Given the original mesh and the list of selected cells, it creates the mesh consisting only of the desired cells, with the mapping list for points, faces, and cells. More...

Collaboration diagram for fvMeshSubset:

[legend]

Public Member Functions
	fvMeshSubset (const fvMesh &baseMesh)

	fvMeshSubset (const fvMesh &baseMesh, const bitSet &selectedCells, const label patchID=-1, const bool syncPar=true)

	fvMeshSubset (const fvMesh &baseMesh, const labelUList &selectedCells, const label patchID=-1, const bool syncPar=true)

	fvMeshSubset (const fvMesh &baseMesh, const labelHashSet &selectedCells, const label patchID=-1, const bool syncPar=true)

	fvMeshSubset (const fvMesh &baseMesh, const label regioni, const labelUList &regions, const label patchID=-1, const bool syncPar=true)

const fvMesh &	baseMesh () const noexcept

const fvMesh &	mesh () const noexcept

bool	hasSubMesh () const noexcept

const fvMesh &	subMesh () const

fvMesh &	subMesh ()

const labelList &	pointMap () const

const labelList &	faceMap () const

const labelList &	faceFlipMap () const

const labelList &	cellMap () const

const labelList &	patchMap () const

void	clear ()

void	setCellSubset (const bitSet &selectedCells, const label patchID=-1, const bool syncPar=true)

void	setCellSubset (const labelUList &selectedCells, const label patchID=-1, const bool syncPar=true)

void	setCellSubset (const labelHashSet &selectedCells, const label patchID=-1, const bool syncPar=true)

void	setCellSubset (const label regioni, const labelUList &regions, const label patchID=-1, const bool syncCouples=true)

labelList	getExposedFaces (const bitSet &selectedCells, const bool syncCouples=true) const

labelList	getExposedFaces (const label regioni, const labelUList &regions, const bool syncCouples=true) const

void	setCellSubset (const bitSet &selectedCells, const labelList &exposedFaces, const labelList &patchIDs, const bool syncCouples=true)

void	setCellSubset (const label regioni, const labelList &regions, const labelList &exposedFaces, const labelList &patchIDs, const bool syncCouples=true)

template<class Type >
tmp< GeometricField< Type, fvPatchField, volMesh > >	interpolate (const GeometricField< Type, fvPatchField, volMesh > &, const bool allowUnmapped=false) const

template<class Type >
tmp< GeometricField< Type, fvsPatchField, surfaceMesh > >	interpolate (const GeometricField< Type, fvsPatchField, surfaceMesh > &, const bool allowUnmapped=false) const

template<class Type >
tmp< GeometricField< Type, pointPatchField, pointMesh > >	interpolate (const GeometricField< Type, pointPatchField, pointMesh > &, const bool allowUnmapped=false) const

template<class Type >
tmp< DimensionedField< Type, volMesh > >	interpolate (const DimensionedField< Type, volMesh > &, const bool allowUnmapped=false) const

void	setLargeCellSubset (const labelUList &region, const label currentRegion, const label patchID=-1, const bool syncCouples=true)

void	setLargeCellSubset (const labelHashSet &globalCellMap, const label patchID=-1, const bool syncPar=true)

void	setLargeCellSubset (const labelList &regions, const label regioni, const labelList &exposedFaces, const labelList &patchIDs, const bool syncCouples=true)

Static Public Member Functions
template<class Type >
static tmp< GeometricField< Type, fvPatchField, volMesh > >	interpolate (const GeometricField< Type, fvPatchField, volMesh > &, const fvMesh &sMesh, const labelUList &patchMap, const labelUList &cellMap, const labelUList &faceMap, const bool allowUnmapped=false)

template<class Type >
static tmp< GeometricField< Type, fvsPatchField, surfaceMesh > >	interpolate (const GeometricField< Type, fvsPatchField, surfaceMesh > &, const fvMesh &sMesh, const labelUList &patchMap, const labelUList &cellMap, const labelUList &faceMap)

template<class Type >
static tmp< GeometricField< Type, pointPatchField, pointMesh > >	interpolate (const GeometricField< Type, pointPatchField, pointMesh > &, const pointMesh &sMesh, const labelUList &patchMap, const labelUList &pointMap)

template<class Type >
static tmp< DimensionedField< Type, volMesh > >	interpolate (const DimensionedField< Type, volMesh > &, const fvMesh &sMesh, const labelUList &cellMap)

Static Public Attributes
static word	exposedPatchName

Detailed Description

Given the original mesh and the list of selected cells, it creates the mesh consisting only of the desired cells, with the mapping list for points, faces, and cells.

Puts all exposed internal faces into either

a user supplied patch
a newly created patch "oldInternalFaces"
setCellSubset does coupled patch subsetting as well. If it detects a face on a coupled patch 'losing' its neighbour it will move the face into the oldInternalFaces patch.
if a user supplied patch is used it is up to the destination patchField to handle exposed internal faces (mapping from face -1). If not provided the default is to assign the internalField. All the basic patch field types (e.g. fixedValue) will give a warning and preferably derived patch field types should be used that know how to handle exposed faces (e.g. use uniformFixedValue instead of fixedValue)

Source files

Definition at line 69 of file fvMeshSubset.H.

Constructor & Destructor Documentation

◆ fvMeshSubset() [1/5]

fvMeshSubset ( const fvMesh & baseMesh )

explicit

Definition at line 467 of file fvMeshSubset.C.

◆ fvMeshSubset() [2/5]

fvMeshSubset	(	const fvMesh &	baseMesh,
		const bitSet &	selectedCells,
		const label	patchID = `-1`,
		const bool	syncPar = `true`
	)

Definition at line 480 of file fvMeshSubset.C.

References patchID.

◆ fvMeshSubset() [3/5]

fvMeshSubset	(	const fvMesh &	baseMesh,
		const labelUList &	selectedCells,
		const label	patchID = `-1`,
		const bool	syncPar = `true`
	)

Definition at line 508 of file fvMeshSubset.C.

References patchID.

◆ fvMeshSubset() [4/5]

fvMeshSubset	(	const fvMesh &	baseMesh,
		const labelHashSet &	selectedCells,
		const label	patchID = `-1`,
		const bool	syncPar = `true`
	)

Definition at line 494 of file fvMeshSubset.C.

References patchID.

◆ fvMeshSubset() [5/5]

fvMeshSubset	(	const fvMesh &	baseMesh,
		const label	regioni,
		const labelUList &	regions,
		const label	patchID = `-1`,
		const bool	syncPar = `true`
	)

Definition at line 522 of file fvMeshSubset.C.

References patchID.

Member Function Documentation

◆ baseMesh()

const Foam::fvMesh & baseMesh ( ) const

inlinenoexcept

Definition at line 23 of file fvMeshSubsetI.H.

Referenced by zoneSubSet::baseMesh(), vtkWrite::writeVolFields(), and ensightWrite::writeVolFields().

Here is the caller graph for this function:

◆ mesh()

const Foam::fvMesh & mesh ( ) const

inlinenoexcept

Definition at line 29 of file fvMeshSubsetI.H.

◆ hasSubMesh()

bool hasSubMesh ( ) const

inlinenoexcept

Definition at line 35 of file fvMeshSubsetI.H.

References bool.

Referenced by fvMeshSubsetProxy::interpolate(), and fvMeshSubsetProxy::interpolateInternal().

Here is the caller graph for this function:

◆ subMesh() [1/2]

Foam::fvMesh & subMesh ( ) const

inline

Definition at line 41 of file fvMeshSubsetI.H.

Referenced by structuredDecomp::decompose(), fvMeshDistribute::distribute(), fvMeshSubsetProxy::mesh(), structuredRenumber::renumber(), and momentumError::write().

Here is the caller graph for this function:

◆ subMesh() [2/2]

fvMesh& subMesh ( )

inline

◆ pointMap()

const Foam::labelList & pointMap ( ) const

inline

Definition at line 57 of file fvMeshSubsetI.H.

Referenced by fvMeshDistribute::distribute().

Here is the caller graph for this function:

◆ faceMap()

const Foam::labelList & faceMap ( ) const

inline

Definition at line 65 of file fvMeshSubsetI.H.

Referenced by fvMeshDistribute::distribute().

Here is the caller graph for this function:

◆ faceFlipMap()

const Foam::labelList & faceFlipMap ( ) const

inline

Definition at line 73 of file fvMeshSubsetI.H.

Referenced by fvMeshDistribute::distribute().

Here is the caller graph for this function:

◆ cellMap()

const Foam::labelList & cellMap ( ) const

inline

Definition at line 84 of file fvMeshSubsetI.H.

Referenced by structuredDecomp::decompose(), fvMeshDistribute::distribute(), and structuredRenumber::renumber().

Here is the caller graph for this function:

◆ patchMap()

const Foam::labelList & patchMap ( ) const

inline

Definition at line 92 of file fvMeshSubsetI.H.

Referenced by fvMeshDistribute::distribute().

Here is the caller graph for this function:

◆ clear()

void clear ( )

Definition at line 538 of file fvMeshSubset.C.

◆ setCellSubset() [1/6]

void setCellSubset	(	const bitSet &	selectedCells,
		const label	patchID = `-1`,
		const bool	syncPar = `true`
	)

Definition at line 551 of file fvMeshSubset.C.

References Foam::abort(), polyMesh::boundaryMesh(), primitiveMesh::cells(), clear(), PtrList::clone(), Foam::endl(), polyMesh::faceNeighbour(), polyMesh::faceOwner(), polyMesh::faces(), Foam::FatalError, FatalErrorInFunction, polyBoundaryMesh::findPatchID(), forAll, Pstream::gatherList(), Foam::identity(), primitiveMesh::isInternalFace(), Foam::labelMax, Pstream::listCombineGather(), Pstream::listCombineScatter(), UPstream::myProcNo(), Foam::name(), polyBoundaryMesh::names(), autoPtr::New(), primitiveMesh::nInternalFaces(), IOobject::NO_READ, IOobject::NO_WRITE, UPstream::nProcs(), UPstream::parRun(), patchID, patchNames(), polyMesh::points(), Foam::reduce(), List::resize(), Pstream::scatterList(), List::setSize(), bitSet::sortedToc(), polyPatch::start(), bitSet::test(), timeName, and Foam::Zero.

Referenced by fvMeshSubset::setLargeCellSubset().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ setCellSubset() [2/6]

void setCellSubset	(	const labelUList &	selectedCells,
		const label	patchID = `-1`,
		const bool	syncPar = `true`
	)

Definition at line 1189 of file fvMeshSubset.C.

References Foam::BitSetOps::create(), and patchID.

Here is the call graph for this function:

◆ setCellSubset() [3/6]

void setCellSubset	(	const labelHashSet &	selectedCells,
		const label	patchID = `-1`,
		const bool	syncPar = `true`
	)

Definition at line 1205 of file fvMeshSubset.C.

References Foam::BitSetOps::create(), and patchID.

Here is the call graph for this function:

◆ setCellSubset() [4/6]

void setCellSubset	(	const label	regioni,
		const labelUList &	regions,
		const label	patchID = `-1`,
		const bool	syncCouples = `true`
	)

Definition at line 1221 of file fvMeshSubset.C.

References Foam::BitSetOps::create(), and patchID.

Here is the call graph for this function:

◆ getExposedFaces() [1/2]

Foam::labelList getExposedFaces	(	const bitSet &	selectedCells,
		const bool	syncCouples = `true`
	)		const

Definition at line 1238 of file fvMeshSubset.C.

References removeCells::getExposedFaces().

Here is the call graph for this function:

◆ getExposedFaces() [2/2]

Foam::labelList getExposedFaces	(	const label	regioni,
		const labelUList &	regions,
		const bool	syncCouples = `true`
	)		const

Definition at line 1250 of file fvMeshSubset.C.

References removeCells::getExposedFaces().

Here is the call graph for this function:

◆ setCellSubset() [5/6]

void setCellSubset	(	const bitSet &	selectedCells,
		const labelList &	exposedFaces,
		const labelList &	patchIDs,
		const bool	syncCouples = `true`
	)

Definition at line 1263 of file fvMeshSubset.C.

◆ setCellSubset() [6/6]

void setCellSubset	(	const label	regioni,
		const labelList &	regions,
		const labelList &	exposedFaces,
		const labelList &	patchIDs,
		const bool	syncCouples = `true`
	)

Definition at line 1281 of file fvMeshSubset.C.

◆ interpolate() [1/8]

static tmp<GeometricField<Type, fvPatchField, volMesh> > interpolate	(	const GeometricField< Type, fvPatchField, volMesh > &	,
		const fvMesh &	sMesh,
		const labelUList &	patchMap,
		const labelUList &	cellMap,
		const labelUList &	faceMap,
		const bool	allowUnmapped = `false`
	)

static

Referenced by momentumError::calcMomentError(), momentumError::divDevRhoReff(), and fvMeshSubsetProxy::interpolate().

Here is the caller graph for this function:

◆ interpolate() [2/8]

tmp<GeometricField<Type, fvPatchField, volMesh> > interpolate	(	const GeometricField< Type, fvPatchField, volMesh > &	,
		const bool	allowUnmapped = `false`
	)		const

◆ interpolate() [3/8]

static tmp<GeometricField<Type, fvsPatchField, surfaceMesh> > interpolate	(	const GeometricField< Type, fvsPatchField, surfaceMesh > &	,
		const fvMesh &	sMesh,
		const labelUList &	patchMap,
		const labelUList &	cellMap,
		const labelUList &	faceMap
	)

static

◆ interpolate() [4/8]

tmp<GeometricField<Type, fvsPatchField, surfaceMesh> > interpolate	(	const GeometricField< Type, fvsPatchField, surfaceMesh > &	,
		const bool	allowUnmapped = `false`
	)		const

◆ interpolate() [5/8]

static tmp<GeometricField<Type, pointPatchField, pointMesh> > interpolate	(	const GeometricField< Type, pointPatchField, pointMesh > &	,
		const pointMesh &	sMesh,
		const labelUList &	patchMap,
		const labelUList &	pointMap
	)

static

◆ interpolate() [6/8]

tmp<GeometricField<Type, pointPatchField, pointMesh> > interpolate	(	const GeometricField< Type, pointPatchField, pointMesh > &	,
		const bool	allowUnmapped = `false`
	)		const

◆ interpolate() [7/8]

static tmp<DimensionedField<Type, volMesh> > interpolate	(	const DimensionedField< Type, volMesh > &	,
		const fvMesh &	sMesh,
		const labelUList &	cellMap
	)

static

◆ interpolate() [8/8]

tmp<DimensionedField<Type, volMesh> > interpolate	(	const DimensionedField< Type, volMesh > &	,
		const bool	allowUnmapped = `false`
	)		const

◆ setLargeCellSubset() [1/3]

void setLargeCellSubset	(	const labelUList &	region,
		const label	currentRegion,
		const label	patchID = `-1`,
		const bool	syncCouples = `true`
	)

inline

Definition at line 428 of file fvMeshSubset.H.

References Foam::Info, Foam::nl, patchID, and fvMeshSubset::setCellSubset().

Here is the call graph for this function:

◆ setLargeCellSubset() [2/3]

void setLargeCellSubset	(	const labelHashSet &	globalCellMap,
		const label	patchID = `-1`,
		const bool	syncPar = `true`
	)

inline

Definition at line 451 of file fvMeshSubset.H.

References Foam::Info, Foam::nl, patchID, and fvMeshSubset::setCellSubset().

Here is the call graph for this function:

◆ setLargeCellSubset() [3/3]

void setLargeCellSubset	(	const labelList &	regions,
		const label	regioni,
		const labelList &	exposedFaces,
		const labelList &	patchIDs,
		const bool	syncCouples = `true`
	)

inline

Definition at line 469 of file fvMeshSubset.H.

References Foam::Info, Foam::nl, and fvMeshSubset::setCellSubset().

Here is the call graph for this function:

Member Data Documentation

◆ exposedPatchName

Foam::word exposedPatchName

static

Definition at line 157 of file fvMeshSubset.H.

The documentation for this class was generated from the following files:

src/dynamicMesh/fvMeshSubset/fvMeshSubset.H
src/dynamicMesh/fvMeshSubset/fvMeshSubset.C
src/dynamicMesh/fvMeshSubset/fvMeshSubsetI.H

Public Member Functions

Static Public Member Functions

Static Public Attributes

Detailed Description

Constructor & Destructor Documentation

◆ fvMeshSubset() [1/5]

◆ fvMeshSubset() [2/5]

◆ fvMeshSubset() [3/5]

◆ fvMeshSubset() [4/5]

◆ fvMeshSubset() [5/5]

Member Function Documentation

◆ baseMesh()

◆ mesh()

◆ hasSubMesh()

◆ subMesh() [1/2]

◆ subMesh() [2/2]

◆ pointMap()

◆ faceMap()

◆ faceFlipMap()

◆ cellMap()

◆ patchMap()

◆ clear()

◆ setCellSubset() [1/6]

◆ setCellSubset() [2/6]

◆ setCellSubset() [3/6]

◆ setCellSubset() [4/6]

◆ getExposedFaces() [1/2]

◆ getExposedFaces() [2/2]

◆ setCellSubset() [5/6]

◆ setCellSubset() [6/6]

◆ interpolate() [1/8]

◆ interpolate() [2/8]

◆ interpolate() [3/8]

◆ interpolate() [4/8]

◆ interpolate() [5/8]

◆ interpolate() [6/8]

◆ interpolate() [7/8]

◆ interpolate() [8/8]

◆ setLargeCellSubset() [1/3]

◆ setLargeCellSubset() [2/3]

◆ setLargeCellSubset() [3/3]

Member Data Documentation

◆ exposedPatchName
