ( const word &  name )

explicit

Definition at line 39 of file foamGltfAccessor.C.

~accessor()

~accessor ( )

default

Member Function Documentation

getValueType() [1/2]

static string getValueType ( )

staticprotected

toString() [1/2]

static string toString ( const Type &  val )

staticprotected

Referenced by accessor::set().

Here is the caller graph for this function:

bufferViewId()

Foam::label & bufferViewId ( )

noexcept

Definition at line 55 of file foamGltfAccessor.C.

byteOffset()

Foam::label & byteOffset ( )

noexcept

Definition at line 61 of file foamGltfAccessor.C.

componentType()

Foam::label & componentType ( )

noexcept

Definition at line 67 of file foamGltfAccessor.C.

count()

Foam::label & count ( )

noexcept

Definition at line 73 of file foamGltfAccessor.C.

type()

Foam::string & type ( )

noexcept

Definition at line 79 of file foamGltfAccessor.C.

set()

void set	(	const Field< Type > &	fld,
		bool	calcMinMax = true
	)

Definition at line 79 of file foamGltfAccessorTemplates.C.

References fld, Foam::glTF::FLOAT, Foam::glTF::key(), Foam::max(), maxValue, Foam::min(), minValue, and accessor::toString().

Here is the call graph for this function:

write()

void write

(

Ostream &

os

)

const

Definition at line 85 of file foamGltfAccessor.C.

References Foam::indent(), Foam::nl, os(), and base::write().

Referenced by Foam::operator<<().

Here is the call graph for this function:

Here is the caller graph for this function:

getValueType() [2/2]

Foam::string getValueType

(

)

Definition at line 27 of file foamGltfAccessorTemplates.C.

References Foam::abort(), Foam::FatalError, and FatalErrorInFunction.

Here is the call graph for this function:

toString() [2/2]

Foam::string toString

(

const Type &

val

)

Definition at line 61 of file foamGltfAccessorTemplates.C.

References Foam::component(), and StringStreamAllocator< StreamType >::str().

Here is the call graph for this function:

Member Data Documentation

bufferViewId_

label bufferViewId_

protected

Definition at line 71 of file foamGltfAccessor.H.

byteOffset_

label byteOffset_

protected

Definition at line 74 of file foamGltfAccessor.H.

componentType_

label componentType_

protected

Definition at line 77 of file foamGltfAccessor.H.

count_

label count_

protected

Definition at line 80 of file foamGltfAccessor.H.

type_

string type_

protected

Definition at line 83 of file foamGltfAccessor.H.

max_

string max_

protected

Definition at line 86 of file foamGltfAccessor.H.

min_

string min_

protected

Definition at line 89 of file foamGltfAccessor.H.

minMax_

bool minMax_

protected

Definition at line 92 of file foamGltfAccessor.H.

---

The documentation for this class was generated from the following files:

• src/fileFormats/gltf/foamGltfAccessor.H
• src/fileFormats/gltf/foamGltfAccessor.C
• src/fileFormats/gltf/foamGltfAccessorTemplates.C
