Public Member Functions | Protected Member Functions | Protected Attributes | List of all members
interRegionExplicitPorositySource Class Reference
Numerics » Finite volume Options » Sources

Applies inter-region explicit porosity source. More...

Inheritance diagram for interRegionExplicitPorositySource:
Inheritance graph
[legend]
Collaboration diagram for interRegionExplicitPorositySource:
Collaboration graph
[legend]

Public Member Functions

 TypeName ("interRegionExplicitPorositySource")

 interRegionExplicitPorositySource (const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh)

 interRegionExplicitPorositySource (const interRegionExplicitPorositySource &)=delete

void operator= (const interRegionExplicitPorositySource &)=delete

virtual ~interRegionExplicitPorositySource ()=default

virtual void addSup (fvMatrix< vector > &eqn, const label fieldi)

virtual void addSup (const volScalarField &rho, fvMatrix< vector > &eqn, const label fieldi)

virtual bool read (const dictionary &dict)

- Public Member Functions inherited from interRegionOption
 TypeName ("interRegionOption")

 interRegionOption (const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh)

 interRegionOption (const interRegionOption &)=delete

void operator= (const interRegionOption &)=delete

virtual ~interRegionOption ()=default

const word & nbrRegionName () const

const meshToMesh & meshInterp () const

- Public Member Functions inherited from option
 TypeName ("option")

 declareRunTimeSelectionTable (autoPtr, option, dictionary,(const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh),(name, modelType, dict, mesh))

 option (const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh)

autoPtr< option > clone () const

virtual ~option ()=default

const word & name () const noexcept

const fvMesh & mesh () const noexcept

const dictionary & coeffs () const noexcept

bool active () const noexcept

void setApplied (const label fieldi)

bool active (const bool on) noexcept

virtual bool isActive ()

virtual label applyToField (const word &fieldName) const

virtual void checkApplied () const

virtual void addSup (fvMatrix< scalar > &eqn, const label fieldi)

virtual void addSup (fvMatrix< symmTensor > &eqn, const label fieldi)

virtual void addSup (fvMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void addSup (fvMatrix< tensor > &eqn, const label fieldi)

virtual void addSup (const volScalarField &rho, fvMatrix< scalar > &eqn, const label fieldi)

virtual void addSup (const volScalarField &rho, fvMatrix< symmTensor > &eqn, const label fieldi)

virtual void addSup (const volScalarField &rho, fvMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void addSup (const volScalarField &rho, fvMatrix< tensor > &eqn, const label fieldi)

virtual void addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< scalar > &eqn, const label fieldi)

virtual void addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< vector > &eqn, const label fieldi)

virtual void addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< symmTensor > &eqn, const label fieldi)

virtual void addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< tensor > &eqn, const label fieldi)

virtual void constrain (fvMatrix< scalar > &eqn, const label fieldi)

virtual void constrain (fvMatrix< vector > &eqn, const label fieldi)

virtual void constrain (fvMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void constrain (fvMatrix< symmTensor > &eqn, const label fieldi)

virtual void constrain (fvMatrix< tensor > &eqn, const label fieldi)

virtual void correct (volScalarField &field)

virtual void correct (volVectorField &field)

virtual void correct (volSphericalTensorField &field)

virtual void correct (volSymmTensorField &field)

virtual void correct (volTensorField &field)

virtual void postProcessSens (scalarField &sensField, const word &fieldName=word::null, const word &designVariablesName=word::null)

virtual void postProcessSens (vectorField &sensField, const word &fieldName=word::null, const word &designVariablesName=word::null)

virtual void postProcessSens (tensorField &sensField, const word &fieldName=word::null, const word &designVariablesName=word::null)

virtual void writeHeader (Ostream &) const

virtual void writeFooter (Ostream &) const

virtual void writeData (Ostream &) const


Protected Member Functions

void initialise ()

- Protected Member Functions inherited from interRegionOption
void setMapper ()

- Protected Member Functions inherited from option
void resetApplied ()


Protected Attributes

autoPtr< porosityModel > porosityPtr_

bool firstIter_

word UName_

word muName_

- Protected Attributes inherited from interRegionOption
bool master_

word nbrRegionName_

autoPtr< meshToMesh > meshInterpPtr_

- Protected Attributes inherited from option
const word name_

const word modelType_

const fvMesh & mesh_

dictionary dict_

dictionary coeffs_

wordList fieldNames_

List< bool > applied_

bool active_


Additional Inherited Members

- Static Public Member Functions inherited from option
static autoPtr< option > New (const word &name, const dictionary &dict, const fvMesh &mesh)

- Public Attributes inherited from option
bool log


Detailed Description

Applies inter-region explicit porosity source.

Usage
Minimal example by using constant/fvOptions:
interRegionExplicitPorositySource1
{
    // Mandatory entries (unmodifiable)
    type                 interRegionExplicitPorositySource;

    interRegionExplicitPorositySourceCoeffs
    {
        // Mandatory entries (unmodifiable)
        type     <porosityModel>;

        // Optional entries (runtime modifiable)
        U        U;
        mu       thermo:mu;
    }

    // Mandatory/Optional (inherited) entries
    ...
}

where the entries mean:

Property Description Type Reqd Dflt
type Type name: interRegionExplicitPorositySource word yes -
type Name of porosity model word yes -
U Name of operand velocity field word no U
mu Name of operand dynamic viscosity field word no thermo:mu

The inherited entries are elaborated in:

Sources described by, for example using the DarcyForchheimer model:

    interRegionExplicitPorositySourceCoeffs
    {
        type            DarcyForchheimer;
        DarcyForchheimerCoeffs
        {
            d   d [0 -2 0 0 0 0 0] (5e7 -1000 -1000);
            f   f [0 -1 0 0 0 0 0] (0 0 0);

            coordinateSystem
            {
                origin  (0 0 0);
                e1      (0.70710678 0.70710678 0);
                e2      (0 0 1);
            }
        }
    }
Note
  • The porous region must be selected as a cellZone.
Source files

Definition at line 145 of file interRegionExplicitPorositySource.H.

Constructor & Destructor Documentation

◆ interRegionExplicitPorositySource() [1/2]

interRegionExplicitPorositySource ( const word &  name,
const word &  modelType,
const dictionary &  dict,
const fvMesh &  mesh
)

Definition at line 107 of file interRegionExplicitPorositySource.C.

References option::resetApplied().

Here is the call graph for this function:

◆ interRegionExplicitPorositySource() [2/2]

interRegionExplicitPorositySource ( const interRegionExplicitPorositySource &  )
delete

◆ ~interRegionExplicitPorositySource()

virtual ~interRegionExplicitPorositySource ( )
virtualdefault

Member Function Documentation

◆ initialise()

void initialise ( )
protected

Definition at line 46 of file interRegionExplicitPorositySource.C.

References Foam::abort(), ZoneMesh::clearAddressing(), option::coeffs_, Foam::FatalError, FatalErrorInFunction, interRegionExplicitPorositySource::firstIter_, objectRegistry::lookupObject(), option::mesh_, option::name_, interRegionOption::nbrRegionName_, porosityModel::New(), interRegionExplicitPorositySource::porosityPtr_, fvMesh::time(), and zoneID.

Here is the call graph for this function:

◆ TypeName()

TypeName ( "interRegionExplicitPorositySource"  )

◆ operator=()

void operator= ( const interRegionExplicitPorositySource &  )
delete

◆ addSup() [1/2]

void addSup ( fvMatrix< vector > &  eqn,
const label  fieldi
)
virtual

Reimplemented from option.

Definition at line 131 of file interRegionExplicitPorositySource.C.

References fvMatrix::dimensions(), IOobject::NO_READ, IOobject::NO_WRITE, GeometricField::primitiveFieldRef(), fvMatrix::psi(), fvMatrix::source(), U, and Foam::Zero.

Here is the call graph for this function:

◆ addSup() [2/2]

void addSup ( const volScalarField &  rho,
fvMatrix< vector > &  eqn,
const label  fieldi
)
virtual

Reimplemented from option.

Definition at line 184 of file interRegionExplicitPorositySource.C.

References Foam::dimDensity, fvMatrix::dimensions(), Foam::dimViscosity, Foam::constant::physicoChemical::mu, IOobject::NO_READ, IOobject::NO_WRITE, GeometricField::primitiveFieldRef(), fvMatrix::psi(), rho, fvMatrix::source(), U, and Foam::Zero.

Here is the call graph for this function:

◆ read()

bool read ( const dictionary &  dict)
virtual

Reimplemented from interRegionOption.

Definition at line 283 of file interRegionExplicitPorositySource.C.

References dict, and interRegionOption::read().

Here is the call graph for this function:

Member Data Documentation

◆ porosityPtr_

autoPtr<porosityModel> porosityPtr_
protected

Definition at line 154 of file interRegionExplicitPorositySource.H.

Referenced by interRegionExplicitPorositySource::initialise().

◆ firstIter_

bool firstIter_
protected

Definition at line 157 of file interRegionExplicitPorositySource.H.

Referenced by interRegionExplicitPorositySource::initialise().

◆ UName_

word UName_
protected

Definition at line 160 of file interRegionExplicitPorositySource.H.

◆ muName_

word muName_
protected

Definition at line 163 of file interRegionExplicitPorositySource.H.

The documentation for this class was generated from the following files:
