SemiImplicitSource Class Reference

Applies semi-implicit source within a specified region for Type, where <Type>=Scalar/Vector/SphericalTensor/SymmTensor/Tensor. The injection rate coefficients are specified as pairs of Su-Sp coefficients, i.e.: More...

Collaboration diagram for SemiImplicitSource:

Public Types
enum	volumeModeType { vmAbsolute, vmSpecific }

Public Member Functions
	TypeName ("SemiImplicitSource")
	SemiImplicitSource (const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh)
const volumeModeType &	volumeMode () const
volumeModeType &	volumeMode ()
virtual void	addSup (fvMatrix< Type > &eqn, const label fieldi)
virtual void	addSup (const volScalarField &rho, fvMatrix< Type > &eqn, const label fieldi)
virtual bool	read (const dictionary &dict)

Static Public Attributes
static const Enum< volumeModeType >	volumeModeTypeNames_

Protected Member Functions
void	setFieldData (const dictionary &dict)

Protected Attributes
volumeModeType	volumeMode_
scalar	VDash_
PtrList< Function1< Type > >	Su_
PtrList< Function1< scalar > >	Sp_

Detailed Description

Applies semi-implicit source within a specified region for Type, where <Type>=Scalar/Vector/SphericalTensor/SymmTensor/Tensor. The injection rate coefficients are specified as pairs of Su-Sp coefficients, i.e.:

where

	=	net source for field 'x'
	=	explicit source contribution
	=	linearised implicit contribution

Usage

Minimal example by using constant/fvOptions:

<Type>SemiImplicitSource1
{
    // Mandatory entries (unmodifiable)
    type                <Type>SemiImplicitSource;

    // Mandatory entries (runtime modifiable)
    volumeMode          <volumeModeType>;
    injectionRateSuSp
    {
        k           (30.7 0);
        epsilon     (1.5  0);

        // The injectionRate can also be specified as a Function1
        // by having dictionaries for the field entries instead
        k
        {
            // Time-ramp from 0 to 30.7 at time 5
            Su table
            (
                (0 0.0)
                (5 30.7)
            );
            Sp      0.0;
        }
        epsilon
        {
            Su      1.5;
            Sp      0.0;
        }
    }

    // Mandatory/Optional (inherited) entries
    ...
}

where the entries mean:

Property	Description	Type	Reqd	Dflt
type	Type name: <Type>SemiImplicitSource	word	yes	-
volumeMode	Volume mode type	word	yes	-
injectionRateSuSp	Injection rate settings	dictionary	yes	-

The inherited entries are elaborated in:

• fvOption.H
• cellSetOption.H

Options for the volumeMode entry:

      absolute  | Values are given as \<quantity\>
      specific  | Values are given as \<quantity\>/m3

See also

• Foam::fvOption

Source files

• SemiImplicitSource.H
• SemiImplicitSource.C

Definition at line 165 of file SemiImplicitSource.H.

Member Enumeration Documentation

volumeModeType

enum volumeModeType

Enumerator
vmAbsolute
vmSpecific

Definition at line 189 of file SemiImplicitSource.H.

Constructor & Destructor Documentation

SemiImplicitSource()

SemiImplicitSource	(	const word &	name,
		const word &	modelType,
		const dictionary &	dict,
		const fvMesh &	mesh
	)

Definition at line 106 of file SemiImplicitSource.C.

References dict, and Foam::blockMeshTools::read().

Here is the call graph for this function:

Member Function Documentation

setFieldData()

void setFieldData ( const dictionary &  dict )

protected

Definition at line 45 of file SemiImplicitSource.C.

References Foam::BitOps::count(), dict, Tuple2::first(), Tuple2::second(), and dictionary::set().

Here is the call graph for this function:

TypeName()

TypeName

(

"SemiImplicitSource"

)

volumeMode() [1/2]

const Foam::fv::SemiImplicitSource< Type >::volumeModeType & volumeMode ( ) const

inline

Definition at line 27 of file SemiImplicitSourceI.H.

volumeMode() [2/2]

Foam::fv::SemiImplicitSource< Type >::volumeModeType & volumeMode ( )

inline

Definition at line 35 of file SemiImplicitSourceI.H.

addSup() [1/2]

void addSup ( fvMatrix< Type > &  eqn, const label  fieldi  )

virtual

Definition at line 125 of file SemiImplicitSource.C.

References Foam::expressions::patchExpr::debug, fvMatrix::dimensions(), Foam::dimVolume, Foam::endl(), Foam::Info, psi, fvMatrix::psi(), Sp, Su, Foam::fam::SuSp(), and Foam::Zero.

Here is the call graph for this function:

addSup() [2/2]

void addSup ( const volScalarField &  rho, fvMatrix< Type > &  eqn, const label  fieldi  )

virtual

Definition at line 180 of file SemiImplicitSource.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), and Foam::Info.

Here is the call graph for this function:

read()

bool read ( const dictionary &  dict )

virtual

Definition at line 197 of file SemiImplicitSource.C.

References dict, and Foam::blockMeshTools::read().

Here is the call graph for this function:

Member Data Documentation

volumeModeTypeNames_

const Foam::Enum< typename Foam::fv::SemiImplicitSource< Type >::volumeModeType > volumeModeTypeNames_

static

Definition at line 196 of file SemiImplicitSource.H.

volumeMode_

volumeModeType volumeMode_

protected

Definition at line 204 of file SemiImplicitSource.H.

VDash_

scalar VDash_

protected

Definition at line 207 of file SemiImplicitSource.H.

Su_

PtrList<Function1<Type> > Su_

protected

Definition at line 210 of file SemiImplicitSource.H.

Sp_

PtrList<Function1<scalar> > Sp_

protected

Definition at line 211 of file SemiImplicitSource.H.

---

The documentation for this class was generated from the following files:

• src/fvOptions/sources/general/semiImplicitSource/SemiImplicitSource.H
• src/fvOptions/sources/general/semiImplicitSource/SemiImplicitSource.C
• src/fvOptions/sources/general/semiImplicitSource/SemiImplicitSourceI.H
