systemCall Class Reference

Executes system calls, entered in the form of string lists. More...

Inheritance diagram for systemCall:

Collaboration diagram for systemCall:

Public Member Functions
	TypeName ("systemCall")
	systemCall (const word &name, const Time &runTime, const dictionary &dict)
virtual	~systemCall ()=default
virtual bool	read (const dictionary &dict)
virtual bool	execute ()
virtual bool	write ()
virtual bool	end ()
Public Member Functions inherited from functionObject
	declareRunTimeSelectionTable (autoPtr, functionObject, dictionary,(const word &name, const Time &runTime, const dictionary &dict),(name, runTime, dict))
	functionObject (const word &name, const bool withNamePrefix=defaultUseNamePrefix)
autoPtr< functionObject >	clone () const
virtual	~functionObject ()=default
virtual const word &	type () const =0
const word &	name () const noexcept
bool	useNamePrefix () const noexcept
bool	useNamePrefix (bool on) noexcept
virtual bool	execute (const label subIndex)
virtual bool	adjustTimeStep ()
virtual bool	filesModified () const
virtual void	updateMesh (const mapPolyMesh &mpm)
virtual void	movePoints (const polyMesh &mesh)

Protected Member Functions
label	dispatch (const stringList &calls)
	systemCall (const systemCall &)=delete
void	operator= (const systemCall &)=delete
Protected Member Functions inherited from functionObject
word	scopedName (const word &name) const

Protected Attributes
stringList	executeCalls_
stringList	writeCalls_
stringList	endCalls_
bool	masterOnly_

Additional Inherited Members
Static Public Member Functions inherited from functionObject
static autoPtr< functionObject >	New (const word &name, const Time &runTime, const dictionary &dict)
Public Attributes inherited from functionObject
bool	log
Static Public Attributes inherited from functionObject
static int	debug
static bool	postProcess
static bool	defaultUseNamePrefix
static word	outputPrefix

Detailed Description

Executes system calls, entered in the form of string lists.

Calls can be made at the following points in the calculation:

• every time step
• every output time
• end of the calculation

Usage

Example of the function object specification:

systemCall1
{
    type        systemCall;
    libs        (utilityFunctionObjects);
    ...
    executeCalls
    (
        "echo execute"
    );
    writeCalls
    (
        "echo === writing data ==="
    );
    endCalls
    (
        "echo === echoing .bashrc ==="
        "cat ~/.bashrc"
        "echo \*\*\* done \*\*\*"
    );
}

Where the entries comprise:

Property	Description	Required	Default value
type	type name: systemCall	yes
executeCalls	list of calls on execute	yes
writeCalls	list of calls on write	yes
endCalls	list of calls on end	yes
master	execute on master only	no	false

Note

Since this function object executes system calls, there is a potential security risk. In order to use the systemCall function object, the allowSystemOperations must be set to '1'; otherwise, system calls will not be allowed.

Additionally, since the system commands are normally sent via the shell, special shell character may require backslash escaping.

See also

Foam::functionObject Foam::functionObjects::timeControl

Source files

• systemCall.H
• systemCall.C

Definition at line 136 of file systemCall.H.

Constructor & Destructor Documentation

systemCall() [1/2]

systemCall ( const systemCall &  )

protecteddelete

systemCall() [2/2]

systemCall	(	const word &	name,
		const Time &	runTime,
		const dictionary &	dict
	)

Definition at line 79 of file systemCall.C.

References dict, and Foam::read().

Here is the call graph for this function:

~systemCall()

virtual ~systemCall ( )

virtualdefault

Member Function Documentation

dispatch()

Foam::label dispatch ( const stringList &  calls )

protected

Definition at line 48 of file systemCall.C.

References UPstream::master(), systemCall::masterOnly_, Pstream::scatter(), and Foam::system().

Here is the call graph for this function:

operator=()

void operator= ( const systemCall &  )

protecteddelete

TypeName()

TypeName

(

"systemCall"

)

read()

bool read ( const dictionary &  dict )

virtual

Reimplemented from functionObject.

Definition at line 97 of file systemCall.C.

References dynamicCode::allowSystemOperations, Foam::foamVersion::api, dict, Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::isAdministrator(), Foam::nl, functionObject::read(), and WarningInFunction.

Here is the call graph for this function:

execute()

bool execute ( )

virtual

Implements functionObject.

Definition at line 145 of file systemCall.C.

write()

bool write ( )

virtual

Implements functionObject.

Definition at line 152 of file systemCall.C.

end()

bool end ( )

virtual

Reimplemented from functionObject.

Definition at line 159 of file systemCall.C.

Member Data Documentation

executeCalls_

stringList executeCalls_

protected

Definition at line 145 of file systemCall.H.

writeCalls_

stringList writeCalls_

protected

Definition at line 148 of file systemCall.H.

endCalls_

stringList endCalls_

protected

Definition at line 151 of file systemCall.H.

masterOnly_

bool masterOnly_

protected

Definition at line 154 of file systemCall.H.

Referenced by systemCall::dispatch().

---

The documentation for this class was generated from the following files:

• src/functionObjects/utilities/systemCall/systemCall.H
• src/functionObjects/utilities/systemCall/systemCall.C
