variableHeatTransfer Class Reference
Numerics » Finite volume Options » Sources

Applies a variable heat transfer model depending on local values for inter-region heat exchanges. More...

Inheritance diagram for variableHeatTransfer:
Inheritance graph
[legend]
Collaboration diagram for variableHeatTransfer:
Collaboration graph
[legend]

Public Member Functions

 TypeName ("variableHeatTransfer")

 variableHeatTransfer (const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh)

 variableHeatTransfer (const variableHeatTransfer &)=delete

void operator= (const variableHeatTransfer &)=delete

virtual ~variableHeatTransfer ()=default

virtual void calculateHtc ()

virtual bool read (const dictionary &dict)

- Public Member Functions inherited from interRegionHeatTransferModel
 TypeName ("interRegionHeatTransferModel")

 interRegionHeatTransferModel (const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh)

virtual ~interRegionHeatTransferModel ()=default

const word & nbrRegionName () const

const meshToMesh & meshInterp () const

const volScalarField & htc () const

const interRegionHeatTransferModel & nbrModel () const

interRegionHeatTransferModel & nbrModel ()

virtual void addSup (fvMatrix< scalar > &eqn, const label fieldi)

virtual void addSup (const volScalarField &rho, fvMatrix< scalar > &eqn, const label fieldi)

template<class Type >
Foam::tmp< Foam::Field< Type > > interpolate (const interRegionHeatTransferModel &nbrModel, const Field< Type > &field) const

template<class Type >
Foam::tmp< Foam::Field< Type > > interpolate (const Field< Type > &field) const

- Public Member Functions inherited from interRegionOption
 TypeName ("interRegionOption")

 interRegionOption (const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh)

 interRegionOption (const interRegionOption &)=delete

void operator= (const interRegionOption &)=delete

virtual ~interRegionOption ()=default

const word & nbrRegionName () const

const meshToMesh & meshInterp () const

- Public Member Functions inherited from option
 TypeName ("option")

 declareRunTimeSelectionTable (autoPtr, option, dictionary,(const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh),(name, modelType, dict, mesh))

 option (const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh)

autoPtr< option > clone () const

virtual ~option ()=default

const word & name () const noexcept

const fvMesh & mesh () const noexcept

const dictionary & coeffs () const noexcept

bool active () const noexcept

void setApplied (const label fieldi)

bool active (const bool on) noexcept

virtual bool isActive ()

virtual label applyToField (const word &fieldName) const

virtual void checkApplied () const

virtual void addSup (fvMatrix< vector > &eqn, const label fieldi)

virtual void addSup (fvMatrix< symmTensor > &eqn, const label fieldi)

virtual void addSup (fvMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void addSup (fvMatrix< tensor > &eqn, const label fieldi)

virtual void addSup (const volScalarField &rho, fvMatrix< vector > &eqn, const label fieldi)

virtual void addSup (const volScalarField &rho, fvMatrix< symmTensor > &eqn, const label fieldi)

virtual void addSup (const volScalarField &rho, fvMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void addSup (const volScalarField &rho, fvMatrix< tensor > &eqn, const label fieldi)

virtual void addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< scalar > &eqn, const label fieldi)

virtual void addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< vector > &eqn, const label fieldi)

virtual void addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< symmTensor > &eqn, const label fieldi)

virtual void addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< tensor > &eqn, const label fieldi)

virtual void constrain (fvMatrix< scalar > &eqn, const label fieldi)

virtual void constrain (fvMatrix< vector > &eqn, const label fieldi)

virtual void constrain (fvMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void constrain (fvMatrix< symmTensor > &eqn, const label fieldi)

virtual void constrain (fvMatrix< tensor > &eqn, const label fieldi)

virtual void correct (volScalarField &field)

virtual void correct (volVectorField &field)

virtual void correct (volSphericalTensorField &field)

virtual void correct (volSymmTensorField &field)

virtual void correct (volTensorField &field)

virtual void postProcessSens (scalarField &sensField, const word &fieldName=word::null, const word &designVariablesName=word::null)

virtual void postProcessSens (vectorField &sensField, const word &fieldName=word::null, const word &designVariablesName=word::null)

virtual void postProcessSens (tensorField &sensField, const word &fieldName=word::null, const word &designVariablesName=word::null)

virtual void writeHeader (Ostream &) const

virtual void writeFooter (Ostream &) const

virtual void writeData (Ostream &) const


Additional Inherited Members

- Static Public Member Functions inherited from option
static autoPtr< option > New (const word &name, const dictionary &dict, const fvMesh &mesh)

- Public Attributes inherited from option
bool log

- Protected Member Functions inherited from interRegionHeatTransferModel
void setNbrModel ()

void correct ()

template<class Type >
tmp< Field< Type > > interpolate (const interRegionHeatTransferModel &nbrModel, const Field< Type > &field) const

template<class Type >
tmp< Field< Type > > interpolate (const Field< Type > &field) const

template<class Type >
void interpolate (const interRegionHeatTransferModel &nbrModel, const Field< Type > &field, Field< Type > &result) const

template<class Type >
void interpolate (const Field< Type > &field, Field< Type > &result) const

- Protected Member Functions inherited from interRegionOption
void setMapper ()

- Protected Member Functions inherited from option
void resetApplied ()

- Protected Attributes inherited from interRegionHeatTransferModel
word nbrModelName_

interRegionHeatTransferModel * nbrModel_

bool firstIter_

bool semiImplicit_

label timeIndex_

volScalarField htc_

word TName_

word TNbrName_

- Protected Attributes inherited from interRegionOption
bool master_

word nbrRegionName_

autoPtr< meshToMesh > meshInterpPtr_

- Protected Attributes inherited from option
const word name_

const word modelType_

const fvMesh & mesh_

dictionary dict_

dictionary coeffs_

wordList fieldNames_

List< bool > applied_

bool active_


Detailed Description

Applies a variable heat transfer model depending on local values for inter-region heat exchanges.

The area of contact between regions (area) must be provided. The Nu number is calculated as:

\[ Nu = a \, \textrm{Re}^b \, \textrm{Pr}^c \]

and the heat transfer coefficient as:

\[ htc = \frac{\textrm{Nu} \, K}{ds} \]

where

$ htc $ = Heat transfer coefficient
$ Nu $ = Nusselt number
$ Re $ = Reynolds number
$ Pr $ = Fluid Prandtl number
$ K $ = Heat conduction
$ ds $ = Strut diameter
$ a, b, c $ = Model constants

Required fields:

      AoV       | Area per unit volume of heat exchanger    [1/m]
Usage
Minimal example by using constant/fvOptions:
variableHeatTransfer1
{
    // Mandatory entries (unmodifiable)
    type             variableHeatTransfer;

    // Optional entries (runtime modifiable)
    UNbr             U;
    a                0.0;
    b                0.0;
    c                0.0;
    ds               0.0;
    Pr               0.0;

    // Mandatory/Optional (inherited) entries
    ...
}

where the entries mean:

Property Description Type Reqd Dflt
type Type name: variableHeatTransfer word yes -
UNbr Name of operand neighbour velocity field word no U
a Model constant scalar no 0
b Model constant scalar no 0
c Model constant scalar no 0
ds Struct diameter scalar no 0
Pr Fluid Prandtl number scalar no 0

The inherited entries are elaborated in:

See also
Source files

Definition at line 201 of file variableHeatTransfer.H.

Constructor & Destructor Documentation

◆ variableHeatTransfer() [1/2]

variableHeatTransfer ( const word &  name,
const word &  modelType,
const dictionary &  dict,
const fvMesh &  mesh
)

Definition at line 41 of file variableHeatTransfer.C.

◆ variableHeatTransfer() [2/2]

variableHeatTransfer ( const variableHeatTransfer &  )
delete

◆ ~variableHeatTransfer()

virtual ~variableHeatTransfer ( )
virtualdefault

Member Function Documentation

◆ TypeName()

TypeName ( "variableHeatTransfer"  )

◆ operator=()

void operator= ( const variableHeatTransfer &  )
delete

◆ calculateHtc()

void calculateHtc ( )
virtual

Implements interRegionHeatTransferModel.

Definition at line 86 of file variableHeatTransfer.C.

References basicThermo::dictName, interRegionHeatTransferModel::htc_, interRegionHeatTransferModel::interpolate(), objectRegistry::lookupObject(), Foam::mag(), option::mesh_, interRegionHeatTransferModel::nbrRegionName(), Foam::pow(), GeometricField::primitiveFieldRef(), turbulenceModel::propertiesName, and fvMesh::time().

Here is the call graph for this function:

◆ read()

bool read ( const dictionary &  dict)
virtual

Reimplemented from interRegionHeatTransferModel.

Definition at line 113 of file variableHeatTransfer.C.

References dict, and interRegionHeatTransferModel::read().

Here is the call graph for this function:
The documentation for this class was generated from the following files:
