CoEulerDdtScheme< Type > Class Template Reference

Courant number limited first-order Euler implicit/explicit ddt. More...

Inheritance diagram for CoEulerDdtScheme< Type >:

Collaboration diagram for CoEulerDdtScheme< Type >:

Public Types
typedef ddtScheme< Type >::fluxFieldType	fluxFieldType
Public Types inherited from ddtScheme< Type >
typedef GeometricField< typename flux< Type >::type, fvsPatchField, surfaceMesh >	fluxFieldType

Public Member Functions
	TypeName ("CoEuler")
	CoEulerDdtScheme (const fvMesh &mesh, Istream &is)
const fvMesh &	mesh () const
tmp< GeometricField< Type, fvPatchField, volMesh > >	fvcDdt (const dimensioned< Type > &)
tmp< GeometricField< Type, fvPatchField, volMesh > >	fvcDdt (const GeometricField< Type, fvPatchField, volMesh > &)
tmp< GeometricField< Type, fvPatchField, volMesh > >	fvcDdt (const dimensionedScalar &, const GeometricField< Type, fvPatchField, volMesh > &)
tmp< GeometricField< Type, fvPatchField, volMesh > >	fvcDdt (const volScalarField &, const GeometricField< Type, fvPatchField, volMesh > &)
tmp< GeometricField< Type, fvPatchField, volMesh > >	fvcDdt (const volScalarField &alpha, const volScalarField &rho, const GeometricField< Type, fvPatchField, volMesh > &psi)
tmp< fvMatrix< Type > >	fvmDdt (const GeometricField< Type, fvPatchField, volMesh > &)
tmp< fvMatrix< Type > >	fvmDdt (const dimensionedScalar &, const GeometricField< Type, fvPatchField, volMesh > &)
tmp< fvMatrix< Type > >	fvmDdt (const volScalarField &, const GeometricField< Type, fvPatchField, volMesh > &)
tmp< fvMatrix< Type > >	fvmDdt (const volScalarField &alpha, const volScalarField &rho, const GeometricField< Type, fvPatchField, volMesh > &psi)
tmp< fluxFieldType >	fvcDdtUfCorr (const GeometricField< Type, fvPatchField, volMesh > &U, const GeometricField< Type, fvsPatchField, surfaceMesh > &Uf)
tmp< fluxFieldType >	fvcDdtPhiCorr (const GeometricField< Type, fvPatchField, volMesh > &U, const fluxFieldType &phi)
tmp< fluxFieldType >	fvcDdtUfCorr (const volScalarField &rho, const GeometricField< Type, fvPatchField, volMesh > &U, const GeometricField< Type, fvsPatchField, surfaceMesh > &Uf)
tmp< fluxFieldType >	fvcDdtPhiCorr (const volScalarField &rho, const GeometricField< Type, fvPatchField, volMesh > &U, const fluxFieldType &phi)
tmp< surfaceScalarField >	meshPhi (const GeometricField< Type, fvPatchField, volMesh > &)
tmp< surfaceScalarField >	fvcDdtUfCorr (const GeometricField< scalar, fvPatchField, volMesh > &U, const GeometricField< scalar, fvsPatchField, surfaceMesh > &Uf)
tmp< surfaceScalarField >	fvcDdtPhiCorr (const volScalarField &U, const surfaceScalarField &phi)
tmp< surfaceScalarField >	fvcDdtUfCorr (const volScalarField &rho, const volScalarField &U, const surfaceScalarField &Uf)
tmp< surfaceScalarField >	fvcDdtPhiCorr (const volScalarField &rho, const volScalarField &U, const surfaceScalarField &phi)
Public Member Functions inherited from ddtScheme< Type >
virtual const word &	type () const =0
	declareRunTimeSelectionTable (tmp, ddtScheme, Istream,(const fvMesh &mesh, Istream &schemeData),(mesh, schemeData))
	ddtScheme (const fvMesh &mesh)
	ddtScheme (const fvMesh &mesh, Istream &is)
virtual	~ddtScheme ()=default
const fvMesh &	mesh () const
virtual tmp< GeometricField< Type, fvsPatchField, surfaceMesh > >	fvcDdt (const GeometricField< Type, fvsPatchField, surfaceMesh > &)
tmp< surfaceScalarField >	fvcDdtPhiCoeff (const GeometricField< Type, fvPatchField, volMesh > &U, const fluxFieldType &phi, const fluxFieldType &phiCorr)
tmp< surfaceScalarField >	fvcDdtPhiCoeffExperimental (const GeometricField< Type, fvPatchField, volMesh > &U, const fluxFieldType &phi, const fluxFieldType &phiCorr)
tmp< surfaceScalarField >	fvcDdtPhiCoeff (const GeometricField< Type, fvPatchField, volMesh > &U, const fluxFieldType &phi, const fluxFieldType &phiCorr, const volScalarField &rho)
tmp< surfaceScalarField >	fvcDdtPhiCoeff (const GeometricField< Type, fvPatchField, volMesh > &U, const fluxFieldType &phi)
tmp< surfaceScalarField >	fvcDdtPhiCoeff (const GeometricField< Type, fvPatchField, volMesh > &rhoU, const fluxFieldType &phi, const volScalarField &rho)
Public Member Functions inherited from refCount
constexpr	refCount () noexcept
int	count () const noexcept
bool	unique () const noexcept
void	operator++ () noexcept
void	operator++ (int) noexcept
void	operator-- () noexcept
void	operator-- (int) noexcept
Public Member Functions inherited from ddtSchemeBase
	ddtSchemeBase ()
	ddtSchemeBase ()

Additional Inherited Members
Static Public Member Functions inherited from ddtScheme< Type >
static tmp< ddtScheme< Type > >	New (const fvMesh &mesh, Istream &schemeData)
Static Public Attributes inherited from ddtSchemeBase
static bool	experimentalDdtCorr
Protected Member Functions inherited from ddtScheme< Type >
	ddtScheme (const ddtScheme &)=delete
void	operator= (const ddtScheme &)=delete
Protected Attributes inherited from ddtScheme< Type >
const fvMesh &	mesh_
scalar	ddtPhiCoeff_

Detailed Description

template<class Type>
class Foam::fv::CoEulerDdtScheme< Type >

Courant number limited first-order Euler implicit/explicit ddt.

The time-step is adjusted locally so that the local Courant number does not exceed the specified value.

This scheme should only be used for steady-state computations using transient codes where local time-stepping is preferable to under-relaxation for transport consistency reasons.

Source files

• CoEulerDdtScheme.H
• CoEulerDdtScheme.C

Definition at line 62 of file CoEulerDdtScheme.H.

Member Typedef Documentation

fluxFieldType

typedef ddtScheme<Type>::fluxFieldType fluxFieldType

Definition at line 173 of file CoEulerDdtScheme.H.

Constructor & Destructor Documentation

CoEulerDdtScheme()

CoEulerDdtScheme ( const fvMesh &  mesh, Istream &  is  )

inline

Definition at line 103 of file CoEulerDdtScheme.H.

Member Function Documentation

TypeName()

TypeName

(

"CoEuler"

)

mesh()

const fvMesh& mesh ( ) const

inline

Definition at line 115 of file CoEulerDdtScheme.H.

References ddtScheme< Type >::mesh().

Here is the call graph for this function:

fvcDdt() [1/5]

tmp< GeometricField< Type, fvPatchField, volMesh > > fvcDdt ( const dimensioned< Type > &  dt )

virtual

Implements ddtScheme< Type >.

Definition at line 145 of file CoEulerDdtScheme.C.

References dimensioned::dimensions(), Foam::dimTime, mesh, dimensioned::name(), GeometricField::primitiveField(), tmp::ref(), timeName, dimensioned::value(), and Foam::Zero.

Here is the call graph for this function:

fvcDdt() [2/5]

tmp< GeometricField< Type, fvPatchField, volMesh > > fvcDdt ( const GeometricField< Type, fvPatchField, volMesh > &  vf )

virtual

Implements ddtScheme< Type >.

Definition at line 195 of file CoEulerDdtScheme.C.

References GeometricField::boundaryField(), mesh, GeometricField::oldTime(), GeometricField::primitiveField(), and timeName.

Here is the call graph for this function:

fvcDdt() [3/5]

tmp< GeometricField< Type, fvPatchField, volMesh > > fvcDdt ( const dimensionedScalar &  rho, const GeometricField< Type, fvPatchField, volMesh > &  vf  )

virtual

Implements ddtScheme< Type >.

Definition at line 246 of file CoEulerDdtScheme.C.

References GeometricField::boundaryField(), mesh, GeometricField::oldTime(), GeometricField::primitiveField(), rho, and timeName.

Here is the call graph for this function:

fvcDdt() [4/5]

tmp< GeometricField< Type, fvPatchField, volMesh > > fvcDdt ( const volScalarField &  rho, const GeometricField< Type, fvPatchField, volMesh > &  vf  )

virtual

Implements ddtScheme< Type >.

Definition at line 298 of file CoEulerDdtScheme.C.

References GeometricField::boundaryField(), mesh, GeometricField::oldTime(), GeometricField::primitiveField(), rho, and timeName.

Here is the call graph for this function:

fvcDdt() [5/5]

tmp< GeometricField< Type, fvPatchField, volMesh > > fvcDdt ( const volScalarField &  alpha, const volScalarField &  rho, const GeometricField< Type, fvPatchField, volMesh > &  psi  )

virtual

Implements ddtScheme< Type >.

Definition at line 353 of file CoEulerDdtScheme.C.

References Foam::constant::atomic::alpha, GeometricField::boundaryField(), dimensioned::dimensions(), mesh, dimensioned::name(), GeometricField::oldTime(), GeometricField::primitiveField(), rho, and timeName.

Here is the call graph for this function:

fvmDdt() [1/4]

tmp< fvMatrix< Type > > fvmDdt ( const GeometricField< Type, fvPatchField, volMesh > &  vf )

virtual

Implements ddtScheme< Type >.

Definition at line 422 of file CoEulerDdtScheme.C.

References Foam::dimTime, Foam::dimVol, mesh, GeometricField::oldTime(), tmp::ref(), and fvMatrix::source().

Here is the call graph for this function:

fvmDdt() [2/4]

tmp< fvMatrix< Type > > fvmDdt ( const dimensionedScalar &  rho, const GeometricField< Type, fvPatchField, volMesh > &  vf  )

virtual

Implements ddtScheme< Type >.

Definition at line 457 of file CoEulerDdtScheme.C.

References Foam::dimTime, Foam::dimVol, mesh, GeometricField::oldTime(), tmp::ref(), rho, and fvMatrix::source().

Here is the call graph for this function:

fvmDdt() [3/4]

tmp< fvMatrix< Type > > fvmDdt ( const volScalarField &  rho, const GeometricField< Type, fvPatchField, volMesh > &  vf  )

virtual

Implements ddtScheme< Type >.

Definition at line 494 of file CoEulerDdtScheme.C.

References Foam::dimTime, Foam::dimVol, mesh, GeometricField::oldTime(), tmp::ref(), rho, and fvMatrix::source().

Here is the call graph for this function:

fvmDdt() [4/4]

tmp< fvMatrix< Type > > fvmDdt ( const volScalarField &  alpha, const volScalarField &  rho, const GeometricField< Type, fvPatchField, volMesh > &  psi  )

virtual

Implements ddtScheme< Type >.

Definition at line 533 of file CoEulerDdtScheme.C.

References Foam::constant::atomic::alpha, dimensioned::dimensions(), Foam::dimTime, Foam::dimVol, mesh, GeometricField::oldTime(), tmp::ref(), rho, and fvMatrix::source().

Here is the call graph for this function:

fvcDdtUfCorr() [1/4]

tmp< typename CoEulerDdtScheme< Type >::fluxFieldType > fvcDdtUfCorr ( const GeometricField< Type, fvPatchField, volMesh > &  U, const GeometricField< Type, fvsPatchField, surfaceMesh > &  Uf  )

virtual

Implements ddtScheme< Type >.

Definition at line 576 of file CoEulerDdtScheme.C.

References Foam::fvc::dotInterpolate(), Foam::fvc::interpolate(), mesh, timeName, U, and Uf.

Here is the call graph for this function:

fvcDdtPhiCorr() [1/4]

tmp< typename CoEulerDdtScheme< Type >::fluxFieldType > fvcDdtPhiCorr ( const GeometricField< Type, fvPatchField, volMesh > &  U, const fluxFieldType &  phi  )

virtual

Implements ddtScheme< Type >.

Definition at line 609 of file CoEulerDdtScheme.C.

References Foam::fvc::dotInterpolate(), Foam::fvc::interpolate(), mesh, phi, timeName, and U.

Here is the call graph for this function:

fvcDdtUfCorr() [2/4]

tmp< typename CoEulerDdtScheme< Type >::fluxFieldType > fvcDdtUfCorr ( const volScalarField &  rho, const GeometricField< Type, fvPatchField, volMesh > &  U, const GeometricField< Type, fvsPatchField, surfaceMesh > &  Uf  )

virtual

Implements ddtScheme< Type >.

Definition at line 641 of file CoEulerDdtScheme.C.

References Foam::abort(), Foam::dimDensity, Foam::dimVelocity, Foam::fvc::dotInterpolate(), Foam::FatalError, FatalErrorInFunction, Foam::fvc::interpolate(), mesh, rho, timeName, U, and Uf.

Here is the call graph for this function:

fvcDdtPhiCorr() [2/4]

tmp< typename CoEulerDdtScheme< Type >::fluxFieldType > fvcDdtPhiCorr ( const volScalarField &  rho, const GeometricField< Type, fvPatchField, volMesh > &  U, const fluxFieldType &  phi  )

virtual

Implements ddtScheme< Type >.

Definition at line 726 of file CoEulerDdtScheme.C.

References Foam::abort(), Foam::dimArea, Foam::dimVelocity, Foam::fvc::dotInterpolate(), Foam::FatalError, FatalErrorInFunction, mesh, phi, rho, timeName, and U.

Here is the call graph for this function:

meshPhi()

tmp< surfaceScalarField > meshPhi ( const GeometricField< Type, fvPatchField, volMesh > &  )

virtual

Implements ddtScheme< Type >.

Definition at line 816 of file CoEulerDdtScheme.C.

References Foam::dimTime, Foam::dimVolume, mesh, IOobject::NO_READ, IOobject::NO_WRITE, tmp::ref(), timeName, and Foam::Zero.

Here is the call graph for this function:

fvcDdtUfCorr() [3/4]

tmp< surfaceScalarField > fvcDdtUfCorr	(	const GeometricField< scalar, fvPatchField, volMesh > &	U,
		const GeometricField< scalar, fvsPatchField, surfaceMesh > &	Uf
	)

fvcDdtPhiCorr() [3/4]

tmp< surfaceScalarField > fvcDdtPhiCorr	(	const volScalarField &	U,
		const surfaceScalarField &	phi
	)

fvcDdtUfCorr() [4/4]

tmp< surfaceScalarField > fvcDdtUfCorr	(	const volScalarField &	rho,
		const volScalarField &	U,
		const surfaceScalarField &	Uf
	)

fvcDdtPhiCorr() [4/4]

tmp< surfaceScalarField > fvcDdtPhiCorr	(	const volScalarField &	rho,
		const volScalarField &	U,
		const surfaceScalarField &	phi
	)

---

The documentation for this class was generated from the following files:

• src/finiteVolume/finiteVolume/ddtSchemes/CoEulerDdtScheme/CoEulerDdtScheme.H
• src/finiteVolume/finiteVolume/ddtSchemes/CoEulerDdtScheme/CoEulerDdtScheme.C
