Implementation of cellLooper. Does pure geometric cut through cell. More...

Inheritance diagram for geomCellLooper:

Collaboration diagram for geomCellLooper:

Public Member Functions
	TypeName ("geomCellLooper")

	geomCellLooper (const polyMesh &mesh)

virtual	~geomCellLooper ()=default

virtual bool	cut (const vector &refDir, const label celli, const boolList &vertIsCut, const boolList &edgeIsCut, const scalarField &edgeWeight, labelList &loop, scalarField &loopWeights) const

virtual bool	cut (const plane &cutPlane, const label celli, const boolList &vertIsCut, const boolList &edgeIsCut, const scalarField &edgeWeight, labelList &loop, scalarField &loopWeights) const

Public Member Functions inherited from cellLooper
	TypeName ("cellLooper")

	declareRunTimeSelectionTable (autoPtr, cellLooper, word,(const polyMesh &mesh),(mesh))

	cellLooper (const polyMesh &mesh)

autoPtr< cellLooper >	clone () const

virtual	~cellLooper ()=default

Public Member Functions inherited from edgeVertex
	edgeVertex (const polyMesh &mesh)

const polyMesh &	mesh () const

bool	isEdge (const label eVert) const

label	getEdge (const label eVert) const

label	getVertex (const label eVert) const

label	vertToEVert (const label vertI) const

label	edgeToEVert (const label edgeI) const

point	coord (const label cut, const scalar weight) const

label	cutPairToEdge (const label cut0, const label cut1) const

Ostream &	writeCut (Ostream &os, const label cut, const scalar) const

Ostream &	writeCuts (Ostream &os, const labelList &, const scalarField &) const

Static Public Member Functions
static scalar	snapTol ()

static void	setSnapTol (const scalar tol)

Static Public Member Functions inherited from cellLooper
static autoPtr< cellLooper >	New (const word &type, const polyMesh &mesh)

Static Public Member Functions inherited from edgeVertex
static void	updateLabels (const labelList &map, List< refineCell > &)

static void	updateLabels (const labelList &map, Map< label > &)

static void	updateLabels (const labelList &map, labelHashSet &)

static bool	isEdge (const primitiveMesh &mesh, const label eVert)

static label	getEdge (const primitiveMesh &mesh, const label eVert)

static label	getVertex (const primitiveMesh &mesh, const label eVert)

static label	vertToEVert (const primitiveMesh &mesh, const label vertI)

static label	edgeToEVert (const primitiveMesh &mesh, const label edgeI)

static point	coord (const primitiveMesh &, const label cut, const scalar weight)

static label	cutPairToEdge (const primitiveMesh &, const label cut0, const label cut1)

Additional Inherited Members
Protected Member Functions inherited from cellLooper
labelList	getVertFacesNonEdge (const label celli, const label edgeI, const label vertI) const

label	getFirstVertEdge (const label facei, const label vertI) const

labelList	getVertEdgesNonFace (const label celli, const label facei, const label vertI) const

label	getMisAlignedEdge (const vector &refDir, const label celli) const

	cellLooper (const cellLooper &)=delete

void	operator= (const cellLooper &)=delete

Detailed Description

Implementation of cellLooper. Does pure geometric cut through cell.

Handles all cell shapes in the same way: cut edges with plane through cell centre and normal in direction of provided direction. Snaps cuts close to edge endpoints (close = snapTol * minEdgeLen) to vertices.

Currently determines cuts through edges (and edge endpoints close to plane) in random order and then sorts them acc. to angle. Could be converted to use walk but problem is that face can be cut multiple times (since does not need to be convex). Another problem is that edges parallel to plane might not be cut. So these are handled by looking at the distance from edge endpoints to the plane.

Source files

Definition at line 62 of file geomCellLooper.H.

Constructor & Destructor Documentation

◆ geomCellLooper()

geomCellLooper ( const polyMesh & mesh )

explicit

Definition at line 201 of file geomCellLooper.C.

◆ ~geomCellLooper()

virtual ~geomCellLooper ( )

virtualdefault

Member Function Documentation

◆ TypeName()

TypeName ( "geomCellLooper" )

◆ snapTol()

static scalar snapTol ( )

inlinestatic

Definition at line 127 of file geomCellLooper.H.

◆ setSnapTol()

static void setSnapTol ( const scalar tol )

inlinestatic

Definition at line 132 of file geomCellLooper.H.

◆ cut() [1/2]

bool cut	(	const vector &	refDir,
		const label	celli,
		const boolList &	vertIsCut,
		const boolList &	edgeIsCut,
		const scalarField &	edgeWeight,
		labelList &	loop,
		scalarField &	loopWeights
	)		const

virtual

Implements cellLooper.

Reimplemented in topoCellLooper, and hexCellLooper.

Definition at line 210 of file geomCellLooper.C.

References mesh.

Referenced by hexCellLooper::cut().

Here is the caller graph for this function:

◆ cut() [2/2]

bool cut	(	const plane &	cutPlane,
		const label	celli,
		const boolList &	vertIsCut,
		const boolList &	edgeIsCut,
		const scalarField &	edgeWeight,
		labelList &	loop,
		scalarField &	loopWeights
	)		const
