Surface gradient scheme with no non-orthogonal correction. More...

Inheritance diagram for orthogonalSnGrad< Type >:

Collaboration diagram for orthogonalSnGrad< Type >:

Public Member Functions
	TypeName ("orthogonal")

	orthogonalSnGrad (const fvMesh &mesh)

	orthogonalSnGrad (const fvMesh &mesh, Istream &)

virtual	~orthogonalSnGrad ()=default

virtual tmp< surfaceScalarField >	deltaCoeffs (const GeometricField< Type, fvPatchField, volMesh > &) const

virtual bool	corrected () const noexcept

virtual tmp< GeometricField< Type, fvsPatchField, surfaceMesh > >	correction (const GeometricField< Type, fvPatchField, volMesh > &) const

Public Member Functions inherited from snGradScheme< Type >
virtual const word &	type () const =0

	declareRunTimeSelectionTable (tmp, snGradScheme, Mesh,(const fvMesh &mesh, Istream &schemeData),(mesh, schemeData))

	snGradScheme (const fvMesh &mesh)

virtual	~snGradScheme ()=default

const fvMesh &	mesh () const

virtual tmp< GeometricField< Type, fvsPatchField, surfaceMesh > >	snGrad (const GeometricField< Type, fvPatchField, volMesh > &) const

tmp< GeometricField< Type, fvsPatchField, surfaceMesh > >	snGrad (const tmp< GeometricField< Type, fvPatchField, volMesh >> &) const

Public Member Functions inherited from refCount
constexpr	refCount () noexcept

int	count () const noexcept

bool	unique () const noexcept

void	operator++ () noexcept

void	operator++ (int) noexcept

void	operator-- () noexcept

void	operator-- (int) noexcept

Additional Inherited Members
Static Public Member Functions inherited from snGradScheme< Type >
static tmp< snGradScheme< Type > >	New (const fvMesh &mesh, Istream &schemeData)

static tmp< GeometricField< Type, fvsPatchField, surfaceMesh > >	snGrad (const GeometricField< Type, fvPatchField, volMesh > &, const tmp< surfaceScalarField > &, const word &snGradName="snGrad")

static tmp< GeometricField< Type, fvsPatchField, surfaceMesh > >	sndGrad (const GeometricField< Type, fvPatchField, volMesh > &, const word &snGradName="sndGrad")

Detailed Description

template<class Type>
class Foam::fv::orthogonalSnGrad< Type >

Surface gradient scheme with no non-orthogonal correction.

Usage

Minimal example by using system/fvSchemes:

snGradSchemes
{
    snGrad(<term>)       orthogonal;
}

Note

Interpolation weighting factors (i.e. delta coefficients) are based on the deltaCoeffs function rather than the nonOrthDeltaCoeffs function, which is used by the uncorrected scheme.

Source files

Definition at line 70 of file orthogonalSnGrad.H.

Constructor & Destructor Documentation

◆ orthogonalSnGrad() [1/2]

orthogonalSnGrad ( const fvMesh & mesh )

inline

Definition at line 89 of file orthogonalSnGrad.H.

◆ orthogonalSnGrad() [2/2]

orthogonalSnGrad	(	const fvMesh &	mesh,
		Istream &
	)

inline

Definition at line 95 of file orthogonalSnGrad.H.

◆ ~orthogonalSnGrad()

virtual ~orthogonalSnGrad ( )

virtualdefault

Member Function Documentation

◆ TypeName()

TypeName ( "orthogonal" )

◆ deltaCoeffs()

virtual tmp<surfaceScalarField> deltaCoeffs ( const GeometricField< Type, fvPatchField, volMesh > & ) const

inlinevirtual

Implements snGradScheme< Type >.

Definition at line 109 of file orthogonalSnGrad.H.

References surfaceInterpolation::deltaCoeffs(), and snGradScheme< Type >::mesh().

Here is the call graph for this function:

◆ corrected()

virtual bool corrected ( ) const

inlinevirtualnoexcept

Reimplemented from snGradScheme< Type >.

Definition at line 117 of file orthogonalSnGrad.H.

◆ correction()

tmp< GeometricField< Type, fvsPatchField, surfaceMesh > > correction ( const GeometricField< Type, fvPatchField, volMesh > & ) const

virtual

Reimplemented from snGradScheme< Type >.

Definition at line 41 of file orthogonalSnGrad.C.

References NotImplemented.

The documentation for this class was generated from the following files:

src/finiteVolume/finiteVolume/snGradSchemes/orthogonalSnGrad/orthogonalSnGrad.H
src/finiteVolume/finiteVolume/snGradSchemes/orthogonalSnGrad/orthogonalSnGrad.C
