Surface gradient scheme with under-/over-relaxed full or limited explicit non-orthogonal correction. More...

Inheritance diagram for relaxedSnGrad< Type >:

Collaboration diagram for relaxedSnGrad< Type >:

Public Member Functions
	TypeName ("relaxed")

	relaxedSnGrad (const fvMesh &mesh)

	relaxedSnGrad (const fvMesh &mesh, Istream &schemeData)

virtual	~relaxedSnGrad ()=default

virtual tmp< surfaceScalarField >	deltaCoeffs (const GeometricField< Type, fvPatchField, volMesh > &) const

virtual bool	corrected () const noexcept

virtual tmp< GeometricField< Type, fvsPatchField, surfaceMesh > >	correction (const GeometricField< Type, fvPatchField, volMesh > &) const

Public Member Functions inherited from snGradScheme< Type >
virtual const word &	type () const =0

	declareRunTimeSelectionTable (tmp, snGradScheme, Mesh,(const fvMesh &mesh, Istream &schemeData),(mesh, schemeData))

	snGradScheme (const fvMesh &mesh)

virtual	~snGradScheme ()=default

const fvMesh &	mesh () const

virtual tmp< GeometricField< Type, fvsPatchField, surfaceMesh > >	snGrad (const GeometricField< Type, fvPatchField, volMesh > &) const

tmp< GeometricField< Type, fvsPatchField, surfaceMesh > >	snGrad (const tmp< GeometricField< Type, fvPatchField, volMesh >> &) const

Public Member Functions inherited from refCount
constexpr	refCount () noexcept

int	count () const noexcept

bool	unique () const noexcept

void	operator++ () noexcept

void	operator++ (int) noexcept

void	operator-- () noexcept

void	operator-- (int) noexcept

Additional Inherited Members
Static Public Member Functions inherited from snGradScheme< Type >
static tmp< snGradScheme< Type > >	New (const fvMesh &mesh, Istream &schemeData)

static tmp< GeometricField< Type, fvsPatchField, surfaceMesh > >	snGrad (const GeometricField< Type, fvPatchField, volMesh > &, const tmp< surfaceScalarField > &, const word &snGradName="snGrad")

static tmp< GeometricField< Type, fvsPatchField, surfaceMesh > >	sndGrad (const GeometricField< Type, fvPatchField, volMesh > &, const word &snGradName="sndGrad")

Detailed Description

template<class Type>
class Foam::fv::relaxedSnGrad< Type >

Surface gradient scheme with under-/over-relaxed full or limited explicit non-orthogonal correction.

Usage

Minimal example by using system/fvSchemes:

snGradSchemes
{
    snGrad(<term>)       relaxed;
}

and by using system/fvSolution:

relaxationFactors
{
    fields
    {
        snGrad(<term>)   <relaxation factor>;
    }
}

Source files

Definition at line 77 of file relaxedSnGrad.H.

Constructor & Destructor Documentation

◆ relaxedSnGrad() [1/2]

relaxedSnGrad ( const fvMesh & mesh )

inline

Definition at line 102 of file relaxedSnGrad.H.

◆ relaxedSnGrad() [2/2]

relaxedSnGrad	(	const fvMesh &	mesh,
		Istream &	schemeData
	)

inline

Definition at line 109 of file relaxedSnGrad.H.

◆ ~relaxedSnGrad()

virtual ~relaxedSnGrad ( )

virtualdefault

Member Function Documentation

◆ TypeName()

TypeName ( "relaxed" )

◆ deltaCoeffs()

virtual tmp<surfaceScalarField> deltaCoeffs ( const GeometricField< Type, fvPatchField, volMesh > & ) const

inlinevirtual

Implements snGradScheme< Type >.

Definition at line 124 of file relaxedSnGrad.H.

References snGradScheme< Type >::mesh(), and surfaceInterpolation::nonOrthDeltaCoeffs().

Here is the call graph for this function:

◆ corrected()

virtual bool corrected ( ) const

inlinevirtualnoexcept

Reimplemented from snGradScheme< Type >.

Definition at line 132 of file relaxedSnGrad.H.

◆ correction()

Foam::tmp< Foam::GeometricField< Type, Foam::fvsPatchField, Foam::surfaceMesh > > correction ( const GeometricField< Type, fvPatchField, volMesh > & vf ) const
