reference Class Reference
FunctionObjects » Field function objects

Computes a field whose values are offset to a reference value obtained by from a Function1. More...

Inheritance diagram for reference:
Inheritance graph
[legend]
Collaboration diagram for reference:
Collaboration graph
[legend]

Public Member Functions

 TypeName ("reference")

 reference (const word &name, const Time &runTime, const dictionary &dict)

 reference (const reference &)=delete

void operator= (const reference &)=delete

virtual ~reference ()=default

virtual bool read (const dictionary &dict)

- Public Member Functions inherited from fieldExpression
 TypeName ("fieldExpression")

 fieldExpression (const word &name, const Time &runTime, const dictionary &dict, const word &fieldName=word::null, const word &resultName=word::null)

 fieldExpression (const fieldExpression &)=delete

void operator= (const fieldExpression &)=delete

virtual ~fieldExpression ()=default

virtual bool execute ()

virtual bool write ()

virtual bool clear ()

- Public Member Functions inherited from fvMeshFunctionObject
 TypeName ("fvMeshFunctionObject")

 fvMeshFunctionObject (const word &name, const Time &runTime, const dictionary &dict)

 fvMeshFunctionObject (const word &name, const objectRegistry &obr, const dictionary &dict)

virtual ~fvMeshFunctionObject ()=default

- Public Member Functions inherited from regionFunctionObject
 TypeName ("regionFunctionObject")

 regionFunctionObject (const word &name, const Time &runTime, const dictionary &dict)

 regionFunctionObject (const word &name, const objectRegistry &obr, const dictionary &dict)

virtual ~regionFunctionObject ()=default

template<class ObjectType >
const ObjectType * lookupObjectPtr (const word &fieldName) const

template<class ObjectType >
ObjectType * lookupObjectRefPtr (const word &fieldName) const

- Public Member Functions inherited from stateFunctionObject
 stateFunctionObject (const word &name, const Time &runTime)

virtual ~stateFunctionObject ()=default

dictionary & propertyDict ()

bool foundProperty (const word &entryName) const

void clearTrigger ()

label getTrigger () const

bool setTrigger (const label triggeri, bool increaseOnly=true)

bool getDict (const word &entryName, dictionary &dict) const

bool getObjectDict (const word &objectName, const word &entryName, dictionary &dict) const

template<class Type >
Type getProperty (const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
bool getProperty (const word &entryName, Type &value) const

template<class Type >
void setProperty (const word &entryName, const Type &value)

template<class Type >
Type getObjectProperty (const word &objectName, const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
bool getObjectProperty (const word &objectName, const word &entryName, Type &value) const

template<class Type >
void setObjectProperty (const word &objectName, const word &entryName, const Type &value)

template<class Type >
void setResult (const word &entryName, const Type &value)

template<class Type >
void setObjectResult (const word &objectName, const word &entryName, const Type &value)

template<class Type >
Type getResult (const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
Type getObjectResult (const word &objectName, const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
bool getObjectResult (const word &objectName, const word &entryName, Type &value) const

word resultType (const word &entryName) const

word objectResultType (const word &objectName, const word &entryName) const

wordList objectResultEntries () const

wordList objectResultEntries (const word &objectName) const

void writeResultEntries (Ostream &os) const

void writeResultEntries (const word &objectName, Ostream &os) const

void writeAllResultEntries (Ostream &os) const

- Public Member Functions inherited from timeFunctionObject
 timeFunctionObject (const word &name, const Time &runTime)

virtual ~timeFunctionObject ()=default

const Time & time () const

objectRegistry & storedObjects ()

const objectRegistry & storedObjects () const

- Public Member Functions inherited from functionObject
 declareRunTimeSelectionTable (autoPtr, functionObject, dictionary,(const word &name, const Time &runTime, const dictionary &dict),(name, runTime, dict))

 functionObject (const word &name, const bool withNamePrefix=defaultUseNamePrefix)

autoPtr< functionObject > clone () const

virtual ~functionObject ()=default

virtual const word & type () const =0

const word & name () const noexcept

bool useNamePrefix () const noexcept

bool useNamePrefix (bool on) noexcept

virtual bool execute (const label subIndex)

virtual bool end ()

virtual bool adjustTimeStep ()

virtual bool filesModified () const

virtual void updateMesh (const mapPolyMesh &mpm)

virtual void movePoints (const polyMesh &mesh)


Additional Inherited Members

- Static Public Member Functions inherited from functionObject
static autoPtr< functionObject > New (const word &name, const Time &runTime, const dictionary &dict)

- Public Attributes inherited from functionObject
bool log

- Static Public Attributes inherited from functionObject
static int debug

static bool postProcess

static bool defaultUseNamePrefix

static word outputPrefix

- Protected Member Functions inherited from fieldExpression
void setResultName (const word &typeName, const word &defaultArg)

template<class Type >
bool foundObject (const word &name, const bool verbose=true) const

- Protected Member Functions inherited from fvMeshFunctionObject
 fvMeshFunctionObject (const fvMeshFunctionObject &)=delete

void operator= (const fvMeshFunctionObject &)=delete

- Protected Member Functions inherited from regionFunctionObject
virtual const objectRegistry & obr () const

template<class ObjectType >
bool foundObject (const word &fieldName) const

template<class ObjectType >
const ObjectType * cfindObject (const word &fieldName) const

template<class ObjectType >
const ObjectType * findObject (const word &fieldName) const

template<class ObjectType >
ObjectType * findObject (const word &fieldName)

template<class ObjectType >
ObjectType * getObjectPtr (const word &fieldName) const

template<class ObjectType >
const ObjectType & lookupObject (const word &fieldName) const

template<class ObjectType >
ObjectType & lookupObjectRef (const word &fieldName) const

template<class ObjectType >
bool store (word &fieldName, const tmp< ObjectType > &tfield, bool cacheable=false)

template<class ObjectType >
bool storeInDb (const word &fieldName, const tmp< ObjectType > &tfield, const objectRegistry &obr)

bool writeObject (const word &fieldName)

bool clearObject (const word &fieldName)

void clearObjects (const wordList &objNames)

 regionFunctionObject (const regionFunctionObject &)=delete

void operator= (const regionFunctionObject &)=delete

- Protected Member Functions inherited from stateFunctionObject
const functionObjects::properties & stateDict () const

functionObjects::properties & stateDict ()

 stateFunctionObject (const stateFunctionObject &)=delete

void operator= (const stateFunctionObject &)=delete

- Protected Member Functions inherited from timeFunctionObject
void clearOutputObjects (const wordList &objNames)

 timeFunctionObject (const timeFunctionObject &)=delete

void operator= (const timeFunctionObject &)=delete

- Protected Member Functions inherited from functionObject
word scopedName (const word &name) const

- Protected Attributes inherited from fieldExpression
word fieldName_

word resultName_

autoPtr< Detail::zoneSubSet > zoneSubSetPtr_

- Protected Attributes inherited from fvMeshFunctionObject
const fvMesh & mesh_

- Protected Attributes inherited from regionFunctionObject
word subRegistryName_

const objectRegistry & obr_

const objectRegistry * obrPtr_

- Protected Attributes inherited from timeFunctionObject
const Time & time_


Detailed Description

Computes a field whose values are offset to a reference value obtained by from a Function1.

The field values are calculated using:

\[ r_c = s(f_{c}(t) - f_p + f_{off}) \]

where

$ r_c $ = field values at cell
$ s $ = optional scale factor (default = 1)
$ f_{c}(t) $ = current field values at cell at this time
$ f_p $ = reference value
$ f_{off} $ = offset field value (default = 0)

Operands:

Operand Type Location
input {vol,surface}<Type>Field $FOAM_CASE/<time>/<inpField>
output file - -
output field {vol,surface}<Type>Field $FOAM_CASE/<time>/<outField>

where <Type>=Scalar/Vector/SphericalTensor/SymmTensor/Tensor.

Usage
Minimal example by using system/controlDict.functions:
reference1
{
    // Mandatory entries (unmodifiable)
    type        reference;
    libs        (fieldFunctionObjects);

    // Mandatory (inherited) entry (runtime modifiable)
    field       <field>;

    // Reference value
    refValue    <Function1>;

    // Optional entries (runtime modifiable)
    scale       1.0;
    offset      0.0;

    // Optional (inherited) entries
    ...
}

Where the entries comprise:

Property Description Type Req'd Dflt
type Type name: reference word yes -
field Name of the operand field word yes -
refValue Function1 reference value Function1 yes -
offset Offset value type-value no zero
scale Scale factor scalar no 1

The inherited entries are elaborated in:

Usage by the postProcess utility is not available.

See also
Source files

Definition at line 204 of file reference.H.

Constructor & Destructor Documentation

◆ reference() [1/2]

reference ( const word &  name,
const Time &  runTime,
const dictionary &  dict
)

Definition at line 57 of file reference.C.

References dict, word::null, and Foam::read().

Here is the call graph for this function:

◆ reference() [2/2]

reference ( const reference &  )
delete

◆ ~reference()

virtual ~reference ( )
virtualdefault

Member Function Documentation

◆ TypeName()

TypeName ( "reference"  )

◆ operator=()

void operator= ( const reference &  )
delete

◆ read()

bool read ( const dictionary &  dict)
virtual

Reimplemented from fieldExpression.

Definition at line 76 of file reference.C.

References dict, Foam::endl(), Log, Foam::name(), Foam::nl, fieldExpression::read(), and Foam::type().

Here is the call graph for this function:
The documentation for this class was generated from the following files:
