Applies corrections to the turbulent kinetic energy equation (i.e. k) and turbulent viscosity field (i.e. nut) for incompressible multiphase flow cases. More...

Inheritance diagram for multiphaseStabilizedTurbulence:

[legend]

Collaboration diagram for multiphaseStabilizedTurbulence:

[legend]

Public Member Functions
	TypeName ("multiphaseStabilizedTurbulence")

	multiphaseStabilizedTurbulence (const word &sourceName, const word &modelType, const dictionary &dict, const fvMesh &mesh)

	multiphaseStabilizedTurbulence (const multiphaseStabilizedTurbulence &)=delete

void	operator= (const multiphaseStabilizedTurbulence &)=delete

virtual	~multiphaseStabilizedTurbulence ()=default

virtual void	addSup (const volScalarField &rho, fvMatrix< scalar > &eqn, const label fieldi)

virtual void	addSup (fvMatrix< scalar > &eqn, const label fieldi)

virtual void	correct (volScalarField &field)

virtual bool	read (const dictionary &dict)

Public Member Functions inherited from option
	TypeName ("option")

	declareRunTimeSelectionTable (autoPtr, option, dictionary,(const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh),(name, modelType, dict, mesh))

	option (const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh)

autoPtr< option >	clone () const

virtual	~option ()=default

const word &	name () const noexcept

const fvMesh &	mesh () const noexcept

const dictionary &	coeffs () const noexcept

bool	active () const noexcept

void	setApplied (const label fieldi)

bool	active (const bool on) noexcept

virtual bool	isActive ()

virtual label	applyToField (const word &fieldName) const

virtual void	checkApplied () const

virtual void	addSup (fvMatrix< vector > &eqn, const label fieldi)

virtual void	addSup (fvMatrix< symmTensor > &eqn, const label fieldi)

virtual void	addSup (fvMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void	addSup (fvMatrix< tensor > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &rho, fvMatrix< vector > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &rho, fvMatrix< symmTensor > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &rho, fvMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &rho, fvMatrix< tensor > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< scalar > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< vector > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< symmTensor > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< tensor > &eqn, const label fieldi)

virtual void	constrain (fvMatrix< scalar > &eqn, const label fieldi)

virtual void	constrain (fvMatrix< vector > &eqn, const label fieldi)

virtual void	constrain (fvMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void	constrain (fvMatrix< symmTensor > &eqn, const label fieldi)

virtual void	constrain (fvMatrix< tensor > &eqn, const label fieldi)

virtual void	correct (volVectorField &field)

virtual void	correct (volSphericalTensorField &field)

virtual void	correct (volSymmTensorField &field)

virtual void	correct (volTensorField &field)

virtual void	postProcessSens (scalarField &sensField, const word &fieldName=word::null, const word &designVariablesName=word::null)

virtual void	postProcessSens (vectorField &sensField, const word &fieldName=word::null, const word &designVariablesName=word::null)

virtual void	postProcessSens (tensorField &sensField, const word &fieldName=word::null, const word &designVariablesName=word::null)

virtual void	writeHeader (Ostream &) const

virtual void	writeFooter (Ostream &) const

virtual void	writeData (Ostream &) const

Additional Inherited Members
Static Public Member Functions inherited from option
static autoPtr< option >	New (const word &name, const dictionary &dict, const fvMesh &mesh)

Public Attributes inherited from option
bool	log

Protected Member Functions inherited from option
void	resetApplied ()

Protected Attributes inherited from option
const word	name_

const word	modelType_

const fvMesh &	mesh_

dictionary	dict_

dictionary	coeffs_

wordList	fieldNames_

List< bool >	applied_

bool	active_

Detailed Description

Applies corrections to the turbulent kinetic energy equation (i.e. k) and turbulent viscosity field (i.e. nut) for incompressible multiphase flow cases.

Turbulent kinetic energy is over-predicted in VOF solvers at the phase interface and throughout the water column in nearly-potential flow regions beneath surface waves.

References:

    Buoyancy source term in turbulent kinetic energy equation:
        Devolder, B., Rauwoens, P., and Troch, P. (2017).
        Application of a buoyancy-modified k-w SST turbulence model to
        simulate wave run-up around a monopile subjected to regular waves
        using OpenFOAM.
        Coastal Engineering, 125, 81-94.
        DOI:10.1016/j.coastaleng.2017.04.004

    Correction to turbulent viscosity:
        Larsen, B.E. and Fuhrman, D.R. (2018).
        On the over-production of turbulence beneath surface waves in
        Reynolds-averaged Navier-Stokes models
        J. Fluid Mech, 853, 419-460.
        DOI:10.1017/jfm.2018.577

Sources applied to:

  k         | Turbulent kinetic energy                   [m2/s2]
  nut       | Turbulent viscosity                        [m/s2]

Required fields:

  epsilon   | Turbulent kinetic energy dissipation rate  [m2/s3]
  k         | Turbulent kinetic energy                   [m2/s2]
  nut       | Turbulent viscosity                        [m/s2]

Usage

Minimal example by using constant/fvOptions:

multiphaseStabilizedTurbulence1
{
    // Mandatory entries (unmodifiable)
    type                 multiphaseStabilizedTurbulence;

    // Optional entries (unmodifiable)
    rho             <rhoName>;
    Cmu             0.09;  // from k-epsilon model
    C               1.51;  // from k-omega model
    lambda2         0.1;   // A value of 0 sets the nut correction to 0
    alpha           1.36;  // 1/Prt

    // Mandatory/Optional (inherited) entries
    ...
}

where the entries mean:

Property	Description	Type	Reqd	Dflt
`type`	Type name: multiphaseStabilizedTurbulence	word	yes	-
`rho`	Name of operand density field	word	yes	rho
`Cmu`	Model coefficient	scalar	no	0.09
`C`	Model coefficient	scalar	no	1.51
`lambda2`	Ratio of nut correction	scalar	no	0.1
`alpha`	Inverse of turbulent Prandtl number	scalar	no	1.36

The inherited entries are elaborated in:

fvOption.H

Note

The model C coefficient for the k-epsilon model equates to C2/C1 = 1.33; the (default) value of 1.51 comes from the k-omega model and is more conservative.
Only applicable to epsilon-based turbulence closure models.

Source files

Definition at line 171 of file multiphaseStabilizedTurbulence.H.

Constructor & Destructor Documentation

◆ multiphaseStabilizedTurbulence() [1/2]

multiphaseStabilizedTurbulence	(	const word &	sourceName,
		const word &	modelType,
		const dictionary &	dict,
		const fvMesh &	mesh
	)

Definition at line 46 of file multiphaseStabilizedTurbulence.C.

References Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, and Log.

Here is the call graph for this function:

◆ multiphaseStabilizedTurbulence() [2/2]

multiphaseStabilizedTurbulence ( const multiphaseStabilizedTurbulence & )

delete

◆ ~multiphaseStabilizedTurbulence()

virtual ~multiphaseStabilizedTurbulence ( )

virtualdefault

Member Function Documentation

◆ TypeName()

TypeName ( "multiphaseStabilizedTurbulence" )

◆ operator=()

void operator= ( const multiphaseStabilizedTurbulence & )

delete

◆ addSup() [1/2]

void addSup	(	const volScalarField &	rho,
		fvMatrix< scalar > &	eqn,
		const label	fieldi
	)

virtual

Reimplemented from option.

Definition at line 126 of file multiphaseStabilizedTurbulence.C.

References NotImplemented.

◆ addSup() [2/2]

void addSup	(	fvMatrix< scalar > &	eqn,
		const label	fieldi
	)

virtual

Reimplemented from option.

Definition at line 138 of file multiphaseStabilizedTurbulence.C.

References Foam::endl(), epsilon, Foam::exit(), Foam::FatalError, FatalErrorInFunction, g, Foam::fac::grad(), k, Log, Foam::name(), Foam::New(), fvMatrix::psi(), rho, and Foam::fam::SuSp().

Here is the call graph for this function:

◆ correct()

void correct ( volScalarField & field )

virtual

Reimplemented from option.

Definition at line 189 of file multiphaseStabilizedTurbulence.C.

References Foam::dimless, Foam::dimTime, Foam::endl(), epsilon, field(), option::fieldNames_, objectRegistry::findObject(), Foam::fvc::grad(), k, Log, Foam::magSqr(), Foam::max(), option::mesh_, option::name(), turbulenceModel::propertiesName, Foam::skew(), Foam::sqr(), Foam::symm(), and U.

Here is the call graph for this function:

◆ read()

virtual bool read ( const dictionary & dict )

inlinevirtual

Reimplemented from option.

Definition at line 250 of file multiphaseStabilizedTurbulence.H.

The documentation for this class was generated from the following files:

src/fvOptions/sources/derived/multiphaseStabilizedTurbulence/multiphaseStabilizedTurbulence.H
src/fvOptions/sources/derived/multiphaseStabilizedTurbulence/multiphaseStabilizedTurbulence.C
