Copies content of local objectRegistry to all processors. More...

Inheritance diagram for syncObjects:

Collaboration diagram for syncObjects:

Public Member Functions
	TypeName ("syncObjects")

	syncObjects (const word &name, const Time &runTime, const dictionary &dict)

virtual	~syncObjects ()=default

const objectRegistry &	obr () const

const fileName &	root () const

virtual bool	read (const dictionary &)

virtual bool	execute ()

virtual bool	write ()

Public Member Functions inherited from functionObject
	declareRunTimeSelectionTable (autoPtr, functionObject, dictionary,(const word &name, const Time &runTime, const dictionary &dict),(name, runTime, dict))

	functionObject (const word &name, const bool withNamePrefix=defaultUseNamePrefix)

autoPtr< functionObject >	clone () const

virtual	~functionObject ()=default

virtual const word &	type () const =0

const word &	name () const noexcept

bool	useNamePrefix () const noexcept

bool	useNamePrefix (bool on) noexcept

virtual bool	execute (const label subIndex)

virtual bool	end ()

virtual bool	adjustTimeStep ()

virtual bool	filesModified () const

virtual void	updateMesh (const mapPolyMesh &mpm)

virtual void	movePoints (const polyMesh &mesh)

Protected Member Functions
void	sync ()

Protected Member Functions inherited from functionObject
word	scopedName (const word &name) const

Additional Inherited Members
Static Public Member Functions inherited from functionObject
static autoPtr< functionObject >	New (const word &name, const Time &runTime, const dictionary &dict)

Public Attributes inherited from functionObject
bool	log

Static Public Attributes inherited from functionObject
static int	debug

static bool	postProcess

static bool	defaultUseNamePrefix

static word	outputPrefix

Detailed Description

Copies content of local objectRegistry to all processors.

Currently only supports IOFields. It is used to distribute IOFields from different processors/regions/worlds when doing loose coupling. To be used in combination with 'mapped' boundary conditions.

Usage

Example of function object specification:

syncObjects1
{
    type        syncObjects;
    libs        ("libutilityFunctionObjects.so");
    ...

    // Where is data located relative to runTime. Given as a filename
    // with every '/' indicating a sub-objectRegistry w.r.t. runTime.
    // Local data is under <root>/send/processorXXX. After execution
    // (potentially remote) data will be under the corresponding
    // <root>/receive/processorYYY objectRegistry.
    //root        "level0/level1/level2";
}

Where the entries comprise:
