Applies a viscous dissipation energy source to the energy equation. More...

Inheritance diagram for viscousDissipation:

Collaboration diagram for viscousDissipation:

Public Member Functions
	TypeName ("viscousDissipation")

	viscousDissipation (const word &sourceName, const word &modelType, const dictionary &dict, const fvMesh &mesh)

	viscousDissipation (const viscousDissipation &)=delete

void	operator= (const viscousDissipation &)=delete

virtual	~viscousDissipation ()=default

virtual void	addSup (const volScalarField &rho, fvMatrix< scalar > &eqn, const label fieldi)

virtual bool	read (const dictionary &dict)

Public Member Functions inherited from option
	TypeName ("option")

	declareRunTimeSelectionTable (autoPtr, option, dictionary,(const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh),(name, modelType, dict, mesh))

	option (const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh)

autoPtr< option >	clone () const

virtual	~option ()=default

const word &	name () const noexcept

const fvMesh &	mesh () const noexcept

const dictionary &	coeffs () const noexcept

bool	active () const noexcept

void	setApplied (const label fieldi)

bool	active (const bool on) noexcept

virtual bool	isActive ()

virtual label	applyToField (const word &fieldName) const

virtual void	checkApplied () const

virtual void	addSup (fvMatrix< scalar > &eqn, const label fieldi)

virtual void	addSup (fvMatrix< vector > &eqn, const label fieldi)

virtual void	addSup (fvMatrix< symmTensor > &eqn, const label fieldi)

virtual void	addSup (fvMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void	addSup (fvMatrix< tensor > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &rho, fvMatrix< vector > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &rho, fvMatrix< symmTensor > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &rho, fvMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &rho, fvMatrix< tensor > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< scalar > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< vector > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< symmTensor > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< tensor > &eqn, const label fieldi)

virtual void	constrain (fvMatrix< scalar > &eqn, const label fieldi)

virtual void	constrain (fvMatrix< vector > &eqn, const label fieldi)

virtual void	constrain (fvMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void	constrain (fvMatrix< symmTensor > &eqn, const label fieldi)

virtual void	constrain (fvMatrix< tensor > &eqn, const label fieldi)

virtual void	correct (volScalarField &field)

virtual void	correct (volVectorField &field)

virtual void	correct (volSphericalTensorField &field)

virtual void	correct (volSymmTensorField &field)

virtual void	correct (volTensorField &field)

virtual void	postProcessSens (scalarField &sensField, const word &fieldName=word::null, const word &designVariablesName=word::null)

virtual void	postProcessSens (vectorField &sensField, const word &fieldName=word::null, const word &designVariablesName=word::null)

virtual void	postProcessSens (tensorField &sensField, const word &fieldName=word::null, const word &designVariablesName=word::null)

virtual void	writeHeader (Ostream &) const

virtual void	writeFooter (Ostream &) const

virtual void	writeData (Ostream &) const

Additional Inherited Members
Static Public Member Functions inherited from option
static autoPtr< option >	New (const word &name, const dictionary &dict, const fvMesh &mesh)

Public Attributes inherited from option
bool	log

Protected Member Functions inherited from option
void	resetApplied ()

Protected Attributes inherited from option
const word	name_

const word	modelType_

const fvMesh &	mesh_

dictionary	dict_

dictionary	coeffs_

wordList	fieldNames_

List< bool >	applied_

bool	active_

Detailed Description

Applies a viscous dissipation energy source to the energy equation.

Sources applied to either of the below, if exist:

  e         | Internal energy                            [m2/s2]
  h         | Enthalphy                                  [m2/s2]
  field     | User-specified field

Required fields:

  U         | Velocity                                   [m/s]
  rho       | Fluid density (for compressible flows)     [kg/m3]

Usage

Minimal example by using constant/fvOptions:

viscousDissipation1
{
    // Mandatory entries (unmodifiable)
    type                 viscousDissipation;

    // Optional entries (unmodifiable)
    fields           (<fieldName>);
    U                <UName>;
    rho              <rhoName>;

    // Conditional optional entries (unmodifiable)

        // when rho=rhoInf
        rhoInf       1000;

    // Mandatory/Optional (inherited) entries
    ...
}

where the entries mean:

Property	Description	Type	Reqd	Dflt
`type`	Type name: viscousDissipation	word	yes	-
`fields`	Name of operand (energy) field	word	no	-
`U`	Name of operand velocity field	word	no	U
`rho`	Name of operand density field	word	no	none
`rhoInf`	Value of fluid density	scalar	cndtnl	0

The inherited entries are elaborated in:

fvOption.H

Note

The entry fields accepts only a single field name.
The sources are applied onto the entire computational domain.
rho=rhoInf sets a zero-density for single phase flows.
Not applicable to multiphase flows.

Source files

Definition at line 143 of file viscousDissipation.H.

Constructor & Destructor Documentation

◆ viscousDissipation() [1/2]

viscousDissipation	(	const word &	sourceName,
		const word &	modelType,
		const dictionary &	dict,
		const fvMesh &	mesh
	)

Definition at line 78 of file viscousDissipation.C.

References basicThermo::dictName, Foam::exit(), Foam::FatalError, FatalErrorInFunction, dictionary::readEntry(), and option::resetApplied().

Here is the call graph for this function:

◆ viscousDissipation() [2/2]

viscousDissipation ( const viscousDissipation & )

delete

◆ ~viscousDissipation()

virtual ~viscousDissipation ( )

virtualdefault

Member Function Documentation

◆ TypeName()

TypeName ( "viscousDissipation" )

◆ operator=()

void operator= ( const viscousDissipation & )

delete

◆ addSup()

void addSup	(	const volScalarField &	rho,
		fvMatrix< scalar > &	eqn,
		const label	fieldi
	)

virtual

Reimplemented from option.

Definition at line 162 of file viscousDissipation.C.

References D, Foam::dimTime, Foam::fvc::grad(), Foam::inv(), tmp::New(), IOobject::NO_READ, IOobject::NO_WRITE, GeometricField::ref(), U, and Foam::Zero.

Here is the call graph for this function:

◆ read()

virtual bool read ( const dictionary & dict )

inlinevirtual
