Public Member Functions | Protected Attributes | List of all members
explicitPorositySource Class Reference
Numerics » Finite volume Options » Sources

Applies an explicit porosity source to the momentum equation within a specified region. More...

Inheritance diagram for explicitPorositySource:
Inheritance graph
[legend]
Collaboration diagram for explicitPorositySource:
Collaboration graph
[legend]

Public Member Functions

 TypeName ("explicitPorositySource")

 explicitPorositySource (const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh)

 explicitPorositySource (const explicitPorositySource &)=delete

void operator= (const explicitPorositySource &)=delete

virtual ~explicitPorositySource ()=default

const porosityModel & model () const

virtual void addSup (fvMatrix< vector > &eqn, const label fieldi)

virtual void addSup (const volScalarField &rho, fvMatrix< vector > &eqn, const label fieldi)

virtual void addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< vector > &eqn, const label fieldi)

virtual bool read (const dictionary &dict)

- Public Member Functions inherited from cellSetOption
 TypeName ("cellSetOption")

 cellSetOption (const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh)

virtual ~cellSetOption ()=default

scalar timeStart () const noexcept

scalar duration () const noexcept

bool inTimeLimits (const scalar timeValue) const

selectionModeType selectionMode () const noexcept

bool useSubMesh () const noexcept

const word & cellSetName () const noexcept

scalar V () const noexcept

const labelList & cells () const noexcept

scalar timeStart (scalar val) noexcept

scalar duration (scalar val) noexcept

virtual bool isActive ()

- Public Member Functions inherited from option
 TypeName ("option")

 declareRunTimeSelectionTable (autoPtr, option, dictionary,(const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh),(name, modelType, dict, mesh))

 option (const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh)

autoPtr< option > clone () const

virtual ~option ()=default

const word & name () const noexcept

const fvMesh & mesh () const noexcept

const dictionary & coeffs () const noexcept

bool active () const noexcept

void setApplied (const label fieldi)

bool active (const bool on) noexcept

virtual label applyToField (const word &fieldName) const

virtual void checkApplied () const

virtual void addSup (fvMatrix< scalar > &eqn, const label fieldi)

virtual void addSup (fvMatrix< symmTensor > &eqn, const label fieldi)

virtual void addSup (fvMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void addSup (fvMatrix< tensor > &eqn, const label fieldi)

virtual void addSup (const volScalarField &rho, fvMatrix< scalar > &eqn, const label fieldi)

virtual void addSup (const volScalarField &rho, fvMatrix< symmTensor > &eqn, const label fieldi)

virtual void addSup (const volScalarField &rho, fvMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void addSup (const volScalarField &rho, fvMatrix< tensor > &eqn, const label fieldi)

virtual void addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< scalar > &eqn, const label fieldi)

virtual void addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< symmTensor > &eqn, const label fieldi)

virtual void addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< tensor > &eqn, const label fieldi)

virtual void constrain (fvMatrix< scalar > &eqn, const label fieldi)

virtual void constrain (fvMatrix< vector > &eqn, const label fieldi)

virtual void constrain (fvMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void constrain (fvMatrix< symmTensor > &eqn, const label fieldi)

virtual void constrain (fvMatrix< tensor > &eqn, const label fieldi)

virtual void correct (volScalarField &field)

virtual void correct (volVectorField &field)

virtual void correct (volSphericalTensorField &field)

virtual void correct (volSymmTensorField &field)

virtual void correct (volTensorField &field)

virtual void postProcessSens (scalarField &sensField, const word &fieldName=word::null, const word &designVariablesName=word::null)

virtual void postProcessSens (vectorField &sensField, const word &fieldName=word::null, const word &designVariablesName=word::null)

virtual void postProcessSens (tensorField &sensField, const word &fieldName=word::null, const word &designVariablesName=word::null)

virtual void writeHeader (Ostream &) const

virtual void writeFooter (Ostream &) const

virtual void writeData (Ostream &) const


Protected Attributes

autoPtr< porosityModel > porosityPtr_

- Protected Attributes inherited from cellSetOption
scalar timeStart_

scalar duration_

selectionModeType selectionMode_

word cellSetName_

List< point > points_

labelList cells_

scalar V_

- Protected Attributes inherited from option
const word name_

const word modelType_

const fvMesh & mesh_

dictionary dict_

dictionary coeffs_

wordList fieldNames_

List< bool > applied_

bool active_


Additional Inherited Members

- Public Types inherited from cellSetOption
enum  selectionModeType { smAll, smCellSet, smCellZone, smPoints }

- Static Public Member Functions inherited from option
static autoPtr< option > New (const word &name, const dictionary &dict, const fvMesh &mesh)

- Public Attributes inherited from option
bool log

- Static Public Attributes inherited from cellSetOption
static const Enum< selectionModeType > selectionModeTypeNames_

- Protected Member Functions inherited from cellSetOption
void setSelection (const dictionary &dict)

void setCellSelection ()

void setVol ()

- Protected Member Functions inherited from option
void resetApplied ()


Detailed Description

Applies an explicit porosity source to the momentum equation within a specified region.

Sources applied to:

  U         | Velocity                                   [m/s]

Required fields:

  U         | Velocity                                   [m/s]
Usage
Minimal example by using constant/fvOptions:
explicitPorositySource1
{
    // Mandatory entries (unmodifiable)
    type                 <porosityModelName>;

    <porosityModelName>Coeffs
    {
        // Optional entries (runtime modifiable)
        UNames          (<Uname1> <Uname2> ... <UnameN>);

        // Conditional optional entries (runtime modifiable)

            // when the entry "UNames" is not present
            U           U;

        // Mandatory/Optional (inherited) entries
        ...
    }

    // Mandatory/Optional (inherited) entries
    ...
}

where the entries mean:

Property Description Type Reqd Dflt
type Type name: <porosityModelName> word yes -
UNames Names of operand velocity fields wordList no -
U Name of operand velocity field word no U

The inherited entries are elaborated in:

Example usage, here employing the Darcy-Forchheimer model:

    explicitPorositySourceCoeffs
    {
        type            DarcyForchheimer;

        DarcyForchheimerCoeffs
        {
            d   d [0 -2 0 0 0 0 0] (5e7 -1000 -1000);
            f   f [0 -1 0 0 0 0 0] (0 0 0);

            coordinateSystem
            {
                origin  (0 0 0);
                e1      (0.70710678 0.70710678 0);
                e2      (0 0 1);
            }
        }
    }
Note
  • The porous region must be selected as a cellZone.
See also
Source files

Definition at line 156 of file explicitPorositySource.H.

Constructor & Destructor Documentation

◆ explicitPorositySource() [1/2]

explicitPorositySource ( const word &  name,
const word &  modelType,
const dictionary &  dict,
const fvMesh &  mesh
)

Definition at line 43 of file explicitPorositySource.C.

References dict, Foam::New(), and Foam::blockMeshTools::read().

Here is the call graph for this function:

◆ explicitPorositySource() [2/2]

explicitPorositySource ( const explicitPorositySource &  )
delete

◆ ~explicitPorositySource()

virtual ~explicitPorositySource ( )
virtualdefault

Member Function Documentation

◆ TypeName()

TypeName ( "explicitPorositySource"  )

◆ operator=()

void operator= ( const explicitPorositySource &  )
delete

◆ model()

const porosityModel& model ( ) const
inline

Definition at line 199 of file explicitPorositySource.H.

References explicitPorositySource::porosityPtr_.

Referenced by kEpsilonLopesdaCosta< BasicTurbulenceModel >::setPorosityCoefficients().

Here is the caller graph for this function:

◆ addSup() [1/3]

void addSup ( fvMatrix< vector > &  eqn,
const label  fieldi
)
virtual

Reimplemented from option.

Definition at line 71 of file explicitPorositySource.C.

References fvMatrix::dimensions(), and fvMatrix::psi().

Here is the call graph for this function:

◆ addSup() [2/3]

void addSup ( const volScalarField &  rho,
fvMatrix< vector > &  eqn,
const label  fieldi
)
virtual

Reimplemented from option.

Definition at line 83 of file explicitPorositySource.C.

References fvMatrix::dimensions(), and fvMatrix::psi().

Here is the call graph for this function:

◆ addSup() [3/3]

void addSup ( const volScalarField &  alpha,
const volScalarField &  rho,
fvMatrix< vector > &  eqn,
const label  fieldi
)
virtual

Reimplemented from option.

Definition at line 96 of file explicitPorositySource.C.

References Foam::constant::atomic::alpha, fvMatrix::dimensions(), and fvMatrix::psi().

Here is the call graph for this function:

◆ read()

bool read ( const dictionary &  dict)
virtual

Reimplemented from cellSetOption.

Definition at line 109 of file explicitPorositySource.C.

References option::coeffs_, dict, option::fieldNames_, dictionary::getOrDefault(), cellSetOption::read(), dictionary::readIfPresent(), option::resetApplied(), and List::resize().

Here is the call graph for this function:

Member Data Documentation

◆ porosityPtr_

autoPtr<porosityModel> porosityPtr_
protected

Definition at line 165 of file explicitPorositySource.H.

Referenced by explicitPorositySource::model().

The documentation for this class was generated from the following files:
