EulerD2dt2Scheme< Type > Class Template Reference

First-order Euler implicit d2dt2 using the current and two previous time-step values. More...

Inheritance diagram for EulerD2dt2Scheme< Type >:

Collaboration diagram for EulerD2dt2Scheme< Type >:

Public Member Functions
	TypeName ("Euler")
	EulerD2dt2Scheme (const fvMesh &mesh)
	EulerD2dt2Scheme (const fvMesh &mesh, Istream &is)
const fvMesh &	mesh () const
tmp< GeometricField< Type, fvPatchField, volMesh > >	fvcD2dt2 (const GeometricField< Type, fvPatchField, volMesh > &)
tmp< GeometricField< Type, fvPatchField, volMesh > >	fvcD2dt2 (const volScalarField &, const GeometricField< Type, fvPatchField, volMesh > &)
tmp< fvMatrix< Type > >	fvmD2dt2 (const GeometricField< Type, fvPatchField, volMesh > &)
tmp< fvMatrix< Type > >	fvmD2dt2 (const dimensionedScalar &, const GeometricField< Type, fvPatchField, volMesh > &)
tmp< fvMatrix< Type > >	fvmD2dt2 (const volScalarField &, const GeometricField< Type, fvPatchField, volMesh > &)
Public Member Functions inherited from d2dt2Scheme< Type >
virtual const word &	type () const =0
	declareRunTimeSelectionTable (tmp, d2dt2Scheme, Istream,(const fvMesh &mesh, Istream &schemeData),(mesh, schemeData))
	d2dt2Scheme (const fvMesh &mesh)
	d2dt2Scheme (const fvMesh &mesh, Istream &)
virtual	~d2dt2Scheme ()=default
const fvMesh &	mesh () const
Public Member Functions inherited from refCount
constexpr	refCount () noexcept
int	count () const noexcept
bool	unique () const noexcept
void	operator++ () noexcept
void	operator++ (int) noexcept
void	operator-- () noexcept
void	operator-- (int) noexcept

Additional Inherited Members
Static Public Member Functions inherited from d2dt2Scheme< Type >
static tmp< d2dt2Scheme< Type > >	New (const fvMesh &mesh, Istream &schemeData)
Protected Member Functions inherited from d2dt2Scheme< Type >
	d2dt2Scheme (const d2dt2Scheme &)=delete
void	operator= (const d2dt2Scheme &)=delete
Protected Attributes inherited from d2dt2Scheme< Type >
const fvMesh &	mesh_

Detailed Description

template<class Type>
class Foam::fv::EulerD2dt2Scheme< Type >

First-order Euler implicit d2dt2 using the current and two previous time-step values.

Source files

• EulerD2dt2Scheme.H
• EulerD2dt2Scheme.C

Definition at line 53 of file EulerD2dt2Scheme.H.

Constructor & Destructor Documentation

EulerD2dt2Scheme() [1/2]

EulerD2dt2Scheme ( const fvMesh &  mesh )

inline

Definition at line 75 of file EulerD2dt2Scheme.H.

EulerD2dt2Scheme() [2/2]

EulerD2dt2Scheme ( const fvMesh &  mesh, Istream &  is  )

inline

Definition at line 81 of file EulerD2dt2Scheme.H.

Member Function Documentation

TypeName()

TypeName

(

"Euler"

)

mesh()

const fvMesh& mesh ( ) const

inline

Definition at line 90 of file EulerD2dt2Scheme.H.

References d2dt2Scheme< Type >::mesh().

Here is the call graph for this function:

fvcD2dt2() [1/2]

tmp< GeometricField< Type, fvPatchField, volMesh > > fvcD2dt2 ( const GeometricField< Type, fvPatchField, volMesh > &  vf )

virtual

Implements d2dt2Scheme< Type >.

Definition at line 40 of file EulerD2dt2Scheme.C.

References GeometricField::boundaryField(), dimensioned::dimensions(), mesh, IOobject::NO_READ, IOobject::NO_WRITE, GeometricField::oldTime(), GeometricField::primitiveField(), Foam::sqr(), timeName, and dimensioned::value().

Here is the call graph for this function:

fvcD2dt2() [2/2]

tmp< GeometricField< Type, fvPatchField, volMesh > > fvcD2dt2 ( const volScalarField &  rho, const GeometricField< Type, fvPatchField, volMesh > &  vf  )

virtual

Implements d2dt2Scheme< Type >.

Definition at line 117 of file EulerD2dt2Scheme.C.

References GeometricField::boundaryField(), dimensioned::dimensions(), mesh, IOobject::NO_READ, IOobject::NO_WRITE, GeometricField::oldTime(), GeometricField::primitiveField(), rho, Foam::sqr(), timeName, and dimensioned::value().

Here is the call graph for this function:

fvmD2dt2() [1/3]

tmp< fvMatrix< Type > > fvmD2dt2 ( const GeometricField< Type, fvPatchField, volMesh > &  vf )

virtual

Implements d2dt2Scheme< Type >.

Definition at line 232 of file EulerD2dt2Scheme.C.

References Foam::dimTime, Foam::dimVol, mesh, GeometricField::oldTime(), tmp::ref(), fvMatrix::source(), and Foam::sqr().

Here is the call graph for this function:

fvmD2dt2() [2/3]

tmp< fvMatrix< Type > > fvmD2dt2 ( const dimensionedScalar &  rho, const GeometricField< Type, fvPatchField, volMesh > &  vf  )

virtual

Implements d2dt2Scheme< Type >.

Definition at line 291 of file EulerD2dt2Scheme.C.

References Foam::dimTime, Foam::dimVol, mesh, GeometricField::oldTime(), tmp::ref(), rho, fvMatrix::source(), and Foam::sqr().

Here is the call graph for this function:

fvmD2dt2() [3/3]

tmp< fvMatrix< Type > > fvmD2dt2 ( const volScalarField &  rho, const GeometricField< Type, fvPatchField, volMesh > &  vf  )

virtual

Implements d2dt2Scheme< Type >.

Definition at line 351 of file EulerD2dt2Scheme.C.

References Foam::dimTime, Foam::dimVol, mesh, GeometricField::oldTime(), tmp::ref(), rho, fvMatrix::source(), and Foam::sqr().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/finiteVolume/finiteVolume/d2dt2Schemes/EulerD2dt2Scheme/EulerD2dt2Scheme.H
• src/finiteVolume/finiteVolume/d2dt2Schemes/EulerD2dt2Scheme/EulerD2dt2Scheme.C
