Applies sources on either epsilon or omega to correct mixing-length scale estimations for atmospheric boundary layer modelling. More...

Inheritance diagram for atmLengthScaleTurbSource:

[legend]

Collaboration diagram for atmLengthScaleTurbSource:

[legend]

Public Member Functions
	TypeName ("atmLengthScaleTurbSource")

	atmLengthScaleTurbSource (const word &sourceName, const word &modelType, const dictionary &dict, const fvMesh &mesh)

	atmLengthScaleTurbSource (const atmLengthScaleTurbSource &)=delete

void	operator= (const atmLengthScaleTurbSource &)=delete

virtual void	addSup (fvMatrix< scalar > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &rho, fvMatrix< scalar > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< scalar > &eqn, const label fieldi)

virtual bool	read (const dictionary &dict)

Public Member Functions inherited from cellSetOption
	TypeName ("cellSetOption")

	cellSetOption (const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh)

virtual	~cellSetOption ()=default

scalar	timeStart () const noexcept

scalar	duration () const noexcept

bool	inTimeLimits (const scalar timeValue) const

selectionModeType	selectionMode () const noexcept

bool	useSubMesh () const noexcept

const word &	cellSetName () const noexcept

scalar	V () const noexcept

const labelList &	cells () const noexcept

scalar	timeStart (scalar val) noexcept

scalar	duration (scalar val) noexcept

virtual bool	isActive ()

Public Member Functions inherited from option
	TypeName ("option")

	declareRunTimeSelectionTable (autoPtr, option, dictionary,(const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh),(name, modelType, dict, mesh))

	option (const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh)

autoPtr< option >	clone () const

virtual	~option ()=default

const word &	name () const noexcept

const fvMesh &	mesh () const noexcept

const dictionary &	coeffs () const noexcept

bool	active () const noexcept

void	setApplied (const label fieldi)

bool	active (const bool on) noexcept

virtual label	applyToField (const word &fieldName) const

virtual void	checkApplied () const

virtual void	addSup (fvMatrix< vector > &eqn, const label fieldi)

virtual void	addSup (fvMatrix< symmTensor > &eqn, const label fieldi)

virtual void	addSup (fvMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void	addSup (fvMatrix< tensor > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &rho, fvMatrix< vector > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &rho, fvMatrix< symmTensor > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &rho, fvMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &rho, fvMatrix< tensor > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< vector > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< symmTensor > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void	addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< tensor > &eqn, const label fieldi)

virtual void	constrain (fvMatrix< scalar > &eqn, const label fieldi)

virtual void	constrain (fvMatrix< vector > &eqn, const label fieldi)

virtual void	constrain (fvMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void	constrain (fvMatrix< symmTensor > &eqn, const label fieldi)

virtual void	constrain (fvMatrix< tensor > &eqn, const label fieldi)

virtual void	correct (volScalarField &field)

virtual void	correct (volVectorField &field)

virtual void	correct (volSphericalTensorField &field)

virtual void	correct (volSymmTensorField &field)

virtual void	correct (volTensorField &field)

virtual void	postProcessSens (scalarField &sensField, const word &fieldName=word::null, const word &designVariablesName=word::null)

virtual void	postProcessSens (vectorField &sensField, const word &fieldName=word::null, const word &designVariablesName=word::null)

virtual void	postProcessSens (tensorField &sensField, const word &fieldName=word::null, const word &designVariablesName=word::null)

virtual void	writeHeader (Ostream &) const

virtual void	writeFooter (Ostream &) const

virtual void	writeData (Ostream &) const

Additional Inherited Members
Public Types inherited from cellSetOption
enum	selectionModeType { smAll, smCellSet, smCellZone, smPoints }

Static Public Member Functions inherited from option
static autoPtr< option >	New (const word &name, const dictionary &dict, const fvMesh &mesh)

Public Attributes inherited from option
bool	log

Static Public Attributes inherited from cellSetOption
static const Enum< selectionModeType >	selectionModeTypeNames_

Protected Member Functions inherited from cellSetOption
void	setSelection (const dictionary &dict)

void	setCellSelection ()

void	setVol ()

Protected Member Functions inherited from option
void	resetApplied ()

Protected Attributes inherited from cellSetOption
scalar	timeStart_

scalar	duration_

selectionModeType	selectionMode_

word	cellSetName_

List< point >	points_

labelList	cells_

scalar	V_

Protected Attributes inherited from option
const word	name_

const word	modelType_

const fvMesh &	mesh_

dictionary	dict_

dictionary	coeffs_

wordList	fieldNames_

List< bool >	applied_

bool	active_

Detailed Description

Applies sources on either epsilon or omega to correct mixing-length scale estimations for atmospheric boundary layer modelling.

Corrections applied to either of the below, if exist:

  epsilon   | Turbulent kinetic energy dissipation rate [m2/s3]
  omega     | Specific dissipation rate                 [1/s]

Required fields, either of the below:

  epsilon   | Turbulent kinetic energy dissipation rate [m2/s3]
  omega     | Specific dissipation rate                 [1/s]

References:

    Mixing-length scale limiter for epsilon (tag:AC):
        Apsley, D. D., & Castro, I. P. (1997).
        A limited-length-scale k-ε model for the neutral and
        stably-stratified atmospheric boundary layer.
        Boundary-layer meteorology, 83(1), 75-98.
        DOI:10.1023/A:1000252210512

    Mixing-length scale limiter for omega (tag:L):
        Langner, J. (2016).
        Implementierung und validierung von RANS-modellen der
        thermisch geschichteten, atmosphärischen grenzschicht.
        Masterarbeit zum thema, Technische Universität Berlin.

    Mixing-length scale estimation (tag:P):
        Pope, S. B. (2000).
        Turbulent flows.
        Cambridge, UK: Cambridge Univ. Press
        DOI:10.1017/CBO9780511840531

Usage

Example by using constant/fvOptions:

atmLengthScaleTurbSource1
{
    // Mandatory entries (unmodifiable)
    type                 atmLengthScaleTurbSource;

    atmLengthScaleTurbSourceCoeffs
    {
        // Mandatory (inherited) entries (unmodifiable)
        selectionMode    all;

        // Optional entries (unmodifiable)
        rho              rho;
        Lmax             41.575;
        n                3.0;
    }

    // Optional (inherited) entries
    ...
}

where the entries mean:

Property	Description	Type	Req'd	Dflt
`type`	Type name: atmLengthScaleTurbSource	word	yes	-
`rho`	Name of density field	word	no	rho
`Lmax`	Maximum mixing-length scale [m]	scalar	no	41.575
`n`	Mixing-length scale exponent	scalar	no	3.0

The inherited entries are elaborated in:

See also

cellSetOption.H

Source files

Definition at line 159 of file atmLengthScaleTurbSource.H.

Constructor & Destructor Documentation

◆ atmLengthScaleTurbSource() [1/2]

atmLengthScaleTurbSource	(	const word &	sourceName,
		const word &	modelType,
		const dictionary &	dict,
		const fvMesh &	mesh
	)

Definition at line 76 of file atmLengthScaleTurbSource.C.

References Foam::abort(), Foam::endl(), Foam::FatalError, FatalErrorInFunction, tmp::isTmp(), Log, Foam::nl, turbulenceModel::propertiesName, dictionary::read(), and option::resetApplied().

Here is the call graph for this function:

◆ atmLengthScaleTurbSource() [2/2]

atmLengthScaleTurbSource ( const atmLengthScaleTurbSource & )

delete

Member Function Documentation

◆ TypeName()

TypeName ( "atmLengthScaleTurbSource" )

◆ operator=()

void operator= ( const atmLengthScaleTurbSource & )

delete

◆ addSup() [1/3]

void addSup	(	fvMatrix< scalar > &	eqn,
		const label	fieldi
	)

virtual

Reimplemented from option.

Definition at line 171 of file atmLengthScaleTurbSource.C.

◆ addSup() [2/3]

void addSup	(	const volScalarField &	rho,
		fvMatrix< scalar > &	eqn,
		const label	fieldi
	)

virtual

Reimplemented from option.

Definition at line 200 of file atmLengthScaleTurbSource.C.

References rho.

◆ addSup() [3/3]

void addSup	(	const volScalarField &	alpha,
		const volScalarField &	rho,
		fvMatrix< scalar > &	eqn,
		const label	fieldi
	)

virtual

Reimplemented from option.

Definition at line 218 of file atmLengthScaleTurbSource.C.

References Foam::constant::atomic::alpha, and rho.

◆ read()

virtual bool read ( const dictionary & dict )

inlinevirtual

Reimplemented from cellSetOption.

Definition at line 277 of file atmLengthScaleTurbSource.H.

The documentation for this class was generated from the following files:

src/atmosphericModels/fvOptions/atmLengthScaleTurbSource/atmLengthScaleTurbSource.H
src/atmosphericModels/fvOptions/atmLengthScaleTurbSource/atmLengthScaleTurbSource.C
src/atmosphericModels/fvOptions/atmLengthScaleTurbSource/atmLengthScaleTurbSourceTemplates.C
