d2dt2Scheme< Type > Class Template Reference

Abstract base class for finite volume d2dt2 schemes. More...

Inheritance diagram for d2dt2Scheme< Type >:

Collaboration diagram for d2dt2Scheme< Type >:

Public Member Functions
virtual const word &	type () const =0
	declareRunTimeSelectionTable (tmp, d2dt2Scheme, Istream,(const fvMesh &mesh, Istream &schemeData),(mesh, schemeData))
	d2dt2Scheme (const fvMesh &mesh)
	d2dt2Scheme (const fvMesh &mesh, Istream &)
virtual	~d2dt2Scheme ()=default
const fvMesh &	mesh () const
virtual tmp< GeometricField< Type, fvPatchField, volMesh > >	fvcD2dt2 (const GeometricField< Type, fvPatchField, volMesh > &)=0
virtual tmp< GeometricField< Type, fvPatchField, volMesh > >	fvcD2dt2 (const volScalarField &, const GeometricField< Type, fvPatchField, volMesh > &)=0
virtual tmp< fvMatrix< Type > >	fvmD2dt2 (const GeometricField< Type, fvPatchField, volMesh > &)=0
virtual tmp< fvMatrix< Type > >	fvmD2dt2 (const dimensionedScalar &, const GeometricField< Type, fvPatchField, volMesh > &)=0
virtual tmp< fvMatrix< Type > >	fvmD2dt2 (const volScalarField &, const GeometricField< Type, fvPatchField, volMesh > &)=0
Public Member Functions inherited from refCount
constexpr	refCount () noexcept
int	count () const noexcept
bool	unique () const noexcept
void	operator++ () noexcept
void	operator++ (int) noexcept
void	operator-- () noexcept
void	operator-- (int) noexcept

Static Public Member Functions
static tmp< d2dt2Scheme< Type > >	New (const fvMesh &mesh, Istream &schemeData)

Protected Member Functions
	d2dt2Scheme (const d2dt2Scheme &)=delete
void	operator= (const d2dt2Scheme &)=delete

Protected Attributes
const fvMesh &	mesh_

Detailed Description

template<class Type>
class Foam::fv::d2dt2Scheme< Type >

Abstract base class for finite volume d2dt2 schemes.

Source files

• d2dt2Scheme.H
• d2dt2Scheme.C

Definition at line 62 of file d2dt2Scheme.H.

Constructor & Destructor Documentation

d2dt2Scheme() [1/3]

d2dt2Scheme ( const d2dt2Scheme< Type > &  )

protecteddelete

d2dt2Scheme() [2/3]

d2dt2Scheme ( const fvMesh &  mesh )

inline

Definition at line 104 of file d2dt2Scheme.H.

d2dt2Scheme() [3/3]

d2dt2Scheme ( const fvMesh &  mesh, Istream &    )

inline

Definition at line 110 of file d2dt2Scheme.H.

~d2dt2Scheme()

virtual ~d2dt2Scheme ( )

virtualdefault

Member Function Documentation

operator=()

void operator= ( const d2dt2Scheme< Type > &  )

protecteddelete

type()

virtual const word& type ( ) const

pure virtual

declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	tmp	,
		d2dt2Scheme< Type >	,
		Istream	,
		(const fvMesh &mesh, Istream &schemeData)	,
		(mesh, schemeData)
	)

New()

tmp< d2dt2Scheme< Type > > New ( const fvMesh &  mesh, Istream &  schemeData  )

static

Definition at line 39 of file d2dt2Scheme.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), IOstream::eof(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, FatalIOErrorInLookup, InfoInFunction, and mesh.

Referenced by Foam::fvc::d2dt2(), and Foam::fvm::d2dt2().

Here is the call graph for this function:

Here is the caller graph for this function:

mesh()

const fvMesh& mesh ( ) const

inline

Definition at line 133 of file d2dt2Scheme.H.

References d2dt2Scheme< Type >::mesh_.

Referenced by steadyStateD2dt2Scheme< Type >::mesh(), and EulerD2dt2Scheme< Type >::mesh().

Here is the caller graph for this function:

fvcD2dt2() [1/2]

virtual tmp<GeometricField<Type, fvPatchField, volMesh> > fvcD2dt2 ( const GeometricField< Type, fvPatchField, volMesh > &  )

pure virtual

Implemented in EulerD2dt2Scheme< Type >, and steadyStateD2dt2Scheme< Type >.

fvcD2dt2() [2/2]

virtual tmp<GeometricField<Type, fvPatchField, volMesh> > fvcD2dt2 ( const volScalarField &  , const GeometricField< Type, fvPatchField, volMesh > &    )

pure virtual

Implemented in EulerD2dt2Scheme< Type >, and steadyStateD2dt2Scheme< Type >.

fvmD2dt2() [1/3]

virtual tmp<fvMatrix<Type> > fvmD2dt2 ( const GeometricField< Type, fvPatchField, volMesh > &  )

pure virtual

Implemented in EulerD2dt2Scheme< Type >, and steadyStateD2dt2Scheme< Type >.

fvmD2dt2() [2/3]

virtual tmp<fvMatrix<Type> > fvmD2dt2 ( const dimensionedScalar &  , const GeometricField< Type, fvPatchField, volMesh > &    )

pure virtual

Implemented in EulerD2dt2Scheme< Type >, and steadyStateD2dt2Scheme< Type >.

fvmD2dt2() [3/3]

virtual tmp<fvMatrix<Type> > fvmD2dt2 ( const volScalarField &  , const GeometricField< Type, fvPatchField, volMesh > &    )

pure virtual

Implemented in EulerD2dt2Scheme< Type >, and steadyStateD2dt2Scheme< Type >.

Member Data Documentation

mesh_

const fvMesh& mesh_

protected

Definition at line 71 of file d2dt2Scheme.H.

Referenced by d2dt2Scheme< Type >::mesh().

---

The documentation for this class was generated from the following files:

• src/finiteVolume/finiteVolume/d2dt2Schemes/d2dt2Scheme/d2dt2Scheme.H
• src/finiteVolume/finiteVolume/d2dt2Schemes/d2dt2Scheme/d2dt2Scheme.C
